SERVICE
SAMSUNG R700
If there are the Contents not included in this book, please refer to K-zone Service Manual
R700
GENEVA
NP-R700xxxx/xxx
Manual
FEATURES
1. Simple & Essential Note PC
-. New Intel SantaRosa technology.
-. Internal 1.3M Camera
-. 17'' WXGA+ 200nit Glare LCD
-. Windows Vista Home/Premium
Supportable.
2. High Performance
-. Intel Core™2 Duo processor
-. Powerful connectivity.
-. Convenient Multi-media.
