Description
DC bus
PE1
connection
C / L+
D / L -
PE1
Fig. 1.2 Block diagram, type of construction M
1-4
Terminal strip
Option boards
in the elec-
tronics box
Master
Fusing and
DC link
Slave
Fusing and
DC link
CU P
Inverter with
CU and PMU
Inverter with
CU and PMU
SIMOVERT MASTER DRIVES
Connector for OP1
PE2
PE2
Siemens AG 6SE7087-6BM70
Operating Instructions
08.96
Motor
connection
U2/T1
V2/T2
W2/T3
