- Page 1 Snom IP Phone Configuration Guides Version 2.0 Date: September 28, 2015 Yeastar Information Technology Co. Ltd.
-
Page 2: Table Of Contents
Snom IP Phone Configuration Guides Contents 1. Introduction ......................3 2. Register with MyPBX Manually ................4 3. Provisioning for MyPBX ..................7 3.1 Phone Provisioning via PnP Mode ..............8 3.2 Phone provisioning via DHCP Mode ............... 11 2/14... -
Page 3: Introduction
1. Introduction This guide shows you how to manually configure Snom IP phones with MyPBX and how to provision the Snom IP phones with MyPBX. It has been tested with the latest firmware version supported by MyPBX firmware version X.19.0.47. -
Page 4: Register With Mypbx Manually
Snom IP Phone Configuration Guides 2. Register with MyPBX Manually 1. Start up the phone and identify its IP Address by pressing the "Help" or "7" button. For this example we will assume the IP Address of the phone is 192.168.5.126, and IP Address of the MyPBX Phone System machine is... - Page 5 Snom IP Phone Configuration Guides of MyPBX Management Console 5. Click the "Save" button, and then click the "Reboot" button that appears at the top of the page. Your phone will restart. After rebooting, the phone will retrieve its configuration files and register with MyPBX Phone System. This can be verified via the "Extension Status"...
- Page 6 Snom IP Phone Configuration Guides 6. For some issues about function of intercom, please refer to the following setting on Snom web interface 6/14...
-
Page 7: Provisioning For Mypbx
Snom IP Phone Configuration Guides 3. Provisioning for MyPBX The easiest way to set up a Snom phone for use with MyPBX is to use the built-in plug and play provisioning functionality inside MyPBX. This will allow the phone to configure itself by retrieving a generated phone configuration file. -
Page 8: Phone Provisioning Via Pnp Mode
Snom IP Phone Configuration Guides 3.1 Phone Provisioning via PnP Mode Step1. Log in Snom IP phone web user interface, go to “Setup->Advanced->Update ” to enable PnP feature on your phone. Step2. Check MAC address of your Snom IP Phone on “Status->System Information”... - Page 9 Snom IP Phone Configuration Guides Step4. Search MAC address you would like configure in “Phone Provisioning->Not Configured Phone” page Fill in the phone detail message on the pop-up windows. Input Name, Call waiting, Line, Extension, Label, Line active and so on for the phone.
- Page 10 Click OK to reboot the IP phone and provisioning the phone. Then IP phone will reboot twice to apply the configurations take effect, when done, you can find the account 506 is registered in MyPBX’s line status page and Snom IP phone’s status page.
-
Page 11: Phone Provisioning Via Dhcp Mode
Snom IP Phone Configuration Guides 3.2 Phone provisioning via DHCP Mode Step1. Disable DHCP Server on your local network. E.g. Disable DHCP Server on Linksys Router. 11/14... - Page 12 Log in MyPBX web interface, go to “System ->Network Preferences->DHCP Server”, enable DHCP server. Step3. Set your Yealink phone as one DHCP client. Go to “Network->Advanced” to enable DHCP. Step4. Go to MyPBX “PBX->Extensions->Phone Provisioning”, select your Snom phone from “Not configured Phone”. 12/14...
- Page 13 Snom IP Phone Configuration Guides Step5. Assign extensions to the phone, and you can also configure the Memory keys and Line keys. Step6. Save the settings and reboot the IP phone. After you save the changes, system will prompt you to save the changes and reboot to save changes without rebooting.
- Page 14 Snom IP Phone Configuration Guides <END> 14/14...
