Oki B431L6 Maintenance Manual
  1. Manuals
  2. Brands
  3. Oki Manuals
  4. Printer
  5. B431L6
  6. Maintenance manual

Oki B431L6 Maintenance Manual

Hide thumbs

Advertisement

Quick Links

This document is "OKI DATA – CONFIDENTIAL"
Only persons and parties authorised by OKI DATA have
permissions to access this document.
This document should not be accessed by any parties
without the approval of OKI DATA.
Anyone who is found to be contradicting the above may be subject to legal action.
OEL

Maintenance Manual

B401/B411L6/B431L6
Revision 1
Rev
Date
Oki Data Corporation
1
2012-02-14
Name
B401/B411/B431
Maintenance Manual

Advertisement

loading

Related Manuals for Oki B431L6

Summary of Contents for Oki B431L6

  • Page 1: Maintenance Manual

    This document is “OKI DATA – CONFIDENTIAL” Only persons and parties authorised by OKI DATA have permissions to access this document. This document should not be accessed by any parties without the approval of OKI DATA. Anyone who is found to be contradicting the above may be subject to legal action.
  • Page 2 Oki Data CONFIDENTIAL Document Revision History Corrected items Person in Rev. No. Date charge Page Description of change 2012-02-14 ISSUE EMD12 T.Ishikuro ii / 44983601TH Rev.1...
  • Page 3 PREFACE Oki Data CONFIDENTIAL PREFACE This Maintenance Manual describes the maintenance methods in the printer field for the maintenance personnel. In addition, regarding the handling and operating method of the printer, please refer to the "User’s Manual". The differences between various types of printers described in this Maintenance Manual are as follows.
  • Page 4 Oki Data CONFIDENTIAL Note! • It is prohibited to reprint entire or partial of the content without prior consent. • For the reason of printer improving and manual content revising, the content of this maintenance manual may change without any warning in the future.

  • Page 5: Table Of Contents

    Contents Oki Data CONFIDENTIAL Contents 1. CONFIGURATION ......................1-1 1.1 System Configuration ........................1-1 1.2 Printer Configuration .........................1-2 1.3 Optional Configuration ........................1-4 1.4 Specification ............................1-5 1.5 Printing display ..........................1-8 1.5.1 VCCI label, Serial No. label .......................1-8 1.5.2 Warning label ..........................1-8 1.5.3 Warning / Caution display ......................1-9...
  • Page 6 Contents Oki Data CONFIDENTIAL 3.3.25 Lever In Sensor / Lever WR Sensor / /Photo Interrupter ............3-32 3.3.26 Paper feeding roller (Roller-Pick-Up,Roller-Feed-NOW,Roller-Assy-MPT) ......3-33 3.3.27 Frame-Assy-Retard , Spring-Retard..................3-35 3.4 Lubricating points ..........................3-36 4. ADJUSTMENT ......................4-1 4.1 Category and function of maintenance mode ...................4-1 4.1.1...
  • Page 7 Contents Oki Data CONFIDENTIAL 3.3.2 Guard-Connector, Connector (9715S-08Z02-G4C) ..........Appendix C-7 3.3.3 Board-GOG ......................Appendix C-8 3.3.4 CONN Cord-AMP8P-AMP8P ................Appendix C-9 3.3.5 Gear-Assy-Clatch (Hop, Regist), Motor-Pulse ............. Appendix C-10 3.3.6 Frame-Assy-Retard, Spring-Retard ..............Appendix C-12 4. Cleaning of Paper Feed Roller and Separation Roller ............Appendix C-13 5.

  • Page 8: Configuration

    1. CONFIGURATION Oki Data CONFIDENTIAL 1. CONFIGURATION 1.1 System Configuration As the diagram 1.1 shows, for the standard configuration printer is configured by controller unit and engine unit. Figure1-1 44983601TH Rev.1...

  • Page 9: Printer Configuration

    1. CONFIGURATION Oki Data CONFIDENTIAL 1.2 Printer Configuration The printer main unit includes the following hardware parts. • Electrophotographic processing part • Paper feeding part • Controller • Operational part • Power supply unit Note! • Fuser-Assy has to be replaced by Assy unit.
  • Page 10 1. CONFIGURATION Oki Data CONFIDENTIAL B431d/B431dn Figure1-3 44983601TH Rev.1...

  • Page 11: Optional Configuration

    1. CONFIGURATION Oki Data CONFIDENTIAL 1.3 Optional Configuration The options attached to the printer are as follows. These options can be ordered respectively for the printer main unit. (1) Second tray unit (B411/B431) (2) Additionally installed memory (B411/B431) Domestic oriented printer only use 64MB,128MB,256MB.

  • Page 12: Specification

    1. CONFIGURATION Oki Data CONFIDENTIAL 1.4 Specification (1) Type Desktop (2) Dimension 244.5mm (Height) x 387mm (Width) x 364 (Depth) :B4011d/B401dn/B411d/B411dn/B431d/B431dn (3) Weight Approx. 11.6kg (It includes the weight of the printer main unit and consumables. It doesn't include the weight of options and paper. ) (4) Development method Dray type –...
  • Page 13 1. CONFIGURATION Oki Data CONFIDENTIAL (6) Paper feeding method / Ejecting method It is possible to use it. × : It is not possible to use it. It is possible to use it by a part of size Paper ejecting...
  • Page 14 1. CONFIGURATION Oki Data CONFIDENTIAL Paper feeding method Automatic feeding Paper ejecting method Face down (Rear ejecting) / Face up (Front ejecting) (10) Resolution (Max.) 2400 × 600 dots / inch (B401/B411) 1200 × 1200 dots / inch (B431) (11) Input electricity AC100V ±...

  • Page 15: Printing Display

    1. CONFIGURATION Oki Data CONFIDENTIAL 1.5 Printing display 1.5.1 VCCI label, Serial No. label The VCCI label and Serial No. label have been attached on the specified part of printer as shows below. A F 8 5 1 2 3 4 5 6 A 0 Made in 1.5.2 Warning label...

  • Page 16: Warning / Caution Display

    1. CONFIGURATION Oki Data CONFIDENTIAL 1.5.3 Warning / Caution display The following warning / caution are displayed on the electrical power / sensor board. Warning / Caution content record Component side Soldering side High voltage power board Heat sink Heat sink...

  • Page 17: Operational Explanation

    2. Operational explanation Oki Data CONFIDENTIAL 2. Operational explanation 2.1 Electrophotographic process mechanism (1) Electrophotographic process The following describes the overview of electrophotographic process. 1. Charging Equally charge the surface of image drum by implying negative voltage to the charged roller due to negative charge.
  • Page 18 2. Operational explanation Oki Data CONFIDENTIAL 1. Charging Charge the image drum surface by implying voltage to the charged roller that contacts the image drum surface. Charged roller Power Image drum 2. Exposure The light emitting from the LED Head will be exposed to the negative charged image drum. When the surface electric potential of exposed part of the image drum goes to decrease, the electrostatic latent image complying with image signal is formed.
  • Page 19 2. Operational explanation Oki Data CONFIDENTIAL 3. Image development Toner is attracted to the electrostatic latent image on the image drum surface, then the electrostatic latent image changes to toner image. 1 As the roller on the supply spot of toner rotates while scrubbing the image-developing roller, fiction electricity occurs between the image developing roller and toner;...
  • Page 20 2. Operational explanation Oki Data CONFIDENTIAL Note! The necessary bypass voltage in image processing is impressed on the toner feeding roller and image developing roller as show below. While the cover is closed it will be connected and bias will be applied.
  • Page 21 2. Operational explanation Oki Data CONFIDENTIAL 4. Transfer The transfer roller, which is from conductive sponge material, is created to meet intimate attachment of image drum roller surface and feeding paper. The feeding paper is set up on the surface of image drum.
  • Page 22 2. Operational explanation Oki Data CONFIDENTIAL 6. Drum cleaning After completion of transfer, the toner remaining on the image drum is scraped off by the cleaning blade. As a result of this, the surface of the image drum is cleaned, and the remaining toner that has been scraped off is collected as waste toner in a waste toner area.

  • Page 23: Printing Process

    2. Operational explanation Oki Data CONFIDENTIAL 2.2 Printing process The paper fed from Tray 1 and Tray 2 is conveyed by feeding roller, conveying roller, and resist roller. When feeding paper is from MPT, it is conveyed by MPT, feeding roller, and resist roller. After that the feeding paper that is conveyed by image drum and the nip part of transfer roller forms toner image on the paper through electrophotographic process.
  • Page 24 2. Operational explanation Oki Data CONFIDENTIAL (1) Paper feeding from Tray 1 1. As DC motor rotating (Clockwise rotation), if set the paper feeding clutch as ON, as the paper feeding roller and pick up roller rotating, the paper that is inside the tray is conveyed.
  • Page 25 2. Operational explanation Oki Data CONFIDENTIAL (3) Fuser unit and paper ejecting 1. The fuser unit is driven by the DC motor. After the DC motor starts running (clockwise), the heat roller starts rotating. 2. Simultaneously the eject motor starts running (counterclockwise), and then the eject roller starts rotating and ejects paper.
  • Page 26 2. Operational explanation Oki Data CONFIDENTIAL (4) Paper reversing and paper multi-feeding 1. In a certain period of time after the paper rear end passes the eject sensor lever, the eject motor runs backward (clockwise) and then the eject roller rotates in the reverse direction (clockwise).

  • Page 27: Toner Entrance Detection

    2. Operational explanation Oki Data CONFIDENTIAL 2.3 Toner entrance detection Toner sensor detection principle Toner low is detected by the toner sensor (reflect sensor) installed in the printer. The light shield plate is installed in the ID, and its rotation is synchronized with mixing of toner. If the light shield plate or toner...

  • Page 28: Parts Replacement

    3. Parts replacement Oki Data CONFIDENTIAL 3. Parts replacement This section explains the replacement procedure of part, assembly, and unit in the working place. Disassembling procedure relating to reassembling is conducted conversely. 3.1 Preparation for parts replacement (1) Be sure to unplug the AC cord and interface cable before starting to replace parts.
  • Page 29 3. Parts replacement Oki Data CONFIDENTIAL [Maintenance tools] The necessary tools for replacing the print circuit board, assembly, and unit is shown as graph 3-1. Graph 3-1 Maintenance tools Maintenance tools Quantity Application Remark 3~5mm No.2-200 + Magnetic driver Screw No.3-100 Driver...

  • Page 30: Parts Layout

    3. Parts replacement Oki Data CONFIDENTIAL 3.2 Parts layout This section explains the main parts layout of the equipment. B401d/B401dn/B411d/B411dn Figure 3-1 3-3 / 44983601TH Rev.1...
  • Page 31 3. Parts replacement Oki Data CONFIDENTIAL B431d/B431dn Figure 3-2 3-4 / 44983601TH Rev.1...

  • Page 32: Parts Replacement Method

    3. Parts replacement Oki Data CONFIDENTIAL 3.3 Parts replacement method This section explains the replacement method of the parts and assemblies that are shown in the following disassembling diagram. The explaining diagram of parts replacement procedure is B431dn. Replace part after performing the following operation.

  • Page 33: 44983601Th Rev.1

    3. Parts replacement Oki Data CONFIDENTIAL 3.3.1 LED Head (1) Open the Stacker Cover. (2) Remove the ID UNIT. (3) Disengage the tab of the Holder-Head from the stacker cover by using a flat-head screwdriver or something. (4) Pull the Holder-Head toward you as illustrated below.

  • Page 34: Roller Transfer (3.3.2)

    3. Parts replacement Oki Data CONFIDENTIAL 3.3.2 Roller-Transfer (1) Open the Stacker Cover. (2) Remove the ID UNIT. (3) Take the Frame-Assy-TR out of the printer. (4) Disengage the latches of Bearing-TR on both ends. (5) Hold the Bearing-TR on the both side, and then lift up the Roller-Transfer (At this moment, Gear-TR is also removed.)

  • Page 35: Duplex Belt (3.3.3)

    3. Parts replacement Oki Data CONFIDENTIAL 3.3.3 Duplex Belt (1) Take out the Frame-Assy-TR. (Refer to 3.3.2) (2) Remove the cassette and set the printer unit on its right side. (3) Remove the E-ring and slide the Shaft-Dup-Clutch in the direction of the arrow.

  • Page 36: Cover-Side-R

    3. Parts replacement Oki Data CONFIDENTIAL 3.3.4 Cover-Side-R (1) Remove the cassette. (2) Open MPT, the Cover-Assy-Stacker and the Cover-Assy-Rear. (3) Remove the screw (Silver) (4) Disengage the four tabs (a to d) and remove Cover-Side-R by opening it from the front side of the printer in the direction of the arrow.

  • Page 37: Cover-Side-L

    3. Parts replacement Oki Data CONFIDENTIAL 3.3.5 Cover-Side-L (1) Remove the cassette. (2) Open MPT, the Cover-Assy-Stacker and the Cover-Assy-Rear. (3) Disengage the four tabs (a to d) and remove Cover-Side-L by opening it from the front side of the printer in the direction of the arrow.

  • Page 38: Cu-Board

    3. Parts replacement Oki Data CONFIDENTIAL 3.3.6 CU-Board (1) Remove the Cover-Side-R. (Refer to 3.3.4) (2) Remove the five screws (Silver) . Remove the Plate-Shield ① ② ① (3) Remove the two screw (Silver : Small) , remove the two screw (Silver)

  • Page 39: Pwb Unit - Acdc Switch

    3. Parts replacement Oki Data CONFIDENTIAL 3.3.7 PWB unit - ACDC Switch Warning Risk of Electric Shock There is a risk of electric shock during replacement of the low voltage power supply. Use insulating gloves or avoid direct contact with any conducting part of the power supply, and caution should be exercised during replacement.

  • Page 40: Dc Motor

    3. Parts replacement Oki Data CONFIDENTIAL 3.3.8 DC Motor (1) Remove the Cover-Side-R. (Refer to 3.3.4) (2) Remove the five screws (Silver) . Remove the Plate-Shield (3) Remove the cable of DC Motor from CU-board. (4) Remove the three screws(Silver)

  • Page 41: Hopping / Mpt / Regist Clutch

    3. Parts replacement Oki Data CONFIDENTIAL 3.3.9 Hopping / MPT / Regist Clutch (1) Remove the CU-Board. (Refer to 3.3.6) (2) Remove the Power-Supply Unit ( Board ). (Refer to 3.3.7) (3) Remove the DC Motor. (Refer to 3.3.8) (4) Remove the Sheet-Insulation-CU...

  • Page 42: Hv-Board / Motor-Fan

    3. Parts replacement Oki Data CONFIDENTIAL 3.3.10 HV-Board / Motor-FAN (1) Remove the Cover-Side-L. (Refer to 3.3.5) (2) Remove the screw (Black) and the four screws (Silver) , disengage the two tabs (a and b), and remove HV-Board . Be careful not to lose Spring-Contact that is removed with the board.

  • Page 43: Cover Assy Ope

    3. Parts replacement Oki Data CONFIDENTIAL 3.3.11 Cover Assy OPE (1) Remove the Cover-Side-R and Cover–Side-L. (Refer to 3.3.4 / 3.3.5) (2) Remove the five screws (Silver) . Remove the Plate-Shield (3) Remove the FFC cable from the CU-board. (4) Remove the two screws (Black) .

  • Page 44: Ope Pcb Assy ( B431 )

    3. Parts replacement Oki Data CONFIDENTIAL 3.3.12 Ope PCB Assy ( B431 ) (1) Remove the Cover Assy Ope. (Refer to 3.3.11) (2) Remove the two screws (Black) (3) Remove the Ope PCB Assy (4) Remove the FFC cable and the LCD (5) Installing is performed by the reverse procedure with removing.

  • Page 45: Cover Assy Stacker

    3. Parts replacement Oki Data CONFIDENTIAL 3.3.13 Cover Assy Stacker (1) Remove the Cover-Side-R and Cover–Side-L. (Refer to 3.3.4 / 3.3.5) (2) Remove the two screws (Silver) . Remove the Cover-Eject (At this moment, Plate-Rear is also removed.) (3) With the Cover Assy Stacker closed, detach Lever-Link-Fuser (on both sides) from the Fuser Assy release lever by using a flat-head screwdriver or something.
  • Page 46 3. Parts replacement Oki Data CONFIDENTIAL (7) Remove the Cover Assy Stacker (8) Installing is performed by the reverse procedure with removing. (Note on removing / installing) 1. Beware of not to touch the DC motor inattentively (Do not rotate motor).

  • Page 47: Stacker Cover

    3. Parts replacement Oki Data CONFIDENTIAL 3.3.14 Stacker Cover (1) Remove the Cover Assy Stacker. (Refer to 3.3.13) (2) Remove the LED Head. (Refer to 3.3.1) (3) Remove the Lever-Link-Fuser (on both sides). (4) Remove the four screws (Black) , remove the Cover-Lever .

  • Page 48: Fuser Assy

    3. Parts replacement Oki Data CONFIDENTIAL 3.3.15 Fuser Assy Note! Replace the Fuser-Assy by Assy unit. It is forbidden for disassembling the Fuser-Assy, also, reusing the disassembled Fuser-Assy. (1) Take out the Frame-Assy-TR. (Refer to 3.3.2) (2) Remove the Cover Assy Stacker. (Refer to 3.3.13)

  • Page 49: Mpt Assy , Manual Assy (3.3.16)

    3. Parts replacement Oki Data CONFIDENTIAL 3.3.16 MPT Assy , Manual Assy (1) Remove the Cover-Side-R and Cover–Side-L. (Refer to 3.3.4 / 3.3.5) (2) Remove the Cover-Assy-OPE. (Refer to 3.3.11) (3) Remove the two screws (Silver) Plate-Front . Remove the...

  • Page 50: Cover Assy Rear (3.3.17)

    3. Parts replacement Oki Data CONFIDENTIAL 3.3.17 Cover Assy Rear (1) Remove the Cover-Side-R and Cover–Side-L. (Refer to 3.3.4 / 3.3.5) (2) Remove the CU-Board. (Refer to 3.3.6) (3) Remove the Sheet-Insulation-CU (4) Remove the Spacer (5) Slide Cover Assy Rear and pull it out of the hole on the right of the printer.
  • Page 51 3. Parts replacement Oki Data CONFIDENTIAL (6) Remove the two screws (Black) and separate Cover-Rear and Guide-Eject-Upper-Assy (7) Remove the Gear-Idle (8) Remove the Gear-Exit (2 places), remove the Bearing-Eject_R (2 places). Remove the Bearing- Feeder (2 places). (9) Remove the Shaft-Assy-Eject (2 places).

  • Page 52: Guide Eject Lower Assy (3.3.18)

    3. Parts replacement Oki Data CONFIDENTIAL 3.3.18 Guide Eject Lower Assy (1) Remove the Cover-Side-R and Cover–Side-L. (Refer to 3.3.4 / 3.3.5) (2) Remove the CU-Board. (Refer to 3.3.6) (3) Remove the Sheet-Insulation-CU (4) Remove the two screws (Silver) . Remove the Cover-Eject (At this moment, Plate-Rear is also removed.)

  • Page 53: Eject Motor (3.3.19)

    3. Parts replacement Oki Data CONFIDENTIAL 3.3.19 Eject Motor (1) Remove the Cover-Side-R and Cover–Side-L. (Refer to 3.3.4 / 3.3.5) (2) Remove the CU-Board. (Refer to 3.3.6) (3) Remove the Cover Assy Stacker. (Refer to 3.3.13) (4) Remove the Fuser Assy. (Refer to 3.3.15) (5) Remove the Cover Assy Rear.

  • Page 54: Plate Side R Assy / Plate Side L Assy / Front Assy

    3. Parts replacement Oki Data CONFIDENTIAL 3.3.20 Plate Side R Assy / Plate Side L Assy / Front Assy (1) Remove the Cover-Side-R and Cover–Side-L. (Refer to 3.3.4 / 3.3.5) (2) Remove the CU-Board. (Refer to 3.3.6) (3) Remove the Power Supply Unit. (Refer to 3.3.7) (4) Remove the DC Motor.

  • Page 55: Plate Side L Assy (3.3.21)

    3. Parts replacement Oki Data CONFIDENTIAL 3.3.21 Plate Side L Assy (1) Separate the Plate Side L Assy. (Refer to 3.3.20) (2) Remove the three screws (Silver) Guide-Cassette-L and Spring-Lock-Cassette . Remove the (3) Remove Lever-Sensor Cassette and Spring-Sensor from the Guide-Cassette-L...

  • Page 56: Plate Side R Assy (3.3.22)

    3. Parts replacement Oki Data CONFIDENTIAL 3.3.22 Plate Side R Assy (1) Separate the Plate Side R Assy. (Refer to 3.3.20) (2) Remove the two screws (Silver) Guide-Cassette-R . Remove the (3) Remove the two screws (Black) . Remove the Connector...

  • Page 57: Roller Regist (3.3.23)

    3. Parts replacement Oki Data CONFIDENTIAL 3.3.23 Roller Regist (1) Separate the Front Assy. (Refer to 3.3.20) (2) Remove the two screws (Black) and Plate-Feed-B (Be careful not to lose the gear that is removed with the plate.) (3) Remove the Gear-Idle-MPT .

  • Page 58: Roller Feed Assy (3.3.24)

    3. Parts replacement Oki Data CONFIDENTIAL 3.3.24 Roller Feed Assy (1) Separate the Front Assy. (Refer to 3.3.20) (2) Remove the two screws (Black) and Plate-Feed-B (Be careful not to lose the gear that is removed with the plate.) (3) Remove the two screws (Black) Separate the Regist Assy.

  • Page 59: Lever In Sensor / Lever Wr Sensor / /Photo Interrupter

    3. Parts replacement Oki Data CONFIDENTIAL 3.3.25 Lever In Sensor / Lever WR Sensor / /Photo Interrupter (1) Separate the Front Assy. (Refer to 3.3.20) (2) Separate the Roller-Pressure and Roller Regist. (Refer to 3.3.23) (3) Remove the two screws (Black)

  • Page 60: Paper Feeding Roller (Roller-Pick-Up,Roller-Feed-Now,Roller-Assy-Mpt)

    3. Parts replacement Oki Data CONFIDENTIAL 3.3.26 Paper feeding roller (Roller-Pick-Up,Roller-Feed-NOW,Roller-Assy-MPT) • In the case of Tray 1 (1) Turn off the printer and pull out the paper cassette tray. (2) Remove the feed roller as pushing its tab outward.
  • Page 61 3. Parts replacement Oki Data CONFIDENTIAL • In the case of Multi-purpose Tray ( B431dn) (1) Turn off the printer. (2) Open the multipurpose tray and the paper support. (3) Open the feed roller cover by pushing its tab to the right.

  • Page 62: Frame-Assy-Retard , Spring-Retard

    3. Parts replacement Oki Data CONFIDENTIAL 3.3.27 Frame-Assy-Retard , Spring-Retard (1) Remove the cassette. (2) Open the Retard-Cover by pushing two tabs in the directions of the arrows. (3) Remove Frame-Assy-Retard by pushing it in the direction of the arrow.

  • Page 63: Lubricating Points

    3. Parts replacement Oki Data CONFIDENTIAL 3.4 Lubricating points This subsection indicates the lubricating points of the printer. Conversely, it means that any other parts than the specified lubricating points must not be lubricated. There is no need to lubricate in the midst of a disassembling job. However, if lubricating oil has been wiped off, supply the specified oil.
  • Page 64 3. Parts replacement Oki Data CONFIDENTIAL Plate-Assy-Side-L C-9310 or C-5005 Class A Apply a normal amount of Tetra (C-9310 or C-5005) to the hatched areas.( Contact surface ) 3-37 / 44983601TH Rev.1...
  • Page 65 3. Parts replacement Oki Data CONFIDENTIAL -1 Plate-Assy-Side-R EM-30LP Class B Apply a normal amount of MOLYKOTE (EM-30LP) to the sliding surface with Drum Shaft. (hatched areas) Plate-Assy-Side-R -2 Plate-Assy-Side-R EM-30LP Class D Apply MOLYKOTE (EM-30LP) at the 3 places (120 ° divide) on the hatched areas.
  • Page 66 3. Parts replacement Oki Data CONFIDENTIAL -3 Plate-Assy-Side-R EM-30LP Class C Apply a normal amount of MOLYKOTE (EM-30LP) to the hatched areas. (Shaft end surface side) Plate-ID-Gear(Caulking) -4 Plate-Assy-Side-R EM-30LP Class C Apply MOLYKOTE (EM-30LP) at the 3 places (120°divide) on the hatched areas.
  • Page 67 3. Parts replacement Oki Data CONFIDENTIAL Frame-Assy-Hopping Plate-Feed-A Caulking EM-30LP Class C Apply a normal amount of MOLYKOTE(EM-30LP) to the hatching areas. (Shaft) Shaft-Roller-Feed Roller-Feed EM-30LP Class C Apply a normal amount of MOLYKOTE(EM-30LP) to the hatching areas. (Shaft) 3-40 /...
  • Page 68 3. Parts replacement Oki Data CONFIDENTIAL -1 Frame Assy-Regist Note:1 EM-30LP Class A Apply a normal amount of MOLYKOTE (EM-30LP) to the hatched areas. (Side of roller and ditch of shaft) (The other side is also the same. : Two places in total)
  • Page 69 3. Parts replacement Oki Data CONFIDENTIAL -2 Frame Assy-Regist EM-30LP Class C Apply a normal amount of MOLYKOTE(EM-30LP) to the hatching areas. (Shaft end surface side) Roller-Pressure Roller-Regist EM-30LP Class C Apply a normal amount of MOLYKOTE(EM-30LP) to the hatching areas.
  • Page 70 3. Parts replacement Oki Data CONFIDENTIAL -1 Front-Assy Plate-Feed-B_Caulking Gear-Idle-Z35 Gear-Idle-MPT-Z35 EM-30LP Class C Apply a normal amount of MOLYKOTE(EM-30LP) to the hatching areas. (Post end surface side) Gear-Reduction-MPT-Z37-20 Frame Assy-Regist 3-43 / 44983601TH Rev.1...
  • Page 71 3. Parts replacement Oki Data CONFIDENTIAL -2 Front-Assy EM-30LP Class C Apply a normal amount of MOLYKOTE (EM-30LP) to the hatched areas. (Shaft end surface side) Plate-Feed-B_Caulking 3-44 / 44983601TH Rev.1...
  • Page 72 3. Parts replacement Oki Data CONFIDENTIAL Frame-Assy-MPT / Frame-Assy-Manual Note:1 EM-30LP Class A Apply a normal amount of MOLYKOTE (EM-30LP) to the hatched areas. (Side of roller and ditch of shaft) (The other side is also the same. : Two places in total)
  • Page 73 3. Parts replacement Oki Data CONFIDENTIAL -1 Guide-Assy –Eject-U Gear-Idle_Exit(Z38) EM-30LP Class C Apply a normal amount of MOLYKOTE (EM-30LP) to surface of the post (bearing portion),the flange portions. EM-30LP Class B Apply a normal amount of MOLYKOTE (EM-30LP) to the whole circle of gear teeth. Of 4pcs 3-46 / 44983601TH Rev.1...
  • Page 74 3. Parts replacement Oki Data CONFIDENTIAL -2 Guide-Assy –Eject-U Gear-Exit(Z19) Bearing-Eject_R EM-30LP Class C Apply a normal amount of MOLYKOTE (EM-30LP) to flange surface. EM-30LP Class C Apply a normal amount of MOLYKOTE (EM-30LP) to bearing surface of the shaft.
  • Page 75 3. Parts replacement Oki Data CONFIDENTIAL -1 Frame-Assy-TR EM-30LP Class C Apply a normal amount of MOLYKOTE(EM-30LP) to the hatching areas. (Bearing sliding surface) EM-30LP Class C Apply a normal amount of MOLYKOTE (EM-30LP) to the hatched areas. (Gear tooth surface)
  • Page 76 3. Parts replacement Oki Data CONFIDENTIAL -2 Frame-Assy-TR Note:1 EM-30LP Class A Apply a normal amount of MOLYKOTE (EM-30LP) to the hatched areas. (Side of roller and ditch of shaft) (The other side is also the same. : Four places in total)
  • Page 77 3. Parts replacement Oki Data CONFIDENTIAL -3 Frame-Assy-TR C-9310 or C-5005 Class A Apply a normal amount of Tetra(C-9310 or C-5005) to the hatched areas. (Contact surface) C-9310 or C-5005 Class A Apply a normal amount of Tetra(C-9310 or C-5005) to the hatched areas.(Contact surface)
  • Page 78 3. Parts replacement Oki Data CONFIDENTIAL Duplex-Assy EM-30LP Class B Apply a normal amount of MOLYKOTE (EM-30LP) to the hatched areas. (Shaft end surface side) Bearing-DUP Roller-Feed_Dup MXL87-Belt-Dup EM-30LP Class B Bearing-DUP Apply a normal amount of MOLYKOTE (EM-30LP) to the hatched areas.
  • Page 79 3. Parts replacement Oki Data CONFIDENTIAL Fuser-Assy C-9310 or C-5005 Class A Apply a normal amount of Tetra(C-9310 or C-5005) to the hatched areas. (Contact surface) 3-52 / 44983601TH Rev.1...

  • Page 80: Adjustment

    4. ADJUSTMENT Oki Data CONFIDENTIAL 4. ADJUSTMENT This chapter provides explains relating to the adjustment that is necessary while replacing part. Adjustment is performed by modifying the value of parameter that is set on the EEPROM of main PCB board. Parameter can be set by key operation that is from the operator panel.
  • Page 81 4. ADJUSTMENT Oki Data CONFIDENTIAL Operation panel display Default Function Category Setting item Setting item value * Only English is supported for panel display (Upper case) (Lower case) OP MENU FX EMULATION ENABLE Set Category FX EMULATION MENU Enable/Disable. DISABLE Set to Disable, Category FX EMULATION MENU of user menu is not displayed.
  • Page 82 4. ADJUSTMENT Oki Data CONFIDENTIAL Operation panel display Default Function Category Setting item Setting item value * Only English is supported for panel display (Upper case) (Lower case) FILE SYS Initialize resident FLASH. FLASH EXECUTE MAINTE1 Press Enter switch then the following confirming message is...
  • Page 83 4. ADJUSTMENT Oki Data CONFIDENTIAL • User maintenance mode menu chart “Display Indicating” Press Key Press Key “MENU ” “MENU ” and move Set ENABLE/DISABLE for all categories of “SETTING” OP MENU ALL CATEGORY ALL CATEGORY USER MENU. Select by key “MENU ”...
  • Page 84 4. ADJUSTMENT Oki Data CONFIDENTIAL Press Key Set LED LIGHTING CONTROL for NEAR “SETTING” CONFIG MENU NEARLIFE LED NEARLIFE LED LIFE WARNING occurring of toner and ENABLE DISABLE drum. Select by Key “SETTING” and press key “MENU ” “MENU ”...

  • Page 85: System Maintenance Mode (System Maintenance Menu)

    4. ADJUSTMENT Oki Data CONFIDENTIAL 4.1.2 System maintenance mode (System maintenance menu) Note! • This mode is only used by maintenance personnel; it is not released to the end user. • This mode is only B431. • Refer to "Maintenance Utility" for B401/B411.
  • Page 86 4. ADJUSTMENT Oki Data CONFIDENTIAL Operation panel display Function Default Category * Only English is supported for panel Setting item Setting item value display (Upper case) (Lower case) PERSONALITY PCL ENABLE Change the default of Support PDL Language DISABLE for each destination.
  • Page 87 4. ADJUSTMENT Oki Data CONFIDENTIAL Operation panel display Function Default Category * Only English is supported for panel Setting item Setting item value display (Upper case) (Lower case) DOTSHIFT MANUAL -2.0MILLIMETER Set landscape DOTSHIFT of Manual Slot while printing. -1.0MILLIMETER Item is displayed even Tray 2 is not -0.5MILLIMETER...
  • Page 88 4. ADJUSTMENT Oki Data CONFIDENTIAL • System maintenance mode menu chart “Display Indicating” Press Key “SETTING” OKIUSER OKIUSER Set destination. Displayed by “MENU ” and “MENU ”. Select by “SETTING” Select by Key “SETTING” and press key JPOEM1 Press Key “MENU ” “MENU ”...
  • Page 89 4. ADJUSTMENT Oki Data CONFIDENTIAL Press Key Press Key “MENU ” “MENU ” and move “SETTING” DOTSHIFT TRAY1 -2.0MILLIMETER Set landscape dot shift. 0.0MILLIMETER -1.5MILLIMETER Select by Key -1.0MILLIMETER “SETTING” and -0.5MILLIMETER press key “MENU ” “MENU ” 0.0MILLIMETER +0.5MILLIMETER +2.0MILLIMETER...

  • Page 90: Self-Diagnostic Mode

    4. ADJUSTMENT Oki Data CONFIDENTIAL 4.1.3 Self-diagnostic Mode (1) To enter Self-diagnostic mode, turn on the power switch while holding down the "MENU " and "MENU " buttons and then select "ENGINE DIAG MODE" . (2) The function of this mode is selected from Menu.
  • Page 91 4. ADJUSTMENT Oki Data CONFIDENTIAL 4-12 / 44983601TH Rev.1...
  • Page 92 4. ADJUSTMENT Oki Data CONFIDENTIAL 4-13 / 44983601TH Rev.1...
  • Page 93 4. ADJUSTMENT Oki Data CONFIDENTIAL 4.1.3.2 Ordinary self-diagnostic mode (level 1) Menu items of the ordinary self-diagnostic mode are shown below. Item Self-diagnostic menu Adjustment contents Maintenance utilities Switch scan test SWITCH SCAN Entry sensor check and switch check Refer to 2.4.1.5.1 Motor clutch test MOTOR&CLTCH TEST Motor and clutch operation test...

  • Page 94: Switch Scan Test

    4. ADJUSTMENT Oki Data CONFIDENTIAL 4.1.3.3 Switch scan test This self-diagnostic menu is used to check the entry sensor and the switch. ] or Enter the self-diagnostic mode (level 1), press the [MENU [MENU key repeatedly ,and press the [OK] key when the "SWITCH SCAN"...
  • Page 95 4. ADJUSTMENT Oki Data CONFIDENTIAL 4-16 / 44983601TH Rev.1...

  • Page 96: Motor Clutch Test

    4. ADJUSTMENT Oki Data CONFIDENTIAL 4.1.3.4 Motor clutch test This self-diagnostic menu is used to test the motor and clutch. ] or 1. Enter the self-diagnostic mode (level 1), press the [MENU [MENU key repeatedly ,and press the [OK] key when the "MOTOR & CLUTCH TEST" is displayed in the upper row of the display area. (Pressing the [MENU key increments the test item and pressing the [MENU key decrements the test item.)
  • Page 97 4. ADJUSTMENT Oki Data CONFIDENTIAL Table 4-4 Unit name display Drive restriction condition Remarks MAIN MOTOR EXIT MOTOR FWD FaceUp Cover close EXIT MOTOR REV FaceUp Cover open REGIST CLUTCH MAIN MOTOR driving T1 HOP CLUTCH MAIN MOTOR driving MPT HOP CLUTCH (*1)

  • Page 98: Test Print

    4. ADJUSTMENT Oki Data CONFIDENTIAL 4.1.3.5 Test print This self-diagnostic menu is used to print the test pattern that is built inside PU. Other test patterns are stored in the controller. This test print cannot be used to check the print quality.
  • Page 99 4. ADJUSTMENT Oki Data CONFIDENTIAL While the message "PRINT EXECUTE" that is set by the operation specified in step 2 is being displayed, press the [OK] key and the test print is executed with the setting value that has been set by steps 2 and 3.
  • Page 100 4. ADJUSTMENT Oki Data CONFIDENTIAL • Displays are switched by pressing the [MENU key. ETMP=***UTMP=*** ETMP : environment temperature [unit: DEC] UTMP : fuse target temperature [unit: DEC] • Displays are switched by pressing the [MENU key. DB:k** DB : Develop voltage setting table ID number [unit: HEX] •...

  • Page 101: Consumable Item Counter Display

    4. ADJUSTMENT Oki Data CONFIDENTIAL 4.1.3.6 Consumable item counter display This self-diagnostic menu is used to display the consumption status of the consumable items. ] or Enter the self-diagnostic mode (level 1), press the [MENU [MENU key repeatedly ,and press the [OK] key when the "CONSUMABLE STATUS"...
  • Page 102 4. ADJUSTMENT Oki Data CONFIDENTIAL 4.1.3.8 Switching between the Factory mode and the Shipping mode This self-diagnostic menu item is used to switch between the Factory mode and the Shipping mode. Enter the self-diagnostic mode (level 1) and keep pressing the [MENU ] or [MENU ] key until the following message is displayed.
  • Page 103 4. ADJUSTMENT Oki Data CONFIDENTIAL 4.1.3.9 Self-diagnostic function setting This self-diagnostic menu is used to set valid/invalid of the error detection by the various sensors. The error detection can be made invalid or valid for locating source of abnormality. However, this menu item requires expert knowledge to set among the engine operations.

  • Page 104: Led Head Serial Number Display

    4. ADJUSTMENT Oki Data CONFIDENTIAL 4.1.3.10 LED head serial number display This self-diagnostic menu item is used to check whether the downloaded LED head data matches the serial number of the actual LED head. ] or Enter the self-diagnostic mode (level 1), press the [MENU...

  • Page 105: Energy Conservation Mode Setting

    4. ADJUSTMENT Oki Data CONFIDENTIAL 4.1.4 Energy conservation mode setting This printer is equipped with two types of energy conservation mode, MODE1 as "NORMAL MODE" and MODE2 as "ECO MODE." When energy conservation mode is set to "ECO MODE," the printer prints at a low speed at the beginning of cold start to reduce the period of time required for warming up from the normal temperature.

  • Page 106: Eeprom Initialization

    4. ADJUSTMENT Oki Data CONFIDENTIAL 4.1.5 EEPROM Initialization The treatment for EEPROM Initialization at each phenomenon is displayed as Diagram 4-1. Diagram 4-1 EEPROM Initial Setting Range CU EEPROM Area PU EEPROM Area Administrator Menu/ Engine Maintenance Menu Area System Maintenance...

  • Page 107: Adjustment At Part Replacement

    4. ADJUSTMENT Oki Data CONFIDENTIAL 4.2 Adjustment at part replacement Adjustment is necessary while replacing the following part. Replacing part Adjustment Main PCB board EEPROM data upload / download 4.2.1 EEPROM data upload / download method In the case of replacing the Print Board of Controller, copy the old EEPROM content to the new EEPROM of new board and then save the customer setting.

  • Page 108: Periodic Maintenance

    5. Periodic Maintenance Oki Data CONFIDENTIAL 5. Periodic Maintenance 5.1 Periodic Replacement Parts The following parts should be replaced at a specified cycle. Name Conditions Cleaning Remarks • Toner Cartridge After printing approx. 4,000 pages • LED head Consumables • Image Drum Cartridge After printing approx.

  • Page 109: Cleaning The Feed Rollers And The Retard Roller

    5. Periodic Maintenance Oki Data CONFIDENTIAL 5.4 Cleaning the Feed rollers and the Retard roller (1) Wipe the two feed rollers with a tightly wrung cloth soaked in water through the opening for installation of a paper cassette. Feed roller Note! Use water only.

  • Page 110: Procedures For Repairing

    6. Procedures for Repairing Oki Data CONFIDENTIAL 6. Procedures for Repairing 6.1 Troubleshooting (1) Check “8. Troubleshooting” of the user’s manual. (2) Collect the information of the status at the failure as much as possible. (3) Inspect the device in the status similar to the status at the failure occurrence.

  • Page 111: Troubleshooting Flow

    6. Procedures for Repairing Oki Data CONFIDENTIAL 6.5 Troubleshooting Flow If there are failures in the printer, troubleshooting is performed according to the following process flow. Troubles Perform troubleshooting Perform detailed trouble- Troubles displayed from the LCD status shooting from the trouble- on the LCD message table.
  • Page 112 6. Procedures for Repairing Oki Data CONFIDENTIAL Table 6-1 (2/8) LCD (16 digits on the upper level Error and 16 digits on the lower level) Status code Contents level (" " shows that nothing is Ready Atten displayed on the upper level.)
  • Page 113 6. Procedures for Repairing Oki Data CONFIDENTIAL Table 6-1 (3/8) LCD (16 digits on the upper level Error and 16 digits on the lower level) Status code Contents level (" " shows that nothing is Ready Atten displayed on the upper level.)
  • Page 114 6. Procedures for Repairing Oki Data CONFIDENTIAL Table 6-1 (4/8) LCD (16 digits on the upper level Error and 16 digits on the lower level) Status code Contents level (" " shows that nothing is Ready Atten displayed on the upper level.) Warning It is displayed after jobs are canceled by "Canceling...
  • Page 115 6. Procedures for Repairing Oki Data CONFIDENTIAL Table 6-1 (5/8) LCD (16 digits on the upper level Error and 16 digits on the lower level) Status code Contents level (" " shows that nothing is Ready Atten displayed on the upper level.)
  • Page 116 6. Procedures for Repairing Oki Data CONFIDENTIAL Table 6-1 (6/8) LCD (16 digits on the upper level Error and 16 digits on the lower level) Status code Contents level (" " shows that nothing is Ready Atten displayed on the upper level.)
  • Page 117 6. Procedures for Repairing Oki Data CONFIDENTIAL Table 6-1 (7/8) LCD (16 digits on the upper level Error and 16 digits on the lower level) Status code Contents level (" " shows that nothing is Ready Atten displayed on the upper level.)
  • Page 118 6. Procedures for Repairing Oki Data CONFIDENTIAL Table 6-1 (8/8) LCD (16 digits on the upper level Error and 16 digits on the lower level) Status code Contents level (" " shows that nothing is Ready Atten displayed on the upper level.) CU RAM Check Error (option slot) Reinstall the memory.

  • Page 119: Lcd Message Troubleshooting

    6. Procedures for Repairing Oki Data CONFIDENTIAL 6.5.2 LCD Message Troubleshooting If you still have trouble even after using the LCD Status Message / Trouble List, follow the troubleshooting flowchart displayed below to solve the trouble. Trouble Flowchart No. The printer does not work normally after tuning on the power.
  • Page 120 6. Procedures for Repairing Oki Data CONFIDENTIAL The case where the printer does not work normally after tuning on the power • Turn off the power and then, turn on the power again. • Are messages in the display of LCD all in black? •...
  • Page 121 6. Procedures for Repairing Oki Data CONFIDENTIAL [Jam Error] -1 Paper feed jam • Does a jam error occur when turning on the power? • Yes Is there any paper in the entrance sensor? • Yes Remove the paper • No Does the entrance sensor lever work normally? (It moves freely by touching.)
  • Page 122 6. Procedures for Repairing Oki Data CONFIDENTIAL [Jam Error] -2 Running jam • Does a jam error occur when turning on the power? • Yes Is there any paper in the write sensor? • Yes Remove the paper. • No Does the write sensor lever work normally? (It moves freely by touching.)
  • Page 123 6. Procedures for Repairing Oki Data CONFIDENTIAL [Jam Error] -3 Ejection Jam • Does an ejection jam error occur when turning on the power? • Yes Is there paper in the ejection sensor lever? • Yes Remove the paper. • No Does the ejection sensor lever work normally? (It moves freely by touching.)
  • Page 124 6. Procedures for Repairing Oki Data CONFIDENTIAL Paper Size Error • Is the paper which is specified size used? • No Use a specified-size paper. • Yes Does the entrance sensor lever work normally? (It moves freely by touching.) • No Replace the entrance sensor lever, or clean the entrance sensor.
  • Page 125 6. Procedures for Repairing Oki Data CONFIDENTIAL Fuser unit Assy (Error 170) (Error 171) (Error 172) (Error 173) • IIs the thermistor connector inserted into the THERM connector of the main board normally? • No Insert the Thermistor connector correctly.
  • Page 126 6. Procedures for Repairing Oki Data CONFIDENTIAL Exhaust Fan Error (Error 120) • Is the exhaust fan rotating? • Yes Replace the main board. • No Is the fan connector of the high-voltage power supply unit connected to the board properly? •No...

  • Page 127: Print Troubleshooting

    6. Procedures for Repairing Oki Data CONFIDENTIAL 6.5.3 Print Troubleshooting The troubleshooting procedure of abnormal printing is described as follows. The typical abnormal printing is shown in the following Figure 6-2. Trouble Flowchart number Pale printing or the whole printing is faded. (Fig.6-2 The white section is dirty.
  • Page 128 6. Procedures for Repairing Oki Data CONFIDENTIAL Pale printing or the whole printing is faded. • Does the printer lack toner? (Is the message of Toner Low displayed?) • Yes Supply the toner. LED head • No Is specified paper used.
  • Page 129 6. Procedures for Repairing Oki Data CONFIDENTIAL The white section is dirty • Is the image drum exposed by the external light? • Yes Install the image drum in the printer and wait 30 minutes. • No From [MAINTENANCE MENU], select [PAPER BLACK SET] - [SMR SETTING] and set a larger value for adjustment.
  • Page 130 6. Procedures for Repairing Oki Data CONFIDENTIAL Vertical black belt/ Black line • Clean the LED lens array of the LED head. • Has the trouble been solved? • Yes Completed. • No Replace the LED head. • Has the trouble been solved? •...
  • Page 131 6. Procedures for Repairing Oki Data CONFIDENTIAL In case of error printing • Does the contact plate of the transfer roller contact the TR terminal of the high-voltage power supply unit properly? (See Figure 6-4 , Section 7.2(2)) • No Adjust the contact plate so that it contacts the TR terminal of the high-voltage power supply unit properly.
  • Page 132 6. Procedures for Repairing Oki Data CONFIDENTIAL Vertical white belt/ White line • Is the LED lens dirty? • Yes Clean the LED lens. • No Does the contact plate of the transfer roller contact the TR terminal of the high-voltage power supply unit properly? (See Figure 6-4.
  • Page 133 6. Procedures for Repairing Oki Data CONFIDENTIAL Fuse Fuse Figure 6-3 6-24 / 44983601TH Rev.1...
  • Page 134 6. Procedures for Repairing Oki Data CONFIDENTIAL Transfer roller Frame-Assy-TR Contact plate for transfer High voltage power supply board TR terminal Contact plate for transfer Figure 6-4 6-25 / 44983601TH Rev.1...
  • Page 135 6. Procedures for Repairing Oki Data CONFIDENTIAL Fuser Assy Contact plate Figure 6-5 6-26 / 44983601TH Rev.1...

  • Page 136: Connection Diagram

    7. Connection Diagram Oki Data CONFIDENTIAL 7. Connection Diagram 7.1 Connection diagram 7-1 / 44983601TH Rev.1...

  • Page 137: Board Layout

    7. Connection Diagram Oki Data CONFIDENTIAL 7.2 Board Layout (1) Main control board The front side of the printer. MCLT RCLT FACEUP HEAD0 HCLT EXITM THERM LCDPNL USB1 RCO TONER EXIT IN_WR PWFAN1 SWRL DFAN1 CENT POWER HVIF DIMM 7-2 /...
  • Page 138 7. Connection Diagram Oki Data CONFIDENTIAL • USB1 Connector Pin Allocation (Connection to USB I/F) Pin No. I/O Signal Function vbus Power Serial Data Serial Data Logic Ground • LAN Connector Pin Allocation (Connection to LAN I/F) Pin No. I/O...
  • Page 139 7. Connection Diagram Oki Data CONFIDENTIAL • DIMM Connector Pin Allocation (Option RAM Slot) Pin No. I/O Signal Function VREF Reference Power Voltage Not used Logic Ground Not used Not used Not used Not used Not used Logic Ground Not used...
  • Page 140 7. Connection Diagram Oki Data CONFIDENTIAL Pin No. I/O Signal Function Logic Power Logic Ground ODT0 ODTControl0 Data Mask0 CKE0 Clock Enable0 Logic Ground /Write Enable Data Bus4 Logic Power Data Bus5 Not used Logic Ground Bank Select1 Data Bus6...
  • Page 141 7. Connection Diagram Oki Data CONFIDENTIAL Pin No. I/O Signal Function Address Bus5 Not used Logic Power Logic Ground Address Bus9 Not used Address Bus12 Not used Logic Power Logic Ground Not used Not used Not used Logic Ground Not used...
  • Page 142 7. Connection Diagram Oki Data CONFIDENTIAL • HEAD0 Connector Pin Allocation (Connection the LED HEAD Assy) Pin No. I/O Signal Function C VSS Logic Ground O CLKP Clock O CLKN Clock C VSS Logic Ground O LOAD Load O HSYNCN...
  • Page 143 7. Connection Diagram Oki Data CONFIDENTIAL • RCLT Connector Pin Allocation (Connection to the Regist Clutch) Pin No. I/O Signal Function O +24V Clutch Drive Power C REGIST Analog Ground • HCLT Connector Pin Allocation (Connection to Hopping clutch) Pin No. I/O...
  • Page 144 7. Connection Diagram Oki Data CONFIDENTIAL • RCO Connector Pin Allocation (Connection to the Photo interrupter) Pin No. I/O Signal Function O +5V Logic Circuit Power Supply RCOPN-N Rear Cover open C GND Logic Ground • EXIT Connector Pin Allocation (Connection to the Photo interrupter) Pin No.
  • Page 145 7. Connection Diagram Oki Data CONFIDENTIAL • PAP Connector Pin Allocation (Connection to the Photo interrupter) Pin No. I/O Signal Function O +5V Logic Circuit Power Supply PAPER-N Paper end Sensor signal input C GND Logic Ground • 2ND Connector Pin Allocation (Connection to the Option tray I/F) Pin No.
  • Page 146 7. Connection Diagram Oki Data CONFIDENTIAL • HVIF Connector Pin Allocation (Connection to High-Voltage power supply) Pin No. I/O Signal Function O +24V High-Voltage Board Drive Power C GND Logic Ground C GND Logic Ground Humidity Sensor Humidity Sensor O HUM_PWM...
  • Page 147 7. Connection Diagram Oki Data CONFIDENTIAL (2) High-Voltage Power/ Sensor Board TR terminal Component side T1 - 7pin Soldering side Checking contact between the transfer roller shaft and the TR terminal Contact is normal if the resistance value measured between the transfer roller shaft and Pin 7 of T1 is 130 MΩ.
  • Page 148 7. Connection Diagram Oki Data CONFIDENTIAL • CN2 Connector Pin Allocation (Connection to FAN(ID)) Pin No. I/O Signal Function FANPOW FAN Drive Power FANGND Ground FANALM-P FAN Alarm Detection • CN3 Connector Pin Allocation (Connection to Tag) Pin No. I/O...
  • Page 149 7. Connection Diagram Oki Data CONFIDENTIAL (3) Low-Voltage Power CN301 CN201 CN101 A circuit (common to 100V and 200V) for applying a load between +5V and GND to check output by using a low-voltage supply unit alone. CN301 8 or 9 pin , 0.5 W or more...
  • Page 150 7. Connection Diagram Oki Data CONFIDENTIAL • CN101 Connector Pin Allocation (Connection to the AC SW Assy) Pin No. I/O Signal Function AC(LIVE) AC input AC(NEUTRAL) AC input • CN2 Connector Pin Allocation (Connection to the Fuser Unit) Pin No. I/O...

  • Page 151: Resistance Value

    7. Connection Diagram Oki Data CONFIDENTIAL 7.3 Resistance value 7-16 / 44983601TH Rev.1...
  • Page 152 7. Connection Diagram Oki Data CONFIDENTIAL 7-17 / 44983601TH Rev.1...

  • Page 153: Appendix A Centronics Parallel Interface

    Cables compatible with IEEE Std 1284-1994 under 1.8mm (or equivalent product) should be used. (It is recommended to use twisted pair cable with shield for noise control.) Note! The cable is not included in the printer. Moreover, you can not purchase it from the Oki Data Corporation. Appendix A-1 /...
  • Page 154 Appendix A Centronics Parallel Interface Oki Data CONFIDENTIAL (3) List of Parallel I/F Signals Pin No Signal Name Direction Function nStrobe(HostClk) TO PRINTER Pulse to read data. The data is read at the posterior border. DATA 1 TO PRINTER 8-bit parallel data The high level is “1”...
  • Page 155 Appendix A Centronics Parallel Interface Oki Data CONFIDENTIAL (5) Specification Item Contents Mode Compatible mode, Nibble mode, and ECP mode Data Bit Length 8 bit (Compatible mode) Input Prime Enable/ Disable Receive Buffer 8K, 20K, 50k, 100k, 1M Byte Control The handshake control is performed in each mode.
  • Page 156 Appendix A Centronics Parallel Interface Oki Data CONFIDENTIAL C) Data Reception (Menu Setting: Ack/ Busy Timing= Ark in Busy) nStrobe PError nAck (ACK) Menu Setting (Ack Width) NARROW MEDIUM WIDE T (ACK) 0.5 us 1.0 us 3.0 us d) Data Reception (Menu Setting: Ack/ Busy Timing= Ark in Busy)
  • Page 157 Appendix A Centronics Parallel Interface Oki Data CONFIDENTIAL f) Offline Notice for transfer Notice for transfer to the Offline to the Online Printer Idling Offline Online Status Busy PError nFault Select Receive RUNNING PEND RUNNING Receive DMA Completion Receive DMA Restart...
  • Page 158 Appendix A Centronics Parallel Interface Oki Data CONFIDENTIAL (7) Interface Parameter Setting This is a procedure to perform on the operator panel of the printer (B431). In the setting of B401/B411, use "Configuration Tool". By pressing the "OK" key after selecting a display content of the operator panel with the "MENU "...
  • Page 159 Appendix A Centronics Parallel Interface Oki Data CONFIDENTIAL Items ACK width at compatible receiving ACK WIDTH Display Function NARROW Narrow 0.5μs Normal 1.0μs Wide 3.0μs Default Setting: Narrow Press the "MENU " key. Items Output order of BUSY signal and...

  • Page 160: Appendix B Usb Interface

    Appendix B USB Interface Oki Data CONFIDENTIAL Appendix B USB Interface (1) Connector • Printer side : B Receptacle (Female) (Upstream port) Equivalent to UBR24-4K5CO (ACON. Co., Ltd.) • Cable side : B Plug (Male) (2) Cable • Cable with USB 2.0 specification under 2.0m (It is recommended to use a shielded cable.) Note! The cable is not included.
  • Page 161 Appendix B USB Interface Oki Data CONFIDENTIAL (8) Signal Level • Input and Output Level Parameter Signal Minimum Maximum Unit Input level: High (Driven) High (Floating) VIHZ Output level: High (Driven) Output signal crossover voltage VCRS • Signal level Signal Level...

  • Page 162: Appendix C Maintenance Manual For Second Tray Unit

    Appendix C Maintenance Manual for Second Tray unit Oki Data CONFIDENTIAL Appendix C Maintenance Manual for Second Tray unit Overview 1.1 Function The extended paper feed unit is installed under the printer. the device performs the auto paper feed by the operation of the pulse motor (hopping) to control a signal from the printer.

  • Page 163: Description For Operation Of Second Tray Unit

    Appendix C Maintenance Manual for Second Tray unit Oki Data CONFIDENTIAL 2. Description for Operation of Second Tray unit Second Tray unit receives a signal from the printer main body and feeds paper to the printer main body. Paper Feed from the Second Tray unit (Tray2) 1.

  • Page 164: Part Replacement

    Appendix C Maintenance Manual for Second Tray unit Oki Data CONFIDENTIAL 3. Part Replacement This section describes how to disassemble/ assemble/ install in the field. This section describes how to disassemble, however, as for the assembly, take the opposite sequence to the disassembling procedure.
  • Page 165 Appendix C Maintenance Manual for Second Tray unit Oki Data CONFIDENTIAL 3.2 Arrangement of Parts The arrangement of main parts is as shown in the following figure. Figure 3-1 Appendix C-4 / 44983601TH Rev.1...
  • Page 166 Appendix C Maintenance Manual for Second Tray unit Oki Data CONFIDENTIAL 3.3 How to Replace Parts This section describes how to replace parts shown in the following disassembling procedure. In the part replacement procedure, parts on which a part number is displayed in white figure in the black circle are RSPL.

  • Page 167: Roller-Pick-Up, Roller-Feed-Now (3.3.1)

    Appendix C Maintenance Manual for Second Tray unit Oki Data CONFIDENTIAL 3.3.1 Roller-Pick-Up, Roller-Feed-Now (1) Remove Cassette-Assy. (2) Push the tab in the direction of the arrow to remove Roller-Pick-Up (3) Push the tab in the direction of the arrow to remove Roller-Feed-NOW (4) As for reinstalling, take the opposite sequence to removal sequence.

  • Page 168: Guard-Connector, Connector(9715S-08Z02-G4C) (3.3.2)

    Appendix C Maintenance Manual for Second Tray unit Oki Data CONFIDENTIAL 3.3.2 Guard-Connector, Connector (9715S-08Z02-G4C) (1) Remove the two screws Remove the two nuts (2) Disconnect the cable, and remove Guard-Connector and Connector (9715S-08Z02-G4C) (3) Installing is performed by the inverse procedure with removing.

  • Page 169: Board-Gog (3.3.3)

    Appendix C Maintenance Manual for Second Tray unit Oki Data CONFIDENTIAL 3.3.3 Board-GOG (1) Remove the two screws (Black) . Remove the Cover-Rear (2) Remove the two screws (silver) . Remove the Cover-Blind-R (3) Remove the two screws (silver) . Remove the Cover-Blind-L (4) Remove the two screws (silver) .

  • Page 170: Conn Cord-Amp8P-Amp8P (3.3.4)

    Appendix C Maintenance Manual for Second Tray unit Oki Data CONFIDENTIAL 3.3.4 CONN Cord-AMP8P-AMP8P (1) Remove the Guard-Connector . (Refer to 3.3.2) (2) Remove the Cover-Rear, Cover-Blind-R/L, Plate-Top. (Refer to 3.3.3) (3) Remove CONN-Cord-AMP8P-AMP8P from Board-GOG. (4) Installing is performed by the inverse procedure with removing.
  • Page 171 Appendix C Maintenance Manual for Second Tray unit Oki Data CONFIDENTIAL 3.3.5 Gear-Assy-Clatch (Hop, Regist), Motor-Pulse (1) Remove the Cover-Rear, Cover-Blind-R/L, Plate-Top. (Refer to 3.3.3) (2) Remove the two screws (Black) , disengage the two tabs, and remove Cover-Front ①...
  • Page 172 Appendix C Maintenance Manual for Second Tray unit Oki Data CONFIDENTIAL (5) Remove the E-ring , Gear-Assy-Clutch (Hop) and Gear-Assy-Clutch (Regist) (6) Remove the two screws (Silver) . Remove the Motor-Pulse (7) Installing is performed by the inverse procedure with removing.

  • Page 173: Frame-Assy-Retard, Spring-Retard (3.3.6)

    Appendix C Maintenance Manual for Second Tray unit Oki Data CONFIDENTIAL 3.3.6 Frame-Assy-Retard, Spring-Retard (1) Detach Cassette-Assy. (2) Push two tabs in the direction of the arrow to remove Retard-Cover. (3) Push Frame-Assy Retard in the direction of the arrow. (Spring-Retard is also removed together.)
  • Page 174 Appendix C Maintenance Manual for Second Tray unit Oki Data CONFIDENTIAL 4. Cleaning of Paper Feed Roller and Separation Roller Clean the rollers when [392: Paper Jam] often occurs. (1) Pull the paper cassette. (2) Wipe the two feed rollers with a tightly wrung cloth soaked in water through the opening for installation of a paper cassette.

  • Page 175: Procedure For Troubleshooting

    Appendix C Maintenance Manual for Second Tray unit Oki Data CONFIDENTIAL 5. Procedure for Troubleshooting 5.1 Precautions for Troubleshooting (1) Check the basic items to be checked in the user’s manual. (2) Obtain detail information at the failure from customers as much as possible.

  • Page 176: Troubleshooting Method

    Appendix C Maintenance Manual for Second Tray unit Oki Data CONFIDENTIAL 5.3 Troubleshooting Method When trouble occurs in the device, search the trouble with the following steps. Trouble occurs. According to the Perform the Trouble displayed on LCD status detailed search for...

  • Page 177: Lcd Status Message List

    Appendix C Maintenance Manual for Second Tray unit Oki Data CONFIDENTIAL 5.3.1 LCD Status Message List The list of statuses and trouble displayed as the message format in LCD is outlined in Table 5-1. Table 5-1 List of Statuses and Trouble of Second Tray unit...
  • Page 178 Appendix C Maintenance Manual for Second Tray unit Oki Data CONFIDENTIAL • (Jam Error) Paper Feed Jam • Does a jam occur around the entrance when turning on the power? • Yes Is the paper on the entrance sensor lever? •...
  • Page 179 Appendix C Maintenance Manual for Second Tray unit Oki Data CONFIDENTIAL 6. Connection Diagram 6.1 Connection diagram Connection to the printer MAIN1 Entrance sensor SNS12 MOTOR Hopping sensor SNS03 Paper end sensor Feed clutch Regist clutch 6.2 Board Arrangement GOG board...
  • Page 180 Appendix C Maintenance Manual for Second Tray unit Oki Data CONFIDENTIAL •MAIN1 Connector Pin Allocation (Connection to the Main control board) PIN No. I/O Signal Function Analog Ground Motor/ Clutch Drive Power Logic Ground Logic Circuit Power supply OPTSCK-N OPT data output...

  • Page 181: Appendix D Network Interface

    Appendix D Network Interface Oki Data CONFIDENTIAL Appendix D Network Interface 100BASE-TX / 10BASE-T (1) Network protocol TCP/IP: (*: B431 Only) Network rayer ARP, IP, ICMP, IPv6 Transport rayer TCP, UDP Apprication rayer LPR, Port9100, FTP, HTTP, HTTPS*, IPP, SNMPv1/v3,...
  • Page 182 Appendix D Network Interface Oki Data CONFIDENTIAL (3) Conector contact arrengement RJ45 Conector (4) Cable Category5 UTP RJ45 (5) IPv6 Ready Logo (6) Setup Each setting item can be set up by the menu and network administration tool. Operation Panel Display...
  • Page 183 Appendix D Network Interface Oki Data CONFIDENTIAL Operation Panel Display Default Function Items Setting value SUBNET MASK xxx.xxx.xxx.xxx Set the subnet mask. [Display Conditions] • "TCP/IP" is enabled, and "IP VERSION" is IP v4 or IPv4+v6. GATEWAY xxx.xxx.xxx.xxx Set the gateway address.
  • Page 184 Appendix D Network Interface Oki Data CONFIDENTIAL (7) Functions that substitute the network reset button functions Network reset button functions available on B401/B411/B431 can be performed by the following operation. (7-1) Initialization of network functions B431 Initialize network functions from the operator panel.

This manual is also suitable for:

B411l6B401B401dB401dnB411dB411dn
