GB
Description of water heater
1) Switch
2) Front cover
3) Regulation handle
4) Water feeding pipe
5) Water outlet pipe
Technical data
Model
Capacity
Current
Tension
Power
Water pressure
Weight enamelled
Weight vidron
This appliance complies with the requirement set forth in EMC
89/336/EEC concerning the electromagnetic compatibility.
General remarks
Local regulations may provide restrictions for installation in bath-rooms.
Installations in charge of the purchaser the Merloni Termo Sanitari spa
cannot be held responsible for the damages caused by wrong installation
and for not following instructions included in this pamphlet, particularly
on:
1) The electric connection has to be in compliance with the relative para-
graphe.
2) The safety valve supplied with the apparatus has not be tempered with
neither substituted.
3) The installation has be carried out by qualified personnel.
Installation instructions
The range of the water-heaters includes models prepared for being fitted
over or under the pont of use (wash-basin, sink). The models to be fitted
under the point of use called "under sink" are shown by the letter UR or
S.
6
(see picture 8)
Above-sink
Under-sink
l:
10
A:
V ˜
W:
bar
kg:
6,6
kg:
6,6
Above-sink
Above-sink
Under-sink
15
see rating label
see rating label
see rating label
see rating label
7,4
12,8
7,5
10,4
30
