A Before you start, you should prepare the following items:
One Windows-based PC with print server setup CD
One printer
One printer cable
One HUB
B Wired Network with Print Server:
Printer
C Hardware Installation:
1 Turn off the printer's power.
2 Connect the print server to your printer with the supplied printer cable.
3 Turn the printer's power on.
4 Plug the AC power adapter into the power connector on the print server.
5 Wait 10 seconds as part of the print server's Power On Self Test (POST).
D Software Installation:
1 To enable network communication with print server, your computer must have a
proper IP address, e.g. 192.168.0.100. If you need an instruction to configure the
IP address of your computer, please refer to the Appendix of this Quick
Installation Guide.
Print Server
Computer
HUB
Computer
1
Computer
