Basic Configuration
By default the DrayTek Vigor 120 is configured as a bridge between
PPPoE and PPPoA. This is the correct settings for most ISPs.
The PPPoA protocol is used for your connection from the Vigor120 to the
ISP. PPPoE is used locally between the Vigor120 modem and your host
device (router, PC etc.).
The network device (Firewall, broadband router or a PC) behind the Vigor
120 is required to be configured as either PPPoE or as a Static/Dynamic IP
address client in order to establish Internet connectivity.
PPPoA Configuration:
As a PPPoE -> PPPoA bridge modem, it is not necessary to access the
web interface of the Vigor 120 unless your ISP does not use the most
common ADSL methods (PPPoA and 0/38 as VPI/VCI).
1. Set up physical connectivity as explained in section 3.
2. Configure the network device (Firewall, broadband router or a PC)
behind the Vigor 120 for PPPoE with the ISP Username and Password.
There are more guides to this with some specific router examples on the
support web site (see later).
MPoA Configuration (only for ISPs that require it):
When connecting the Modem to an MPoA line you will need to log on to
the web interface of the unit to make suitable changes:
1. Open a web browser on your PC and type http://192.168.2.1.
Now, the web interface main screen will appear:
2.
