- Page 1 User Manual...
-
Page 2: Table Of Contents
Master/Slave Mode (wired) ........................15 Master/Slave Mode (D-Fi USB) ......................15 5. Maintenance ..........................16 Product Maintenance ..........................16 6. Technical Specifications ......................17 Returns ............................18 Contact Us ............................ 19 Page 2 of 19 COLORband T3 USB User Manual Rev. 1... -
Page 3: Before You Begin
Chauvet reserves the right to revise the content of this document without any obligation to notify any person or company of such revision, however, Chauvet has no obligation to make, and does not commit to make, any such revisions. -
Page 4: Product At A Glance
Keep this User Manual for future use. If you sell the product, be sure that they also receive this document. Page 4 of 19 COLORband T3 USB User Manual Rev. 1... -
Page 5: Introduction
WARNING! DO NOT plug anything other than a D-Fi USB into the USB port. Doing so may cause damage to the product. Product Dimensions 6.2 in 157 mm 2 in 49 mm 38.9 in 987 mm COLORband T3 USB User Manual Rev. 1 Page 5 of 19... -
Page 6: Setup
Product Additional Products You can power link up to 21 COLORband T3 USB products on 120 VAC or up to 38 COLORband T3 USB products on 230 VAC. The power linking diagram corresponds to the North American version of the... -
Page 7: Mounting
Mounting Before mounting the product, read and follow the safety recommendations indicated in Safety Notes. The COLORband T3 USB may be mounted in any position; however, make sure Orientation adequate ventilation is provided around the product. · Rigging Before deciding on a location for the product, always make sure there is easy access to the product for maintenance and programming purposes. -
Page 8: Operation
Address The COLORband T3 USB uses up to 14 DMX channels in a 14CH DMX mode, which defines the highest configurable address to 499. If you are not familiar with the DMX protocol, download the DMX Primer from www.chauvetlighting.com. -
Page 9: Dmx Linking
DMX Linking The COLORband T3 USB works with a DMX controller. Information about DMX is in the CHAUVET Primer, which available from Chauvet website http://www.chauvetlighting.com/downloads/DMX_Primer_rev05_WO.pdf. Set the product in DMX mode to control with a DMX controller. Configuration Connect the product to a suitable power outlet. -
Page 10: Dmx Channel Assignments And Values
102 ó 152 Dimmer speed mode 1 (fast speed) Dimmer Speed 153 ó 203 Dimmer speed mode 2 (medium speed) 204 ó 255 Dimmer speed mode 3 (slow speed) Zones for DMX Control Page 10 of 19 COLORband T3 USB User Manual Rev. 1... -
Page 11: 9-Ch
102 ó 152 Dimmer speed mode 1 (fast speed) Dimmer Speed 153 ó 203 Dimmer speed mode 2 (medium speed) 204 ó 255 Dimmer speed mode 3 (slow speed) COLORband T3 USB User Manual Rev. 1 Page 11 of 19... -
Page 12: 6-Ch
153 ó 203 Dimmer speed mode 2 (medium speed) 204 ó 255 Dimmer speed mode 3 (slow speed) Channel Function Value Percent/Setting 3-CH 000 ó 255 0–100% 000 ó 255 0–100% Green 000 ó 255 0–100% Blue Page 12 of 19 COLORband T3 USB User Manual Rev. 1... -
Page 13: Configuration (Standalone)
Use <UP> and <DOWN> to increase or decrease the sound sensitivity (u--0–100). Press <ENTER>. The product will return to the last selected mode. To run the COLORband T3 USB in preset color mode, follow the instructions below: Preset Color Press <MENU> repeatedly until C-- shows on the display. -
Page 14: Irc-6 Infrared Remote Control
IRC-6 Infrared The COLORband T3 USB is compatible with the IRC-6 infrared remote control from Chauvet. To activate IR mode, follow the instructions below: Remote Press <MENU> repeatedly until SET shows on the display. Control Press <ENTER> to accept. Press <UP> or <DOWN> to select On or OFF. -
Page 15: Master/Slave Mode (Wired)
Do not connect more than 31 slaves to the master. Master/Slave The D-Fi USB allows a single COLORband T3 USB product (the “master”) to control the actions of one or more COLORband T3 USB products (the “slaves”) without the need of Mode a DMX controller or DMX cables. -
Page 16: Maintenance
Softly drag any dirt or grime to the outside of the transparent surface. Gently polish the transparent surfaces until they are free of haze and lint. Always dry the transparent surfaces carefully after cleaning them. Page 16 of 19 COLORband T3 USB User Manual Rev. 1... -
Page 17: Technical Specifications
104 °F (40 °C) Convection Channel Range I/O Connectors 3, 6, 8, 9, or 14 3-pin XLR Ordering Item Code UPC Number Product Name 03031169 781462215170 COLORband T3 USB COLORband T3 USB User Manual Rev. 1 Page 17 of 19... -
Page 18: Returns
If you are located in Mexico, contact Chauvet Mexico. · If you are located in Benelux, contact Chauvet Europe BVBA. · If you are located in any other country, DO NOT contact Chauvet. Instead, contact your local distributor. See www.chauvetlighting.com for distributors outside the U.S., UK, Ireland, Mexico, or Benelux. -
Page 19: Contact Us
Outside the U.S., United Kingdom, Ireland, Mexico, or Benelux contact the dealer of record. Follow their instructions to request support or to return a product. Visit our website for contact details. COLORband T3 USB User Manual Rev. 1 Page 19 of 19...
