Invacare® Modulite
3.
Loosen and remove screws (4) incl. washers and nuts with a 6
mm Allen key and a 13 mm wrench.
4.
Remove seat adapter (3).
The dismantling of the seat support on the chassis is
described under "Seat support" of the corresponding
service manual.
24
Installing seat and seat support
1.
Replace all parts in reverse order.
Make sure that all screws, washers and nuts are replaced
in the correct order and securely tightened during
installation.
When installing the seat, pay attention to its heavy weight.
Tighten screws to a torque of 25 Nm.
2.
Check all functions of the vehicle and go for a test drive.
1604311-A
