Regency HZ33CE
WARNING:
If the information in these instructions are not followed exactly,
a fire or explosion may result causing property damage,
personal injury or loss of life.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
Installation and service must be performed by a qualified
installer, service agency or the gas supplier.
Tested by:
919-120a
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
Gas Fireplace
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
Owners &
Installation Manual
MODEL: H
H
www.regency-fire.com
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appliance
Do not touch any electrical switch:
do not use any phone in your
building.
Immediately call your gas supplier
from a neighbour's phone. Follow
the gas supplier's instructions.
If you cannot reach your gas
supplier, call the fire department.
33CE-NG Natural Gas
Z
Z
33CE-LP Propane
HZ33CE Video
11/18/14
Advertisement
Table of Contents
Related Manuals for Regency HZ33CE-NG
Summary of Contents for Regency HZ33CE-NG
- Page 1 Owners & Regency HZ33CE Installation Manual Gas Fireplace MODEL: H 33CE-NG Natural Gas H 33CE-LP Propane HZ33CE Video www.regency-fire.com WARNING: FOR YOUR SAFETY If the information in these instructions are not followed exactly, What to do if you smell gas: a fire or explosion may result causing property damage, Do not try to light any appliance personal injury or loss of life.
- Page 2 To the New Owner: Congratulations! You are the owner of a state-of-the-art Gas Fireplace by REGENCY . The HZ33CE has been ® designed to provide you with all the warmth and charm of a fire at the flick of a switch. The model HZ33CE has been approved by Warnock Hersey for both safety and efficiency. As it also bears our own mark, it promises to provide you with economy, comfort and security for many trouble free years to follow. Please take a moment now to acquaint yourself with these instructions and the many features of your Regency Fireplace. ® Horizon Benefits Video HZ33CE Video Regency HZ33CE Gas Fireplace...
-
Page 3: Manufactured Mobile Home Requirements
MANUFACTURED MOBILE HOME REQUIREMENTS INFORMATION FOR MOBILE/MANUFACTURED HOMES AFTER FIRST SALE This Regency ® product has been tested and listed by Warnock Hersey as a Direct Vent Wall Furnace to the following standards: VENTED GAS FIREPLACE HEATERS ANSI Z21.88 - 2009 / CSA 2.33 - 2009 and GAS-FIRED APPLIANCES FOR USE AT HIGH ALTITUDES CAN / CGA 2.17-M91. This Direct Vent System Appliance must be installed in accordance with the manufacturer's installation instructions and the Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280, or the current Standard of Fire Safety Criteria for Manufactured Home Installations, Sites, and Communities ANSI/NFPA 501A, and with CAN/CSA Z240-MH Mobile Home Standard in Canada. This appliance installation must comply with the manufacturer's installation instructions and local codes, if any. In the absence of local codes follow the current National Fuel Gas Code, ANSI Z223.1 and the current National Electrical Code ANSI/NFPA 70 in the U.S.A., and the current CAN/CGA B149 Gas Installation Code and the current Canadian Electrical Code CSA C22.1 in Canada. This appliance comes equipped with a dedicated #8 Ground Lug for attachment of the ground wire to the steel chassis as applicable to local codes. The appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical Code, CSA C22.1. This appliance may only be installed in an aftermarket permanently located, manufactured (U.S.A only) or mobile home, where not prohibited by local codes. This appliance can only be used with the type of gas indicated on the rating plate. This appliance is not convertible for use with other gases, unless a certified kit is used. (Kit # 434-972). Ensure that structural members are not cut or weakened during installation. Regency HZ33CE Gas Fireplace... -
Page 4: Table Of Contents
886 S.I.T. Valve Description .........31 The Warranty: Limited Lifetime ........59 Gas Pipe Pressure Testing ..........31 Conversion from NG to LP ..........32 Wiring Diagrams ............38 Proflame system GT ...........38 Proflame system GTM ..........39 Proflame system GTMF with optional fan....39 Regency HZ33CE Gas Fireplace... -
Page 5: Safety Label
FOYER AU GAZ À ÉVACUATION - NE PAS UTILISER AVEC DUCOMBUSTIBLE SOLIDE. 919-119 Made in Canada / Fabrique au Canada For the State of Massachusetts, installation and repair must be done by a plumber or gas fitter licensed in the Commonwealth of Massachusetts. For the State of Massachusetts, flexible con- nectors shall not exceed 36 inches in length. For the State of Massachusetts, the appli- ances individual manual shut-off must be a t-handle type valve. The State of Massachusetts requires the installation of a carbon monoxide alarm in accordance with NFPA 720 and a CO alarm with battery back up in the same room where the gas appliance is installed. Regency HZ33CE Gas Fireplace... -
Page 6: Requirements
(e) A copy of all installation instructions for all Product Approved side wall horizontally vented gas fueled equipm ent, all venting instructions, all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipment at the completion of the installation. Regency HZ33CE Gas Fireplace... -
Page 7: Dimensions
2-1/2" 34-9/16" [64mm] [878mm] NAILING STRIP 3" (76mm) 26" 660mm 29-7/16" 747mm 4 SIDED FACEPLATE DIMENSIONS MANTEL DIMENSIONS 42-5/16" (1074mm) 47-9/16" 5-1/8" 3" (1207mm) 9" (76mm) (130mm) (229mm) 29-9/16" 8-1/8" (750mm) (206mm) 52-1/8" 2" (1324mm) (51mm) Regency HZ33CE Gas Fireplace... -
Page 8: Installation
ALERTED TO THE HAZARDS OF HIGH SURFACE TEMPERATURES, ESPE- 3. See general construction and assembly in- CIALLY THE FIREPLACE GLASS, AND structions. The appliance and vent should be SHOULD STAY AWAY TO AVOID BURNS enclosed. OR CLOTHING IGNITION. 4. This appliance must be connected to the speci- fied vent and termination cap to the outside of the building envelope. Never vent to another room or inside a building. Make sure that the vent is fitted as per Venting instructions. Regency HZ33CE Gas Fireplace... -
Page 9: Installation Checklist
Remote Control or Wall Thermostat Optional Fan Assembly Optional 4 sided Faceplate f) Optional Mantel 10. Wall Mounted ON/OFF Switch: Use the toggle wall switch supplied with the manual package. Use of a “decor” switch Diagram 1 causes higher resistance which is a problem on gas fireplaces. 11. Final check. B) Flat on Wall Corner Before leaving this unit with the customer, the C) Recessed into Wall/Alcove installer must ensure that the appliance is firing D) Corner correctly and operation fully explained to customer. Regency HZ33CE Gas Fireplace... -
Page 10: Clearances
Side Opening of Unit Horiztonal - Bottom 1-1/2" C: *Ceiling Vertical (Flex Vent) 1-1/2" 30" (762mm) Top Opening of Unit (room and/or alcove) Vertical (Rigid) 1-1/4" D: Alcove Width 84" (1219mm) Sidewall to Sidewall (Minimum) E: Alcove Depth 36" (914mm) Front to Back Wall (Maximum) F: Mantel 12" (305mm) G: Mantel Clearances From Top Opening of Unit 15-3/4" (400mm) Regency HZ33CE Gas Fireplace... -
Page 11: Mantel Leg Clearances
15-3/4" (400mm) 13-3/4"(349mm) Non-combustible material 11-3/4"(298mm) 3"(76mm) Standoff 24-1/4"(616mm) Top opening to floor of Unit Side View MANTEL LEG CLEARANCES Combustible mantel leg clearances from side of unit as per diagram: Top View Side opening of Unit 6-3/4" Allowable mantel leg projection 9" Regency HZ33CE Gas Fireplace... -
Page 12: Framing & Finishing
Non-combustible Material (3-1/2" x 34-9/16") Supplied with Unit Non-combustible Nailing Strip -1/2" back from unit face Finishing Material (ie. tile) Ensure finished material is brought to lip Non-combustible Finishing Material (ie. tile) Combustible Material 29-7/16" 747mm Regency HZ33CE Gas Fireplace... -
Page 13: Important Message
INSTALLATION IMPORTANT Regency Fireplace Products are designed, produced, tested and certified to the highest industry standards. The finishing of the walls surrounding your Regency Horizon Fireplace is as critical as the installation itself. The temperatures around linear gas fireplaces are typically higher than would be acceptable for combustible materials. Your Regency Horizon Fireplace is no exception to this rule. Therefore, the units are specified with non-combustible required materials to specific dimensions above and around the units. This is due to these areas reaching higher temperature levels than required/acceptable for a combustible material. To obtain the best, most durable finish around your fireplace, this calls for a high level of care and attention to the preparation and finish around this appliance, using only the highest quality materials, able to withstand the temperatures produced. By following the installation instructions in the manual exactly, you will increase your chances of a damage free finish. While every precaution is taken in providing the recommendations on preparation and finish, given the variations in paint quality, with temperature limits and workmanship in application, Regency is unable to guarantee the life of the joint compounds, paint or any other finish materials or workmanship applied to or used in any application surrounding the fireplace. This includes framing as well as finishing. Over time natural convection from any fireplace can cause discoloration in the area directly above the appliance. Lower quality paints, under-prepared finishes, poor applications, and any framing discrepancies or in the installation can cause this discoloration process to be expedited. Discoloration is not the responsibility of Regency Fireplace Products. This is outwith the control of Regency Fireplace Products Ltd., therefore not covered under any part of the warranty policy. While discoloration is not the responsibility of Regency Fireplace Products, we believe careful attention to the recommendations provided here will result in an aesthetically pleasing result free of issues outlined above. Regency HZ33CE Gas Fireplace... -
Page 14: Clean Finish
/ height of finished hearth (tile, carpet, etc.) The base of the fireplace, 4 sided faceplate or mantel should be level or higher Rough edges may be visible from an angle. than the finished hearth height. To maintain a clean finished edge - facing material edges may be finished with a J-style trim or metal cornerbead (both materials available at your local building or hardware store). IMPORTANT: Materials used must be NON-COMBUSTIBLE. Regency HZ33CE Gas Fireplace... -
Page 15: Framing Dimensions
31-3/4" (806mm) Framing Rise from Floor 0" (when not using a surround) 2" min (when using Mantel) 3-5/16" min (when using 4 sided Faceplate) J * F or Finish with Tile Framing Depth Vertical 22-3/4" (578mm) Vertical Rise Surround Horizontal 19-3/4" (502mm) Rigid / 16" (406mm) Flex Corner Wall Length 38-15/16" (988mm) Corner Facing Wall Width 55-1/2" (1410mm) Framed Chase Ceiling* 36" (914mm) Rigid 32" (812mm) Flex Vent Centerline Height* 30" (762mm) Rigid 26" (660mm) Flex Gas Connection Height* 1 1/2" (38mm) Gas Connection Inset* 7-3/16" (183mm) Gas Connection Width* 3" (76mm) * Measured from base of unit. Regency HZ33CE Gas Fireplace... -
Page 16: Venting Introduction
INSTALLATION VENTING INTRODUCTION The HZ33CE uses the "balanced flue" technology Co-Axial system. The inner liner vents products of combustion to the outside while the outer liner draws outside combustion air into the combustion chamber thereby eliminating the need to use heated room air for combustion and losing warm room air up the chimney. There are 5 vent systems approved for use with the HZ33CE: the Regency ® Direct Vent Flex System for Horizontal Terminations only and the Simpson Dura-Vent, Selkirk Direct-Temp, Amerivent Direct Vent and Security Secure Vent Systems for Horizontal and Vertical Terminations (see following "Venting" Sections for more details). Note: These flue pipes must not be connected to any other appliance. The gas appliance and vent system must be vented directly to the outside of the building, and never be attached to a chimney serving a separate solid fuel or gas burning appliance. Each direct vent gas appliance must use it's own separate vent system. Common vent systems are prohibited. (See "Rigid Pipe Venting System" for more details and exceptions). NOTE: Ensure compliance with the outside vent terminal location before cutting hole as both dimensions must be met. Regency HZ33CE Gas Fireplace... -
Page 17: Exterior Vent Termination Requirements
36"(90cm) Clearance to service regulator vent outlet 36"(90cm) Clearance to non-mechanical air supply inlet to building or the combustion air inlet to any other appliance 12"(30cm) 9" (23cm) Clearance to a mechanical air supply inlet 72"(1.8m) 36"(90cm) #3' (91cm) above if within 10' (3m) horizontally. ┼ Clearance above paved sidewalk or a paved driveway located on public property 84"(2.1m) ‡ Clearance under veranda, porch, deck, or balcony 12"(30cm) In accordance with current CSA B149.1, Natural Gas and Propane Installation Code In accordance with the current ANSI Z223.1/NFPA 54, National Fuel Gas Code A vent shall not terminate directly above a sidewalk or paved driveway which is located between two single family dwellings and serves both dwellings ┼ ‡ Permitted only if veranda, porch, deck, or balcony is fully open on a minimum of two sides beneath the floor * Clearance in accordance with local installation codes and the requirements of the gas supplier 3 feet (91cm) within a height of 15 feet (4.5m) above the meter / regulator assembly 3 feet (91cm) above - if within 10 feet (3m) horizontally Regency HZ33CE Gas Fireplace... -
Page 18: Regency ® Direct Vent Flex System
(8. screws #8 x 1-1/2" drill point, stainless steel (4. Notes: 1. Liner sections should be continuous without any joints or seams. 2. Only Flex pipe purchased from Regency ® may be used for Flex installations. Alternate Horizontal Termination... -
Page 19: Rigid Pipe Venting Systems
(502mm) 13 - 1/4" 12" When using Rigid Vent other than 8 -1/4" 3" to 7" Slip Simpson Dura-Vent, 3 screws must be 27" used to secure rigid pipe to adaptor. 13 - 1/4" 3" to 14-1/2 " Slip (686mm) The FPI AstroCap and FPI Riser Vent terminal are certified for installations using FPI venting systems as well as Simpson Dura-Vent Direct Vent, ® American Metal Products Ameri Vent Direct Vent, Security Secure Vent , Selkirk Direct-Temp. AstroCap is a proprietary trademark of FPI Fireplace ® Products International Ltd. Dura-Vent® and Direct Vent are registered and/or proprietary trademarks of Simpson Dura-Vent Co. Inc. Regency HZ33CE Gas Fireplace... -
Page 20: 4" X 6-5/8" Rigid Pipe Cross Reference Chart
4" X 6-5/8" RIGID PIPE CROSS REFERENCE CHART 4” X 6- 5/8” RIGID PIPE CROSS REFERENCE CHART Components from different Manufacturers may not be mixed. Not all Rigid Pipe components are available directly from FPI. Components from different Manufacturers may not be mixed. Not all rigid pipe components are available directly from Regency. Description Selkirk American Metal... - Page 21 Never allow the vent to run downward - this could cause high temperatures and may present a possible fi re hazard. Regency Fireplace Products . 6988 Venture St. . Delta, BC . Canada . V4G 1H4 . 604-946-5155 . www.regency-fi re.com...
-
Page 22: Rigid Pipe Venting Arrangements
Firestops are required at each floor level and whenever passing through a wall. • Maintain clearances to combustibles. • Vent must be supported at offsets. Note: Must use optional rigid pipe adapter when using rigid vent systems (Part # 510-994.. Regency HZ33CE Gas Fireplace... -
Page 23: Vertical Termination With Co-Linear Flex System
Alternate Approved Caps Exhaust 46DVA-VC Vertical Termination Cap Flue 46DVA-VCH High Wind Cap 46DVAGK 3" Co-linear Adapter with flashing Outer Pipe with Kit# 946-563 Air Intake Pipe Length Co-Linear Flex Rigid Pipe Adaptor Adapter # 510-994 with Kit# 946-563 45 Elbow Inner Pipe Adapter with Kit# 946-563 Regency HZ33CE Gas Fireplace... -
Page 24: Venting Arrangements - Vertical Terminations
VENTING ARRANGEMENTS - VERTICAL TERMINATIONS with Co-linear Flex System for both Residential & Manufactured Homes into Masonry Fireplaces Floor Floor Horizontal Distance (Feet) Horizontal Distance (Feet) Horizontal Distance (Feet) The shaded area in the diagrams show the allowable vertical terminations. Regency HZ33CE Gas Fireplace... -
Page 25: Horizontal Terminations
Maintain clearances to combustibles. 8"(0.2m) • Horizontal vent must be supported every 3 feet. • Firestops are required at each floor level and whenever passing through a wall. 2’ (0.6m) Minimum Minimum Simpson Dura-Vent Center-Line Flex Kit Center-Line Regency HZ33CE Gas Fireplace... - Page 26 1' Max. 1' Min. 3' Max. length is 30 feet with minimum of 8 feet total 2' Max. 2' Min. 5' Max. vertical and maximum 8 feet total horizontal. 3' Max. 4' Min. 6' Max. Please note minimum 4' Max. 6' Min. 7' Max. 1 foot between 90 elbows is required. 5' Max. 8' Min. 8' Max. Regency HZ33CE Gas Fireplace...
- Page 27 4' Max. 4' Min. Please note minimum 1 Please note minimum foot between 90 elbows is 4' Min. 7' Max. 5' Min. 5' Max. 5' Min. 1 foot between 90 required. elbows is required. 5' Min. 8' Max. 6' Min. 6' Max. 6' Min. For additional vertical venting with 2 x 90 elbows, refer to "Rigid Pipe Venting Arrangements" Section. Regency HZ33CE Gas Fireplace...
- Page 28 10 feet total vertical and B) 3' Min. 4' Max. 6' Min. max. 8 feet total horizontal. C) 4' Min. 5' Max. 7' Min. Please note min. 1 foot D) 5' Min. 6' Max. 8' Min. between 90 elbows is E) 6' Min. 7' Max. 9' Min. required. F) 7' Min. 8' Max. 10' Min. Regency HZ33CE Gas Fireplace...
-
Page 29: Unit Installation With Horizontal Termination
“Mill-Pac” sealant (supplied) to every in- pipe. ner pipe connection. Failure to do so may result in drafting or performance issues not covered under warranty. Silicone (red RTV) is optional. b) Horizontal runs of vent must be Regency HZ33CE Gas Fireplace... -
Page 30: Unit Installation With Vertical Termination
Important: Always check for gas leaks with a vent height may solve the problem. soap and water solution or gas leak detector. Do not use open flame for leak testing. 7. Ensure vent is vertical and secure the base of the flashing to the roof with roofing rails, slide storm collar over the pipe section and seal with a mastic. Diagram 2 8. Install the vertical termination cap by twist- Regency HZ33CE Gas Fireplace... -
Page 31: Pilot Adjustment
INSTALLATION GAS PIPE PRESSURE PILOT ADJUSTMENT HZ33CE-NG System Data TESTING Periodically check the pilot flames. Correct flame pattern has two strong blue flames: Conversion Kit# 434-972 (NG to LP) The appliance must be isolated from the gas 1 flowing around the flame sensor and 1... -
Page 32: Conversion From Ng To Lp
11. Reverse steps 2 - 1. Diagram 1 12. Check for gas leaks. 13. Check inlet and outlet pressures. 14. Check operation of fl ame control. Diagram 4 Installer Notice: These instructions must be left with the appliance 02/23/12 919-126 Regency HZ33CE Gas Fireplace... - Page 33 12) Reverse steps 5 and 4. (green) 13) Match the remote control to the receiver - see remote control instructions. 14) Reverse steps 2 and 1. 15) Check to ensure there are no gas leaks. Regency HZ33CE Gas Fireplace 10/13/09 918-857...
- Page 34 4) Remove DFC (digital fi rebox control box) from the fl oor of the unit. 9) Remove the hi/lo knob if installed by removing 2 screws as shown below. 5) Disconnect wire harness, ground wire and spark wire from DFC. Regency HZ33CE Gas Fireplace 918-858a 09/16/09...
- Page 35 19) Reverse steps 2 and 1. 20) Check to ensure there are no gas leaks. 14) To unattach these wires - un-clip from the wires on the stepper motor side as shown below. Press down this tab Regency HZ33CE Gas Fireplace 918-858a 09/16/09...
- Page 36 10) Install 4 - AA batteries into the receiver. Ensure correct polarity. 6) Plug in receiver DC supply wire from the unit wiring harness, to the DFC supply from the remote wiring harness - as shown below. Regency HZ33CE Gas Fireplace 03/11/14 918-867b...
- Page 37 fl oor of the unit with a velcro pad. Heat shield 13) From the remote wire harness, plug the FCM wire into the fan control module. Be careful not to damage. FCM wire Fan Control Module Regency HZ33CE Gas Fireplace...
-
Page 38: Wiring Diagrams
Switch or Optional Wall Switch Pro ame DFC Board DFC Wire Harness Assembly Note: 4 AA batteries must be installed to operate Optional AC Adaptor the burner switch. Do not use a 9 volt battery. Battery Holder 1 of 10 IMPORTANT: If the optional remote control is used, the AA batteries normally installed into the battery holder must be removed. The AA batteries in the receiver now operate the unit. Having AA batteries in both the battery holder and receiver will damage the gas valve. PROFLAME SYSTEM GT Proflame System Configuration 886 GTMF Wire Diagram SureFire™ Switch Optional AC Adaptor Regency HZ33CE Gas Fireplace... -
Page 39: Proflame System Gtm
(for mobile home) Neutral Black Green Live Ground 120V AC 60 Hz Black Black Black Fan Thermodisc (normally open) ground wire NOTE: Wiring schematics for HZ54E (120 Volts), Regency HZ33CE Gas Fireplace plug-in fan circuit with speed control switch on wall. - Page 40 INSTALLATION AC POWER ADAPTOR INSTALLATION (FOR SUREFIRE SYSTEMS) Regency HZ33CE Gas Fireplace...
-
Page 41: Installing The Optional Fan (Prior To Unit Installation)
These fans collect a lot of dust from within your home. Ensure you maintain these fan motors on a regular basis by vacuuming out the fan blades and housing using a soft brush nozzle. Diagram 4 Regency HZ33CE Gas Fireplace... -
Page 42: Optional Fan Wiring Diagram
2. Remove Flush door (See instructions in this Manual). 3. Remove inner panels (See instructions in this Manual). 4. Remove glass crystals or ceramic stones. 5. Remove the base tray by removing 6 screws in the locations shown below. Diagram 2 Diagram 1: Remove the 6 screws and then lift out the base tray Regency HZ33CE Gas Fireplace... - Page 43 These fans collect a lot of dust from within your home. Ensure you maintain these fan motors on a regular basis by vacuuming out the fan blades and housing using a soft brush nozzle. Diagram 6 Regency HZ33CE Gas Fireplace...
-
Page 44: Optional Wall Thermostat
Full open 22 GA. 9 Ft. CAUTION: Carbon will be produced if air shutter is tightly closed. Note: Any damage due to carboning resulting from improperly setting the aeration controls is NOT covered under warranty. BATTERY INSTALLATION 1. 4 AA batteries must be installed in the battery pack to operate the burner switch. 2. Install 2 AA batteries per side and connect as shown below - the battery pack is located on the lower left side of the unit. Regency HZ33CE Gas Fireplace... -
Page 45: Optional Reflective Panel Installation
4. With the top panel in place - install back panel. The back panel fits under the top panel, push the top panel up to fit back panel into position. (Diagram 3) Completed Panel Installation Diagram 3 Note: Diagram is shown without a burner. Back Panel Regency HZ33CE Gas Fireplace... -
Page 46: Glass Crystals And Optional Stones
The Burner and Firebox Floor should not be visible when the flame is out. OPTIONAL SPA STONES INSTALLATION (AROUND BURNER NOTE: Spa stones are NOT to be placed anywhere on the burner tube or Pilot assembly area. Regency HZ33CE Gas Fireplace... -
Page 47: Optional Log Set Installation
HZ33CE shown - Logs 1 and 5 in position. 9. Place Log 4 on the glass on the right side in location shown below. HZ33CE - install bracket, left side HZ33CE shown - Logs 1,4 and 5 in position. 07/10/13 919-265 Regency HZ33CE Gas Fireplace... - Page 48 Log 2 rests on the burner tray as shown below. 13. Adjust aeration, see unit manual for setting. HZ30E use top pin landing HZ33CE shown - Final Install HZ30E shown - installing Log 2 919-265 07/10/13 Regency HZ33CE Gas Fireplace...
- Page 49 6. Place lava embers/rocks on glass - ensure rocks do not block pilot. Do not place lava rocks/embers too close to logs as this may cause carboning. 7. Adjust aeration, see unit manual for setting. HZ30E shown - Final Install Regency HZ33CE Gas Fireplace 07/10/13 919-265...
-
Page 50: Glass Screen Guard And Glass Door Installation
STANDARD FLUSH DOOR AND SCREEN Both the standard flush door and glass screen guard come with a black frame. To install the glass screen guard simply hook the over top of the flush glass door see Diagram 1. Install both screen and glass door by hooking the top door flange onto the top of the unit and swing the door towards the unit, Diagram 2. Be careful that the glass gasket does not roll up; there must be a gap between the gasket and the door lip to ensure that the door sits securely on the unit. See Diagram 3. Glass Door Screen Door Diagram 2 Diagram 1 Diagram 3 Use the hook to pull the spring out until you can put the hook into the slot on the bottom door bracket. Repeat for 2nd spring. See Diagram 4. Diagram 4 To remove the flush door and screen, reverse the above steps. Regency HZ33CE Gas Fireplace... -
Page 51: Optional 4-Sided Faceplate Installation
Diagram 2 -Bracket screw locations on unit. 2. Install four (4) wood screws, two (2) on each side of the bracket into the wall studs as shown below. Diagram 6 -Final Install Diagram 3 -Bracket screw locations. Regency HZ33CE Gas Fireplace... -
Page 52: Optional Mantel Installation
Diagram 2 -Bracket screw locations on unit. 2. Install four (4) wood screws, two (2) on each side of the bracket into the wall studs as shown below. Diagram 3 -Bracket screw locations into stud. Diagram 6 -Final Install Regency HZ33CE Gas Fireplace... -
Page 53: Operating Instructions
The glass should be cleaned after the unit has cooled down or the film will bake on and become very difficult to remove. Use a non-abrasive cleaner and DO NOT ATTEMPT TO CLEAN THE GLASS WHILE IT IS HOT. Regency HZ33CE Gas Fireplace... -
Page 54: Copy Of Lighting Plate Instructions
If service is to be performed - you must disconnect power to the unit, from the battery pack, refer to manual. Appuyez sur le bouton ON / OFF Si le service est effectuée, vous devez débrancher l'appareil, du bloc-piles, voir le manuel d'instruction pour plus de détails. DO NOT REMOVE THIS INSTRUCTION PLATE 918-628b Regency HZ33CE Gas Fireplace... -
Page 55: Maintenance Instructions
& reinstalled appliance with the glass panels in accordance with the manufacturer's removed, cracked or broken. instructions. Replacement of the glass panels 8. Verify operation after servicing. should be done by a licensed or qualified service person. Regency HZ33CE Gas Fireplace... -
Page 56: Valve Tray Replacement
Diagram 1: Remove the 6 screws and then lift out the base tray 5. Remove 2 screws in location shown below - slide burner to the right then lift out. (See Diagram 2. Diagram 5: Lift out Valve Tray Assembly Installing Valve Diagram 2 1. Install new Valve Tray Assembly. 6. Disconnect the inlet gas line. 2. Reverse steps 8-1. 7. Disconnect the EV1, EV2, and ground wires from the valve - as shown below. Ground Diagram 3 Regency HZ33CE Gas Fireplace... -
Page 57: Parts List
Fan Assembly 770-523 Thermodisc Cage Assy 437-018 Access panel 904-434 Orifice #47 NG 437-024 Screen Frame 904-241 Orifice #56 LP 433-538 Door Assembly 911-004 886 Proflame Valve 437-023 **Clean Front Face 437-578 Valve Assembly 433-511 **Firebox Assembly 437-012 Bracket Not a replacement part 437-525 Burner Assembly 911-006 Pilot Assembly - NG 437-015 Burner Filler Tray Assy 911-007 Pilot Assembly - LP 437-004 Pilot Cover 919-120 Manual Regency HZ33CE Gas Fireplace... -
Page 58: Accessories
PARTS LIST ACCESSORIES Part # Description 434-044 Enamel Panel Top 434-042 Enamel Panel Left 434-041 Enamel Panel Right 434-043 Enamel Panel Back Regency HZ33CE Gas Fireplace... -
Page 59: Warranty
It is the general practice of FPI to charge for larger, higher priced replacement parts and issue credit once the replaced component has been returned to FPI and evaluated for manufacturer defect. The authorized selling dealer is responsible for all in-field service work carried out on your Regency product. FPI will not be liable for results or costs of workmanship from ® unauthorized service persons or dealers. At all times FPI reserves the right to inspect product in the field which is claimed to be defective. All claims must be submitted to FPI by authorized selling dealers. It is essential that all submitted claims provide all of the necessary information including customer name, purchase date, serial #, type of unit, problem, and part or parts requested, without this information the warranty will be invalid. Exclusions: This limited Lifetime Warranty does not extend to or include paint, door or glass gasketing or trim. At no time will FPI be liable for any consequential damages which exceed the purchase price of the unit. FPI has no obligation to enhance or modify any unit once manufactured. ie. as products evolve, field modifications or upgrades will not be performed. FPI will not be liable for travel costs for service work. Installation and environmental problems are not the responsibility of the manufacturer and therefore are not covered under the terms of this warranty policy. Embers, rockwool, gaskets, door handles and paint are not covered under the terms of this warranty policy. Any unit which shows signs of neglect or misuse is not covered under the terms of this warranty policy. The warranty will not extend to any part which has been tampered with or altered in any way, or in our judgment has been subject to misuse, improper installation, negligence or accident, spillage or downdrafts caused by environmental or geographical conditions, inadequate ventilation, excessive offsets, negative air pressure caused by mechanical systems such as furnaces, fans, clothes dryer, etc. Freight damage to stoves and replacement parts is not covered by warranty and is subject to a claim against the freight carrier by the dealer. FPI will not be liable for acts of God, or acts of terrorism, which cause malfunction of the appliance. Performance problems due to operator error will not be covered by this warranty policy. Products made or provided by other manufacturers and used in conjunction with the operation of this appliance without prior authorization from FPI, may nullify your warranty on this product. Any alteration to the unit which causes sooting or carboning that results in damage to the interior / exterior faceplate is not the responsibility of FPI. * Subsidy according to job scale as predetermined by FPI. Regency HZ33CE Gas Fireplace... - Page 60 Register your Regency warranty online ® www.regency-fire.com Reasons to register your product online today! • View and modify a list of all your registered products. • Request automatic email notification of new product updates. • Stay informed about the current promotions, events, and spe- cial offers on related products.
