Page 1: Detachable Front Panel
VOLUME FF/EJ POWER BAND TUNING AM/FM RADIO DETACHABLE FRONT PANEL CASSETTE PLAYER Released 9-25-02 AV303 STEREO CASSETTE AV-303 BALANCE WITH OWNER'S MANUAL... -
Page 2: Installation Instructions
INSTALLATION INSTRUCTIONS This unit is designed for installation in cars, trucks, and vans with an existing radio opening. In many cases, a special installation kit will be required to mount the radio to the dashboard. These kits are available at electronics supply stores and car stereo specialist shops. Always check the kit application before purchasing to make sure the kit works with your vehicle. -
Page 3: Universal Installation
EXISTING DASH OPENING (FILE EDGES TO FIT IF NECESSARY-DO NOT OVER FILE) NOTE: IF DASH IS SOLID, USE MOUNTING SLEEVE AS A TEMPLATE & CUT OPENING PERFORATED STRAP FASTEN THIS END TO SCREW STUD ON REAR OF CHASSIS SCREW MOUNTING SLEEVE FASTEN THIS END TO SECURE PART OF DASHBOARD. - Page 4 WIRING DI WIRING DI WIRING DIA A A A A GR WIRING DI WIRING DI ANTENNA ANTENNA SOCKET ON REAR OF RADIO USE 1/4" EXISTING ANTENNA CABLE SPADE LUG FOR GROUND CONNECTION GROUNDED METAL PART OF CAR BODY (REMOVE ANY PAINT) BLACK FUSE (3 AMP.) LEFT SPEAKER...
- Page 5 4 SPE 4 SPEA A A A A K K K K K ER SY 4 SPE ER SYSTEM WIRING ER SY ER SY 4 SPE 4 SPE ER SY LEFT FRONT SPEAKER WHITE GREEN LEFT REAR SPEAKER NOTE: CONNECT ALL OTHER WIRES AS SHOWN ON PAGE 4 STEM WIRING STEM WIRING STEM WIRING...
-
Page 6: Power On/Off Button
OPERATING INSTRUCTIONS VOLUME VOLUME POWER BAND TUNING 1 1 1 1 1 POWER ON-OFF BUTTON Alternately press this button to turn the unit on and off. 2 2 2 2 2 VOLUME CONTROL To increase the volume level, rotate this control knob in the clockwise (CW) direction;... - Page 7 4 4 4 4 4 TONE CONTROL Rotate this control knob to adjust the sound output for the desired bass or treble tonal range. When the control is positioned at the mid-range detent posi- tion, the bass and treble response should be very nearly equal.
- Page 8 bl bl bl bl bl AM ANTENNA TRIMMER It is very important to adjust the Antenna Trimmer for optimum AM reception. The antenna trimmer is located on left rear corner of the chassis. Adjust this control after wiring connections are complete and before the radio is inserted into the dashboard opening.
-
Page 9: Notes On Use Of Front Panel
bp bp bp bp bp FRONT PANEL RELEASE (REL) BUTTON This button is used to release the mechanism that holds the front panel to the chassis. To detach the front panel, press the button so that the right side of the panel is released. -
Page 10: Care And Maintenance
CARE AND MAINTENANCE The radio portion of your new sound system does not require any maintenance. We recommend you keep this manual for general reference of the many features found in this unit. As with any cassette player, the cassette section of this sound system does require a minimum of maintenance to keep it in good working condition. -
Page 11: 12 Month Limited Warranty
