- Page 1 User’ s Guide MADE IN Shop online at omega.com e-mail: info@omega.com For latest product manuals: omegamanual.info FPU500 OMEGAFLEX Peristaltic Pump ®...
- Page 2 OMEGAnet ® omega.com U.S.A.: One Omega Drive, Box 4047 ISO 9001 Certified Stamford, CT 06907-0047 Tel: (203) 359-1660 e-mail: info@omega.com Canada: 976 Bergar Laval (Quebec) H7L 5A1, Canada Tel: (514) 856-6928 e-mail: info@omega.ca For immediate technical or application assistance: U.S.A. and Canada: Sales Service: 1-800-826-6342 / 1-800-TC-OMEGA Customer Service: 1-800-622-2378 / 1-800-622-BEST Engineering Service: 1-800-872-9436 / 1-800-USA-WHEN...
-
Page 3: Unpacking Instructions
Remove the Packing List and verify that you have received all equipment, including the following (quantities in parentheses): Peristaltic Pump (1) Mounting Screws * (2) Operator’s Manual (1) *Long Mounting Screws (2) Optional If you have any questions about the shipment, please call the Customer Service Department. -
Page 4: Table Of Contents
TABLE OF Peristaltic Pump CONTENTS Unpacking Instructions ... i Chapter 1 Introduction ... 1-1 Description ... 1-1 Features ... 1-1 Chapter 2 Parts of the Pump ... 2-1 Overall View of the Pump ... 2-1 Left Side of the Pump ... 2-2 Right Side of the Pump ... - Page 5 Index Adapter Plate ... 3-6 Adapter Plate Specifications ... 3-8 Clamp Screw Adjustment ... 5-5 Creeping of Tubing ... 5-5 Flow Rates ... 1-1 Mounting Screw Types ... 3-1 Pump Attaching ... One pump to the Motor ... 3-2 One pump to an Adapter Plate ... 3-6 (Stacking) More than Two Pumps ...
- Page 6 Index Notes...
-
Page 7: Chapter 1 Introduction
Introduction 1.1 Description The peristaltic pump offers exceptional simplicity, ease-of- use, and variable flow capacity. The pump is self-priming and non-siphoning. It prevents back flow since one of the three rollers is always compressing the tubing. As one section of a tube fatigues, simply move the tube along to an unused section and continue pumping. - Page 8 Introduction Notes...
-
Page 9: Chapter 2 Parts Of The Pump
Parts of the Pump 2.1 Overall View of the Pump Item Description Stator Latch Clamp Plate Clamp Screw Rotor Shaft Mounting Holes Lower Shield Base Mounting Screws Tubing Figure 2-1. Overall View Function Fixed surface for tubing compression Used to open and close the Stator Secures the tubing during pump operation Adjusts the tubing clamp position Main drive shaft for the pump... -
Page 10: Left Side Of The Pump
Parts of the Pump 2.2 Left Side of the Pump Item Description Stator Latch Clamp Screw Rotor Shaft Lower Shield Base Figure 2-2. View of the Left Side Function Fixed surface for tubing compression Used to open and close the stator Adjusts the tubing clamp position Main drive shaft for the pump Shields the tubing, supports the Rotor Assembly... -
Page 11: Right Side Of The Pump
2.3 Right Side of the Pump Item Description Clamp Plate Clamp Screw Rotor Shaft Lower Shield Base Figure 2-3. View of the Right Side Function Secures the tubing during pump operation Adjusts the tubing clamp position Main drive shaft for the pump Shields the tubing, supports the Rotor Assembly Mounting surface to attach the pump to the motor, supports the Rotor Assembly... - Page 12 Parts of the Pump Notes...
-
Page 13: Chapter 3 Setting Up The Pump(S)
Setting Up the Pump(s) 3.1 Introduction To attach a single pump directly to a pump motor, follow the procedure in Section 3.3.1. To stack two pumps to a motor, follow the procedure in Section 3.3.2. To attach the pump to an adapter plate (for your own motor), follow the procedure in Section 3.3.3. -
Page 14: Attaching The Pump
Setting Up the Pump(s) 3.3 Attaching the Pump 3.3.1 Attaching a Single Pump Directly to the Motor Refer to Figures 3-1 through 3-4 and Figure A. Figure 3-1. Pump in Closed Position Figure 3-3. Aligning the Pins and Holes TOP ALIGNMENT FACE OF MOTOR BOTTOM... - Page 15 Refer to Figure 3-1. Make sure the pump is in the closed position. Refer to Figure 3-2 and Figure A. Place the blade of a flathead screwdriver in the groove of the Rotor Shaft (5). Rotate the Rotor Shaft until its back tab slips into the groove of the motor shaft. Do not try to force the pump onto the motor until you perform Step Refer to Figure 3-3 and Figure A.
-
Page 16: Stacking Two Pumps Onto One Motor
Setting Up the Pump(s) 3.3.2 Stacking Two Pumps onto One Motor Refer to Figures 3-5 through 3-7 and Figure B. FACE OF MOTOR FIRST PUMP SECOND PUMP Figure 3-5. Placing the Second Pump on Top of the First Pump Figure 3-7. Securing Both Pumps to the Motor FACE OF MOTOR FIRST PUMP... - Page 17 Refer to Figures 3-1 through 3-3. Perform Steps 1, 2 and 3 in Section 3.3.1 to put the first pump on the face of the motor. Refer to Figure 3-5 and Figure B. Make sure the second pump is in the closed position. Refer to Figure 3-6 and Figure B.
-
Page 18: Attaching A Single Pump To An Adapter Plate
Setting Up the Pump(s) 3.3.3 Attaching a Single Pump to an Adapter Plate Refer to Figures 3-8 through 3-11 and Figure C. ALIGNMENT PINS MOTOR SHAFT THREADED HOLES TO MOUNT ADAPTER PLATE TO VENDOR CLEARANCE HOLES MOTOR (4X) FOR VENDOR MOTOR ALIGNMENT PINS (2X) ALIGNMENT PINS FOR... - Page 19 The adapter plate is designed to have the same alignment pins and mounting holes as the front face of the standard pump motor. It acts as an interface between a non-standard pump motor and the peristaltic pump. The non-standard pump motor must have a motor shaft groove large enough to accept the the pump rotor shaft.
-
Page 20: Using Your Own Adapter Plate
Setting Up the Pump(s) 3.3.4 Using Your Own Adapter Plate Figure 3-12 shows the dimensions of the front of the pump and the rear of the pump. These diagrams enable you to locate and drill out the proper size holes so you can mount the pump to a motor using your own adapter plate. - Page 21 Setting Up the Pump(s) Notes...
-
Page 22: Chapter 4 Tubing Information
Tubing Information 4.1 Selecting Tubing Select a tubing material and size that is right for your application (the fluid and flow rate that you are pumping). Table 9-2 in Chapter 9, shows the average flow rates for different size tubing. Normalized flow rates (mL per revolution) vary significantly, based on motor speed, tubing materials, viscosity, and mechanical tolerances in pump dimensions. - Page 23 Tubing Information Notes...
-
Page 24: Operating
Operating the Pump 5.1 Introduction This chapter discusses the following topics: • Loading the tubing (Section 5.2) • Operating the Pump (Section 5.3) and • Adjusting the Clamp Screw (Section 5.4). Read each section thoroughly to guarantee successful pump operation. -
Page 25: Loading The Tubing
Operating the Pump 5.2 Loading the Tubing Before you load the tubing in the pump, make sure that power to the motor is turned off and that the rotor has come to a complete stop. The rotor is partially exposed when the pump is in the open position. - Page 26 Refer to Figure 5-1 and Figure D. Snap open the Stator (1) by pushing the spring-loaded area of the Latch (2). Remove any old tubing from the pump, if necessary. Refer to Figure 5-2 and Figure D. Loop the Tubing (10) over the rollers.
-
Page 27: Operating The Pump
Operating the Pump 5.3 Operating the Pump With the pump set up, adjust all control settings for the pump motor and start pumping. Figure 5-5 shows fluid flow directions with respect to motor directions. Extensive testing has shown that the minimum motor speed required to prime the tubing varies significantly with the size of the tubing. -
Page 28: Adjusting The Clamp Screw
Operating the Pump MOTOR TURNING CLOCKWISE OUTLET INLET Figure 5-5b. Inlet and Outlet Flow 5.4 Adjusting the Clamp Screw Once you start the pump, you may need to adjust the Clamp Screw (4) slightly, to prevent the tube from creeping (moving) through the pump. - Page 29 Operating the Pump Turn the pump motor off. Rotate the clamp screw a quarter turn clockwise, in order to increase the pressure of the clamp plate on the tube. Turn the motor power back on and observe the tubing. If the tubing has not stopped creeping, go back to Step 1.
- Page 30 Operating the Pump Notes...
-
Page 31: Chapter 6 Maintenance
Maintenance 6.1 Introduction • No lubrication is required for the pump. All bearings are pre-sealed and rated for long life. • After many hours of use, fine particles of tubing will tend to accumulate inside the pump and on the rollers. Use a high pressure air hose (60 PSI) to blow out most of the particles from the pump. -
Page 32: Replacing The Rotor Assembly
Maintenance 6.2 Replacing the Rotor Assembly (Part Number FPU500-RA) In the replacement kit you will find one Rotor Assembly (13) and two Washers (12). Figure 6-1 shows the exploded view of the pump. Figure 6-1. Exploded View of the Pump... - Page 33 Using a phillips head screwdriver, remove the two #6 Self- Tapping Screws (14) on the back of the base that hold the pump together. Pull apart the three major plastic assemblies in the pump – the Lower Shield (7), Base (8), and Stator (1) Assemblies. ⁄...
- Page 34 Maintenance Notes...
-
Page 35: Chapter 7 Troubleshooting Guide
Troubleshooting Guide Problem No flow out of the outlet tubing Solution 1. Check to see that the Stator is snapped shut. If it is, push down on the Stator while the motor is running. This action enhances the self-priming capability of the pump. 2. - Page 36 Troubleshooting Guide Problem Fluid flows in the opposite direction of what is intended Fluid flow direction cannot be reversed The tube moves when pumping The Stator will not snap shut Screws are too short to fasten two stacked pumps to the motor Solution 1.
- Page 37 Problem Motor will not turn Motor will not turn – overcurrent condition The pump will not stay on the motor Troubleshooting Guide Solution 1. Make sure the tubing is loaded properly. The tubing should be centered in the middle of the rollers. Reload if necessary.
- Page 38 Troubleshooting Guide Notes...
-
Page 39: Chapter 8 Technical Details
Technical Details 8.1 Theory of Operation A peristaltic pump is a fluid pump which operates to create a moving region of compression along a flexible tube. The motion of the compressed region of the tube along its axis forces fluid ahead and creates a partial vacuum behind the region. -
Page 40: Stacking More Than Two Pumps
Technical Details Because of the back tab and groove found in the Rotor Shaft design, pumps can be stacked one of top of another and attached to a common pump motor. Only one motor needs to be purchased to pump fluid between several different containers. -
Page 41: Specifications
Specifications Table 9-1. Tubing Size vs Min. Motor Speed Required for Priming * Tubing Size - ID (* Tests are done using 20°C water, 0 PSI back pressure) Maximum Fluid Back Pressure: Tube Wall Thickness Required: Tube Inner Diameter Range: Tubing Materials: Tubing Durometer: Fluid Temperature Range:... - Page 42 Specifications Pump Dimensions (H x W x D): Pump Weight: Adapter Plate Dimensions (H x W x D): Adapter Plate Weight: Speed Range: Flow Direction: Motor Power Required for Two Pumps to Operate at 600 RPM: Pump Housing: Rotor Assembly: Max.
- Page 43 Tubing Wall Tubing Size Thickness Inner Diameter 1.5 mm 3.0 mm 1.5 mm 4.0 mm 1.5 mm 5.0 mm 1.5 mm 6.0 mm 1.5 mm 7.0 mm 1.5 mm 8.0 mm * Metric mL per Revolution numbers are rounded off Normalized flow rates (mL per revolution) vary significantly, based on motor speed, tubing materials, and mechanical tolerances in pump dimensions.
- Page 44 Specifications Tubing operating life test were done at 600 RPM, with 20°C water, 0 PSI, back pressure until the tubing breaks. Average tubing life hours are shown. However, tubing life varies considerably depending on tubing formulation, tubing back pressure, and fluid pumped.
- Page 45 Table 9-4. Average Tubing Life (Cont'd) ⁄ ⁄ ⁄ ⁄ ⁄ ⁄ ⁄ ⁄ ⁄ ⁄ Table 9-6. Average Flow Rates for Viscous Liquids Liquid Tubing Wall Thickness Mineral Oil ⁄ " Mineral Oil ⁄ " Mineral Oil ⁄ " Mineral Oil ⁄...
- Page 46 Specifications Notes...
-
Page 47: Chapter 10 Spare Parts And Accessories
Spare Parts and Accessories Part Number FPU500-SMS FPU500-LMS FPU500-AP FPU500-RA Part Number * RECOMMENDED TUBING TYPES AND SIZES TYVY Series TYVY Series TYVY Series TYVY Series TYVY Series TYVY Series TYSP Series TYSP Series TYSP Series TYSP Series * Contact the Sales Department for the specific part numbers of the tubing you wish to purchase. - Page 48 Spare Parts and Accessories Part Number * RECOMMENDED TUBING TYPES AND SIZES TYTY Series TYTY Series TYTY Series TYTY Series TYSC Series TYSC Series TYSC Series TYSC Series TYNP Series TYNP Series TYNP Series TYNP Series TYNP Series TYVT Series TYVT Series TYVT Series TYVT Series...
- Page 49 You can use an optional Peristaltic Pump Motor (Part Number FPU5-MT) to run the pumps. Figure 10-1 shows the motor. You can attach one pump to each side of the motor or two pumps to either side. Contact Sales for more information about the pump motor. INLET SELECT LEFT PUMP INPUT...
- Page 50 Spare Parts and Accessories Notes 10-4...
