Jensen CD 3610 Owner's Manual

Audiovox owners manual car cd player cd 3610
Hide thumbs Also See for CD 3610:
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
CD3610
Owner's Manual
X
CD3610
Audiovox Electronics Corporation
150 Marcus Boulevard
Hauppauge, NY 11788
1-800-323-4815
www.jensen.com
© 2004 Audiovox
Thank You!
Thank you for choosing a Jensen product. We hope you will find the instructions in this owner's
manual clear and easy to follow. If you take a few minutes to look through it, you'll learn how to
use all the features of your new Jensen receiver for maximum enjoyment.
Preparation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Basic Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Tuner Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
CD Player Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
CD Changer Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
50
WATTS X 4
AUX IN
CD-R/RW
CD RECEIVER
v.011404

Preparation

Getting Started
It's a good idea to read all of the instructions before beginning the installation.
Tools and Supplies
The following tools and supplies are needed to install the radio.
•
Torx type, Flat-head and Phillips screwdrivers
•
Wire cutters and strippers
•
Tools to remove existing radio (screwdriver, socket wrench set or other tools)
•
Electrical tape
•
Crimping tool
•
Volt meter/test light
•
Crimp connections
TUNE
•
18 gauge wire for power connections
•
16-18 gauge speaker wire
Speaker Requirements: Only connect speakers rated in the load impedance of 4 ohms.
Speakers with a load impedance less than 4 ohms could damage the unit.
Disconnect Battery
Before you begin, always disconnect the battery negative terminal.
Remove Radio from Sleeve
Lift latches on both sides of sleeve to remove half-sleeve from radio.
MU T
Remove Radio from Sleeve
Remueva el Radio de la Manga
Enlever la radio du manchon
TUN E

Advertisement

Table of Contents
loading

Related Manuals for Jensen CD 3610

Summary of Contents for Jensen CD 3610

  • Page 1: Table Of Contents

    CD3610 Owner’s Manual CD3610 CD RECEIVER Audiovox Electronics Corporation 150 Marcus Boulevard Hauppauge, NY 11788 1-800-323-4815 www.jensen.com © 2004 Audiovox v.011404 Thank You! Thank you for choosing a Jensen product. We hope you will find the instructions in this owner’s manual clear and easy to follow.
  • Page 2 Manual del Usuario ¡Gracias! Gracias por elegir los productos Jensen. Esperamos que encuentre en este manual instrucciones claras y fáciles de seguir. Si se toma unos pocos minutos para leerlo, aprenderá cómo utilizar todas las funciones de su nuevo radio Jensen para su máximo entretenimiento. Preparación .

  • Page 3: Wiring

    Preparation (continued) Install Half-Sleeve Install adapter and dash kit if necessary (optional). Install half-sleeve into adapter or dashboard. Push tabs out to secure half-sleeve in the radio opening. Install support strap to make unit more stable. Wiring Wiring with a Wiring Adapter (Purchased Separately) Connect Wires You can make all these connections without even being in the car.
  • Page 4 Preparación (continuado) Instalación de la Camisa Instale el adaptador y kit del tablero de instrumentos, si es necesario (opcional). Instale la media camisa en el adaptador o en tablero de instrumentos. Hale las aletas hacia afuera para asegurar la media camisa en al apertura del radio. Instale la abrazadera de soporte para que la unidad quede más estable.

  • Page 5: Installation

    Installation Final Installation Connect wiring adapter to existing wiring harness. Connect antenna lead. Slide radio chassis into half-sleeve. Secure radio to bracket using nut (if possible). Replace any items you removed from the dashboard. Final ISO-DIN Installation Remove trim ring. Mount factory brackets on new radio using existing screws from old radio.

  • Page 6: Basic Operation

    Basic Operation 1. Power Press PWR (1) or any other button on the front of the radio (except Open/Eject) to turn the unit on. Press PWR again to turn the unit off. 2. Mode Press MODE (2) to select a different mode of operation as indicated on the display panel. Available modes include Tuner, CD, CD changer (optional) and Auxiliary.
  • Page 7 CD3610 Basic Operation (continued) 4. Volume / Audio Control (continued) Bass Press the volume control three times, then rotate it clockwise or counter clockwise to adjust bass from -6 to +6. “00” represents a flat response. Treble Press the volume control four times, then rotate it clockwise or counter clockwise to adjust Treble from -6 to +6.
  • Page 8 Basic Operation (continued) 5. iX-Bass Press iX-BASS (5) momentarily to activate the iX-BASS feature. When listening to music at low volume levels, this feature will boost the bass and treble ranges to compensate for the characteristics of human hearing. When this feature is activated, “X-BASS On” will appear in the display momentarily.
  • Page 9 CD3610 Basic Operation (continued) 7. Animation / Menu Operation Press DISPLAY/MENU (7a) momentarily to navigate through the following animation options: EQ animation, Animation 1, Animation 2 and back to the default display. The selected animation will appear in the display when the unit is turned on. A second function of DISPLAY / MENU, is to access a menu of radio options.
  • Page 10 Basic Operation (continued) 7. Animation / Menu Operation (continued) Clock Format This option allows selection of a 12 hour or 24 hour clock format. “CLK FORMAT 12H” is the default setting. Rotate the volume control to change to the 24 hour clock format. Time Set The time on the clock will be set to 12:00 as the default.
  • Page 11 CD3610 Basic Operation (continued) 7. Animation / Menu Operation (continued) Programmable Turn-on Volume This option allows selection of the volume level the radio will automatically assume when first turned on. “Vol Last” is the default setting, which will turn the radio on at the volume level selected when the unit was last turned off.
  • Page 12 Basic Operation (continued) 7. Animation / Menu Operation (continued) Selectable Clock Display When the selectable clock display feature is activated, the clock and default greeting note will appear in the display when the radio is turned off but still connected to the ignition wire. “CLK ON LCD On”...
  • Page 13 CD3610 Basic Operation (continued) 9. Detaching the Front Panel To detach the front panel, press the front panel release button (9), which will release the front panel. Grasp the edge of the front panel, and pull it to release. When the front panel is removed, it should be stored carefully to protect it from dirt and damage.

  • Page 14: Tuner Operation

    Tuner Operation 13. Select a Band Press BAND (13) to change between three FM bands and two AM bands. Each band stores up to six preset stations. 14. Tuning Manual Tuning Press the Up Tuning or Down Tuning button (14a and 14b) for more than three seconds to move the radio frequency number up or down one step.
  • Page 15 CD3610 Tuner Operation (continued) 16. Preset Stations (continued) Recall a Station Select a band (if needed). Press a preset button (16) to select the corresponding stored station. 17. Automatically Store / Preset Scan Automatically Store Automatically select six strong stations and store them in the current band. Select a band (if needed).

  • Page 16: Cd Player Operation

    CD Player Operation 19. Insert and Eject CD Insert a CD label-side up with the unit turned on, and the disc will begin to play. Press the Eject button (19) to stop CD play and eject the CD. The unit does not have to be turned on to eject the CD.
  • Page 17 CD3610 CD Player Operation (Continued) 24. Intro Scan (INT) During disc play, press INT (24) to play the first 10 seconds to each track on the disc. When the desired track is reached, press INT again to end the scan and play the selected track. 25.

  • Page 18: Cd Changer Operation

    CD Changer Operation Please call Jensen technical support at 1-800-323-4815 for a list of CD changers compatible with this unit. Refer to the owner’s manual included with the CD changer for instructions on installing, loading and using the CD magazine. 26.

  • Page 19: Troubleshooting

    Press RESET. The disc may be damaged or dirty. AUDIOVOX CORPORATION (the Company) warrants to the original retail purchaser of this product that Press RESET, insert disc and try should this product or any part thereof, under normal use and conditions, be proven defective in material or again.

  • Page 20: Garantia Limitade De 12 Meses

    Asegoerese de que el cable no está pellizcado. AUDIOVOX CORPORATION (la Compañía) garantiza al comprador minorista original del presente producto que en el caso de que este producto o cualquiera de las partes del mismo, bajo circunstancias y condiciones de uso normal, tuviera algún defecto, tanto en el material como en la mano de obra, dentro de un plazo de 12 meses a partir de la...
  • Page 21 Garantie Limitée de 12 Mois Installez un fusible de type et de AUDIOVOX CORPORATION (la Société) garantit à l’acheteur initial du produit que si tout ou partie de ce produit, en puissance appropriés. cours d’utilisation et sous des conditions normales, venait à présenter des vices de matière primitive ou des défauts de fabrication, dans les 12 mois suivant la date d’achat initial, ce(s) défaut(s) sera(seront) réparé(s) ou remplacé(s)
