PC Card Files
Displays a list of all the files stored in the PC card so that you can
select a file you want to display. You can also sort files by file name or
date, or display the file.
Although a list of all the files in the PC card is displayed, you can
view files in text, HTML, JPEG and BMP format only.
Selecting "Execute" displays the file you selected.
Help
Contents
Provides online help menus. An undelined link means that you can
move to an adjustment item directly.
Selecting the underlined link and pressing ENTER moves to the corre-
sponding adjustment item.
Source Information
Displays the status of the current signal. This dialog box has three
pages.
Projector Information
Displays the information for your projector such as lamp usage, serial
number and version number etc..
Displaying Current Status of Link Mode
When selecting the tab "Page 4 ", you will get the following dialog
box.
Master ID
Status
Connected PJ
Slave No.
ID
Status
Page buttons
Reconnect button
Status items
Running
Cooling Lamp
Standby
Communication Error : A communication error has occurred
Connecting...
Error Standby
Test Pattern
Nine test patterns can be selected. You can turn on or off red, green, or
blue respectively.
E – 41
: Indicates the Master projector
: Indicates the status of the master projector
: Indicates number of connected slave pro-
jectors
: Indicates serial number of the slave projec-
tor
: Indicates ID of a slave projector
: Indicates the status of the slave projector
: Turns pages. One screen displays informa-
tion of 3 projectors only. Information of a
maximum of 16 projectors can be displayed
using these page buttons.
: Confirms connection of all linked projec-
tors
: The projector is now working
: The fan is now cooling the lamp
: The projector is in stand-by
: The projector is now verifying for connec-
tion
: An error caused the projector to enter the
stand-by mode
