Model No. NTL07707.1
Serial No.
Write the serial number in the space
above for reference.
Serial Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete cus-
tomer satisfaction. If you have
questions, or if parts are missing,
PLEASE DO NOT CONTACT
THE STORE; please contact
Customer Care.
IMPORTANT: You must note the
product model number and
serial number (see the drawing
above) before contacting us:
CALL TOLL-FREE:
1-888-825-2588
Mon.–Fri. 6 a.m.–6 p.m. MST
Sat. 8 a.m.–4 p.m. MST
ON THE WEB:
www.nordictrackservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
With Universal Dock for iPod
®
USER'S MANUAL
Visit our website at
www.nordictrack.com
new products, prizes,
fitness tips, and much more!
Advertisement
Table of Contents
Related Manuals for NordicTrack TREADMILL NTL07707.1
Summary of Contents for NordicTrack TREADMILL NTL07707.1
- Page 1 Read all precautions and instruc- tions in this manual before using this equipment. Save this manual for future reference. With Universal Dock for iPod ® USER'S MANUAL Visit our website at www.nordictrack.com new products, prizes, fitness tips, and much more!
-
Page 2: Table Of Contents
Apply the decal in the location shown. Note: The decals may not be shown at ac- tual size. NordicTrack is a registered trademark of ICON IP, Inc. iPod ® is a trademark of Apple Computer, Inc., registered in the U.S. and other countries. -
Page 3: Important Precautions
12. To purchase a surge suppressor, see your local NordicTrack dealer or call the tele- phone number on the front cover of this man- ual and order part number 146148, or see your local electronics store. - Page 4 20. Never leave the treadmill unattended while it is running. Always remove the key, unplug the power cord, and switch the reset/off cir- cuit breaker to the off position when the treadmill is not in use. (See the drawing on page 5 for the location of the circuit breaker.) 21.
-
Page 5: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the revolutionary NordicTrack C2155 treadmill with Universal Dock for iPod. The C2155 treadmill offers a selection of features designed to make your workouts at home more enjoyable and effective. And when you’re not exercising, the unique C2155 treadmill can be folded up, requiring less than half the floor space of other treadmills. -
Page 6: Assembly
ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is coated with high-performance lubricant. During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton. - Page 7 1. Make sure that the power cord is unplugged. With the help of a second person, carefully tip the treadmill onto its left side. Partially fold the Frame (56) so that the treadmill is more stable; do not fully fold the Frame yet. Remove and discard the two indicated bolts (A) and the shipping bracket (B).
- Page 8 4. Set the Right Upright Spacer (79) on the Base (83). Be careful not to pinch the Upright Wire (38). With the help of a second person, insert two 3/8" x 5" Bolts (6) with two 3/8" Star Washers (9) into the Right Upright (78), and set the Right Upright in the Right Upright Spacer.
- Page 9 7. Set the console assembly face down on a soft surface to avoid scratching the console assem- bly. Hold the Right Handrail (95) near the con- sole assembly. Next, insert the console wire into the large hole in the Right Handrail and out of the top as shown.
- Page 10 10. Identify the Storage Latch (53). Remove the tie from the end of the tube. Make sure that the sleeve has been slid over hole 1 and that the Latch Knob (54) is locked into the indicated hole. Pull on the sleeve to make sure that it is locked into place.
- Page 11 12. Press the Left Accessory Tray (99) and the Right Accessory Tray (106) into the Console Base (91). 13. Make sure that all parts are properly tightened before you use the treadmill. If there are sheets of clear plastic on the treadmill decals, remove the plastic. To protect the floor or carpet, place a mat under the tread- mill.
-
Page 12: Operation And Adjustment
(see drawing 1 at the right). To purchase a surge suppressor, see your local NordicTrack dealer or call the telephone number on the front cover of this manual and order part number 146148, or see your local electronics store. - Page 13 CONSOLE DIAGRAM FEATURES OF THE CONSOLE The treadmill console offers an impressive array of features designed to help you get the most from your workouts. When the manual mode of the console is se- lected, the speed and incline of the treadmill can be changed with the touch of a button.
- Page 14 HOW TO TURN ON THE POWER IMPORTANT: If the treadmill has been exposed to cold temperatures, allow it to warm to room tem- perature before turning on the power. If you do not do this, the console displays or other electrical components may become damaged.
- Page 15 4. Change the incline of the treadmill as desired. To change the incline of the treadmill, press the Incline in- crease and de- crease buttons. Each time you press the Incline increase or de- crease button, the incline will change by 0.5%. To change the incline quickly, press one of the incline buttons numbered 0 through 12.
- Page 16 6. Measure your heart rate if desired. Before using the handgrip pulse sensor, remove the clear plastic film from the metal contacts. In addition, make sure that your hands are clean. To measure your heart rate, stand on the foot rails and hold the metal contacts—avoid moving your hands.
- Page 17 HOW TO USE A PRESET WORKOUT 1. Insert the key into the console. See HOW TO TURN ON THE POWER on page 2. Select one of the preset workouts. To select a weight loss workout or a performance workout, press the Weight Loss Workouts button or the Performance Workouts but- ton.
- Page 18 HOW TO USE AN IFIT CARD 1. Insert the key into the console. See HOW TO TURN ON THE POWER on page 2. Insert an iFIT card and select a workout. To use an iFIT workout, insert an iFIT card into the iFIT slot;...
-
Page 19: Adjusting Cushioning System
HOW TO USE THE STEREO SOUND SYSTEM This product has been designed specifically to work with iPod and has been certified by the developer to meet Apple performance standards. To play music or audio books through the console’s stereo speakers, you must connect your iPod, MP3 player, CD player, or other personal audio player to the console through the audio jack or through the Integrated Universal... -
Page 20: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, adjust the incline to the lowest position. If you do not do this, you may damage the treadmill when you fold it. Remove the key and unplug the power cord. -
Page 21: How To Lower The Treadmill For Use
HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand. Pull the latch knob to the left and hold it. It may be neces- sary to push the frame forward as you pull the knob to the left. -
Page 22: Troubleshooting
TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please see the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a. - Page 23 Remove the three #8 x 3/4" Screws (1) and care- fully pivot the Hood (61) off. Locate the Reed Switch (71) and the Magnet (50) on the left side of the Pulley (51). Turn the Pulley until the Magnet is aligned with the Reed Switch. Make sure that the gap between the Magnet and the Reed Switch is about 1/8 in.
- Page 24 PROBLEM: The walking belt is off-center or slips when walked on SOLUTION: a. If the walking belt is off-center, first remove the key and UNPLUG THE POWER CORD. If the walking belt has shifted to the left, use the hex key to turn the left rear roller bolt clockwise 1/2 of a turn;...
-
Page 25: Exercise Guidelines
EXERCISE GUIDELINES WARNING: Before beginning this or any exercise program, consult your physi- cian. This is especially important for persons over the age of 35 or persons with pre-exist- ing health problems. The pulse sensor is not a medical device. Various factors may affect the accuracy of heart rate readings. -
Page 26: Part List
PART LIST—Model No. NTL07707.1 To locate the parts listed below, see the EXPLODED DRAWING near the end of this manual. Key No. Qty. Description #8 x 3/4" Screw #8 x 1" Tek Screw Hex Key 3/8" x 2" Bolt 1/4" x 1 1/4" Bolt 3/8"... - Page 27 Key No. Qty. Description Console Ground Wire iFIT Universal iPod Connector Filter Wire Lift Motor Spacer #8 x 2" Screw Right Accessory Tray Frame/Roller Ground Wire Key No. Qty. Description 5/32" Hex Key – 6" Blue Wire, 2F – User’s Manual *These parts are not illustrated.
-
Page 28: Exploded Drawing
EXPLODED DRAWING A—Model No. NTL07707.1 R0907B... - Page 29 EXPLODED DRAWING B—Model No. NTL07707.1 R0907B...
- Page 30 EXPLODED DRAWING C—Model No. NTL07707.1 R0907B...
- Page 31 EXPLODED DRAWING D—Model No. NTL07707.1 R0907B...
-
Page 32: Ordering Replacement Parts
ORDERING REPLACEMENT PARTS To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to pro- vide the following information when contacting us: • the model number and serial number of the product (see the front cover of this manual) •...
