Dear Customer,
Thank you for choosing this quality product from ASKO.
We hope it will meet your expectations and fulfi l your needs for many years
to come. Scandinavian design combines clean lines, everyday functionality
and high quality. These are key characteristics of all our products and the
reason they are greatly appreciated throughout the world.
To get the most out of your new machine, we recommend that you read the
operating instructions before using the machine. The operating instructions
also include information on how you can help protect the environment.
Operating Instructions
Washing Machine
PROFESSIONAL WMC84P
WARNING: Read the instructions before using the machine.
Advertisement
Table of Contents
Related Manuals for Asko PROFESSIONAL WMC84P
Summary of Contents for Asko PROFESSIONAL WMC84P
-
Page 1: Operating Instructions
Dear Customer, Thank you for choosing this quality product from ASKO. We hope it will meet your expectations and fulfi l your needs for many years to come. Scandinavian design combines clean lines, everyday functionality and high quality. These are key characteristics of all our products and the reason they are greatly appreciated throughout the world. -
Page 2: Table Of Contents
CONTENTS SAFETY INSTRUCTIONS TROUBLESHOOTING Installation The washer door will not open Overfl ow guard function Opening the door in an emergency Transport/winter storage After power failure Packing material Wet washing still in the machine Recycling Error messages ADVICE AND TIPS BEFORE WASHING TECHNICAL INFORMATION Sorting your laundry Information for test institute... -
Page 3: Safety Instructions
• Always close the door and start the programme safe place. immediately once you have added detergent. • Installation should be carried out by qualifi ed ASKO • The appliance is not intended for use by young technicians. children or infi rm persons without supervision. -
Page 4: Installation
SAFETY INSTRUCTIONS INSTALLATION • Carry out the installation and connections in accordance with the separate installation instructions. • Installation of water and electricity, if required, must be carried out by a qualifi ed tradesperson. • Remove any transport protection devices before using the machine. -
Page 5: Advice And Tips Before Washing
ADVICE AND TIPS BEFORE WASHING Here are some tips that may help you before washing. COLOURED COTTON Coloured cotton garments labelled with washing SORTING YOUR LAUNDRY instruction 60 °C must be washed at 60 °C initially to remove any excess dye. Failure to observe this advice Sort items according to: could lead to the colour running. -
Page 6: Using Your Washing Machine
USING YOUR WASHING MACHINE Start Program selector Time remaining Stop Program Main power switch The quantity of detergent needed depends, amongst ADD DETERGENT AND FABRIC other things, on how hard the water is. See the detergent SOFTENER pack for details. Phone your local water company to check the water hardness in your area. -
Page 7: Program Selection
USING YOUR WASHING MACHINE PROGRAM SELECTION CLOSE THE DOOR AND PRESS THE START BUTTON The display shows the program name, the water temperature and the spin speed. NOTE! The washing machine has a number of preselected A few seconds after you start a program the washing programs when delivered from the factory. -
Page 8: Settings
SETTINGS HOW TO CHOOSE THE SETTINGS WATER INTAKE 1 Turn off the machine using the main power switch. (depending on the model) 2 Press and hold the Stop button and then press the Connecting to both the hot and cold water supplies main power switch. -
Page 9: Care And Cleaning
CARE AND CLEANING CLEANING THE TRAP AND THE CLEANING THE DETERGENT DRAINAGE PUMP COMPARTMENT The washing machine has a trap where smaller objects Pull out the detergent compartment using the release such as coins and hairpins can collect. To clean the trap button. -
Page 10: Rinse Holes Under The Agitator
CARE AND CLEANING RINSE HOLES UNDER THE AGITATOR IF YOU HAVE HARD WATER If you suspect that objects such as nails or paper clips If you live in an area with hard water (high limescale may have fallen into the wash drum, you should check the content), a greyish-white coating may form on the washer space under the agitator. -
Page 11: Troubleshooting
TROUBLESHOOTING THE WASHER DOOR WILL NOT OPEN THE MACHINE WILL NOT START • Check that the main power switch is on. • Is the washing machine door properly closed? Push it • Has the power supply been cut off ? Check the house fi... -
Page 12: Error Messages
TROUBLESHOOTING Water inlet fault ERROR MESSAGES Check: If an error occurs during the program a message is shown on the display. To exit the message after taking measures, • that the tap on the water pipe is open. turn the machine off and then back on. •... -
Page 13: Technical Information
TECHNICAL INFORMATION INFORMATION FOR TEST INSTITUTE Energy labelling Australian standard: AS/NZS 2040.1:2005 Washing program: Normal, 40 °C, 10 kg cotton Connection: Cold water 20 °C Test method for noise measurement: IEC-60704-2-4 Power requirement when machine turned off < 0,3 W Power requirement for Delayed Start <... - Page 14 TECHNICAL INFORMATION Loading procedure for standard test: When loading the machine for testing according to AS/NZS 2040:2005 it shall be loaded according to the table below. Garments are placed on top of each other in layers and the soil swatches should be placed inside the wash drum in the direction shown in the table, seen from above.
-
Page 15: Technical Data
TECHNICAL INFORMATION TECHNICAL DATA Height: 850 mm Width: 595 mm Depth: 700 mm Weight: 82 kg Cylinder volume: 80 l Max. washing capacity: 10 kg Spin speed (rpm): 400-1400 Sound pressure level: The sound pressure level is below 70 dB(A) Rated power: See type plate. -
Page 16: Installation
INSTALLATION POSITIONING THE WASHING MACHINE CONNECTION TO WATER SUPPLY The washing machine can be installed as a built-in or Water connection should be carried out by an freestanding unit. Place the machine on a fi rm surface appropriately qualifi ed person. Connect the machine with easy access to the plug. -
Page 17: Drainage Connection
INSTALLATION DRAINAGE CONNECTION ELECTRICAL INSTALLATION The machine is supplied with a drainage hose attached, If the machine is delivered from the factory with a plug which must be connected to a drain. See the examples attached it can be connected to an earthed wall socket. below. -
Page 18: Before Contacting The Service
BEFORE CONTACTING THE SERVICE DIVISION BEFORE CONTACTING THE SERVICE DIVISION Before you contact the service division, make sure that you know its model designation (1), type designation (2) and serial number (3). The model designation can be found on the panel. The type designation and serial number can be found on the type plate on the inside of the washer door. -
Page 19: Programme Chart
PROGRAMME CHART Water consumption (approx. liter) 1)+2) Cold Program Normal wash 1400 1,40 3:00 Normal wash 1400 0,90 2:55 Heavy wash 1400 2,45 1:50 Heavy wash 1400 1,60 1:30 White 1400 1,50 1:30 White/Colour 1400 1,10 1:25 White/Colour 1400 0,70 1:00 Super quick wash 0,45... - Page 20 PROGRAMME CHART Adjustment of the displayed washing time Advanced technology allows the appliance to sense the amount of laundry and add the required amount of water during the washing process. Depending on the washing load, washing time can be longer or shorter and the time displayed will be adjusted accordingly.
- Page 21 YOUR NOTES...
- Page 22 YOUR NOTES...
- Page 23 YOUR NOTES...
-
Page 24: Quick Guide
You select a programme by turning the programme selector. The selected programme is shown in the display. CLOSE THE WASHER DOOR AND PRESS THE START BUTTON The time remaining is shown in hours and minutes. We reserve the right to make changes. www.asko.com WM80.C PROFESSIONAL WMC84P en (07-16)
