The Router's Rear Panel

The rear panel of the wireless ADSL modem router contains port connections.
1
Figure 1-2
Viewed from left to right, the rear panel contains the following elements:
1. RJ-11 ADSL port for connecting the router to an ADSL line
2. Four Local Ethernet RJ-45 LAN ports for connecting the router to the local computers
3. AC power adapter outlet
4. Factory Default Reset push button
5. Wireless antenna

What You Need Before You Begin

You need to prepare the following before you can set up your router:
• Active Internet service provided by an ADSL account.
• The Internet Service Provider (ISP) configuration information for your ADSL account.
• ASDL microfilters as explained below.
Connecting the Router to the Internet
2
3
4
v1.1, 2006-2
Wireless ADSL Modem Router Setup Manual
5
1-3
