  • Page 1 OWNER’S MANUAL...

  • Page 2: Safety Information

    Ÿ The safety, stability and handling of this motorcycle may be adversely affected by the addition of accessories or luggage. Ÿ Do not install accessory or replacement parts not approved by sym. Ÿ Failure to follow these warnings could lead to an accident, serious injuries or death.
  • Page 3 4. SAFETY DEFECT REPORT SANYANG INDUSTRY CO., Ltd. NO. 3,chung-Hua Road Hukou Shiang Hsin-Chu County, 303 Taiwan, R.O.C Reporting Safety Defects If you believe that your vehicle has a defect which could cause a crash or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Sanyang Industry Co., Ltd.

  • Page 4: Table Of Contents

    Content/ Subject 1. Contents ........................1 2. Control location ......................3 3. Before riding ........................8 4. Safety riding ........................8 5. Driving ..........................9 6. Use genuine spare parts ....................9 7. Use of each component ....................10 Gauges ........................10 Operation of ignition switch ..................
  • Page 5 Checking the brake light ....................26 Checking for fuel leakage .................... 26 Checking the lubrication of body’s various mechanisms ..........26 Checking the spark plug ....................27 Checking the air cleaner ....................27 11. When there is an abnormal condition or a trouble ............28 Diagnosis when engine does not start .................

  • Page 6: Control Location

    MODE： JET 50/100 SERIES (BL05WA-6) Light / Starter switch Fuel tank cap Rear turn signal Front turn signal Seat lock Rear turn signal Helmet hook High & Low beam / Turn signal / Horn switch Fuses / C.D.I. / Eng. Oil tank cap Frame number Tail light Head light...
  • Page 7 MODE： BL05W6-A SERIES Light / Starter switch Fuel tank cap Head light Seat lock Helmet hook High & Low beam / Turn signal / Horn switch Fuses / C.D.I. / Front turn signal Eng. Oil tank cap Frame number Tail light Storage box Air cleaner Ignition switch...
  • Page 8 MODE： MASK SERIES (BF05W) Light / Starter switch Fuel tank cap Front turn signal Helmet hook High & Low beam / Turn signal / Horn switch Frame number Fuses / C.D.I. / Eng. Oil tank cap Seat lock Tail light Rear turn signal Head light Storage box...
  • Page 9 MODE： BS05W SERIES Light / Starter switch Front turn signal Fuel tank cap Helmet hook High & Low beam / Turn signal / Horn switch Fuses / C.D.I. / Eng. Oil tank cap Frame number Tail light Head light Seat lock Storage box Air cleaner Ignition switch...
  • Page 10 MODE： Jet SportX 50 SERIES (BK05W) ENG. Stop / Starter switch High & Low beam / Turn signal / Horn switch Fuses / C.D.I. / Eng. Oil tank cap Frame number Head light Tail light Seat lock Storage box Air cleaner Fuel tank cap Ignition switch Rear turn signal...

  • Page 11: Before Riding

    This manual describes the correct usage of this scooter including safety riding, simple inspection methods and so on. For a more comfortable and safety riding, please read this manual carefully. Thank you very much for your patronage In order to maximize your scooter’s performance, a periodical inspection and maintenance should be completely carried out.

  • Page 12: Driving

    Also, it may result in unexpected troubles and lower the scooter’s performance. Ÿ Always use SYM Genuine Spare Parts to keep your scooters pure blood and to ensure its long service life. 5. Driving...

  • Page 13: Use Of Each Component

    Gauges Speedometer Model : JET SERIES Fuel Gauge Odometer Turn Signal Indicator Turn Signal Indicator Engine Oil Warning Light High Bean Indicator Model : MASK SERIES High Bean Indicator Speedometer Turn Signal Indicator Odometer Engine Oil Warning Light Fuel Gauge 7.
  • Page 14 Model : BS05W SERIES Fuel Gauge Speedometer Odometer Engine Oil Warning Light Turn Signal Indicator High Bean Indicator Model : BL05W6-A / G100P2 SERIES Clock Odometer Fuel Gauge Speedometer Turn Signal Indicator Turn Signal Indicator High Bean Indicator Engine Oil Warning Light Model : BK05W-6 SERIES Fuel Gauge Speedometer...
  • Page 15 Use only 2-cycle engine oil meeting Japanese Automobile Standard Organization FC specifications. Otherwise, this company will not assume any responsibility for damages resulted from using substandard engine oil. ※ Recommended oil: SYM EXTRA 2X oil. 5. Speedometer This shows your speed in kilometers per hour CAUTION: (km/h) and in mileage per hour (mph).

  • Page 16: Operation Of Ignition Switch

    OPERATION OF IGNITION SWITCH “ON” position IGNITION SWITCH Ÿ Engine can be started in this position. Ÿ Ignition switch key can not be removed. “OFF” position Ÿ Engine is shut off and can not be started in this position. Ÿ Ignition switch key can be removed.

  • Page 17: Use Of Buttons

    USE OF BUTTONS High / Low Turn Signal Switch l Light Switches (If installed) Beam Switch When the switch is turned to this position, headlight, rear light, instrument panel light, and position light will go on. When the switch is turned to this position, rear light, instrument panel light, and position Horn Switch light will go on.

  • Page 18: Saddle Lock

    l High/Low Beam Switch (If installed) This is the high and low beam of headlight switching switch. Press this switch to switch between high and low beams. This is for high beam. This is for low beam. (Please turn to low beam when riding in city) l...

  • Page 19: Storage Box

    STORAGE BOX w This box is located under the saddle. w Maximum load capacity: 10kg. w Do not store valuables in the box. w Please make sure that seat cushion had been locked completely after it was down. Take out valuables before washing to avoid wetting these objects.

  • Page 20: Parking Method

    PARKING METHOD l When approaching the parking lot: 1. Turn on the turn signal light early, and pay attention to the vehicles in front, from rear, left and right, then take the inner lane and approach slowly. 2. Return the throttle valve handle back to its original position, and apply brakes in advance. (Brake light comes on when braking to warn drivers of vehicles behind.) l...

  • Page 21: Important Points And Cautions For Starting Engine

    CAUTION: Ÿ Please check the engine oil and fuel volume are adequate or not before starting engine. Ÿ To start engine the main parking stand must be firmly on the ground and the brake is applied on the rear wheel to prevent the scooter from moving forward suddenly. 1.

  • Page 22: The Best Way To Drive Off

    CAUTION: Ÿ If any problem founded during routine inspection, correct the problem before using the scooter again, have your scooter checked and repaired by the “SYM dealer or authorized service personnel” if necessary. 9. The best way to drive off...

  • Page 23: Inspection And Replenishment Of Engine Oil

    Otherwise, this company will not assume any responsibility for damages resulted from using substandard engine oil. ※Recommended oil: SYM EXTRA 2X oil. Replenishment: 1. Using the main stand to support the vehicle on a level ground, lift up the saddle, and remove the oil tank cover.

  • Page 24: Transmission Oil Inspection And Change

    Install the drain bolt and tighten it. Fill new transmission oil (100~110 c.c.), and install the infusion bolt and tighten it. (make sure that bolts are tightened and check that there’s no leakage.) ※ Recommend Oil: Genuine SYM HYPOID GEAR OIL (SAE 85W-140). Use SAE85-90 when outside temperature is below 0℃.

  • Page 25: Disc Brake Inspection [Depending On Models]

    Ÿ Visual Inspection for leakage or damage. If Park the scooter on a level ground, and check there is any, take your scooter to SYM if fluid level is under the “LOWER” mark. Authorized Dealer or Franchised Dealer for a Recommended Brake Fluid: WELL RUN check or repair.

  • Page 26: Throttle Valve Handle Clearance Adjustment

    Ÿ This scooter is equipped with a maintenance-free type battery, so it is unnecessary to check and add electrolyte. Have your scooter checked by SYM Authorized Dealer or Franchised Dealer should any abnormality is found. Remove the battery terminals and clean if there are dirt and corrosion on them.

  • Page 27: Tire Inspection

    CAUTION: Ÿ This is a closed type battery. Never remove the caps. Ÿ In order to prevent electric leakage and self-discharge when the battery sits idle for long periods. Remove battery from scooter, store it in a well- ventilated and dimly lighted place after the battery has been fully charged.

  • Page 28: Steering Handle Front Shock Absorbers Inspection

    Check steering handle if it is being pulled too tight by the brake cables. Ÿ Take your scooter to SYM Authorized Dealer or Franchised Dealer for a check or adjustment if any abnormal conditions are found. 【Figures on the right are for operation checks only】...

  • Page 29: Checking The Turn Signal Lights And Horn

    CHECKING THE TURN SIGNAL LIGHTS AND HORN Ÿ Turn the ignition switch key to “ON” position. Ÿ Turn on the turn signal light switch, and make sure that the front & rear and left & right signal lights flashes and also check if the warning buzzer sounds. Ÿ...

  • Page 30: Checking The Spark Plug

    CHECKING THE SPARK PLUG Ÿ Remove the cap of high tension cable. (Use a plug wrench in tool box to remove the spark plug by turning it counterclockwise.) Ÿ Check the electrode if it is dirty or fouled by carbon deposits. Ÿ...

  • Page 31: When There Is An Abnormal Condition Or A Trouble

    The fuse may blow if horn not sounding. 【Please go to SYM authorized dealer or franchised dealer immediately if there are no problems on above conditions and engine still can not be started.】 11.when there is an abnormal condition or a trouble...

  • Page 32: Periodical Maintenance Schedule

    The above maintenance schedule is established by taking the monthly 1,000 kilometers as a reference which ever comes first. ¯ Have your scooter checked and adjusted periodically by your SYM Authorized Dealer or Franchised Dealer to maintain the scooter at the optimum condition. Code: I ~ Inspection, cleaning, and adjustment R ~ Replacement...

  • Page 33: Specification

    Model JET Euro50 JET 50α RED DEVIL50 BL05WA BL05W6 Item Specification Length ( mm) 1,785 Width ( mm) Height ( mm) 1,125 1,115 Wheel base ( mm) 1,275 Net Weight 94 kg maximum load 277Kg (610.7lb) Type 2- stroke single cylinders engine Fuel Unleaded gasoline (octane 90 or higher) Cooling type...
  • Page 34 Model MASK 50 JET Sport X 50 RS 50 G100-P2 BK05W BS05W BF05W Item Specification Length (mm) 1,840 1,835 1,870 1,785 Width (mm) Height (mm) 1,120 1,110 1,130 1,125 Wheel base (mm) 1,275 1,280 1,335 1,275 Net Weight 98 kg 94 kg 108 kg 97 kg...

  • Page 35: Postscript

    FUNCTION： Set time in 12 hour mode There are three buttons on the speedometer, explanation as below : 1. SET button “S”: a. Under TRIP mode, press “S” button continuously to reset the TRIP kilometer readings. b. Under ODO mode and the vehicle is standing still, press SET for above 2 seconds to enter CLOCK mode.
