Sharp HT-M700H Service Manual page 82

HT-M700H
NO. PARTS CODE
[6] COILS
L2C
RBLN-A017SJZZ
L3A
RCILLA014SJZZ
L3B
RCILA011SJZZ
L3C
RBLN-A017SJZZ
L4A
RCILLA014SJZZ
L4B
RCILA009SJZZ
L4C
RBLN-A017SJZZ
L5A
RCILLA014SJZZ
L5B
RCILA010SJZZ
L5C
RBLN-A017SJZZ
L6A
RBLN-A014SJZZ
L6B
RCILA011SJZZ
L6C
RBLN-A017SJZZ
L7A
RBLN-A014SJZZ
L7B
RBLN-A016SJZZ
L8A
RBLN-A014SJZZ
L8B
RBLN-A016SJZZ
L9A
RBLN-A014SJZZ
L9B
RBLN-A017SJZZ
L10A
RBLN-A013SJZZ
L10B
RBLN-A017SJZZ
L11A
RBLN-A013SJZZ
L11B
RBLN-A017SJZZ
L12A
RBLN-A013SJZZ
L12B
RBLN-A017SJZZ
L13A
RBLN-A013SJZZ
L13B
RBLN-A011SJZZ
L14A
RBLN-A013SJZZ
L14B
RBLN-A011SJZZ
L15A
RBLN-A013SJZZ
L15B
RBLN-A011SJZZ
L16A
RBLN-A013SJZZ
L16B
RBLN-A011SJZZ
L17
RBLN-A014SJZZ
L18
RBLN-A014SJZZ
L19
RBLN-A014SJZZ
L20
RBLN-A014SJZZ
L21
RBLN-A014SJZZ
L22
RBLN-A014SJZZ
L301
RBLN-0001SJZZ
L321
VP-DH2R2K0000
L342
VP-DH2R2K0000
L351
VP-DH101K0000
L352
VP-DH101K0000
L353
VP-DH102K0000
L354
RFILL0001SJZZ
L501
VP-DHR22K0000
L502
VP-DHR22K0000
L503
VP-DHR22K0000
L504
VP-DHR22K0000
L701
RCORFA003SJZZ
LFB1
RBLN-A010SJZZ
LFB2
RBLN-A010SJZZ
LFB3
RBLN-A010SJZZ
LFB4
RBLN-A009SJZZ
LFB5
RBLN-A009SJZZ
LFB6
RBLN-A009SJZZ
LFB7
RBLN-A010SJZZ
LL1
RBLN-A012SJZZ
LL3
RBLN-A014SJZZ
LL4
RBLN-A014SJZZ
LL5
RBLN-A014SJZZ
LL7
RBLN-A014SJZZ
[7] VARIABLE RESISTORS
VR
RVR-BA006SJZZ
VR351
RVR-M0026AWZZ
[8] VARIABLE CAPACITOR
VD301
VHCSVC348S/-1
[9] VIBRATORS
X321
RCRSP0005SJZZ
X351
RCRM-0007SJZZ
X352
RCRSP0006SJZZ
X701
RCRSPA007SJZZ
X702
RCRM-0008SJZZ
Y1
RCRSPA010SJZZ
PRICE NEW PART
RANK MARK RANK
22 µ H
N
2.4 µ H
N
10 µ H
N
22 µ H
N
2.4 µ H
N
6.2 µ H
N
22 µ H
N
2.4 µ H
N
6.2 µ H
N
22 µ H
N
N
60 ohms.25%
10 µ H
N
22 µ H
N
N
60 ohms.25%
15 µ H
N
N
60 ohms.25%
15 µ H
N
N
60 ohms.25%
22 µ H
N
N
60 ohms.25%
22 µ H
N
N
60 ohms.25%
22 µ H
N
N
60 ohms.25%
22 µ H
N
N
60 ohms.25%
N
600 ohms,100 MHz,25%
N
60 ohms.25%
N
600 ohms,100 MHz,25%
N
60 ohms.25%
N
600 ohms,100 MHz,25%
N
60 ohms.25%
N
600 ohms,100 MHz,25%
N
60 ohms.25%
N
60 ohms.25%
N
60 ohms.25%
N
60 ohms.25%
N
60 ohms.25%
N
60 ohms.25%
AE
Balun
2.2 µ H,Peaking
AB
2.2 µ H,Peaking
AB
100 µ H,Choke
AB
100 µ H,Choke
AB
AB
1 mH,Choke
AF
Low Pass Filter
0.22 µ H
AB
0.22 µ H
AB
0.22 µ H
AB
0.22 µ H
AB
AB
Core
N
300 ohms,100 MHz,25%
N
300 ohms,100 MHz,25%
N
300 ohms,100 MHz,25%
N
100 ohm,100 MHz,25%
N
100 ohm,100 MHz,25%
N
100 ohm,100 MHz,25%
N
300 ohms,100 MHz,25%
N
120 ohms,25%
N
60 ohms,25%
N
60 ohms,25%
N
60 ohms,25%
N
60 ohms,25%
N
Rheostat,200 ohms
AC
10 kohm (B),Semi-VR [VCO]
AK
Variable Capacitance,SVC348S
AF
Crystal,456 kHz
AG
Ceramic,456 kHz
AF
Crystal,4.5 MHz
AE
Crystal,32.768 kHz
AG
Ceramic,8 MHz
AE
Crystal,27 MHz
4
DESCRIPTION
