- Page 1 INSTRUCTION MANUAL Automatic Blood Pressure Monitor with ComFit ™ Cuff BP755 Model...
-
Page 2: Table Of Contents
Before Using the Monitor Introduction ......... . .3 Safety Information . -
Page 3: Introduction
DATE PURCHASED: __________________ SERIAL NUMBER: ____________________ Staple your purchase receipt here Your new digital blood pressure monitor uses the oscillometric method of blood pressure measurement. This means the monitor detects your blood’s movement through your brachial artery and converts the movements into a digital reading. -
Page 4: Safety Information
SAFETY INFORMATION To assure the correct use of the product, basic safety measures should always be followed including the warnings and cautions listed in this instruction manual. SAFETY SYMBOLS USED IN THIS INSTRUCTION MANUAL WARNING CAUTION OPERATING THE DEVICE Contact your physician for specific information about your blood pressure. -
Page 5: Risk Of Electrical Shock
SAFETY INFORMATION OPERATING THE DEVICE (continued) This device is intended for use in measuring blood pressure and pulse rate in the adult population. Do not use this device on infants or persons who cannot express their intentions. Read the Special Conditions section (page 24) of the instruction manual if your systolic pressure is known to be more than 220 mmHg. -
Page 6: Care And Maintenance
SAFETY INFORMATION CARE AND MAINTENANCE Do not subject the monitor to strong shocks, such as dropping the unit on the floor. Do not submerge the device or any of the components in water. Store the device and the components in a clean, safe location. Changes or modification not approved by the manufacturer will void the user warranty. -
Page 7: Before Taking A Measurement
BEFORE TAKING A MEASUREMENT To ensure a reliable reading follow these recommendations: 1. Avoid eating, drinking alcohol, smoking, exercising, and bathing for 30 minutes before taking a measurement. Rest for at least 15 minutes before taking the measurement. 2. Stress raises blood pressure. Avoid taking measurements during stressful times. -
Page 8: Operating Instructions
Air Plug (Connects to Air Jack) Arm Cuff Housing Cord AC Adapter Display Start/Stop Button Air Jack Air Tube INSTRUCTION MANUAL Automatic Blood Pressure Monitor with ComFit ™ Cuff BP755 Model Instruction Manual Battery Compartment AC Adapter Jack Storage Case Quick Start Guide... -
Page 9: Unit Display
Systolic Blood Pressure Diastolic Blood Pressure Memory Symbol Average Value Symbol Movement Error Symbol Battery Low Indicator UNIT DISPLAY Irregular Heartbeat Symbol Heartbeat Symbol/ Hypertension Indicator Pulse Display Deflation Symbol Date/Time Display... -
Page 10: Display Symbols
DISPLAY SYMBOLS IRREGULAR HEARTBEAT SYMBOL ( When the monitor detects an irregular rhythm two or more times during the measurement, the Irregular Heartbeat Symbol ( the display with the measurement values. An irregular heartbeat rhythm is defined as a rhythm that is more than 25% slower or 25% faster from the average rhythm detected while the monitor is measuring the systolic and diastolic... -
Page 11: Heartbeat Symbol/Hypertension Indicator
DISPLAY SYMBOLS HEARTBEAT SYMBOL/HYPERTENSION INDICATOR ( TAKING A MEASUREMENT The Heartbeat Symbol ( measurement. The Heartbeat Symbol ( heartbeat. When the measurement is complete, the Heartbeat Symbol ( flashes on the display with your blood pressure and pulse rate if the reading is above 135 for the Systolic Blood Pressure value and/or above 85 for the Diastolic Blood Pressure value. - Page 12 Contact your physician for specific information about your blood pressure. Self-diagnosis and treatment using measured results may be dangerous. Follow the instructions of your physician or licensed healthcare provider. Omron Healthcare recommends you contact your physician if the Heartbeat Symbol ( values. American Heart Association Scientific Statement 2004...
-
Page 13: Using The Ac Adapter
USING THE AC ADAPTER IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, CAREFULLY FOLLOW THESE INSTRUCTIONS. For connection to a power supply not in the U.S.A., use an attachment plug adapter of the proper configuration for the power outlet. - Page 14 USING THE AC ADAPTER To connect the AC Adapter Insert the AC Adapter Plug into the AC Adapter Jack on the back side of the monitor as illustrated. Plug the AC Adapter into a 120V AC outlet (60 cycles). To disconnect the AC Adapter Hold and pull the housing to remove the AC Adapter from the electrical outlet.
-
Page 15: Battery Installation
BATTERY INSTALLATION NOTE: Use 4 new “AA” size batteries - long life alkaline batteries are recommended. 1. Press the indicator on the battery cover and slide the cover off in the direction of the arrow. 2. Install 4 “AA” size batteries so the + (positive) and - (negative) polarities match the polarities of the battery compartment as indicated. - Page 16 BATTERY INSTALLATION BATTERY REPLACEMENT Low Battery Indicator When the Low Battery Indicator appears on the display screen, turn the monitor off and remove all the batteries. Replace with four new batteries at the same time. Long-life alkaline batteries are recommended. WARNING If battery fluid should get in your eyes, immediately rinse with plenty of clean water.
-
Page 17: Setting The Date And Time
SETTING THE DATE AND TIME Set the monitor to the current date and time before taking a measurement for the first time. If the current date and time are not set correctly, the measurement values stored in the memory and the average values may not be correct. - Page 18 SETTING THE DATE AND TIME 3. SETTING THE MONTH Press the Memory Up button of one month. Press the Date/Time Setting button ( the current month. The day flashes on the display. 4. SETTING THE DAY Press the Memory Up button by increments of one day.
- Page 19 SETTING THE DATE AND TIME 6. SETTING THE MINUTE Press the Memory Up button of one minute. Press the Date/Time Setting button ( The year flashes on the display. 7. TO TURN THE MONITOR OFF Press the START/STOP button. NOTE: The monitor will automatically turn off after the minute has been set after battery replacement.
-
Page 20: Applying The Arm Cuff
APPLYING THE ARM CUFF CAUTION Read all of the information in the instruction manual and any other literature in the box before operating the unit. CAUTION This device is intended for use in measuring blood pressure and pulse rate in the adult population. Do not use this device on infants or persons who cannot express their intentions. - Page 21 APPLYING THE ARM CUFF 3. Hold the thumb grip on the cuff securely with your hand. 4. Turn the palm of your hand upward. 5. Apply the cuff to your left upper arm so the blue stripe is on the inside of your arm and aligned with your middle finger.
- Page 22 APPLYING THE ARM CUFF 6. Wrap the cuff firmly in place around your arm using the cloth fastening. APPLYING THE CUFF ON THE RIGHT ARM When taking a measurement using the right arm use this instruction for Step 5. Apply the cuff to your right upper arm so the thumb grip is centered on the inside of your inner arm.
-
Page 23: Taking A Measurement
TAKING A MEASUREMENT The monitor automatically determines your ideal inflation level. In rare circumstances when a higher inflation may be necessary, the monitor automatically re-inflates the cuff up to 30mmHg higher than the initial inflation and restarts the measurement. 1. Sit on a chair with your feet flat on the floor. Place your arm on a table so the cuff is level with your heart. - Page 24 TAKING A MEASUREMENT 2. Press the START/STOP button. All display symbols appear on the screen. The cuff starts to inflate automatically. As the cuff inflates, the monitor automatically determines your ideal inflation level. Remain still and do not move your arm until the entire measurement process is completed.
-
Page 25: Special Conditions
TAKING A MEASUREMENT 4. When the measurement is complete, the arm cuff completely deflates. Your blood pressure and pulse rate are displayed. 5. Press the START/STOP button to turn the monitor off. NOTE: The monitor will automatically turn off after five minutes. SPECIAL CONDITIONS CAUTION Inflating to a higher pressure than necessary may result in bruising... -
Page 26: Using The Memory Function
USING THE MEMORY FUNCTION Every time you complete a measurement the monitor stores the blood pressure and pulse rate in the memory. The monitor automatically stores up to 90 sets of measurement values (blood pressure and pulse rate). When 90 sets of measurement values are stored, the oldest record is deleted to save the most recent values. - Page 27 USING THE MEMORY FUNCTION 2. Press the Memory Down button set of measurement values on the screen. Press the Memory Up button measurement values. NOTES: • The date and time are alternately displayed with the measurement values. • Press the button repeatedly to display the next values. •...
- Page 28 USING THE MEMORY FUNCTION TO DELETE ALL VALUES STORED IN THE MEMORY You cannot partially delete values stored in the memory. All values will be deleted. 1. While holding the Memory Down button START/STOP button down for more than 2 seconds until the display appears as it does in the following illustration.
-
Page 29: Care And Maintenance
CARE AND MAINTENANCE To keep your digital blood pressure monitor in the best condition and protect the unit from damage, follow the directions listed below: Keep the monitor in the storage case when not in use. Make sure the AC Adapter is placed under the main unit so that is does not damage the display. - Page 30 CARE AND MAINTENANCE Use the unit in a manner consistent with the instructions provided in this manual. CAUTION Use only Omron authorized parts and accessories. Parts and accessories not approved for use with the device may damage the unit. CAUTION Changes or modification not approved by the manufacturer will void the user warranty.
-
Page 31: Error Indicators And Troubleshooting Tips
ERROR INDICATORS AND TROUBLESHOOTING TIPS SYMBOL CAUSE Monitor could not detect pulse wave. Cuff under-inflated. Cuff not applied correctly. Cuff over-inflated. Batteries are worn. CORRECTION Take another measurement and remain still until the measurement is complete. Remove the arm cuff. Read “Taking a Measurement”. - Page 32 ERROR INDICATORS AND TROUBLESHOOTING TIPS PROBLEM No power. No display appears on the unit. Measurement values appear too high or too low. CAUSES AND SOLUTIONS Replace all four batteries with new ones. Check the battery installation for proper placement of the battery polarities.
-
Page 33: Fcc Statement
FCC STATEMENT Note: POTENTIAL FOR RADIO/TELEVISION INTERFERENCE (for U.S.A. only) This product has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 34: Warranty
Your BP755 IntelliSense® Automatic Blood Pressure Monitor, excluding the arm cuff, is warranted to be free from defects in materials and workmanship appearing within 5 years from the date of purchase, when used in accordance with the instructions provided with the monitor. -
Page 35: Specifications
Model: Display: Measurement Range: Accuracy/Calibration: Inflation: Deflation: Rapid Air Release: Pressure Detection: Measurement Method: Pulse Wave Detection: Power Source: Battery Life: Operating Temperature /Humidity: Storage Temperature /Humidity/Air Pressure: Main Unit Weight: Main Unit Dimensions: Cuff Size: Cuff Circumference: Memory: Contents: NOTE: These specifications are subject to change without notice. - Page 36 Manufactured by OMRON HEALTHCARE Made in China Distributed by: OMRON HEALTHCARE, INC. 1200 Lakeside Drive Bannockburn, Illinois 60015 www.omronhealthcare.com Copyright © 2009 Omron Healthcare, Inc.
