Quick Installation Guide

TL-WPS510U
Pocket-sized Wireless Print Server
Rev: 1.0.2
7106500731

Advertisement

Table of Contents
loading

Related Manuals for TP-Link tl-wps510u

Summary of Contents for TP-Link tl-wps510u

  • Page 1: Quick Installation Guide

    Quick Installation Guide TL-WPS510U Pocket-sized Wireless Print Server Rev: 1.0.2 7106500731...

  • Page 2: Factory Default Settings

    1 Before you start, you should prepare the following items Windows 2000/XP/2003/Vista computer with print server setup CD USB Printer(non-GDI/CAPT) USB Printer cable One 802.11b/g Access Point (optional) 2 Factory Default Settings Username: admin Password: 0000 Wireless Mode: Ad-Hoc (Peer-to-Peer) Channel: 1 SSID: WLAN-PS IP Address: 192.168.0.10...
  • Page 3 Step 2 select and double-click Networking Connections. Step 3 Right Click Wireless Connection, select and click Properties. Step 4 Select Internet Protocol (TCP/IP), then double click it or click Properties.
  • Page 4 Step 5.Select “Use the following IP address” and input the static IP address, e.g.192.168.0.101，Subnet mask: 255.255.255.0; Step 6 Find the SSID （WLAN-PS）of wireless print server by Windows Zero Configuration or vendor utility of wireless adapter. Then click Connect.

  • Page 5: For Windows Vista

    For Windows Vista: Step 1 On the Windows taskbar, click the Start, then select Control Panel; Step 2 Select Classic View on the left side then double-click Networking and Sharing center; Step 3 Click Manage network connections on the left side;...
  • Page 6 Step 4 Right click on Wireless Network Connection and select Properties; Step 5 Highlight the Internet Protocol Version 4(TCP/IPv4) and select Properties; Step 6 Select “Use the following IP address” and input the static IP address, e.g.192.168.0.101,Subnet mask: 255.255.255.0, then click OK.
  • Page 7 Step 7 Go back to Network and Sharing Center, then click Manage network connections. Step 8 Right click on Wireless Network Connection and select Connect/ Disconnect;...

  • Page 8: Software Installation

    WLAN-PS, then double click it or click Connect. 5 Software Installation 1) Insert the setup CD into your CD-drive. The auto-run program will be started. 2) Choose TL-WPS510U to begin the setup. 3) Choose Setup Wizard to install the print server and configure the connected printer.
  • Page 9 4) Click Next, the wizard will automatically discover the print server. 5) From the Select A Print Server screen, select the print server that you want to configure and click Next.
  • Page 10 6) On the Change Settings screen, select Yes or No: a) Click Yes if you want to change wireless settings or assign a static IP address to the print server, the default password is 0000 On the Basic Wireless Settings screen, select Communication Type according to your network:...
  • Page 11 Infrastructure mode Ad-Hoc Enter the proper SSID of your wireless network, e.g. the SSID of your wireless router or access point; Channel: optional Data Transmit Rates: select Auto or others Transmit Mode: select Auto or others...
  • Page 12 If you have wireless security on your wireless network, please set the correct Authentication type, then configure it according to your wireless network and click Next. On the TCP/IP Settings screen, specify a fixed or dynamic IP address for the print server, a fixed IP address is highly recommended. Click Next.
  • Page 13 Note: The IP address of print server must be within the same subnet as your network adapter. e.g. Wireless Router or Access Point (192.168.0.1) Wireless Printer Server (192.168.0.10) PC\Laptop (192.168.0.101) b) If you click No on the “Change Settings” page, the printer server will keep using the default IP address and the default settings: Username: admin Encryption: none...
  • Page 14 8) Click Add New Printer to launch Windows Add Printer Wizard. 9) Click Next and select Local Printer, make sure the Automatically detect and install my Plug and Play printer check box is NOT checked. Then click Next.
  • Page 15 10) Make sure the Use the following port radio-button is clicked and select LPT1: (Recommended Printer Port) from the pull-down list. Then click Next. 11) Select Manufacturer and Printer from the lists of printer’s driver. Then click Next.
  • Page 16 12) If you already have the printer’s driver installed, you will be asked whether to keep it or to replace it. Click Next. Supply a name for the printer and choose whether you want to make it your default printer. Then click Next. 13) Then, choose whether you want to share the printer with other network users, print a test page (please select No.), etc.
  • Page 17 newly installed printer. 16) Right-click, select Properties Ports and verify that the print server’s port appears. 17) Go to General; click Print Test Page to verify the configuration. 18) Done.
  • Page 18 Note: If you wish to install more print servers, start setup wizard from your Windows Start menu: start All Programs Network Print Server Standard TCP/IP Printer Port PSWizard and repeat the installation procedure. How to create print server port manually? 1.
  • Page 19 Specifications are subject to change without notice. is a registered trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks of their respective holders. No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD.
