Model AD2083-02C
AD RS-422 Distributor
Installation and Operation Instructions
SpeedDome LT, SpeedDome, SpeedDome Ultra,
SpeedDome Optima, and SpeedDome Optima LT
The AD2083-02C Distributor is used to interface American Dynamics' Switching Systems with
SpeedDomes, SpeedDome LTs, SpeedDome Ultras, SpeedDome Optimas, and SpeedDome Optima LTs.
Part Number 8200-0634-00 A0
