ELECTRIC CHAIN SAW
IMPORTANT: Read and understand this manual before assem-
bling or operating this chain saw. Improper use of saw can cause
severe injury. Keep this manual for future reference.
For parts contact: www.PartsFor.com
OWNER'S MANUAL
TYPE: EL9
LD3516AWB
CLD3516AWB
LD4016AW
CLD4016AW
LD4018AW
CLD4018AW
LD4018AWC
CLD4018AWC
®
Advertisement
Table of Contents
Related Manuals for Remington LD3516AWB
Summary of Contents for Remington LD3516AWB
- Page 1 ® ELECTRIC CHAIN SAW OWNER’S MANUAL TYPE: EL9 LD3516AWB CLD3516AWB LD4016AW CLD4016AW LD4018AW CLD4018AW LD4018AWC CLD4018AWC IMPORTANT: Read and understand this manual before assem- bling or operating this chain saw. Improper use of saw can cause severe injury. Keep this manual for future reference.
-
Page 2: Table Of Contents
Contents IMPORTANT SAFETY INFORMATION ................3 Before Operating Saw ........................3 While Operating Saw ..........................3 Kickback .............................4 Maintenance and Storage of Chain Saw ....................5 UNPACKING ........................5 PRODUCT IDENTIFICATION ....................6 CHAIN SAW NAMES AND TERMS ..................6 QUICK START GUIDE ......................7 SAW CHAIN TENSION ADJUSTMENT ................8 OPERATING CHAIN SAW ....................9 Filling Oil Tank ............................9 Oiling Chain ............................9... -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION • safety hard hat • ear mufflers or ear plugs • hair covering to contain long hair WARNING: When using an electric • face or dust mask (if working in dusty areas) chain saw, basic safety precautions 10. -
Page 4: Kickback
IMPORTANT SAFETY INFORMATION KICKBACK 15. When cutting limb or tree trunk that is under WARNING: Kickback may occur when tension, use extreme caution. Be alert for wood springing back. When wood tension is released, the nose or tip of the guide bar touches limb could spring back and strike operator caus- an object, or when the wood closes in ing severe injury or death. -
Page 5: Product Identification
PRODUCT IDENTIFICATION Oil Level Sight Oil Cap Switch Lockout Front Handle with Hand Guard Saw Chain Rear Handle Power Cord Guide Bar Nose Cord Hitch Chain Tensioning Knob Trigger Guide Bar Lever (Lift and Dial) Figure 2 - Chain Saw Model CHAIN SAW NAMES AND TERMS Bucking Process of cutting a felled tree or log into... -
Page 6: Quick Start Guide
QUICK START GUIDE If you are familiar with chain saws and their proper usage, use this Quick Start Guide to quickly begin using your new Remington brand chain saw. Oil Tank Cap Oil Sight Window Power Cord Cord Slot Hitch... -
Page 7: Saw Chain Tension Adjustment
SAW CHAIN TENSION ADJUSTMENT WARNING: Unplug chain saw from power source before adjusting saw chain tension. WARNING: Cutting edges on chain are sharp. Use protective gloves when handling chain. WARNING: Maintain proper chain tension always. A loose chain will in- crease the risk of kickback. -
Page 8: Operating Chain Saw
SAW CHAIN TENSION ADJUSTMENT EXTENSION CORDS Use proper extension cords with this saw. Use only OPERATING CHAIN SAW extension cords marked for outdoor use. The cord must be marked with suffix W or W-A following the cord type designation. Example: SJTW-A or SJTW. WARNING: Read and understand this Use proper sized cord with this saw. -
Page 9: Cutting With The Chain Saw
OPERATING CHAIN SAW CUTTING WITH THE CHAIN SAW FELLING A TREE 1. Connect saw to extension cord. Connect exten- (Cutting Down a Tree) sion cord to power supply. 2. Make sure section of log to be cut is not laying WARNING: on ground. -
Page 10: Limbing A Tree
OPERATING CHAIN SAW 4. Remove dirt, stones, loose bark, nails, staples, and 3. As felling cut nears hinge, tree should begin to fall. wire from tree where you will make felling cuts. Note: If needed, drive wedges into felling cut to control direction of fall. -
Page 11: Bucking A Log
OPERATING CHAIN SAW BUCKING A LOG Log Supported On One End 1. Make first cut on underside of log (see Figure 11). Use top of guide bar to make this cut. Cut WARNING: Avoid kickback. Kickback 1/3 through diameter of log. This cut will keep can result in severe injury or death. -
Page 12: Trimming A Tree (Pruning)
OPERATING CHAIN SAW TRIMMING A TREE (Pruning) Trimming a tree is the process of cutting limbs from a living tree. Make sure your footing is firm. Keep feet apart. Divide your weight evenly on both feet. Follow directions below to trim a tree. WARNING: Avoid kickback. -
Page 13: Cleaning And Maintenance
CLEANING AND MAINTENANCE 3. Turn tensioning knob 1/2 turn counterclockwise to release tension on guide bar and chain. 4. Using a 5/32" allen wrench, loosen and remove NOTICE: Below are instructions for ser- cap screw attaching lever and sprocket cover to vicing your chain saw. -
Page 14: Sprocket Cover Assembly
CLEANING AND MAINTENANCE Adjustment Block SPROCKET COVER ASSEMBLY Before assembling sprocket cover to saw body, turn tensioning knob counterclockwise until it stops turn- ing. The adjustment block will be all the way to the left of the adjustment block window. 1. -
Page 15: Cleaning Saw Body
CLEANING AND MAINTENANCE Normal Guide Bar Maintenance 1. Remove sprocket cover (see Clearing Sprocket CLEANING SAW BODY Cover of Debris, page 14). 2. Remove saw chain. 3. Remove E-ring and sprocket support (see Figure WARNING: When cleaning saw 20). body, 4. -
Page 16: Sharpening Saw Chain
CLEANING AND MAINTENANCE Keep chain sharp. Your saw will cut faster and more safely. A dull chain will cause undue sprocket, guide Install Guide Bar bar, chain, and motor wear. If you must force chain 1. Place guide bar onto guide bar bolts (see Figure into wood and cutting creates only sawdust with few 20, page 16). -
Page 17: Replacing Saw Chain
CLEANING AND MAINTENANCE Front Corner .025" Depth Gauge (right .635 mm Depth Gauge (left side of chain) side of chain) Groove Groove Figure 26 - Round Off Front Corner Of Depth Top Plate (left Gauge side of chain) Top Plate (right side of chain) REPLACING SAW CHAIN Right Side of Chain... -
Page 18: Storage
TROUBLESHOOTING WARNING: Unplug chain saw from power source before servicing. Severe injury Note: For additional help, visit DESA Power Tools technical service web site at www.desat- or death could occur from electrical shock or body contact with moving chain. ech.com. OBSERVED FAULT POSSIBLE CAUSE REMEDY... - Page 19 Click on the picture above for part numbers or to purchase parts Key # Model Number Description LD3516AWB Chainsaw Oil Cap LD3516AWB Chainsaw Chain LD3516AWB Chainsaw Guide Bar LD3516AWB Chainsaw Sprocket Cover LD3516AWB Chainsaw Lift and Dial Lever LD3516AWB Chainsaw E-Ring Retainer...
