FEATURES
•
Improved legacy RS-422
domes support, including
simplex RS-422
•
Cost-effective RS-422
distribution
•
Sixteen RS-422
connections
•
Daisy-chain of up to ten
domes per connection
•
Provides pan, tilt and
zoom control for
SpeedDome Ultra,
SpeedDome Optima,
SpeedDome Optima LT
Series domes
•
Quick-connect screw
terminals for all cable
connections
•
Universal wall, rack and
surface mounting
•
Diagnostic LEDs
•
Interfaces to both
American Dynamics
High Speed Data Line
and Manchester code-
based systems
•
Relays alarms from
domes/receivers to
American Dynamics
Matrix Switchers
•
Form C relay output
AD2083-02C
AMERICAN DYNAMICS RS-422 DISTRIBUTOR
The AD2083-02C Series provides economical
distribution of American Dynamics RS-422
code to the SpeedDome ®
Optima Series domes.
Using the AD2083-02C Distributor,
multiple dome sites can be driven from the
powerful family of American Dynamics Matrix
Switcher/Controller Systems.
The AD2083-02C outputs commands for pan,
tilt, focus, iris, zoom, preset and pattern
control. It can also receive alarm information
from SpeedDome Ultra Series domes and relay
it to an American Dynamics Matrix System. In
addition, an alarm from any of the domes
activates a Form C relay.
Quick-connect screw terminals and diagnostic
LEDs facilitate efficient installation and
service. The universal mount enables mounting
to the front or rear of equipment racks, or flat
on a wall or horizontal surface.
Supports presets stored in the dome and
simplex RS-422 for the Speed Dome Optima LT
or situations where the data return line is not
available such as fiber optics or microwave links.
