Canon imageRUNNER 2420 Trouble Error Codes List page 23

Saddle connector error
E5F8- The connector of the paper butting plate home position
0001 sensor has been identified as being disconnected.
Connector of guide home position sensor (PI13S)
Saddle connector error
The connector of the paper butting plate home position
E5F8-
sensor has been identified as being disconnected.
0002
Connector of paper butting plate home position sensor
(PI14S)
Saddle connector error
The connector of the paper butting plate leading edge
E5F8-
sensor has been identified as being disconnected.
0003
Connector of paper butting plate leading edge sensor
(PI15S)
There is an error on the hard disk.
[Cause] An HDD detection error has occurred. The HDD
E602- cannot be detected. The HDD does not become ready.
0001 The HDD returns an error. [Detection] while boot ROM is
in session BARSAC startup, mounting (usrIde) [Timing of
Detection] once at startup
There is an error on the hard disk.
[Cause] There is no startup file. The program for the main
E602- CPU does not exist on the HDD or in BOOTDEV/BOOT,
0002 and so on. [Detection] while boot ROM is in use at time of
system file loading (usrIde) [Timing of Detection] once at
startup
There is an error on the hard disk.
[Cause] An HD write abort error has occurred. The
E602-
sectors for BOOTDEV on the HD cannot be read.
0003
[Detection] BARSAC (all; at time of bootable startup)
[Timing of Detection] once at startup
There is an error on the hard disk.
[Cause] A subbootable that matches the PDL type does
E602-
not exit in BOOTDEV/BOOT. [Detection] during loading
0006
of sub boot in oclibroot [Timing of Detection] once at
bootable startup
There is an error on the hard disk.
[Cause] An ICC profile that matches the PDL type does
E602- not exist in BOOTDEV/PDL. [Detection] beginning of
oclibroot; judgment based on functions of PDL team that
0007
are called in [Timing of Detection] once at bootable
startup
E602- There is an error on the hard disk.
01XX /DOSDEV is faulty
There is an error on the hard disk.
E602-
02XX /FSTDEV is faulty.
23
Connect the connector of the
guide home position sensor.
Check the harness. Replace
the finisher controller PCB.
Connect the connector of the
paper butting plate home
position sensor. Check the
harness. Replace the finisher
controller PCB.
Connect the connector of the
paper butting plate leading
edge sensor. Check the
harness. Replace the finisher
controller PCB.
