Pride Mobility JAZZY 1170 XL Owner's Manual

Hide thumbs Also See for JAZZY 1170 XL:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual
Owner's Manual
ATTENTION:
Please read the content
of your owner’s manual
before operating your
power chair.
Exeter, PA
St. Catharines, ON
1-800-800-8586
www.pridemobility.com

Advertisement

Table of Contents
loading

Related Manuals for Pride Mobility JAZZY 1170 XL

Summary of Contents for Pride Mobility JAZZY 1170 XL

  • Page 1 Owner’s Manual ATTENTION: Please read the content of your owner’s manual before operating your power chair. Exeter, PA St. Catharines, ON 1-800-800-8586 www.pridemobility.com...
  • Page 2 The symbol below is used throughout this owner’s manual to identify warnings. It is very important for you to read and understand them completely. WARNING! Failure to heed the warnings in this owner’s manual may result in personal injury. Copyright © 2004 Pride Mobility Products Corp. INFMANU1137\RevI\Sep04 www.pridemobility.com Jazzy 1170XL...

  • Page 3: Table Of Contents

    C O N T E N T S INTRODUCTION ........................4 SAFETY ............................6 III. THE JAZZY 1170XL ......................14 IV. COMFORT ADJUSTMENTS ....................19 BATTERIES AND CHARGING ................... 26 VI. OPERATION ..........................30 VII. CARE AND MAINTENANCE ....................43 VIII.WARRANTY ..........................

  • Page 4: Introduction

    I N T R O D U C T I O N SAFETY WELCOME to Pride Mobility Products Corporation (Pride). The power chair you have purchased com- bines state-of-the-art components with safety, comfort, and styling in mind. We are confident that these design features will provide you with the conveniences you expect during your daily activities.
  • Page 5 I N T R O D U C T I O N PRIDE OWNERS CLUB As an owner of a Pride product, you are invited to register your product's warranty and enroll in the Pride Owners Club. You may do so by filling out and returning your enclosed product registration card or by visiting Pride’s web site at www.pridemobility.com.

  • Page 6: Safety

    I I . S A F E T Y SAFETY WARNING! Do not operate your new power chair for the first time without completely reading and understanding this owner’s manual. Your power chair is a state-of-the-art life-enhancement device designed to increase mobility. Pride pro- vides an extensive variety of products to best fit the individual needs of the power chair user.

  • Page 7: Weight Limitations

    I I . S A F E T Y Perform the following inspections prior to using your power chair: n Check for proper tire inflation. Maintain 35 psi in each tire (if equipped with pneumatic tires). n Check all electrical connections. Make sure they are tight and not corroded. n Check all controller connections to the electronics tray.
  • Page 8 I I . S A F E T Y When climbing an incline, try to keep your power chair moving. If you must stop, start up again slowly and then accelerate cautiously. When driving down an incline, set your power chair to the slowest setting and drive in the forward direction only.
  • Page 9 I I . S A F E T Y Cornering Information While your power chair is equipped with rear caster wheels in back and anti-tip wheels in front, excessively high cornering speeds can still create the possibility of tipping. Factors which affect the possibility of tipping include, but are not limited to: cornering speed, steering angle (how sharply you are turning), uneven road surfaces, inclined road surfaces, riding from an area of low traction to an area of high traction (such as passing from a grassy area to a paved area –...

  • Page 10: Public Streets And Roadways

    I I . S A F E T Y Stationary Obstacles (Steps, Curbs, etc.) Proceed with extreme caution when driving near raised surfaces, unprotected ledges and/or drop-offs (curbs, porches, stairs, etc.). The correct method for approaching a curb is illustrated in figures 2 and 3. Figure 2.

  • Page 11: Positioning Belts

    I I . S A F E T Y Lift/Elevation Products If you will be traveling with your power chair, you may find it necessary to use a lift/elevation product to aid in transportation. Pride recommends that you closely review the instructions, specifications, and safety information set forth by the manufacturer of the lift/elevation product before using that product.

  • Page 12: Reaching And Bending

    I I . S A F E T Y WARNING! If you require a positioning belt to safely operate your power chair, make sure it is fastened securely. Serious personal injury may result if you fall from the power chair. WARNING! The positioning belt is not designed for use as a seat belt in a motor vehicle.

  • Page 13: Removable Parts

    I I . S A F E T Y Preventing Unintended Movement WARNING! If you anticipate being seated in a stationary position for an extended period of time, turn off the power. This will prevent unexpected motion from inadvertent joystick contact. This will also eliminate the possibility of unintended chair movement from electromagnetic (EM) sources.

  • Page 14: The Jazzy 1170Xl

    I I I . Y O U R P O W E R C H A I R The Jazzy has two main assemblies: the seat and the power base. See figures 5 and 6. Typically, the seat assembly includes the armrests, seatback, and seat base. The power base is the heart of the Jazzy. The power base assembly includes two motor/brake assemblies, two drive wheels, two anti-tip wheels, two caster wheels, two batteries, and wiring harnesses.
  • Page 15 I I I . Y O U R P O W E R C H A I R JAZZY 1170XL SPECIFICATIONS Suspension: Active-Trac Suspension Drive Wheels: 16 in., pneumatic, center-mounted (solid tires are optional) Caster Wheels: 9 in., pneumatic, rear articulating (solid tires are optional) Anti-tip Wheels: 8 in., solid, front mounted Maximum Speed:...
  • Page 16 I I I . Y O U R P O W E R C H A I R REAR SEAT TOWER FRONT SEAT TOWER ELECTRONICS TRAY FREEWHEEL LEVER BATTERY BATTERY FREEWHEEL LEVER REAR SEAT TOWER FRONT SEAT TOWER Figure 6. Your Power Chair Power Base (Shroud Removed) CONTROLLER CONNECTOR (VSI CHARGER INHIBIT CONNECTOR AMMETER...
  • Page 17 I I I . Y O U R P O W E R C H A I R Electronics Tray The electronics tray is located on the back of the power base. See figures 6 and 7. The ammeter, the onboard charger AC power cord, the main circuit breaker, the controller connector, and the charger inhibit connector are all located on the electronics tray.

  • Page 18: Freewheel Levers

    I I I . Y O U R P O W E R C H A I R Freewheel Levers For your convenience, your power chair is equipped with two freewheel levers. See figures 6 and 7. These levers allow you to disengage the drive motors and maneuver the chair manually. WARNING ! Do not use your power chair while the drive motors are disengaged unless you are in the presence of an attendant! Do not disengage the drive motors when your power chair is on an incline.

  • Page 19: Comfort Adjustments

    I V . C O M F O R T A D J U S T M E N T S Comfort Adjustments After becoming familiar with your Jazzy’s operation, you may find the need to make some adjustments to increase your comfort, such as seat height and angle, armrest angle, footrest height and angle, and the controller’s position.

  • Page 20: Reclining Seat

    I V . C O M F O R T A D J U S T M E N T S 10. Reinstall the seat. 11. Plug the connectors into the electronics tray. Reclining Seat If your Jazzy is equipped with a reclining seat, you can adjust REMOVE THIS the seatback angle with the seatback release lever.

  • Page 21: Controller Position

    I V . C O M F O R T A D J U S T M E N T S 4. Turn the adjusting screw clockwise to raise the front of REMOVE THIS NUT AND BOLT TO RAISE OR LOWER THE FOOTREST the armrest, or turn the adjusting screw counterclock wise to lower the front of the armrest.
  • Page 22 I V . C O M F O R T A D J U S T M E N T S Swing-away Footrests SFR RELEASE LEVER Swing-away Footrests (SFRs) are an option. They enable you to rotate the leg rests to the side before you transfer on or off of your Jazzy.
  • Page 23 I V . C O M F O R T A D J U S T M E N T S Anti-tip Wheels The anti-tip wheels are designed to give your Jazzy increased stability on rough surfaces. The anti-tip wheels are preset for smooth surfaces or indoor use only. If you plan on using your Jazzy on rough sur- faces, it may be necessary to adjust the anti-tip wheels to better suit your needs.
  • Page 24 I V . C O M F O R T A D J U S T M E N T S Power Elevating Seat Option Your Jazzy may be equipped with a power elevating seat actuator. See figure 21. This feature can enhance the capabilities of the Jazzy in several ways: n By elevating the seat, your level of reach is extended to allow more freedom and independence in many environments.
  • Page 25 I V . C O M F O R T A D J U S T M E N T S NOTE: Be sure you are on a flat level surface before activating the power elevating seat. Power Elevating Seat Operation You can control the power seat through either the toggle switch located on the armrest or your through controller.

  • Page 26: Batteries And Charging

    B A T T E R I E S A N D C H A R G I N G BATTERIES The Jazzy uses two long-lasting, 12-volt, deep-cycle batteries. These batteries are sealed and maintenance free. Since they are sealed, there is no need to check the electrolyte (fluid) level. Deep-cycle batteries are designed to handle a longer and deeper discharge.
  • Page 27 B A T T E R I E S A N D C H A R G I N G OFF-BOARD CHARGER To charge the batteries using the off-board charger: 1. Position your Jazzy next to a standard wall outlet. 2.
  • Page 28 B A T T E R I E S A N D C H A R G I N G How often must I charge the batteries? Many factors come into play when deciding how often to charge the batteries. You may use your Jazzy all day on a daily basis or you may not use it for weeks at a time.
  • Page 29 B A T T E R I E S A N D C H A R G I N G We work closely with our battery manufacturer to provide a battery that best suits your Jazzy’s specific demands. Fresh batteries arrive regularly at Pride and are promptly shipped with a full charge. During shipping, the batteries encounter temperature extremes that may influence initial performance.

  • Page 30: Operation

    V I . O P E R A T I O N VSI CONTROLLER The electronic controller is what you use to operate your power chair. It takes the battery voltage and sends it to the appropriate system. The electronic controller enables you to move the power chair, as well as monitor battery charge, electronic controller functions, and the condition of your electrical system.
  • Page 31 V I . O P E R A T I O N On/Off Key The on/off key turns the VSI on and off. WARNING! Unless faced with an emergency situation, do not use the on/off key to stop the chair. This will cause the power chair to stop abruptly.
  • Page 32 V I . O P E R A T I O N Locking/Unlocking the VSI The VSI has a feature that enables you to lock your power chair to prevent unauthorized use. To lock the VSI: 1. With the VSI switched on, press and hold the on/off button. After 1 second, the VSI should beep. 2.
  • Page 33 V I . O P E R A T I O N Thermal Rollback The VSI controller is equipped with a thermal rollback circuit. The circuit monitors the temperature of the controller, which roughly translates to motor temperature. In the event that the VSI controller becomes excessively hot (above 140°...
  • Page 34 V I . O P E R A T I O N REMOTE PLUS CONTROLLER The electronic controller is what you use to operate your power chair. It takes the battery voltage and sends it to the appropriate system. The electronic controller also enables you to monitor battery charge, electronic controller functions, and the condition of your electrical system.
  • Page 35 V I . O P E R A T I O N WARNING! If your power chair be- gins to move in an unexpected man- ner, immediately release the joy- stick. Unless the joystick is dam- aged, this action should stop your power chair.
  • Page 36 V I . O P E R A T I O N Hazard Key The hazard key toggles both right and left indicators at the same time. You can only cancel this by pressing the hazard key again. Battery Condition Meter The battery condition meter is located in front of the joystick.

  • Page 37: Power Module

    V I . O P E R A T I O N Power Accessories If your power chair is equipped with power accessories such as a power seat or power elevating leg rests, you can operate them through the remote keypad. Contact your authorized Pride Provider for information on how to operate these accessories.
  • Page 38 V I . O P E R A T I O N Trouble Codes Trouble Codes In addition to indicating the current state of battery charge, the battery condition meter can also indicate In addition to indicating the current state of battery charge, the battery condition meter can also indicate possible problems with your power chair.
  • Page 39 V I . O P E R A T I O N DX CONTROLLER The Dynamic DX electronic control system is a modular system. The electronics necessary to operate the power chair are contained in several modules located on different parts of your power chair. The Dynamic DX system consists of the following components: n master remote (Europa) n communications cable(s)
  • Page 40 V I . O P E R A T I O N Out Of Neutral At Power Up Your power chair joystick is equipped with Out Of Neutral At Power Up (OONAPU). If you power up the system and the joystick is not in the neutral po- sition, the system status light flashes rapidly for either as long as the joystick is out of the neutral position or five seconds.
  • Page 41 V I . O P E R A T I O N NOTE: If you turn on the power chair while it is locked and don’t unlock it after one minute, the power chair will automatically turn off itself. Battery Condition Meter The battery condition meter consists of six lights arranged in an arc over the battery icon.
  • Page 42 V I . O P E R A T I O N Off-board Charger/Programming Socket You may use an off-board charger to charge the power chair batteries through the 3-pin socket located on the front of the Europa. See figure 41. If you use an off-board charger, the charger current should not exceed 8 amps.

  • Page 43: Care And Maintenance

    V I I . C A R E A N D M A I N T E N A N C E ROUTINE MAINTENANCE Your Jazzy is a sophisticated power chair. Like any motorized vehicle, it requires routine maintenance checks. You can perform some of these checks, but others require assistance from an authorized Pride Provider.

  • Page 44: Daily Checks

    V I I . C A R E A N D M A I N T E N A N C E WARNING! Make sure your tires are inflated to 35 psi. Do not underinflate or overinflate your tires. Low pressure may result in loss of control, and overinflated tires may burst. Overinflating tires can cause them to explode and can result in personal injury.

  • Page 45: Cleaning Instructions

    V I I . C A R E A N D M A I N T E N A N C E To calibrate the joystick (Remote Plus only): 1. Position the joystick in the full reverse position and hold it there. Turn on the controller. 2.

  • Page 46: Battery Replacement

    V I I . C A R E A N D M A I N T E N A N C E WARNING! To avoid possible injury, be sure that the controller's power is turned off and the power chair is not in freewheel mode before performing this procedure. WARNING! Completely deflate the tire before attempting repair.

  • Page 47: Corrective Maintenance

    V I I . C A R E A N D M A I N T E N A N C E WHEN TO SEE YOUR AUTHORIZED PRIDE PROVIDER FOR SERVICE The following symptoms could indicate a serious problem with your Jazzy. If necessary, contact your authorized Pride Provider.

  • Page 48: Viii.warranty

    V I I I . W A R R A N T Y LIFETIME LIMITED WARRANTY For the lifetime of your power chair from the date of purchase, Pride will repair or replace at our option to the original purchaser, free of charge, any of the following parts found upon examination by an authorized representative of Pride to be defective in material and/or workmanship: Structural frame components, including: n Main Frame...
  • Page 49 Circumstances beyond the control of Pride n Labor, service calls, shipping, and other charges incurred for repair of the product, unless specifically authorized by Pride Mobility Products Corporation n Repairs and/or modifications made to any part without specific consent from Pride...
  • Page 50 N O T E S www.pridemobility.com Jazzy 1170XL...
  • Page 51 Quality Control - Model 1170 XL Thank you for making the Pride Jazzy your choice in power chairs. We have thoroughly inspected your Jazzy. The following checkmarks indicate that it has been test driven and inspected. Model #______________ Joystick Serial # Serial #______________ Controller Serial # Inclusion of all Parts...
