SECTION 5
[REPLACEMENT UNITS]
ORDER NO.
0325900101 U 7800 BPF
0325900102 U 7800 RXPLL-A
0325900103 U 7800 RXPLL-B
0325900104 U 7800 FILTER
0325900105 U 7800 DIDSEL
0325900106 U 7800 DC-DC
0325900107 U 7800 OSC
0325900108 U 7800 PA
0325900109 U 7800 TUNER
0325900110 U 7800 FRONT

[FRONT UNIT]

REF ORDER
NO. NO.
W1 8900008940 CBL OPC-886 (P=1, N=10, L=75)
W2 8900008940 CBL OPC-886 (P=1, N=10, L=75)
W3 8900012870 CBL OPC-1331 (N=40, L=70)
W4 8900008670 CBL OPC-849 (N=30, L=70)
W5 8900008940 CBL OPC-886 (P=1, N=10, L=75)
W6 8900008940 CBL OPC-886 (P=1, N=10, L=75)
W7 8900012880 CBL OPC-1336 (N=18, L=70)
W8 8900008940 CBL OPC-886 (P=1, N=10, L=75)
W9 8900014870 CBL OPC-1332A (P=0.5, N=40, L=100)
W10 8900014730 CBL OPC-683A (P=1, N=10, L=110)
W11 8900008670 CBL OPC-849 (N=30, L=70)
W12 8900008670 CBL OPC-849 (N=30, L=70)
W13 8900008940 CBL OPC-886 (P=1, N=10, L=75)
W14 8900008670 CBL OPC-849 (N=30, L=70)
W15 8900008940 CBL OPC-886 (P=1, N=10, L=75)
W51 9025900020
EP1 6910015291 UBD LTA070B790F
EP11 6910011090 SUT RMS20-250-201-P
EP12 6910011090 SUT RMS20-250-201-P
EP13 0880001460 UBD EX-2500
EP101 6910015650 E.OTH S-G2218-3 (MOUNT PLATE)
EP102 6910015650 E.OTH S-G2218-3 (MOUNT PLATE)
[VR-A BOARD]
REF ORDER
NO. NO.
R1 7210002890 VAR RK161221005J/RV-308
R2 7210002890 VAR RK161221005J/RV-308
R3 7210002890 VAR RK161221005J/RV-308
R4 7210002890 VAR RK161221005J/RV-308
R11 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
R12 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
R13 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
R14 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
R15 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
R16 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
R17 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
R18 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k)
R21 7030003860 S.RES ERJ3GE JPW V
R22 7030003860 S.RES ERJ3GE JPW V
R23 7030003860 S.RES ERJ3GE JPW V
R24 7030003860 S.RES ERJ3GE JPW V
R25 7030003860 S.RES ERJ3GE JPW V
R26 7030003860 S.RES ERJ3GE JPW V
R27 7030003860 S.RES ERJ3GE JPW V
R28 7030003860 S.RES ERJ3GE JPW V
C11 4030006880 S.CER C1608 JB 1H 472K-T
C12 4030006880 S.CER C1608 JB 1H 472K-T
C13 4030006880 S.CER C1608 JB 1H 472K-T
C14 4030006880 S.CER C1608 JB 1H 472K-T
C15 4030006880 S.CER C1608 JB 1H 472K-T
C16 4030006880 S.CER C1608 JB 1H 472K-T
C17 4030006880 S.CER C1608 JB 1H 472K-T
C18 4030006880 S.CER C1608 JB 1H 472K-T

PARTS LIST

UNIT NAME
DESCRIPTION M.
LOCATION
DESCRIPTION M.
LOCATION
B 44.6/27
B 44.6/25.7
B 59.4/29.9
B 44.6/24.4
B 44.6/21.8
B 44.6/23.1
B 63.2/9.5
B 44.6/20.5
B 49.7/41.4
B 52.3/42.4
B 62.8/42.9
B 56.4/31.1
B 52.3/44.4
B 27.7/10.6
B 49.7/36.4
B 65.4/36.9
B 52.3/37.4
B 62.8/37.9
B 49.7/38.4
B 65.4/38.9
B 52.3/39.4
B 62.8/39.9
[VR-A BOARD]
REF ORDER
NO. NO.
J1 6510021720
J2 6510018921
J3 6510019971
J4 6510019971
EP2 6910012350
EP3 6910012350
EP5 6910012350
EP6 6910012350
EP7 6910012350
EP8 6910012350
EP9 6910012350
EP10 6910012350
EP11 6910012350
EP12 6910012350
EP13 6910012350
EP14 6910012350
EP15 6910012350
H/V
EP16 6910012350
EP17 6910012350
EP18 6910012350
EP19 6910012350
EP20 6910012350
EP21 6910012350
[VR-B BOARD]
REF ORDER
NO. NO.
R1 7210003160
R2 7210003160
R3 7030003520
R4 7030003520
R5 7030003520
R6 7030003520
C1 4030006880
C2 4030006880
C3 4030006880
C4 4030006880
J1 6510019971
H/V
[VR-C BOARD]
REF ORDER
NO. NO.
R1 7210003160
R2 7210003160
R3 7030003520
R4 7030003520
R5 7030003520
R6 7030003520
C1 4030006880
C2 4030006880
C3 4030006880
C4 4030006880
J1 6510019971
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
5 - 1
DESCRIPTION
S.CNR 30FLT-SM1-TB
S.CNR B8B-PH-SM4-TB (LF) (SN)
S.CNR 52808-1071
S.CNR 52808-1071
S.BEA MMZ1608Y 102BT
S.BEA MMZ1608Y 102BT
S.BEA MMZ1608Y 102BT
S.BEA MMZ1608Y 102BT
S.BEA MMZ1608Y 102BT
S.BEA MMZ1608Y 102BT
S.BEA MMZ1608Y 102BT
S.BEA MMZ1608Y 102BT
S.BEA MMZ1608Y 102BT
S.BEA MMZ1608Y 102BT
S.BEA MMZ1608Y 102BT
S.BEA MMZ1608Y 102BT
S.BEA MMZ1608Y 102BT
S.BEA MMZ1608Y 102BT
S.BEA MMZ1608Y 102BT
S.BEA MMZ1608Y 102BT
S.BEA MMZ1608Y 102BT
S.BEA MMZ1608Y 102BT
S.BEA MMZ1608Y 102BT
DESCRIPTION
VAR RV-317 (RK0972210)
VAR RV-317 (RK0972210)
S.RES ERJ3GEYJ 472 V (4.7 k)
S.RES ERJ3GEYJ 472 V (4.7 k)
S.RES ERJ3GEYJ 472 V (4.7 k)
S.RES ERJ3GEYJ 472 V (4.7 k)
S.CER C1608 JB 1H 472K-T
S.CER C1608 JB 1H 472K-T
S.CER C1608 JB 1H 472K-T
S.CER C1608 JB 1H 472K-T
S.CNR 52808-1071
DESCRIPTION
VAR RV-317 (RK0972210)
VAR RV-317 (RK0972210)
S.RES ERJ3GEYJ 472 V (4.7 k)
S.RES ERJ3GEYJ 472 V (4.7 k)
S.RES ERJ3GEYJ 472 V (4.7 k)
S.RES ERJ3GEYJ 472 V (4.7 k)
S.CER C1608 JB 1H 472K-T
S.CER C1608 JB 1H 472K-T
S.CER C1608 JB 1H 472K-T
S.CER C1608 JB 1H 472K-T
S.CNR 52808-1071
H/V
M.
LOCATION
B 57.6/41.1
B 20/4.5
B 9.5/33.1
B 9.5/17.9
B 13.6/29.6
B 16.5/30.6
B 16.5/32.6
B 13.7/34.7
B 13.7/36.6
B 16.5/35.7
B 13.7/33.4
B 13.6/23.7
B 13.6/22.4
B 5.3/21.5
B 13.6/20.4
B 5.3/19.3
B 13.6/18.4
B 16.1/17.4
B 13.6/16.4
B 16.1/15.5
B 13.6/14.6
B 12.5/13.2
B 13.6/25
H/V
M.
LOCATION
T 28.6/2.7
T 27.8/8.4
T 10.5/2.7
T 11.1/8.4
T 12.4/8.4
T 11.8/2.7
T 26.5/8.4
T 27.3/2.7
T 19.5/5
H/V
M.
LOCATION
T 28.6/2.7
T 27.8/8.4
T 10.5/2.7
T 11.1/8.4
T 12.4/8.4
T 11.8/2.7
T 26.5/8.4
T 27.3/2.7
T 19.5/5
S.=Surface mount
