Konica Minolta bizhub 554e/454e
Specification & Installation Guide
bizhub 554e/454e Specifications
Type Monochrome Printer/Copier/Scanner
Document holder Stationary (mirror scanning)
Photoconductor OPC
Luminous source LED light-source illumination
Copying system Laser electrostatic copy method
Developing system Dry-2 component developing method
Fusing system Belt Fusing
Resolution Scanning: 600 x 600 dpi
Printing: 1200 x 1200 dpi
Document holder Types: Sheets, books (2-page spreads),
three-dimensional objects
Size: Maximum 11" x 17"
Max. Weight: 4.4 lb.
Paper Thin Paper (14 lb. to 15.5 lb.)*
Plain Paper (16 lb. to 24 lb.)
Thick Paper 1 (24.25 lb. to 32 lb.)
Thick Paper 1+ (32.25 lb. to 41.75 lb.)
Thick Paper 2 (42 lb. to 55.5 lb.)
Thick Paper 3 (55.75 lb. to 68 lb.)
Thick Paper 4 (68.25 lb. to 79.75 lb.)**
Recycled Paper (16 lb. to 24 lb.)
Special Paper (16 lb. to 24 lb.)
Letterhead (16 lb. to 24 lb.)
Color Paper (16 lb. to 24 lb.)
1-Sided Special Paper (16 lb. to 24 lb.)
Banner Paper** (34 lb. to 55.5 lb.)
OHP Transparencies**, envelopes**,
label sheets**, tabs**, postcards**
*Cannot be fed through the bypass tray.
**Can only be fed through the bypass tray.
Copy sizes 1st Tray:
11" x 17" to 8.5" x 11", 5.5" x 8.5", 8" x 13"*
2nd Tray:
12.25" x 18" to 8.5" x 11", 5.5" x 8.5", 8" x 13"*
Bypass Tray:
12" x 18" to 5.5" x 8.5", 12.25" x 18", 4" x 6",
8" x 13"*, Banner Paper
* There are six Foolscap sizes: 220 x 330mm (L),
8.5" x 13.5", 8.5" x 13" (L), 8.25" x 13 (L),
8.12" x 13.25" (L) and 8" x 13" (L). Any one of these
sizes can be selected. For details, please consult with
your authorized Konica Minolta Service representative.
Paper tray 1st Tray and 2nd Tray:
capacity Thin Paper/Plain Paper/Recycled Paper/
Special Paper/Letterhead/Color Paper/
1-Sided Special Paper: 500 sheets;
Thick Paper 1/1+/2/3: 150 sheets
Paper tray Bypass Tray:
capacity (cont.) Plain Paper/Recycled Paper/Special Paper/
Letterhead/Color Paper/1-Sided Special
Paper: 150 sheets; Thick Paper 1/1+/2/3/4/
OHP Transparencies/Postcards/Tabs: 20
sheets; Envelopes: 10; Banner Paper/Label
Sheets: 10 sheets
Copy exit tray Thin Paper: 100 sheets
capacity Plain Paper: 250 sheets
Thick Paper: 10 sheets
Overhead Projection
Transparencies*: 1 sheet
*Can only be fed through the bypass tray.
Warm-up time Less than 25 seconds
(at room temperature/73.4° F)
Image loss width Leading Edge: 0.165"
Trailing Edge: 0.118"
Rear Edge: 0.118"
Front Edge: 0.118"
Thin Paper: 0.197"
First copy 554e: 4.1 sec. or less
454e: 4.6 sec or less
Print speed*: bizhub 554e:
(Simplex/Duplex) Plain paper: 55 sheets/min.
Thick 1/Thick1+/Thick 2/Thick 3/Thick 4:
28 sheets/min.
bizhub 454e:
Plain paper: 45 sheets/min.
Thick 1/Thick1+: 28 sheets/min.
Thick 2/Thick 3/Thick 4: 23 sheets/min.
Print speed (ppm)*: Single Sided/Plain Paper:
Size
11" x 17"
8.5" x 14"
8.5" x 11"P
8.5" x 11"L
5.5" x 8.5"L
8" x 13"L
Double Sided/Plain Paper:
Size
11" x 17"
8.5" x 14"
8.5" x 11"P
8.5" x 11"L
5.5" x 8.5"L
8" x 13"L
*Using 1st Tray
Density control Copy Density: Manual Density Adjustment
(9 Levels); Background Density: Automatic
and Manual Density Adjustments (9 levels)
Power 120V, 16 A, 60 Hz
requirements
Power 1.92 kW or less
consumption
Magnification 1.0 (full size: 1.00+_0.5% or less)
ratios Enlarge: 121.4%, 129.4%, 154.5%, 200%
Reduce: 78.5%, 73.3%, 64.7%, 50.0%
Minimal: 93%
Stored Zoom Ratios: 3
"Minimal" zoom ratio (90% to 99.9%)
10/25/2013
554e 454e
27 22
31 25
55 45
40 33
55 45
31 25
554e 454e
27 22
31 25
55 45
37 31
55 45
31 25
continued
