Page 1 Projector PA803U/PA723U/PA653U/ PA853W/PA703W/PA903X User’s Manual Please visit our web site for User’s Manual in the latest version: http://www.nec-display.com/dl/en/pj_manual/lineup.html • The PA723U and PA703W are not distributed in North America. Model No. NP-PA803U/NP-PA723U/NP-PA653U/NP-PA853W/NP-PA703W/NP-PA903X...
Page 2 Ver. 1 11/16 • Apple, Mac, Mac OS, and MacBook are trademarks of Apple Inc. registered in the U.S. and other countries. • Microsoft, Windows, Windows Vista, Internet Explorer, .NET Framework and PowerPoint are either a registered trademark or trademark of Microsoft Corporation in the United States and/or other countries. • MicroSaver is a registered trademark of Kensington Computer Products Group, a division of ACCO Brands. • Adobe, Adobe PDF, Adobe Reader, and Acrobat are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries. • AccuBlend, NaViSet, and Virtual Remote are trademarks or registered trademarks of NEC Display Solutions, Ltd. in Japan, in the United State and other countries. • The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing, LLC in the United States and other countries. • DisplayPort and DisplayPort Compliance Logo are trademarks owned by the Video Electronics Standards Associa- tion. • HDBaseT™ is a trademark of HDBaseT Alliance. • Trademark PJLink is a trademark applied for trademark rights in Japan, the United States of America and other countries and areas. • Blu-ray is a trademark of Blu-ray Disc Association. • CRESTRON and ROOMVIEW are registered trademarks of Crestron Electronics, Inc. in the United States and other countries.
Page 3: Important Information
Important Information Safety Cautions Precautions Please read this manual carefully before using your NEC projector and keep the manual handy for future reference. CAUTION To turn off main power, be sure to remove the plug from power outlet. The power outlet socket should be installed as near to the equipment as possible, and should be easily accessible. CAUTION TO PREVENT SHOCK, DO NOT OPEN THE CABINET. THERE ARE HIGH-VOLTAGE COMPONENTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol warns the user that uninsulated voltage within the unit may be sufficient to cause electrical shock. Therefore, it is dangerous to make any kind of contact with any part inside of the unit. This symbol alerts the user that important information concerning the operation and maintenance of this unit has been provided. The information should be read carefully to avoid problems. WARNING: TO PREVENT FIRE OR SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. DO NOT USE THIS UNIT’S PLUG WITH AN EXTENSION CORD OR IN AN OUTLET UNLESS ALL THE PRONGS CAN BE FULLY INSERTED. DOC Compliance Notice (for Canada only) This Class B digital apparatus complies with Canadian ICES-003. Machine Noise Information Regulation - 3. GPSGV, The highest sound pressure level is less than 70 dB (A) in accordance with EN ISO 7779.
Page 4: Important Safeguards
Important Information WARNING TO CALIFORNIA RESIDENTS: Handling the cables supplied with this product will expose you to lead, a chemical known to the State of California to cause birth defects or other reproductive harm. WASH HANDS AFTER HANDLING. RF Interference (for USA only) WARNING The Federal Communications Commission does not allow any modifications or changes to the unit EXCEPT those specified by NEC Display Solutions of America, Inc. in this manual. Failure to comply with this government regulation could void your right to operate this equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
Page 5 Important Information WARNING • Do not cover the lens with the lens cap or equivalent while the projector is on. Doing so can lead to melting of the cap due to the heat emitted from the light output. • Do not place any objects, which are easily affected by heat, in front of the projector lens. Doing so could lead to the object melting from the heat that is emitted from the light output. The below pictogram indicated on the cabinet means the precaution for avoiding to place objects in front of the projector lens. This projector can be installed any angle within vertical. For portrait installation, install the projector with the intake vent at the bottom. Observe precautions for portrait installation. * A customized stand is required to be attached to the projector. (→ page 150) 130 mm or more Fire and Shock Precautions • Ensure that there is sufficient ventilation and that vents are unobstructed to prevent the build-up of heat inside your projector. Allow enough space between your projector and a wall. (→ page viii) • Do not try to touch the exhaust vents on the left rear and the rear (when seen from the front) as it can become heated while the projector is turned on and immediately after the projector is turned off. Parts of the projector may become temporarily heated if the projector is turned off with the POWER button or if the AC power supply is disconnected during normal projector operation. Use caution when picking up the projector.
Page 6 Important Information • Do not look into the lens while the projector is on. Serious damage to your eyes could result. The following label, that is indicated at the lens-mounting-section on the projector cabinet, describes this projector is categorized in the risk group 2 of IEC62471-5: 2015. As with any bright light source, do not stare into the beam, RG2 IEC 62471-5: 2015. • Perform the adjustment from behind or from the side of the projector. Adjusting from the front could expose your eyes to strong light which could injure them. • Keep any items (magnifying glass etc.) out of the light path of the projector. The light path being projected from the lens is extensive, therefore any kind of abnormal objects that can redirect light coming out of the lens, can cause an unpredictable outcome such as a fire or injury to the eyes. • Do not place any objects, which are easily affected by heat, in front of a projector exhaust vent. Doing so could lead to the object melting or getting your hands burned from the heat that is emitted from the exhaust vent. • Handle the power cord carefully. A damaged or frayed power cord can cause electric shock or fire. - Do not use any power cord other than the one supplied with the projector. If the supplied power cord does not satisfy requirements of your region's safety standard, and voltage and current for your region, make sure to use the power cord that conforms to and satisfies them. - Do not bend or tug the power cord excessively. - Do not place the power cord under the projector, or any heavy object. - Do not cover the power cord with other soft materials such as rugs. - Do not heat the power cord. - Do not handle the power plug with wet hands. • Turn off the projector, unplug the power cord and have the projector serviced by a qualified service personnel under the following conditions: - When the power cord or plug is damaged or frayed. - If liquid has been spilled into the projector, or if it has been exposed to rain or water. - If the projector does not operate normally when you follow the instructions described in this user’s manual.
Page 7 Remote Control Precautions • Handle the remote control carefully. • If the remote control gets wet, wipe it dry immediately. • Avoid excessive heat and humidity. • Do not short, heat, or take apart batteries. • Do not throw batteries into fire. • If you will not be using the remote control for a long time, remove the batteries. • Ensure that you have the batteries’ polarity (+/−) aligned correctly. • Do not use new and old batteries together, or use different types of batteries together. • Dispose of used batteries according to your local regulations. Note for Canadian Environmental Protection Act, 1999 The lamp(s) in this product contains mercury. Please dispose according to your local authority law. FOR MORE INFORMATION, CONTACT: NEC Display Solutions of America, Inc. 500 Park Boulevard, Suite 1100, Itasca, Illinois 60143-1248 TELEPHONE 800-836-0655 www.necdisplay.com Note for US Residents The lamp in this product contains mercury. Please dispose according to Local, State or Federal Laws.
Page 8: Lamp Replacement
Important Information Lamp Replacement • Use the specified lamp for safety and performance. • To replace the lamp, follow all instructions provided on page 156. • Be sure to replace the lamp and filter when the message [THE LAMP HAS REACHED THE END OF ITS USABLE LIFE. PLEASE REPLACE THE LAMP. USE THE SPECIFIED LAMP FOR SAFETY AND PERFORMANCE.] appears. If you continue to use the lamp after the lamp has reached the end of its usable life, the lamp bulb may shatter, and pieces of glass may be scattered in the lamp case. Do not touch them as the pieces of glass may cause injury. If this happens, contact your dealer for lamp replacement. A Lamp Characteristic The projector has a discharge lamp for special purposes as a light source. A lamp has a characteristic that its brightness gradually decreases with age. Also repeatedly turning the lamp on and off will increase the possibility of its lower brightness.
Page 9: Auto Power Off Function
Important Information Health precautions to users viewing 3D images Before viewing, be sure to read health care precautions that may be found in the user’s manual included with your 3D eyeglasses or your 3D compatible content such as Blu-ray Discs, video games, computer’s video files and the like. To avoid any adverse symptoms, heed the following: • Do not use 3D eyeglasses for viewing any material other than 3D images. • Allow a distance of 2 m/7 feet or greater between the screen and a user. Viewing 3D images from too close a distance can strain your eyes. • Avoid viewing 3D images for a prolonged period of time. Take a break of 15 minutes or longer after every hour of viewing. • If you or any member of your family has a history of light-sensitive seizures, consult a doctor before viewing 3D images. • While viewing 3D images, if you get sick such as nausea, dizziness, queasiness, headache, eyestrain, blurry vision, convulsions, and numbness, stop viewing them. If symptoms still persist, consult a doctor. • View 3D images from the front of the screen. Viewing from an angle may cause fatigue or eyestrain. AUTO POWER OFF Function The factory default setting for [AUTO POWER OFF] is 15 minutes. If no input signal is received and no operation is performed on the projector during 15 minutes, the projector is automatically powered off for saving the power con- sumption. In order to control the projector by an external device, set the [AUTO POWER OFF] to [OFF]. Please refer page 133 for details.
Page 10 Important Information Clearance for Installing the Projector Allow ample clearance between the projector and its surroundings as shown below. The high temperature exhaust coming out of the device may be sucked into the device again. Avoid installing the projector in a place where air movement from the HVAC is directed at the projector. Heated air from the HVAC can be taken in by the projector's intake vent. If this happens, the temperature inside the projector will rise too high causing the over-temperature protector to automatically turn off the projectors power. Example 1 – If there are walls on both sides of the projector. 20 cm/7 .9" or greater 13 cm/5.1" or greater Lamp cover Filter cover (Intake vent) NOTE: The drawing shows the proper clearance required for the left and right of the projector assuming sufficient clearance has been kept for the front, back and top of the projector.
Page 11: Table Of Contents
Table of Contents Important Information .................... i 1. Introduction ......................1 ❶ What’s in the Box? ......................1 ❷ Introduction to the Projector ....................2 Congratulations on Your Purchase of the Projector ...........2 Installation .........................2 Videos ........................2 Network ........................3 Energy-saving ......................3 Maintenance ......................4 About this user’s manual ...................5 ❸ Part Names of the Projector ...................6 Front/Top ........................6 Rear ..........................8 Controls/Indicator Panel ....................9 Terminals ........................ 10 ❹ Part Names of the Remote Control ................11 Battery Installation ....................12 Remote Control Precautions ...................12 Operating Range for Wireless Remote Control ............13...
Page 12 Table of Contents 3. Convenient Features ..................33 ❶ Turning off the Image and Sound ..................33 ❷ Shift the On-Screen Menu displaying position ..............34 ❸ Freezing a Picture ......................35 ❹ Enlarging a Picture .......................35 ❺ Changing Eco Mode/Checking Energy-Saving Effect Using Eco Mode [ECO MODE] .36 Checking Energy-Saving Effect [CARBON METER] ..........37 ❻ Correcting Horizontal and Vertical Keystone Distortion [CORNERSTONE] ....38 ❼ Operation for the On-Screen Menu by a commercially available USB mouse ....40 Menu operation .......................40 Menu position control ....................41 Geometric correction ....................41 ❽ Preventing the Unauthorized Use of the Projector [SECURITY] ........43 ❾ Projecting 3D videos .....................46 Procedure to watch 3D videos using this projector ..........46 When videos cannot be viewed in 3D ..............48 ❿ Controlling the Projector by Using an HTTP Browser ...........49 ⓫ Storing Changes for Lens Shift, Zoom, and Focus [LENS MEMORY]......56 To store your adjusted values in [REF. LENS MEMORY]: ........56...
Page 13 Table of Contents ❻ Menu Descriptions & Functions [DISPLAY] ..............101 [PIP/PICTURE BY PICTURE] ................101 [GEOMETRIC CORRECTION] ................103 [EDGE BLENDING] ....................108 [MULTI SCREEN]....................109 ❼ Menu Descriptions & Functions [SETUP] ..............111 [MENU(1)] ......................111 [MENU(2)] ......................113 [INSTALLATION] ....................114 [CONTROL] ......................118 [NETWORK SETTINGS] ..................125 [SOURCE OPTIONS] ...................130 [POWER OPTIONS] .....................132 Returning to Factory Default [RESET] ..............134 ❽ Menu Descriptions & Functions [INFO.] ..............136 [USAGE TIME] ......................136 [SOURCE(1)] ......................137 [SOURCE(2)] ......................137...
Page 14 Table of Contents 8. Appendix ......................162 ❶ Throw distance and screen size .................162 Lens types and throw distance ................162 Tables of screen sizes and dimensions ..............166 Lens shifting range ....................167 ❷ Compatible Input Signal List ..................169 ❸ Specifications ......................172 ❹ Cabinet Dimensions ....................175 ❺ Mounting the cable cover (sold separately) ..............176 ❻ Pin assignments and signal names of main connectors ..........177 ❼ Changing the Background Logo (Virtual Remote Tool) ..........179 ❽ Troubleshooting ......................180 Feature of each indicator ..................180 Indicator Message (Status message) ..............180 Indicator Message (Error message) ..............182 Explanation on the POWER indicator and standby state ........183 Common Problems & Solutions ................185 If there is no picture, or the picture is not displayed correctly........187 ❾ PC Control Codes and Cable Connection ..............188 ❿ Troubleshooting Check List ..................191 ⓫ REGISTER YOUR PROJECTOR! (for residents in the United States, Canada, and...
Page 15: Introduction
For North America only Limited warranty For customers in Europe: You will find our current valid Guar- antee Policy on our Web Site: • Important Infomation (For North NEC Projector CD-ROM www.nec-display-solutions.com America: 7N8N7661) User’s manual (PDF) • Quick Setup Guide (For North (7N952551) America: 7N8N7671) (For Other...
Page 16: ❷ Introduction To The Projector
Congratulations on Your Purchase of the Projector This projector is one of the very best projectors available today. The projector enables you to project precise images up to 500 inches across (measured diagonally) from your PC or Mac computer (desktop or notebook), VCR, Blu-ray player, or document camera. You can use the projector on a tabletop or cart, you can use the projector to project images from behind the screen, and the projector can be permanently mounted on a ceiling* . The remote control can be used wirelessly. Do not attempt to mount the projector on a ceiling yourself. The projector must be installed by qualified technicians in order to ensure proper operation and reduce the risk of bodily injury. In addition, the ceiling must be strong enough to support the projector and the installation must be in accordance with any local building codes. Please consult your dealer for more information. Installation • Liquid crystal type high brightness/high resolution projector Model Brightness Resolution Aspect Ratio PA803U 8000 lm WUXGA (1920 × 1200) 16:10 PA723U 7200 lm WUXGA (1920 × 1200) 16:10 PA653U 6500 lm WUXGA (1920 × 1200) 16:10 PA853W 8500 lm WXGA (1280 × 800) 16:10 PA703W 7000 lm WXGA (1280 × 800)
Page 17: Network
Extron XTP transmitter connected with the projector.. • Convenient utility software (User Supportware) provided as standard This projector supports our utility software (NaViSet Administrator 2, Virtual Remote Tool, etc.). NaViSet Administrator 2 helps you control the projector by a computer via wired LAN connection. Virtual Remote Tool helps you perform operations by a virtual remote control such as projector's power on or off and signal selection via wired LAN connection. Moreover, it has function to send an image to the projector and register it as the logo data. Please visit our web site for downloading each software. URL: http://www.nec-display.com/dl/en/index.html Energy-saving • Energy-saving design with a standby power consumption of 0.24W (100-130 V) / 0.30W (200-240 V) When the on-screen menu’s standby mode is set to “NORMAL” , the power consumption in the standby mode activat- ing the Power Management is 0.24W (100-130 V) / 0.30W (200-240 V) and 0.20W (100-130 V) / 0.26W (200-240 V) when LAN is ineffective. • “Eco mode” for low power consumption and “Carbon Meter” display The projector is equipped with an “eco mode” for reducing power consumption during use. Furthermore, the power-saving effect when the eco mode is set is converted into the amount of reductions of CO emissions and this is indicated on the confirmation message displayed when the power is turned off and at “Information” on the...
Page 18: Maintenance
1. Introduction Maintenance • Maximum replacement time for the lamp is 5000 hours and for the filter is 10000 hours. When used in the eco mode, the lamp replacement time* is extended to a maximum of 5000 hours. * This time is not guaranteed. At the same time, the maximum usage time for the filter is 10000 hours.** ** It is vary depending on the projector installation circumstances. * Actual menus may be different from the menu images in this user’s manual.
Page 19: About This User's Manual
1. Introduction About this user’s manual The fastest way to get started is to take your time and do everything right the first time. Take a few minutes now to review the user’s manual. This may save you time later on. At the beginning of each section of the manual you’ll find an overview. If the section doesn’t apply, you can skip it. Notation by Resolution These indicate the descriptions of the model groups according to the resolution of the liquid crystal panels. WUXGA Type Applicable to models PA803U/PA723U/PA653U. WXGA Type Applicable to models PA853W/PA703W. XGA Type Applicable to models PA903X. *The description applies to all models if the type name is not indicated. How to Differentiate the Model Group P A 8 0 3 U “U” refers to a WUXGA type. “W” refers to a WXGA type. “X” refers to a XGA type. Model Name Symbol Example: PA803U “NP-” is not indicated on top of the cabinet.
Page 20: ❸ Part Names Of The Projector
1. Introduction ❸ Part Names of the Projector Front/Top The lens is sold separately. The description below is for when the NP13ZL lens is mounted. Zoom Lever/Zoom Ring (→ page Indicator Section (→ page 9) Remote Sensor (→ page 13) Remote Sensor (located on the front and the rear) Exhaust vent (→ page 13) Heated air is exhausted from here. Lamp Cover (→...
Page 21 1. Introduction Filter cover Preparation: Remove the filter cover from the projector. Refer to the clause “Replacing the filter” on page 160 about the filter cover installation. 1. Insert the round protrusion at the filter cover strap end (resinoid strap) to the hole on the filter cover. 2. Insert the square protrusion at the opposite end of the filter cover strap to the hole on the projector body and rotate the strap 90°for fixation.
Page 22: Rear
1. Introduction Rear Remote Sensor (located on the Terminals front and the rear) (→ page 10) (→ page 13) Exhaust vent Heated air is exhausted from here. Intake vent / Filter (→ page 153, 160) Built-in Security Slot ( Cable cover connection AC IN Terminal (right and left) Connect the supplied power cord’s...
Page 23: Controls/Indicator Panel
1. Introduction Controls/Indicator Panel 11 12 (POWER) Button (→ page 17, 31) 2. POWER Indicator (→ page 16, 17, 31, 180, 183) 3. STATUS Indicator (→ page 180, 183) 4. LAMP Indicator (→ page 156, 180, 183) 5. TEMP. Indicator (→ page 36, 180, 183) 6. INPUT Button (→ page 19) 7. MENU Button (→ page 76) 8. ▲▼◀▶ / Volume Buttons ◀▶ (→ page 30, 76) 9. ENTER Button (→ page 76) 10. EXIT Button (→ page 76) 11. FOCUS Button (→ page 26) 12.
Page 24: Terminals
Terminals 13 10 1. HDMI 1 IN Terminal (Type A) 13. REMOTE Terminal (Stereo Mini) (→ page 144, 145, 147) Use this terminal for wired remote control of the projector using the NEC remote control for PX750U/ 2. HDMI 2 IN Terminal (Type A) PH1000U/PH1400U series. (→ page 144, 145, 147) Connect the projector and our remote control, RD- 3. DisplayPort IN Terminal 465E, using a commercially available wired remote (→ page 144)
Page 25: ❹ Part Names Of The Remote Control
1. Introduction ❹ Part Names of the Remote Control 9. Edge Blend. Button 28. EXIT Button (→ page 71) (→ page 76) 29. ▲▼◀▶ Button 10. Multi. Button (→ page 109) (→ page 76) 11. Geometric. Button 30. ENTER Button (→ page 38, 103) (→ page 76) 12. INPUT Button 31. L-CLICK Button* (→ page 19) 32. R-CLICK Button* 13.
Page 26: Battery Installation
1. Introduction Battery Installation 1. Press the catch and remove 2. Install new ones (AA). En- 3. Slip the cover back over the batteries until the battery cover. sure that you have the bat- it snaps into place. teries’ polarity (+/−) aligned NOTE: Do not mix different types of batteries or new correctly. and old batteries. Remote Control Precautions • Handle the remote control carefully.
Page 27: Operating Range For Wireless Remote Control
1. Introduction Operating Range for Wireless Remote Control 40 m/1575 inch 20 m/787 inch 20 m/787 inch 20 m/787 inch Remote sensor on projector cabinet 20 m/787 inch Remote control 15 m/591 inch 15 m/591 inch 15 m/591 inch 15 m/591 inch 40 m/1575 inch 40 m/1575 inch • The infrared signal operates by line-of-sight up to a distance of above meters and within a 60-degree angle of the...
Page 28: Projecting An Image (Basic Operation)
2. Projecting an Image (Basic Operation) This section describes how to turn on the projector and to project a picture onto the screen. ❶ Flow of Projecting an Image Step 1 • Connecting your computer / Connecting the power cord (→ page 15) Step 2 • Turning on the projector (→ page 17) Step 3 • Selecting a source (→ page 19) Step 4 • Adjusting the picture size and position (→ page 21) • Correcting keystone distortion [CORNERSTONE] (→ page 38, 103) Step 5 • Adjusting a picture and sound - Optimizing a computer signal automatically (→ page 30) - Turning up or down volume (→...
Page 29: ❷ Connecting Your Computer/Connecting The Power Cord
2. Projecting an Image (Basic Operation) ❷ Connecting Your Computer/Connecting the Power Cord 1. Connect your computer to the projector. This section will show you a basic connection to a computer. For information about other connections, see “(2) Making Connections” on page 143. Connect the display output terminal (mini D-sub 15 pin) on the computer to the computer video input terminal on the projector with a commercially-available computer cable (with ferrite core) and then turn the knobs of the connectors to secure them.
Page 30 2. Projecting an Image (Basic Operation) Upon connecting the power cable, the POWER indicator of the projector will light in green. If there are no input signals, the device will go into the standby state. (In the state, standby mode is NORMAL.) (→ page 183) COMPUTER IN To wall outlet Computer cable (with ferrite core)
Page 31: ❸ Turning On The Projector
2. Projecting an Image (Basic Operation) ❸ Turning on the Projector 1. Remove the lens cap. 2. Press the (POWER) button on the projector cabinet or the POWER ON button on the remote control. The POWER indicator lit in green will start to blink in blue. After that, the image will be projected onto the screen. TIP: • When the message “PROJECTOR IS LOCKED! ENTER YOUR PASSWORD.” is displayed, it means that the [SECURITY]...
Page 32: Note On Startup Screen (Menu Language Select Screen)
2. Projecting an Image (Basic Operation) Note on Startup screen (Menu Language Select screen) When you first turn on the projector, you will get the Startup menu. This menu gives you the opportunity to select one of the 29 menu languages. To select a menu language, follow these steps: 1. Use the ▲, ▼, ◀ or ▶ button to select one of the 30 languages from the menu. 2. Press the ENTER button to execute the selection.
Page 33: ❹ Selecting A Source
2. Projecting an Image (Basic Operation) ❹ Selecting a Source Selecting the computer or video source NOTE: Turn on the computer or video source equipment connected to the projector. Detecting the Signal Automatically Press the INPUT button for 1 second or longer. The projector will search for the available input source and display it. The input source will change as follows: HDMI1 → HDMI2 → DisplayPort → COMUPTER → HDBaseT → HDMI1 → … • Press it briefly to display the [INPUT] screen.
Page 34 2. Projecting an Image (Basic Operation) Selecting Default Source You can set a source as the default source so that it will be displayed each time the projector is turned on. 1. Press the MENU button. The menu will be displayed. 2. Press the ▶ button to select [SETUP] and press the ▼ button or the ENTER button to select [BASIC]. 3. Press the ▶ button to select [SOURCE OPTIONS] and press the ▼ button or the ENTER button. 4. Press the ▼ button three times to select [DEFAULT INPUT SELECT] and press the ENTER button. The [DEFAULT INPUT SELECT] screen will be displayed. (→...
Page 35: ❺ Adjusting The Picture Size And Position
2. Projecting an Image (Basic Operation) ❺ Adjusting the Picture Size and Position Use the lens shift dial, the adjustable tilt foot lever, the zoom and the focus ring to adjust the picture size and position. In this chapter drawings and cables are omitted for clarity. Adjusting the projected image’s vertical and horizontal Adjusting the focus position [Focus ring] [Lens shift] (→ page 23) (→ page 22) Finely adjusting the size of an image Adjusting the projected image’s inclination (→ page 28) [Tilt foot] *¹ (→ page 29) NOTE* : Adjust the projected image’s height using the tilt feet when you want to project the image at a position higher than the lens shift adjustment range.
Page 36: Adjusting The Vertical Position Of A Projected Image (Lens Shift)
2. Projecting an Image (Basic Operation) Adjusting the vertical position of a projected image (Lens shift) CAUTION • Perform the adjustment from behind or from the side of the projector. Adjusting from the front could expose your eyes to strong light which could injure them. • Keep hands away from the lens mounting portion while performing a lens shift. Failure to do so could result in fingers being pinched by the moving lens. 1. Press either SHIFT/HOME POSITION button on the cabinet or LENS SHIFT BUTTON on the remote control. The [LENS SHIFT] screen will be displayed. 2. Press the ▼▲◀▶ buttons to move the projected image. • To set back the lens to the home position Press and hold the SHIFT/HOME POSITION button over 2 seconds. The lens mounted on the projector goes back to the home position.
Page 37: Focus
2. Projecting an Image (Basic Operation) TIP: • The diagram below shows the lens shift adjustment range (projection format: desk/front) of the WUXGA type (excluding the lens unit NP30ZL). • Refer to Page 167 for the lens shift adjustment range of the WXGA type/XGA type and for ceiling hanging/front projection. NP803U/PA723U/PA653U Width of projected image 50%V Height of projected image 100%V 10%H 10%H 10%V 30%H 30%H 100%H Description of symbols: V indicates vertical (height of the projected image), H indicates horizontal (width of the projected image). Focus Applicable lens: NP12ZL/NP13ZL/NP14ZL Use the focus ring to obtain the best focus. Focus ring...
Page 38: Applicable Lens: Np30Zl
2. Projecting an Image (Basic Operation) Applicable lens: NP30ZL The NP30ZL lens unit aligns the peripheral focus around the optical axis. Peripheral focus ring Focus Ring Zoom Lever 1. Turn the focus ring left and right to align the focus around the optical axis. * The diagram shows an example when the lens shift is moved upward.
Page 39: Applicable Lens: Np11Fl
2. Projecting an Image (Basic Operation) Applicable lens: NP11FL With the NP11FL lens, adjust the focus and picture distortion. Preparations: Press and hold the SHIFT/HOME POSITION button on the cabinet longer than 2 seconds for shifting back the lens to the home position. 1. Turn the distortion ring to the left edge. Distortion ring 2. Turn the focus lever clockwise and counterclockwise to adjust the focus at the center of the screen. Focus lever 3. Use the distortion ring to correct the screen’s distortion. (This also brings the screen peripheral area into focus.) 4.
Page 40: Applicable Lens: Np40Zl/Np41Zl
2. Projecting an Image (Basic Operation) Applicable lens: NP40ZL/NP41ZL 1. Press the FOCUS button on the cabinet. The LENS FOCUS control screen will be displayed on. * Press ◀▶ buttons to adjust focus. In another way, press and hold the CTL button and then press VOLUME/ FOCUS +/- button on the remote control 2. When the cursor is on the CENTER on on-screen menu, press either ◀...
Page 41: Applicable Lens: Np42Zl
2. Projecting an Image (Basic Operation) Applicable lens: NP42ZL 1. Press the FOCUS button on the cabinet. Press ◀▶ buttons to adjust focus. In another way, press and hold the CTL button and then press VOLUME/ FOCUS +/- button on the remote control. * PERIPHERY LENS FOCUS is not available for this lens unit.
Page 42: Zoom
2. Projecting an Image (Basic Operation) Zoom Applicable lens: NP12ZL/NP13ZL/NP14ZL/NP30ZL Turn the zoom ring clockwise and counterclockwise. Zoom ring Applicable lens units: NP40ZL/NP41ZL/NP42ZL 1. Press ZOOM/L-CALIB. button. The ZOOM adjustment screen will be displayed on. • ◀ or ▶ buttons on the cabinet or the remote control are available to adjust ZOOM while the ZOOM adjustment screen is displayed on.
Page 43: Adjusting The Tilt Foot
2. Projecting an Image (Basic Operation) Adjusting the Tilt Foot 1. Turn the left and right tilt foot to adjust. The tilt foot lengthen and shorten when turned. Turn one of the tilt foot to adjust the image so that it is level. • If the projected image is distorted, see “3-6 Correcting Horizontal and Vertical Keystone Distortion [CORNERSTONE]” (→ page 38) and “[GEOMETRIC CORRECTION]”...
Page 44: ❻ Optimizing Computer Signal Automatically
2. Projecting an Image (Basic Operation) ❻ Optimizing Computer Signal Automatically Adjusting the Image Using Auto Adjust When projecting a signal from the computer video input terminal, HDMI 1 input terminal, HDMI 2 input terminal, Dis- playPort input terminal, HDBaseT IN/Ethernet port, adjust the picture quality with a single touch of the button if the edges of the screen are cut off or if the projection quality is bad. Press the AUTO ADJ. button to optimize a computer image automatically. This adjustment may be necessary when you connect your computer for the first time. [Poor picture] [Normal picture] NOTE: Some signals may take time to display or may not be displayed correctly. • If the Auto Adjust operation cannot optimize the computer signal, try to adjust [HORIZONTAL], [VERTICAL], [CLOCK], and [PHASE] manually. (→ page 92, 93) ❼ Turning Up or Down Volume Sound level from the AUDIO OUT terminal can be adjusted.
Page 45: ❽ Turning Off The Projector
2. Projecting an Image (Basic Operation) ❽ Turning off the Projector To turn off the projector: 1. First, press the (POWER) button on the projector cabinet or the STANDBY button on the remote control. The [POWER OFF / ARE YOU SURE ? / CARBON SAV- INGS- SESSION 0.000[g-CO2]] message will appear. Power On Sleep 2. Secondly, press the ENTER button or press the...
Page 46: ❾ After Use
2. Projecting an Image (Basic Operation) ❾ After Use Preparation: Make sure that the projector is turned off. 1. Unplug the power cord. For pulling out the power plug, press and hold the protruded section on the left and right sides of the part (B). 2. Disconnect any other cables. 3. Mount the lens cap on the lens. 4. Before moving the projector, screw in the tilt feet if they have been lengthened.
Page 47: Convenient Features
3. Convenient Features ❶ Turning off the Image and Sound The projected video and the output sound from the sound output terminal will disappear momentarily. Press the BLANK button. The projected video will be cut off. Press the MUTE button. The audio will be cut off. Press the AV-MUTE button. The projected video and audio will be cut off. • Press the buttons one more time for the cancelled video and audio to appear again. When AV-MUTE and BLANK are continued for some time, the energy- saving function will activate to lower the lamp power. NOTE: • When the AV-MUTE and BLANK buttons are pressed immediately after the energy-saving function is activated, sometimes the brightness may not return to normal immediately.
Page 48: ❷ Shift The On-Screen Menu Displaying Position
❷ Shift the On-Screen Menu displaying position 1. Press the MENU button. The On-Screen Menu will be displayed on. 2. Move the cursor by the ▶ button to the [SETUP] and then press the ENTER button. The cursor will move to the [MENU1]. 3. Move the cursor by the ▶ button to the [MENU2]. 4.
Page 49: ❸ Freezing A Picture
3. Convenient Features ❸ Freezing a Picture Press the FREEZE button to freeze a picture. Press again to resume motion. NOTE: The image is frozen but the original video is still playing back. ❹ Enlarging a Picture You can enlarge the picture up to four times. NOTE: • Depending on an input signal, the maximum magnification may be less than four times, or the function may be restricted.
Page 50: ❺ Changing Eco Mode/Checking Energy-Saving Effect Using Eco Mode [Eco Mode]
3. Convenient Features ❺ Changing Eco Mode/Checking Energy-Saving Effect Using Eco Mode [ECO MODE] This feature enables you to select two brightness modes of the lamp: OFF and ON modes. The lamp life can be extended by turning on the [ECO MODE]. [ECO MODE] Description [OFF] This is the default setting (100% Brightness). [ON] Low lamp power consumption (approx. 80% Brightness). To turn on the [ECO MODE], do the following: 1. Press the ECO button on the remote control to display [LIGHT MODE] screen. 2. Use the ▲ or ▼ button to select [ECO MODE]. 3. Use the ▲ or ▼ button to select [ON]. 4. Press the ENTER button. To change from [ON] to [OFF], Go back to Step 2 and select [OFF]. Repeat Step 3. NOTE: • The [ECO MODE] can be changed by using the menu.
Page 51: Checking Energy-Saving Effect [Carbon Meter]
3. Convenient Features Checking Energy-Saving Effect [CARBON METER] This feature will show energy-saving effect in terms of CO emission reduction (kg) when the projector’s [ECO MODE] is set to [OFF], or [ON]. This feature is called as [CARBON METER]. There are two messages: [TOTAL CARBON SAVINGS] and [CARBON SAVINGS-SESSION]. The [TOTAL CARBON SAVINGS] message shows the total amount of CO emission reduction from the time of shipment up to now. You can check the information on [USAGE TIME] from [INFO.] of the menu. (→ page 136) The [CARBON SAVINGS-SESSION] message shows the amount of CO emission reduction between the time of changing to ECO MODE immediately after the time of power-on and the time of power-off. The [CARBON SAVINGS- SESSION] message will be displayed in the [POWER OFF/ ARE YOU SURE ?] message at the time of power-off. TIP: • The formula as shown below is used to calculate the amount of CO emission reduction. Amount of CO emission reduction = (Power consumption in OFF for ECO MODE − Power consumption in ON for ECO MODE) × conversion factor.* When the image is turned off with the AV-MUTE button the amount of CO emmission reduction will also increase. * Calculation for amount of CO emission reduction is based on an OECD publication “CO Emissions from Fuel Combustion, 2008 Edition”.
Page 52: ❻ Correcting Horizontal And Vertical Keystone Distortion [Cornerstone]
3. Convenient Features ❻ Correcting Horizontal and Vertical Keystone Distortion [CORNERSTONE] Use the [CORNERSTONE] feature to correct keystone (trapezoidal) distortion to make the top or bottom and the left or right side of the screen longer or shorter so that the projected image is rectangular. 1. Project an image so that the screen is smaller than the area of the raster. The drawing shows the upper right corner. Projected image 2. Pick up any one of the corners and align the corner of the image with a corner of the screen. 3. Press the Geometric. button either on the cabinet or the remote control. Display the [GEOMETRIC CORRECTION] screen of the on-screen menu. 4. Move the cursor onto [MODE] by ▼ button and press the ENTER. The mode selection screen will displayed on. 5. Select [CORNERSTONE] and press the ENTER.
Page 53 3. Convenient Features 6. Press the ▼ button to align with the [CORNERSTONE] and then press the ENTER button. The drawing shows the upper left icon ( ) is selected. The screen will switch to the [CORNERSTONE] screen. 7. Use the ▲▼◀▶ button to select one icon (▲) which points in the direction you wish to move the projected image frame.
Page 54: ❼ Operation For The On-Screen Menu By A Commercially Available Usb Mouse
3. Convenient Features The confirmation screen is displayed. 12. Press the ◀ or ▶ button to highlight the [OK] and press the ENTER button. This completes the [CORNERSTONE] correction. • Select [CANCEL] and press the ENTER button to return to the [CORNERSTONE] screen. Selecting [CANCEL] will return to the adjustment screen without saving changes (Step 3). Selecting [RESET] will return to the factory default. Selecting [UNDO] will exit without saving changes. NOTE: • Even when the projector is turned on, the last used correction values are applied. • Carry out either one of the following actions to clear the adjustment value of [CORNERSTONE]. • In Step 11, select [RESET] and then press the ENTER button. • In the state [CORNERSTONE] has been selected for [MODE] in the [GEOMETRIC CORRECTION]: • Press the Geometric. button for 2 or more seconds. • Run [DISPLAY] → [GEOMETRIC CORRECTION] → [RESET] in the on-screen menu. • Using CORNERSTONE correction can cause the image to be slightly blurred because the correction is made electronically. • A commercially available USB mouse is available for CORNERSTONE correction. ❼...
Page 55: Menu Position Control
3. Convenient Features ③ Select [EXIT] displayed at the bottom of the menu by left click for going back to the previous level. If the cursor is on the main menu option, it works for closing the menu. (It works as the same perfor- mance with the [EXIT] button on the remote control. Menu position control ① Click the wheel button to display the on-screen menu indication frame. ② Left click at the position on the projection screen where you want to shift the on-screen menu. The nearest corner of the on-screen menu indication frame will shift to the clicked position. ③ Click the wheel button to close the menu indication frame. Geometric correction The USB mouse can be used for CORNERSTONE CORRECTION, HORIZONTAL CORNER, VERTICAL CORNER and WARP. In this clause, the CORNERSTONE CORRECTION by an USB mouse is explained as an example. ① While the adjustment screen of the CORNERSTONE CORRECTION is displayed, right click on the pro- jection screen. The shape of mouse pointer will be changed and the correction will become available.
Page 56 3. Convenient Features ② Left click at the screen corner. The projection screen corner will move to the mouse clicked position. ③ Repeat the step ② for correcting all distortion. After completion of distortion correction, right click on the projection screen. The shape of mouse pointer will be changed to normal. ④ Left click [EXIT] on the correction screen to finish.
Page 57: ❽ Preventing The Unauthorized Use Of The Projector [Security]
3. Convenient Features ❽ Preventing the Unauthorized Use of the Projector [SECURITY] A keyword can be set for your projector using the Menu to avoid operation by an unauthorized user. When a keyword is set, turning on the projector will display the Keyword input screen. Unless the correct keyword is entered, the pro- jector cannot project an image. • The [SECURITY] setting cannot be cancelled by using the [RESET] of the menu. To enable the Security function: 1. Press the MENU button. The menu will be displayed. 2. Press the ▶ button twice to select [SETUP] and press the ▼ button or the ENTER button to select [MENU(1)]. 3. Press the ▶ button to select [CONTROL]. 4. Press the ▼ button three times to select [SECURITY] and press the ENTER button. The OFF/ON menu will be displayed.
Page 58 3. Convenient Features 7. Type in the same combination of ▲▼◀▶ buttons and press the ENTER button. The confirmation screen will be displayed. 8. Select [YES] and press the ENTER button. The SECURITY function has been enabled. To turn on the projector when [SECURITY] is enabled: 1. Press the POWER button. The projector will be turned on and display a message to the effect that the projector is locked. 2.
Page 59 3. Convenient Features To disable the SECURITY function: 1. Press the MENU button. The menu will be displayed. 2. Select [SETUP] → [CONTROL] → [SECURITY] and press the ENTER button. The OFF/ON menu will be displayed. 3. Select [OFF] and press the ENTER button. The SECURITY KEYWORD screen will be displayed. 4. Type in your keyword and press the ENTER button. When the correct keyword is entered, the SECURITY function will be disabled. NOTE: If you forget your keyword, contact your dealer. Your dealer will provide you with your keyword in exchange for your request code. Your request code is displayed in the Keyword Confirmation screen. In this example [NB52-YGK8-2VD6-K585-JNE6-EYA8] is a request code.
Page 60: ❾ Projecting 3D Videos
3. Convenient Features ❾ Projecting 3D videos This projector can be used to watch videos in 3D using commercially-available active shutter-type 3D eyewear. In order to synchronize the 3D video and eyewear, a commercially-available 3D emitter needs to be connected to the projector (on the projector side). The 3D eyewear receives information from the 3D emitter and performs opening and closing on the left and right. CAUTION Health precautions Before use, please make sure to read any health precautions that may be stated in the operating manuals enclosed with the 3D eyewear and 3D video software (Blu-ray player, games, computer animation files, etc.). Please take note of the following in order to avoid adverse health effects. • Please do not use the 3D eyewear for purposes other than to watch 3D videos. • Please keep a distance of at least 2 m away from the screen when watching videos. Watching a video too close to the screen will increase eye fatigue. • Please do not watch videos continuously for a long period of time. Please take a 15 minutes’ break after every hour of watching. • Please consult a doctor before watching if you or any of your family members have a history of suffering from seizures caused by light sensitivity. • Please stop watching immediately and take a rest when you feel physically unwell while watching (vomiting, gid- diness, nausea, headaches, sore eyes, blurred vision, cramps and dumbness in the limbs, etc.). Please consult a doctor if the symptoms persist. • Please watch a 3D video directly in front of the screen. If you watch a 3D video obliquely from the sides, this may result in physical and eye fatigue.
Page 61 3. Convenient Features The [3D SETTINGS] screen will be displayed. (2) Press the ▼ button to align the cursor with the [FORMAT] and press the ENTER button. The format screen will be displayed. (3) Select the input signal format using the ▼ button and then press the ENTER button. The 3D settings screen will disappear and the 3D video will be projected.
Page 62: When Videos Cannot Be Viewed In 3D
3. Convenient Features When videos cannot be viewed in 3D Please check the following points when videos cannot be viewed in 3D. Please also read the operating manual attached to the 3D eyewear. Possible reasons Solutions The selected signal does not support 3D output� Please change the video signal input to one that supports 3D� The format for the selected signal is turned to [OFF(2D)]� Please change the format in the on-screen menu to [AUTO] or a format that supports 3D�...
Page 63: ❿ Controlling The Projector By Using An Http Browser
3. Convenient Features ❿ Controlling the Projector by Using an HTTP Browser Overview Using the web browser on the computer, the HTTP server screen of the projector can be displayed to operate the projector. Possible operations on the HTTP server screen • Configure the settings required for connecting the projector to the network (wired LAN). (NETWORK SETTINGS) • Configure the email notification. (ALERT MAIL) When the projector is connected to a network (wired LAN), notifications on the lamp replacement period and vari- ous errors are sent to the email address that has been set up. • Operate the projector.
Page 64: Handling Of The Address For Operation Via A Browser
3. Convenient Features Handling of the Address for Operation via a Browser Regarding the actual address that is entered for the address or entered to the URL column when operation of the projector is via a browser, the host name can be used as it is when the host name corresponding to the IP address of the projector has been registered to the domain name server by a network administrator, or the host name cor- responding to the IP address of the projector has been set in the “HOSTS” file of the computer being used. Example 1: W hen the host name of the projector has been set to “pj.nec.co.jp”, access is gained to the network setting by specifying http://pj.nec.co.jp/index.html for the address or the entry column of the URL. Example 2: W hen the IP address of the projector is “192.168.73.1”, access is gained to the network setting by specifying http://192.168.73.1/index.html for the address or the entry column of the URL. PROJECTOR ADJUSTMENT POWER: This controls the power of the projector. ON �� Power is switched on� OFF �� Power is switched off�...
Page 65 3. Convenient Features PICTURE: Controls the video adjustment of the projector. BRIGHTNESS ▲ �� Increases the brightness adjustment value� BRIGHTNESS ▼ �� Decreases the brightness adjustment value� CONTRAST ▲ �� Increases the contrast adjustment value� CONTRAST ▼ �� Decreases the contrast adjustment value� COLOR ▲ �� Increases the color adjustment value� COLOR ▼...
Page 66 3. Convenient Features NETWORK SETTINGS http://<IP Address of Projector (Basic)>/index.html • SETTINGS WIRED LAN INTERFACE Select [LAN] for connecting LAN by wire thru the LAN port. Select [HDBaseT] for connecting LAN by wire thru the HDBaseT IN/Ethernet port. SETTING Set for wired LAN. PROFILE 1/PROFILE 2 Two settings can be set for wired LAN connection. Select PROFILE 1 or PROFILE 2. DISABLE Turn off wired LAN connection. The POWER indicator that is informing the STANDBY state will start to blink in orange long interval (→ page 180). DHCP ON Automatically assign IP address, subnet mask, and gateway to the projector from your DHCP server. DHCP OFF Set IP address, subnet mask, and gateway to the projector assigned by your network administrator. IP ADDRESS Set your IP address of the network connected to the projector. SUBNET MASK Set your subnet mask number of the network connected to the projector. GATEWAY Set the default gateway of the network connected to the projector. AUTO DNS ON DHCP server will automatically assign IP address of DNS server connected to the projector.
Page 67 3. Convenient Features • NAME PROJECTOR NAME Enter a name for your projector so that your computer can identify the projector. A projector name must be 16 characters or less. TIP: Projector name will not be affected even when [RESET] is done from the menu. HOST NAME Enter the hostname of the network connected to the projector. A host name must be 16 or less. DOMAIN NAME Enter the domain name of the network connected to the projector. A domain name must be 60 characters or less. SAVE Click this button to save your settings to the projector's memory. • ALERT MAIL ALERT MAIL This option will notify your computer of lamp replace time or error messages via e-mail when using wired LAN. Placing a checkmark will turn on the Alert Mail feature. Clearing a checkmark will turn off the Alert Mail feature. Sample of a message to be sent from the projector: The lamp has reached the end of its usable life. Please replace the lamp. Use the specified lamp for safety and performance. Projector Name: xxxx Lamp Hours Used: xxxx [H] SENDER’S ADDRESS Enter sender’s address. SMTP SERVER NAME Enter the SMTP server name to be connected to the projector. RECIPIENT’S ADDRESS Enter your recipient’s address. Up to three addresses can be entered. 1, 2, 3 TEST MAIL Send a test mail to check whether your settings are correct or not NOTE: • If you execute a test, you may not receive an Alert mail. Should this happen, check if network settings are correct.
Page 68 3. Convenient Features • NETWORK SERVICE PJLink PASSWORD Set a password for PJLink*. A password must be 32 characters or less. Do not forget your password. However, if you forget your password, consult with your dealer. HTTP PASSWORD Set a password for HTTP server. A password must be 10 characters or less. When a password is set up, you will be prompted for your user name (arbitrary) and password during LOGON. AMX BEACON Turn on or off for detection from AMX Device Discovery when connecting to the network supported by AMX’s NetLinx control system. TIP: When using a device that supports AMX Device Discovery, all AMX NetLinx control system will recognize the device and download the appropriate Device Discovery Module from an AMX server. Placing a checkmark will enable detecting the projector from AMX Device Discovery. Clearing a checkmark will disable detecting the projector from AMX Device Discovery. Extron XTP Set for connecting this projector to the Extron XTP transmitter. ON will enable to con- nect with the XTP transmitter. OFF will disable to connect with the XTP transmitter. SAVE Click this button to save your settings to the projector's memory. NOTE: If you forget your password, contact your dealer. Please check 24 digits serial number (XXXX-XXXX-XXXX-XXXX-XXXX-XXXX) displayed on the column for the password. *What is PJLink? PJLink is a standardization of protocol used for controlling projectors of different manufacturers. This standard protocol is established by Japan Business Machine and Information System Industries Association (JBMIA) in 2005. The projector supports all the commands of PJLink Class 1. Setting of PJLink will not be affected even when [RESET] is done from the menu. • CRESTRON ROOMVIEW for managing from the computer. DISABLE Disables ROOMVIEW.
Page 69 3. Convenient Features LENS CONTROL • CONTROL FOCUS CENTER Align the focus around the optical axis. PERIPHERY Align the focus for the screen peripheral area. ZOOM ◀/▶ Finely adjusting the size of an image. SHIFT ▼▲◀▶ Adjust the projected image’s vertical and horizontal position. HOME Return the lens shift position to the home position. CALIB. Correct the adjustable zoom, focus and les shift range. • LENS MEMORY STORE Store the current adjusted values in memory for each input signal. MOVE Applies the adjusted values of LENS SHIFT, motorized ZOOM, and motorized FO- CUS to the current signal. RESET Return the adjusted valued to the last condition. • REF. LENS MEMORY PROFILE1/PROFILE2 Select a stored [PROFILE] number. STORE Store each adjusted value of LENS SHIFT, motorized ZOOM and motorized FOCUS for the selected profile as the common values for every input signal. MOVE Move the lens to the stored values for the selected profile. RESET Reset selected [REF. LENS MEMORY] for the selected [PROFILE] to the default factory settings.
Page 70: ⓫ Storing Changes For Lens Shift, Zoom, And Focus [Lens Memory]
3. Convenient Features LOAD BY If input signal is switched, the lens will not shift to the les shift, zoom and focus val- SIGNAL ues for the selected [PROFILE] number. If input signal is switched, the lens will shift to the values for the selected [PROFILE] number. If no adjusted values have been stored to [LENS MEMORY], the lens will apply [REF. LENS MEMORY] adjusted values. Alternatively, if no adjusted values have been stored to [REF. LENS MEMORY], the unit will return to the default factory set- tings. FORCED Not turn off the image during les shift. MUTE Turn off the image during les shift. NOTE: LENS MEMORY and REF. LENS MEMORY are future expansion functions. ⓫ Storing Changes for Lens Shift, Zoom, and Focus [LENS MEMORY] This function serves to store the adjusted values when using the LENS SHIFT, motorized ZOOM and motorized FO- CUS buttons of the projector. Adjusted values can be applied to the signal you selected. This will eliminate the need to adjust lens shift, focus, and zoom at the time of source selection. There are two ways to save adjusted values for lens shift, zoom, and focus. Function name Description page → page 117 REF. LENS MEMORY Adjusted values common to all input signals. At the time of installation, two kinds of adjusted values can be stored. If no adjusted values have been saved to [LENS MEMORY], the lens will apply [REF.LENS MEMORY] adjusted values.
Page 71 3. Convenient Features 2. Press the ▶ button to select [SETUP] and press the ENTER button. 3. Press the ▶ button to select [INSTALLATION]. 4. Press the ▼ button to select [REF. LENS MEMORY] and press the ENTER button. The [REF. LENS MEMORY] screen will be displayed. 5. Make sure [PROFILE] is highlighted, then press the ENTER button. The [PROFILE] selection screen appears.
Page 72 3. Convenient Features 6. Press the ▼/▲ buttons to select the [PROFILE] number, then press the ENTER button. Return to the [REF. LENS MEMORY] settings screen. 7. Select [STORE] and press the ENTER button. The confirmation screen will be displayed. 8. Press the ◀ button to select and [YES] and press the ENTER button. Select a [PROFILE] number and save the adjusted [LENS SHIFT], [ZOOM], and [FOCUS] values to it. 9.
Page 73: To Call Up Your Adjusted Values From [Ref. Lens Memory]
3. Convenient Features To call up your adjusted values from [REF. LENS MEMORY]: 1. Press the MENU button. The menu will be displayed. 2. Press the ▶ button to select [SETUP] and press the ENTER button. 3. Press the ▶ button to select [INSTALLATION]. 4. Press the ▼ button to select [REF. LENS MEMORY] and press the ENTER button. The [REF. LENS MEMORY] screen will be displayed.
Page 74 3. Convenient Features 5. Make sure [PROFILE] is highlighted, then press the ENTER button. The [PROFILE] selection screen appears. 6. Press the ▼/▲ buttons to select the [PROFILE] number, then press the ENTER button. Return to the [REF. LENS MEMORY] settings screen. 7. Select [MOVE] and press the ENTER button. The lens will shift based on the adjusted values stored in the selected [PROFILE]. 8. Press the ◀ button to select and [YES] and press the ENTER button. The adjusted values will be applied to the current signal.
Page 75 3. Convenient Features TIP: To call up the stored values from [LENS MEMORY]: 1. From the menu, select [ADJUST] → [LENS MEMORY] → [MOVE] and press the ENTER button. The confirmation screen will be displayed. 2. Press the ◀ button to select and [YES] and press the ENTER button. During projection, if the adjusted values for an input signal have been saved, the lens will shift. If not, the lens will shift according to the adjusted values stored in the selected [REF. LENS MEMORY] [PROFILE] number. To automatically apply the stored values at the time of source selection: 1. From the menu, select [SETUP] → [REF. LENS MEMORY] → [LOAD BY SIGNAL] and press the ENTER button.
Page 76: Multi-Screen Projection
4. Multi-Screen Projection ❶ Things that can be done using multi-screen projection This projector can be used singly or arranged in multiple units for multi-screen projection. We will introduce an example using two projection screens here. Case 1 Using a single projector to project two types of videos at the same time [PIP/PICTURE BY PICTURE] Case 2 Using four projectors (liquid crystal panel: WUXGA) to project video with a resolution of 3840 × 2160 pixels [TILING] Case 1. Using a single projector to project two types of videos [PIP/PICTURE BY PICTURE] Connection example and projection image In the case of [PICTURE BY PICTURE] In the case of [PIP] On-screen menu operations...
Page 77: Case 2. Using Four Projectors (Liquid Crystal Panel: Wuxga) To Project Videos With A Resolution Of 3840 × 2160 Pixels [Tiling]
4. Multi-Screen Projection Case 2. Using four projectors (liquid crystal panel: WUXGA) to project videos with a resolution of 3840 × 2160 pixels [TILING] Connection example and projection image On-screen menu operations 1 Four similar videos are displayed when four projectors are projected. Please request the retail store to adjust the projection position of each projector.
Page 78 4. Multi-Screen Projection 2 Operate the on-screen menu using the four respective projectors to divide the image into four portions. Display [DISPLAY] → [MULTI SCREEN] → [PICTURE SETTING] Screen in the on-screen menu and select [TIL- ING]. (1) In the screen for setting the number of horizontal units, select [2 UNITS]. (number of units in the horizontal direction) (2) In the screen for setting the number of vertical units, select [2 UNITS].
Page 79: Things To Note When Installing Projectors
4. Multi-Screen Projection Things to note when installing projectors • Leave sufficient space on the left and right of the projector so that the intake and exhaust vents of the projector are not obstructed. When the intake and exhaust vents are obstructed, the temperature inside the projector will rise and this may result in a malfunction. • Please do not pile up the projectors directly on top of one another when installing them. When the projectors are piled up on top of one another, they may fall down, resulting in damage and failure. • Installation example when using two projectors The following installation is recommended when combining the installation of two projectors for multi-screen projec- tion. Please leave a space of at least 10 cm between the the intake/exhaust vent and the wall. [Installation example] Front Right side Back Intake vent Exhaust vent Air dis- Air intake charge Cabinet Cabinet Cabinet...
Page 80: ❷ Displaying Two Pictures At The Same Time
4. Multi-Screen Projection ❷ Displaying Two Pictures at the Same Time The projector has a feature that allows you to view two different signals simultaneously. You have two modes: PIP mode and PICTURE BY PICTURE mode. The projection video in the first screen display is known as the main display while the projection video that is called out subsequently is known as the sub-display. Select the projection function under [DISPLAY] → [PIP/PICTURE BY PICTURE] → [MODE] in the on-screen menu (the default factory setting when shipped is PIP). (→ page 101) • A single screen is projected when power is turned on. Picture in Picture function A small sub-display is displayed inside the main display. Main Display The sub-display can be set up and adjusted as follows. (→ page 101) • Select whether to display the sub-display at the top right, top left, bottom right or bottom left of the screen (the size of the sub-display can be selected and Sub-Display the position can be fine-tuned) • Switch the main display with the sub-display Picture by picture function Display the main display and sub-display side by side. The main display and sub-display can be set up and adjusted as follows. (→ Main Display Sub-Display page 102)
Page 81: Projecting Two Screens
4. Multi-Screen Projection Projecting two screens 1. Press the MENU button to display the on-screen menu and select [DISPLAY] → [PIP/PICTURE BY PICTURE]. This displays the [PIP/PICTURE BY PICTURE] screen in the on-screen menu. 2. Select [SUB INPUT] using the ▼/▲ buttons, and press the ENTER button. This displays the [SUB INPUT] screen. 3. Select the input signal using the ▼/▲ buttons, and press the ENTER button. * This screen belongs to a HDBaseT model. The [PIP] (PICTURE IN PICTURE) or [PICTURE BY PICTURE] screen set up under [MODE] is projected. (→ page 101) • When the signal name is displayed in grey, this means that it cannot be selected.
Page 82: Switching The Main Display With The Sub-Display And Vice Versa
4. Multi-Screen Projection Switching the main display with the sub-display and vice versa 1. Press the MENU button to display the on-screen menu and select [DISPLAY] → [PIP/PICTURE BY PICTURE]. This displays the [PIP/PICTURE BY PICTURE] screen in the on-screen menu. 2. Select [PICTURE SWAP] using the ▼/▲ buttons and then press the ENTER button. Display the screen for switching the display positions. 3. Select [ON] using the ▼ button and then press the ENTER button. The video of the main display will switch with that of the sub-display. Sub-display video Main display video Main display video...
Page 83: Restrictions
4. Multi-Screen Projection Restrictions • The following operations are enabled only for the main display. • Audio-visual adjustments • Video magnification / compression using the partial D-ZOOM/ZOOM +/− buttons. However, magnification / compression is up to the positions set in [PICTURE BY PICTURE BORDER] only. • TEST PATTERN • The following operations are enabled for both the main display and sub-display. These operations cannot be ap- plied individually. • Momentary deletion of video / audio • Video pause • [PIP/PICTURE BY PICTURE] cannot be used when a 3D video is being displayed. • When using the [PIP/PICTURE BY PICTURE] function, [DYNAMIC CONTRAST] can not be used. • [PIP/PICTURE BY PICTURE] cannot be used when the signal input has a resolution of 1920 × 1200 or more. • The HDBaseT OUT/Ethernet port has a repeater function. The output resolution is limited by the maximum resolu- tion of the connected monitor and projector.
Page 84: ❸ Displaying A Picture Using [Edge Blending]
4. Multi-Screen Projection ❸ Displaying a Picture Using [EDGE BLENDING] A high resolution video can be projected on an even bigger screen by combining multiple projectors on the left, right, top and bottom. This projector is equipped with an “EDGE BLENDING Function” that makes the edges (boundaries) of the projection screen indistinguishable. NOTE: • For projector throw distances, refer to “Throw distance and screen size” on page 162. • Before performing the Edge Blending function, place the projector in the correct position so that the image becomes square in the appropriate size, and then make optical adjustments (lens shift, focus, and zoom). • Adjust the brightness of each projector using [REF. LIGHT] under [LIGHT MODE]. In addition, use [REF. WHITE BALANCE] to adjust the [CONTRAST], [BRIGHTNESS] and [UNIFORMITY]. Before explaining use of the Edge Blending function This section explains the case for “Example: Placing two projectors side by side”. As shown, the projected image on the left is referred to as “Projector A” and the projected image on the right is referred to “Projector B”. Unless otherwise specified hereinafter, the “projector” is used to mean both A and B.
Page 85: Setting The Overlap Of Projection Screens
4. Multi-Screen Projection Preparation: • Turn on the projector and display a signal. • When performing settings or adjustments using one remote control, enable the [CONTROL ID] for assigning ID to each projector so as not to activate the other projectors. (→ page 123) Setting the overlap of projection screens ① Enable [EDGE BLENDING]. 1 Press the “Edge Blend.” button. The [EDGE BLENDING] screen will be displayed. Align the cursor with [MODE] and then press the ENTER but- ton.
Page 86 4. Multi-Screen Projection 4 Select [CONTROL] → [ON] and press the ENTER button. Each [TOP], [BOTTOM], [LEFT], [RIGHT], and [BLACK LEVEL] has its own [CONTROL], [MARKER], [RANGE], and [POSITION]. • For Projector A, set the [CONTROL] for the [TOP], [LEFT] and[BOTTOM] to [OFF]. Similarly for Projector B, set the [CONTROL] for the [TOP], [RIGHT] and [BOTTOM] to [OFF]. ② Adjust [RANGE] and [POSITION] to determine an area of overlapped edges of images projected from each projector.
Page 87: [Blend Curve]
4. Multi-Screen Projection 1 Adjust [RANGE]. Use the ◀ or ▶ button to adjust the overlapped area. TIP: • Adjust to overlap one projector’ marker with the other projector’s marker. 2 Adjust [POSITION]. Use the ◀ or ▶ button to align one edge with the other edge of overlapped images. TIP: • When displaying a signal with a different resolution, perform the Edge Blending function from the start. • Setting of [MARKER] will not be saved and return to [OFF] when the projector is turned off.
Page 88: Black Level Adjustment
4. Multi-Screen Projection 2. Select one option among nine by ▲ or ▼. Black Level Adjustment This adjusts the black level of the overlapping area and the non-overlapping area of the multi-screen (EDGE BLENDING). Adjust the brightness level if you feel the difference is too large. NOTE: This function is enabled only when [MODE] is turned on. Adjustable area varies depending on what combination of [TOP], [BOTTOM], [LEFT] and [RIGHT] are turned on. Example: Adjusting the Black Level when placing two projectors side by side Width of overlap Adjust [CENTER] Adjust [CENTER] Projector A’s Projector B’s image image Adjust [CENTER-RIGHT] Adjust [CENTER-LEFT] 1. Select [DISPLAY] → [EDGE BLENDING] → [BLACK LEVEL] and press the ENTER button.
Page 89: Segmented Portions For Black Level Adjustment
4. Multi-Screen Projection 2. Use the ▼ or ▲ button to select an item and use the ◀ or ▶ to adjust the black level. Do this for the other projector if necessary. 9-segmented portions for Black Level adjustment The center projector This function adjusts the brightness level of 9-segmented portions for the center projector and 4-segmented portions for the left bottom projector as shown below. TOP-CENTER TOP-LEFT TOP-RIGHT...
Page 90: Using On-Screen Menu
5. Using On-Screen Menu ❶ Using the Menus NOTE: The on-screen menu may not be displayed correctly while interlaced motion video image is projected. 1. Press the MENU button on the remote control or the projector cabinet to display the menu. NOTE: The commands such as ENTER, EXIT, ▲▼, ◀▶...
Page 91: ❷ Menu Elements
5. Using On-Screen Menu ❷ Menu Elements Slide bar Solid triangle Available buttons Source Menu mode Highlight Radio button ECO mode symbol Off Timer remaining High Altitude symbol time Thermometer symbol Key Lock symbol Menu windows or dialog boxes typically have the following elements: Highlight ��Indicates the selected menu or item�...
Page 92: ❸ List Of Menu Items
5. Using On-Screen Menu ❸ List of Menu Items • Basic menu items are indicated by shaded area. Some menu items are not available depending on the input source. Menu Item Default Options 1:HDMI1 2:HDMI2 3:DisplayPort INPUT 4:COMPUTER 5:HDBaseT ENTRY LIST TEST PATTERN MODE STANDARD STANDARD, PROFESSIONAL HIGH-BRIGHT, PRESENTATION, VIDEO, MOVIE, GRAPHIC, sRGB, PRESET DICOM SIM� GENERAL AUTO, HIGH-BRIGHT, PRESENTATION, VIDEO, MOVIE, GRAPHIC, REFERENCE sRGB, DICOM SIM�...
Page 93 5. Using On-Screen Menu Menu Item Default Options STEREO VIEWER SINGLE SINGLE, DUAL LEFT, DUAL RIGHT STEREO FILTER SINGLE SINGLE, DUAL LEFT, DUAL RIGHT AUTO, OFF(2D), FRAME PACKING, SIDE BY SIDE(HALF), SIDE 3D SETTINGS FORMAT AUTO BY SIDE(FULL), TOP AND BOTTOM, FRAME ALTERNATIVE, LINE ALTERNATIVE ADJUST L/R INVERT...
Page 94 5. Using On-Screen Menu Menu Item Default Options MODE OFF, ON CONTRAST W CONTRAST R CONTRAST G WHITE BALANCE CONTRAST B BRIGHTNESS W BRIGHTNESS R BRIGHTNESS G BRIGHTNESS B MULTI MODE OFF, ZOOM, TILING DISPLAY SCREEN HORIZONTAL ZOOM VERTICAL ZOOM ZOOM HORIZONTAL POSITION...
Page 95 5. Using On-Screen Menu Menu Item Default Options MENU MODE ADVANCED ADVANCED, BASIC NOT SAVE SETTING VALUES OFF, ON ADMINISTRA- TOR MODE NEW PASSWORD CONFIRM PASSWORD ENABLE OFF, ON ACTIVE OFF, ON SUN, MON, TUE, WED, THU, FRI, SAT, MON-FRI, MON-SAT, EVERY DAY TIME FUNCTION...
Page 96 5. Using On-Screen Menu Menu Item Default Options INTERFACE LAN, HDBaseT PROFILES DISABLE, PROFILE 1, PROFILE 2 DHCP OFF, ON IP ADDRESS WIRED LAN SUBNET MASK GATEWAY AUTO DNS OFF, ON DNS CONFIGURATION RECONNECT PROJECTOR NAME PROJECTOR NAME PJ-******** HOST NAME pj-******** DOMAIN DOMAIN NAME...
Page 97 5. Using On-Screen Menu Menu Item Default Options LAMP LIFE REMAINING LAMP HOURS USED USAGE TIME FILTER HOURS USED TOTAL CARBON SAVINGS INPUT TERMINAL RESOLUTION HORIZONTAL FREQUENCY VERTICAL FREQUENCY SOURCE(1) SYNC TYPE SYNC POLARITY SCAN TYPE SOURCE NAME ENTRY NO� SIGNAL TYPE BIT DEPTH SOURCE(2)
Page 98: ❹ Menu Descriptions & Functions [Input]
5. Using On-Screen Menu ❹ Menu Descriptions & Functions [INPUT] 1:HDMI1 This projects the video of the device connected to the HDMI 1 IN terminal. 2:HDMI2 This projects the video of the device connected to the HDMI 2 IN terminal. 3:DisplayPort This projects the video of the device connected to the Display Port input terminal. 4:COMPUTER This projects the video of the device connected to the computer video input terminal. (This projects the analog RGB signal or component signal.) 5:HDBaseT Projecting the HDBaseT signal. ENTRY LIST Displays a list of signals. See the following pages. TEST PATTERN Closes the menu and switches to the test pattern screen.
Page 99 5. Using On-Screen Menu Using the Entry List When any source adjustments are made, the adjustments are automatically registered in the Entry List. The (adjust- ment values of) registered signals can be loaded from the Entry List whenever necessary. However, only up to 100 patterns can be registered in the Entry List. When 100 patterns have been registered in the Entry List, an error message is then displayed and no additional patterns can be registered. You should thus delete (adjustment values of) signals that are no longer needed. Displaying the Entry list 1. Press the MENU button. The menu will be displayed. 2. Press the ◀ or ▶ button to select [INPUT]. The INPUT list will be displayed. * This screen belongs to a HDBaseT model. 3.
Page 100 5. Using On-Screen Menu Entering the currently projected signal into the Entry List [ (STORE)] 1. Press the ▲ or ▼ button to select any number. 2. Press the ◀ or ▶ button to select [ (STORE)] and press the ENTER button. Calling up a signal from the Entry List [ (LOAD)] Press the ▲...
Page 101 5. Using On-Screen Menu Cutting a signal from the Entry List [ (CUT)] 1. Press the ▲ or ▼ button to select a signal you wish to delete. 2. Press the ◀, ▶, ▲, or ▼ button to select [ (CUT)] and press the ENTER button. The signal will be deleted from the Entry List and the deleted signal will be displayed on the clipboard at the bot- tom of the Entry List.
Page 102: ❺ Menu Descriptions & Functions [Adjust]
5. Using On-Screen Menu ❺ Menu Descriptions & Functions [ADJUST] [PICTURE] [MODE] This function allows you to determine how to save settings for [DETAIL SETTINGS] of [PRESET] for each input. STANDARD �� Saves settings for each item of [PRESET] (Preset 1 through 7) PROFESSIONAL �� Saves all the settings of [PICTURE] for each input� NOTE: • When [TEST PATTERN] is displayed, [MODE] cannot be selected. [PRESET] This function allows you to select optimized settings for your projected image.
Page 103: Detail Settings
5. Using On-Screen Menu [DETAIL SETTINGS] [GENERAL] Storing Your Customized Settings [REFERENCE] This function allows you to store your customized settings in [PRESET 1] to [PRESET 7]. First, select a base preset mode from [REFERENCE], then set [GAMMA CORRECTION] and [COLOR TEMPERA- TURE]. HIGH-BRIGHT �� Recommended for use in a brightly lit room� PRESENTATION �� Recommended for making a presentation using a PowerPoint file� VIDEO �� Recommended for typical TV program viewing� MOVIE ��...
Page 104: Color Correction
5. Using On-Screen Menu Adjusting Color Temperature [COLOR TEMPERATURE] This option allows you to select the color temperature of your choice. A value between 5000 K and 10500 K can be set in 100 K units. NOTE: When [PRESENTATION] or [HIGH-BRIGHT] is selected in [REFERENCE], this function is not available. Adjusting Brightness and Contrast [DYNAMIC CONTRAST] When set, the most optimal contrast ratio is adjusted according to the video. OFF �� Dynamic contrast is disabled� MOTION IMAGE �� Most optimal settings for moving images� STILL IMAGE �� Most optimal settings for static images� Rapidly follows any changes in the video� NOTE: • Depending on the conditions, projector settings such as [DYNAMIC CONTRAST] may not be able to be selected.
Page 105 5. Using On-Screen Menu [SHARPNESS] Controls the detail of the image. [COLOR] Increases or decreases the color saturation level. [HUE] Varies the color level from +/− green to +/− blue. The red level is used as reference. NOTE: • When [TEST PATTERN] is displayed, [CONTRAST], [BRIGHTNESS], [SHARPNESS], [COLOR] and [HUE] cannot be adjusted. [RESET] The settings and adjustments for [PICTURE] will be returned to the factory default settings with the exception of the following; Preset numbers and [REFERENCE] within the [PRESET] screen. The settings and adjustments under [DETAIL SETTINGS] within the [PRESET] screen that are not currently selected will not be reset.
Page 106: [Image Options]
5. Using On-Screen Menu [IMAGE OPTIONS] Adjusting Clock and Phase [CLOCK/PHASE] This allows you to manually adjust CLOCK and PHASE. CLOCK �� Use this item to fine tune the computer image or to remove any vertical banding that might appear� This function adjusts the clock frequencies that eliminate the horizontal banding in the image� This adjustment may be necessary when you connect your computer for the first time�...
Page 107 5. Using On-Screen Menu Adjusting Horizontal/Vertical Position [HORIZONTAL/VERTICAL] Adjusts the image location horizontally and vertically. • An image can be distorted during the adjustment of [CLOCK] and [PHASE]. This is not malfunction. • The adjustments for [CLOCK], [PHASE], [HORIZONTAL], and [VERTICAL] will be stored in memory for the cur- rent signal. The next time you project the signal with the same resolution, horizontal and vertical frequency, its adjustments will be called up and applied. To delete adjustments stored in memory, from the menu, you select [SETUP] → [RESET] → [CURRENT SIGNAL] and reset the adjustments. [BLANKING] Adjusts the display range (blanking) at the top, bottom, left and right edges of the input signal. Selecting Overscan Percentage [OVERSCAN] Select overscan percentage (Auto, 0%, 5% and 10%) for signal. Projected image Overscaned by 10% NOTE: • The [OVERSCAN] item is not available: - w hen [NATIVE] is selected for [ASPECT RATIO].
Page 108 5. Using On-Screen Menu Selecting the Aspect Ratio [ASPECT RATIO] Use this function to select the screen’s lateral:longitudinal aspect ratio. The projector automatically identifies the signal being input and sets the optimum aspect ratio. For Computer signal For HDTV/SDTV signals Resolution Aspect Ratio 640 × 480 SVGA 800 × 600 1024 × 768 WXGA 1280 × 768 15:9 WXGA 1280 × 800 16:10 HD(FWXGA) 1366 × 768 approx. 16:9 WXGA+ 1440 × 900 16:10 SXGA 1280 × 1024 SXGA+ 1400 × 1050 WXGA++ 1600 × 900 16:9 UXGA 1600 × 1200...
Page 109: Input Resolution
5. Using On-Screen Menu Options Function 15:9 The image is displayed in 15:9 aspect ratio 16:10 The image is displayed in 16:10 aspect ratio NATIVE The projector displays the current image in its true resolution when the incoming computer signal has a lower or higher resolution than the projector’s native resolution. (→ page 2) When the incoming computer signal has a higher resolution than the projector's native resolution, the center of an image will be displayed. LETTER BOX The image of a letterbox signal (16:9) is stretched equally in the horizontal and vertical directions to fit the screen. WIDE SCREEN The image of a squeeze signal(16:9) is stretched left and right in 16:9. ZOOM The image of a squeeze signal (16:9) is stretched left and right in 4:3. Parts of the displayed image are cropped at the left and right edges and therefore not visible. FULL Project to full screen size. TIP: • Image position can be adjusted vertically using [POSITION] when the [16:9], [15:9], or [16:10] aspect ratios are selected. • The term “letterbox” refers to a more landscape-oriented image when compared to a 4:3 image, which is the standard aspect ratio for a vide source. The letterbox signal has aspect ratios with the vista size “1.85:1” or cinema scope size “2.35:1” for movie film. • The term “squeeze” refers to the compressed image of which aspect ratio is converted from 16:9 to 4:3. [INPUT RESOLUTION] The resolution is assigned automatically when the resolution of the input signal from the computer video input terminal (analog RGB) cannot be distinguished.
Page 110: [Video]
5. Using On-Screen Menu [VIDEO] Using Noise Reduction [NOISE REDUCTION] When projecting a video image, you can use the [NOISE REDUCTION] function to reduce the screen noise (roughness and distortion). This device is equipped with three types of noise reduction functions. Select the function according to the type of noise. Depending on the noise level, the noise reduction effect can be set to [OFF], [LOW], [MEDIUM] or [HIGH]. [NOISE REDUCTION] can be selected for SDTV, HDTV signal and component signal input. RANDOM NR �� Reduces flickering random noise in an image� MOSQUITO NR �� Reduces mosquito noise that appears around the edges of an image during Blu-ray playback� BLOCK NR ��...
Page 111: Signal Type
5. Using On-Screen Menu [SIGNAL TYPE] Selection of RGB and component signals. Normally, this is set to [AUTO]. Please change the setting if the color of the image remains unnatural. AUTO �� Automatically distinguishes RGB and component signals� RGB �� Switches to the RGB input� REC601 �� Switches to the component signal conforming to the ITU-R Rec601 standard� Setting appropriate to SDTV images� REC709 ��...
Page 112: [3D Settings]
5. Using On-Screen Menu [3D SETTINGS] Please refer to “3-9 Projecting 3D videos” (→ page 46) for the operation. STEREO VIEWER Stack up a single or multiple projectors and carry out the settings for projecting 3D videos. Select the left / right set- tings of the 3D eyewear using the stereo viewer. SINGLE �� Use a single projector to project 3D videos� DUAL LEFT �� Use a dedicated projector for displaying videos on the left� DUAL RIGHT �� Use a dedicated projector for displaying videos on the right� STEREO FILTER Stack up a single or multiple projectors and carry out the settings for projecting 3D videos. Image setting for 3D glasses made by Infitec.
Page 113: Using The Lens Memory Function [Lens Memory]
5. Using On-Screen Menu Using the Lens Memory Function [LENS MEMORY] This function serves to store the adjusted values for each input signal when using the LENS SHIFT, ZOOM and FO- CUS buttons of the projector. Adjusted values can be applied to the signal you selected. This will eliminate the need to adjust lens shift, focus, and zoom at the time of source selection. STORE �� Stores the current adjusted values in memory for each input signal� MOVE �� Applies the adjusted values to the current signal� RESET �� Returns the adjusted values to the last condition� • The lens units NP11FL, NP12ZL, NP13ZL, NP14ZL, and NP30ZL do not support this function.
Page 114 5. Using On-Screen Menu To call up the adjusted values from [LENS MEMORY]: 1. From the menu, select [ADJUST] → [LENS MEMORY] → [MOVE] and press the ENTER button. The confirmation screen will be displayed. 2. Press the ◀ button to select and [YES] and press the ENTER button. During projection, if the adjusted values for an input signal have been saved, the lens will shift. If not, the lens will shift according to the adjusted values stored in the selected [REF. LENS MEMORY] [PROFILE] number. To automatically apply the adjusted values at the time of source selection: 1. From the menu, select [SETUP] → [INSTALLATION] → [REF. LENS MEMORY] → [LOAD BY SIGNAL] and press the ENTER button.
Page 115: ❻ Menu Descriptions & Functions [Display]
5. Using On-Screen Menu ❻ Menu Descriptions & Functions [DISPLAY] [PIP/PICTURE BY PICTURE] SUB INPUT Select the input signal to be displayed in the sub-display. Please refer to “4-2 Displaying Two Pictures at the Same Time” (→ page 66) for details on the operation. MODE Select either PIP (PICTURE IN PICTURE) or PICTURE BY PICTURE when switching to 2-screen display. PICTURE SWAP The videos in the main display and sub-display will be switched. Please refer to “4-2 Displaying Two Pictures at the Same Time” (→ page 68) for details. PIP SETTING Select the display position, position adjustment and size of the sub-display in the PIP screen. START POSITION �� Selection of the display position of the sub-display when switching to the PIP screen� HORIZONTAL POSITION ��...
Page 116 5. Using On-Screen Menu TIP: The horizontal position and vertical position are the amount of movement from the reference points. For example, when TOP-LEFT is adjusted, the position is displayed with the same amount of movement even if displayed with other starting positions. The maximum amount of movement is half the resolution of the projector. Reference point Adjust using the horizon- Reference point tal position Adjust using the vertical position...
Page 117: [Geometric Correction]
5. Using On-Screen Menu [GEOMETRIC CORRECTION] MODE Set pattern for correcting distortion. If [OFF] is selected, the [GEOMETRIC CORRECTION] becomes ineffective. If you need to change either the [MENU ANGLE] or [MENU POSITION], make sure to change these before performing the [GEOMETRIC CORRECTION]. If either of them is changed after performing the [GEOMETRIC CORRECTION], corrected values will be reset to the default values. KEYSTONE Correct distortion in horizontal and vertical directions. HORIZONTAL �� Adjustments when projecting from a diagonal direction to the screen� VERTICAL �� Adjustments when projecting from the top or bottom direction to the screen�...
Page 118 5. Using On-Screen Menu CORNERSTONE Display the 4-point correction screen and adjust the trapezoidal distortion of the projection screen. Please refer to “Correcting Horizontal and Vertical Keystone Distortion [CORNERSTONE]” (→ page 38) for details on the operation. HORIZONTAL CORNER/VERTICAL CORNER Distortion correction for corner projection such as wall surfaces. HORIZONTAL CORNER �� Performs correction for projection onto a wall lying at an angle to the horizontal direction� * Reverse angle correction is also possible� VERTICAL CORNER ��...
Page 119 5. Using On-Screen Menu Adjustment method 1. Align the cursor with the [HORIZONTAL CORNER] or [VERTICAL CORNER] of the [GEOMETRIC CORREC- TION] menu and then press the ENTER button. • The adjustment screen will be displayed. 2. Press the ▼▲◀▶ buttons to align the cursor (yellow box) with the target adjustment point and then press the ENTER button. • The cursor will change into an adjustment point (yellow in color). 3. Press the ▼▲◀▶ buttons to adjust the corners or sides of the screen and then press the ENTER button. • The adjustment point will go back to being a cursor (yellow box). Explanation of screen transition • The adjustment points of the four corners (a, c, f and h in the drawing) will move independently. • The following adjustment points differ at the [HORIZONTAL CORNER] and [VERTICAL CORNER]. HORIZONTAL CORNER: When Point b in the drawing is moved, and the upper side and Point g are moved, the lower side will move in a parallel manner.
Page 120 5. Using On-Screen Menu WARP Correct projected image distortion on a specific surface as a column or a sphere. NOTE: • When the maximum adjustment range is exceeded, distortion adjustment is disabled. Set up the projector at an optimal angle since the more the adjustment volume gets large, the more image quality gets deterioration. • Please note that the image will go out of focus due to the difference in the distance between peripheries and the center of the screen for projections cutting across corners as on a column or a sphere. Lenses with short focal points are also not recommended for projections cutting across corners as the image will go out of focus. Adjustment method 1. Align the cursor with the [WARP] of the [GEOMETRIC CORRECTION] menu and the press the ENTER.
Page 121 5. Using On-Screen Menu PC TOOL Recall the geometric correction data that is registered in the projector beforehand. Three types of correction data can be registered. NOTE: • As electrical correction is carried out in geometric correction, the brightness may be affected and the picture quality may be degraded. RESET Reset the adjustment value that has been set up as MODE in GEOMETRIC CORRECTION (return to the initial value). • This is ineffective when MODE is set OFF. • Reset can be executed by pressing and holding the Geometeric button on the remote control for over 2 seconds.
Page 122: [Edge Blending]
5. Using On-Screen Menu [EDGE BLENDING] This adjusts the edges (boundaries) of the projection screen when projecting high resolution videos using a combina- tion of several projectors in the up, down, left and right positions. MODE This enables or disables the EDGE BLENDING function. When MODE is set to ON, the TOP, BOTTOM, LEFT, RIGHT, BLACK LEVEL and BLEND CURVE settings can be adjusted. TOP/BOTTOM/LEFT/RIGHT This selects the EDGE BLENDING locations on the left, right, top and bottom on the screen. The following settings can be adjusted when an item is selected. (→ page 70) CONTROL �� Enable TOP, BOTTOM, LEFT and RIGHT functions� MARKER �� Set whether to display marker or not when adjusting the range and display position� When turned on, a magenta marker for adjusting the range adjustment and a green marker for adjusting the display position will be displayed�...
Page 123: [Multi Screen]
5. Using On-Screen Menu [MULTI SCREEN] WHITE BALANCE This adjusts the white balance for each projector when projecting using a combination of several projectors. This can be adjusted when [MODE] is set to [ON]. CONTRAST W, CONTRAST R, CONTRAST G, CONTRAST B �� Adjusting the white color of the video� BRIGHTNESS W, BRIGHTNESS R, BRIGHTNESS G, BRIGHTNESS B �� Adjusting the black color of the video� PICTURE SETTING This sets the division condition when projecting using a combination of several projectors.
Page 124 5. Using On-Screen Menu Conditions for using tiling • All the projectors need to fulfil the following conditions. • The panel size must be the same • The projection screen size must be the same • The left and right ends or top and bottom ends of the projection screen must be consistent. • The settings for the left and right edges of the edge blending are the same • The settings for the top and bottom edges of the edge blending are the same If the tiling conditions are satisfied, the video screen of the projector at each installation position will be automati- cally extracted and projected. If the tiling conditions are not satisfied, adjust the video screen of the projector at each installation position using the zoom function. • Assign a unique control ID to each projector. • Set the “Color setting” and “DeepColor setting” on your Blu-ray player or computer to “Auto” . Refer to the owner's manual accompanied with your Blu-ray player or computer for more information. Connect an HDMI output signal of your Blu-ray player or computer to the first projector and then connect to the HDBaseT OUT/Ethernet port on the first projector to the HDBaseT IN/Ethernet port on the second projector, same to the sequel projectors.. Tiling setting example) Number of horizontal units = 2, Number of vertical units = 2 Horizontal order = Second unit Vertical order = First unit...
Page 125: ❼ Menu Descriptions & Functions [Setup]
5. Using On-Screen Menu ❼ Menu Descriptions & Functions [SETUP] [MENU(1)] Selecting Menu Language [LANGUAGE] You can choose one of 29 languages for on-screen instructions. NOTE: Your setting will not be affected even when [RESET] is done from the menu. Selecting Menu Color [COLOR SELECT] You can choose between two options for menu color: COLOR and MONOCHROME. Turning On / Off Source Display [INPUT DISPLAY] This option turns on or off input name display such as HDMI1, HDMI2, DisplayPort, COMPUTER, HDBaseT to be displayed on the top right of the screen. Turning messages on and off [MESSAGE DISPLAY] This option selects whether or not to display projector messages at the bottom of the projected image.
Page 126 5. Using On-Screen Menu Turning On / Off Eco Message [ECO MESSAGE] This option turns on or off the following messages when the projector is turned on. The Eco Message prompts the user to save energy. When [OFF] is selected for [ECO MODE], you will get a message to prompt you to select [ON] for [ECO MODE]. When [ON] is selected for [ECO MODE] To close the message, press any one of the buttons. The message will disappear if no button operation is done for 30 seconds. When [OFF] is selected for [ECO MODE] Pressing the ENTER button will display the [ECO MODE] screen. (→ page 36) To close the message, press the EXIT button. [3D CAUTION MESSAGE] This selects whether to display a caution message or not when switching to a 3D video. The default condition when shipped from the factory is ON. OFF �� The 3D caution message screen will not be displayed� ON �� The 3D caution message screen will be displayed when switching to a 3D video� Press the ENTER button to cancel the message�...
Page 127: [Menu(2)]
5. Using On-Screen Menu [MENU(2)] [MENU ANGLE] Select the direction for displaying the menu. [MENU POSITION] Shift the menu displaying position. HORISONTAL POSITION ��Shift the menu in the horizontal directions� VERTICAL POSITION ��Shift the menu in the vertical directions� RESET ��Reset the menu displaying position to the default factory setting (the screen center)� • Once the projector is powered off, the menu displaying position will reset to the default factory setting.
Page 128: [Installation]
5. Using On-Screen Menu [INSTALLATION] Selecting Projector Orientation [ORIENTATION] This reorients your image for your type of projection. The options are: desktop front projection, ceiling rear projection, desktop rear projection, and ceiling front projection. NOTE: • Please consult the retail store if you require special installation services e.g. when mounting the projector to a ceiling. Never install the projector on your own. This may result in the projector falling down and causing injury to people. • When using the projector suspended from a ceiling, ensure that people do not stay below the projector. In the event the lamp were to break, there is a risk that glass fragments may fall from the projector. AUTO ��...
Page 129: Screen Type
5. Using On-Screen Menu Selecting Aspect Ratio and Position for Screen [SCREEN] [SCREEN TYPE] Sets the aspect ratio of the projection screen. FREE �� The ratio of the liquid crystal panel is selected� Select this when projecting multi-screen and 17:9 screen (2K)� 4:3 SCREEN �� For a screen with a 4:3 aspect ratio 16:9 SCREEN ��...
Page 130: Light Mode
5. Using On-Screen Menu TIP: • When [HIGH ALTITUDE] is selected for [FAN MODE], a symbol icon will be displayed at the bottom of the menu. [LIGHT MODE] When eco-mode is set to [ON], the CO emissions (calculated from the reduction in power consumption) of the projec- tor can be reduced. The eco-mode reduces power consumption by mainly lowering the brightness of the lamp. As a result, the lamp replacement time (as a guide)* is extended. (→ page 37, 136) * Replacement time not guaranteed. REF� LIGHT �� This can be set when the eco-mode is set to [OFF]� Adjust the lamp to match the brightness of each projector when projecting a multi-screen display using multiple projectors�...
Page 131: Lens Calibration
5. Using On-Screen Menu Using the Reference Lens Memory Function [REF. LENS MEMORY] This function serves to store the adjusted values common to all input sources when using the LENS SHIFT, ZOOM and FOCUS buttons of the projector or the remote control. The adjusted values stored in memory can be used as a reference to the current. PROFILE �� Select a stored [PROFILE] number� STORE �� Stores the current adjusted values in memory as a reference� MOVE �� Applies the adjusted reference values stored in [STORE] to the current signal� RESET ��...
Page 132: [Control]
5. Using On-Screen Menu [CONTROL] TOOLS ADMINISTRATOR MODE This allows you to select MENU MODE, save settings, and set a password for the administrator mode. MENU MODE Select either [BASIC] or [ADVANCED] menu. — (→ page 78) NOT SAVE SETTING Placing a check mark will not save your projector settings. — VALUES Clear this check box to save your projector settings. NEW PASSWORD/ Assign a password for the administrator mode. Up to 10 alphanumeric CONFIRM PASS- characters WORD...
Page 133 5. Using On-Screen Menu PROGRAM TIMER This option turns on/standby the projector and changes video signals, and selects LIGHT mode automatically at a specified time. NOTE: • Before using [PROGRAM TIMER], make sure that the [DATE AND TIME] feature is set. (→ page 122) Make sure that the projector is in the standby condition with the POWER cord connected. The projector has a built-in clock. The clock will keep working for about two weeks after the main power is turned off. If the main power is not supplied to the projector for two weeks or more, it requires to set [DATE AND TIME SETTINGS] feature again. Setting a new program timer 1. On the PROGRAM TIMER screen, use the ▲...
Page 134 5. Using On-Screen Menu DAY �� Select days of the week for the program timer� To execute the program from Monday to Friday, select [MON- FRI]� To execute the program in everyday basis, select [EVERYDAY]� TIME �� Set the time to execute the program� Enter time in 24-hour format� FUNCTION ��...
Page 135 5. Using On-Screen Menu Activating the program timer 1. Select [ENABLE] on the [PROGRAM TIMER] screen and press the ENTER button. The selection screen will be displayed. 2. Press the ▼ button to align the cursor with [ON] and then press the ENTER button. Return to the [PROGRAM TIMER] screen. NOTE: • When the effective settings of the [PROGRAM TIMER] have not been set to [ON], the program will not be executed even if the [ACTIVE] items in the program list have been ticked. • Even when the effective settings of the [PROGRAM TIMER] are set to [ON], the [PROGRAM TIMER] will not work until the [PRO- GRAM TIMER] screen is closed. Editing the programmed settings 1. On the [PROGRAM LIST] screen, select a program you want to edit and press the ENTER button. 2. Change the settings on the [EDIT] screen. 3. Select [OK] and press the ENTER button.
Page 136 5. Using On-Screen Menu DATE AND TIME SETTINGS You can set the current time, month, date, and year. NOTE: The projector has a built-in clock. The clock will keep working for about 2 weeks after the main power is turned off. If the main power is off for 2 weeks or more, the built-in clock will cease. If the built-in clock ceases, set the date and time again. The built-in clock will not cease while in the standby mode.
Page 137 5. Using On-Screen Menu Setting ID to the Projector [CONTROL ID] You can operate multiple projectors separately and independently with the single remote control that has the CONTROL ID function. If you assign the same ID to all the projectors, you can conveniently operate all the projectors together using the single remote control. To do so, you have to assign an ID number to each projector. CONTROL ID NUMBER ��Select a number from 1 to 254 you wish to assign to your projector� CONTROL ID ��Select [OFF] to turn off the CONTROL ID setting and select [ON] to turn on the CONTROL ID setting� NOTE: • When [ON] is selected for [CONTROL ID], the projector cannot be operated by using the remote control that does not support the CONTROL ID function. (In this case the buttons on the projector cabinet can be used.)
Page 138 5. Using On-Screen Menu Turning On or Off Remote Sensor [REMOTE SENSOR] This option determines which remote sensor on the projector is enabled in wireless mode. The options are: FRONT/BACK, FRONT, BACK, and HDBaseT*. NOTE: • The remote control of the projector will not be able to receive signals if the power supply of the HDBaseT transmission device connected to the projector is switched on when this has been set to “HDBaseT”. TIP: • If the remote control system does not function when direct sunlight or strong illumination strikes the remote control sensor of the projector, change to other option.
Page 139: [Network Settings]
5. Using On-Screen Menu [NETWORK SETTINGS] Important: • Consult with your network administrator about these settings. • When using a wired LAN, connect the Ethernet cable (LAN cable) to the LAN port on the projector. (→ page 152) • Please use a shielded twisted pair (STP) cable of Category 5e or higher for the LAN cable (sold commercially). TIP: The network settings you make will not be affected even when [RESET] is done from the menu. Hints on How to Set Up LAN Connection To set up the projector for a LAN connection: Select [WIRED LAN] → [PROFILES] → [PROFILE 1] or [PROFILE 2]. Two settings can be set for wired LAN. Next turn on or off for [DHCP], [IP ADDRESS], [SUBNET MASK], and [GATEWAY] and select [OK] and press the ENTER button. (→ page 126) To recall LAN settings stored in the profile number: Select [PROFILE 1] or [PROFILE 2] for wired LAN, and then select [OK] and press the ENTER button. (→ page 126) To connect a DHCP server: Turn on [DHCP] for wired LAN. Select [ON] and press the ENTER button. To specify IP address without using the DHCP server, turn off [DHCP]. (→ page 126) To receive lamp replacement time or error messages via e-mail:...
Page 140 5. Using On-Screen Menu WIRED LAN INTERFACE Select [LAN] for using the LAN port for connecting to the wired — LAN. Select [HDBaseT] for using the HDBaseT IN/Ethernet port for connecting to the wired LAN. The control from the connected device will be disabled if no signal is sent and received for three minutes if the projector is connected to wired LAN thru the HD- BaseT IN/Ethernet. For refusing this, set the standby mode to [SLEEP] in advance. PROFILES • The settings for the wired LAN can be recorded in the projector — memory in two ways. • Select [PROFILE 1] or [PROFILE 2] and then do settings for [DHCP] and the other options. After doing this, select [OK] and press the ENTER button. This will store your settings in memory. • To recall the settings from memory: After selecting [PROFILE 1] or [PROFILE 2] from the [PRO- FILES] list. Select [OK] and press the ENTER button. • Select [DISABLE] when not connecting to a wired LAN DHCP Place a check mark to automatically assign an IP address to the — projector from your DHCP server. Clear this check box to register the IP address or subnet mask number obtained from your network administrator.
Page 141 5. Using On-Screen Menu PROJECTOR NAME PROJECTOR NAME Set a unique projector name. Up to 16 alphanu- meric characters and symbols DOMAIN Set a host name and domain name of the projector. HOST NAME Set a host name of the projector. Up to 16 alphanumeric characters DOMAIN NAME Set a domain name of the projector. Up to 60 alphanumeric characters...
Page 142 5. Using On-Screen Menu ALERT MAIL ALERT MAIL This option will notify your computer of lamp replace time or error — messages via e-mail when using wireless or wired LAN. Placing a checkmark will turn on the Alert Mail feature� Clearing a checkmark will turn off the Alert Mail feature� Sample of a message to be sent from the projector: The lamp has reached the end of its usable life.
Page 143 5. Using On-Screen Menu NETWORK SERVICE HTTP SERVER Set a password for your HTTP server. Up to 10 alphanumeric characters PJLink This option allows you to set a password when you use the Up to 32 alphanumeric PJLink feature. characters NOTE: • Do not forget your password. However, if you forget your password, consult with your dealer. • What is PJLink? PJLink is a standardization of protocol used for controlling projectors of different manufacturers. This standard protocol is established by Japan Business Machine and Information System Industries Associa- tion (JBMIA) in 2005.
Page 144: [Source Options]
5. Using On-Screen Menu [SOURCE OPTIONS] Setting Auto Adjust [AUTO ADJUST] This feature sets the Auto Adjust mode so that the computer signal can be automatically or manually adjusted for noise and stability. You can automatically make adjustment in two ways: [NORMAL] and [FINE]. OFF �� The computer signal will not be automatically adjusted� You can manually optimize the computer signal� NORMAL �� Default setting� The computer signal will be automatically adjusted� Normally select this option� FINE ��...
Page 145 5. Using On-Screen Menu [HDBaseT OUT SELECT] Select signal to output from the HDBaseT OUT/Ethernet port on the projector. When two images are projected simul- taneously (PIP/PICTURE BY PICTURE), the image for the main screen is output. AUTO �� Output the input signal� When [PIP] has been set, the input signal for the main screen is output� HDMI1 �� Output the input signal thru the HDMI1 input terminal� HDMI2 ��...
Page 146: [Power Options]
5. Using On-Screen Menu [POWER OPTIONS] [STANDBY MODE] Select the standby mode: NORMAL �� Automatically transit the standby state and control consumption power based on the projector setting and the state of the connected device� (→ page 183) SLEEP �� Maintain the state of sleep� Consumption power becomes higher than the setting of NORMAL� Select this mode in the following cases: • For using the HDBaseT IN/Ethernet and HDBaseT OUT/Ethernet ports constantly.
Page 147 5. Using On-Screen Menu Enabling Power Management [AUTO POWER OFF] When this option is selected you can enable the projector to automatically turn off (at the selected time: 0:05, 0:10, 0:15, 0:20, 0:30, 1:00) if there is no signal received by any input or if no operation is performed. Using Off Timer [OFF TIMER] 1. Select your desired time between 30 minutes and 16 hours: OFF, 0:30, 1:00, 2:00, 4:00, 8:00, 12:00, 16:00. 2. Press the ENTER button on the remote control. 3. The remaining time starts counting down and it is displayed at the bottom of the On-Screen Menu. 4. The projector will turn off after the countdown is complete. NOTE: • To cancel the preset time, set [OFF] for the preset time or turn off the power. • When the remaining time reaches 3 minutes before the projector is turned off, the [THE PROJECTOR WILL TURN OFF WITHIN 3 MINUTES] message will be displayed on the bottom of the screen.
Page 148: Returning To Factory Default [Reset]
5. Using On-Screen Menu Returning to Factory Default [RESET] The RESET feature allows you to change adjustments and settings to the factory preset for a (all) source (s) except the following: [CURRENT SIGNAL] Resets the adjustments for the current signal to the factory preset levels. The items that can be reset are: [PRESET], [CONTRAST], [BRIGHTNESS], [COLOR], [HUE], [SHARPNESS], [AS- PECT RATIO], [HORIZONTAL], [VERTICAL], [CLOCK], [PHASE], and [OVERSCAN]. [ALL DATA] Reset all the adjustments and settings for all the signals to the factory preset. All items can be reset EXCEPT [ENTRY LIST], [LANGUAGE], [BACKGROUND], [FILTER MESSAGE], [EDGE BLENDING], [MULTI SCREEN], [SCREEN TYPE], [GEOMETRIC CORRECTION], [REF. WHITE BALANCE], [STATIC CONVERGENCE], [ADMINISTRATOR MODE], [CONTROL PANEL LOCK], [SECURITY], [COMMUNICA- TION SPEED], [DATE AND TIME SETTINGS], [CONTROL ID], [STANDBY MODE], [FAN MODE], [EDID VERSION], [HDCP VERSION], [LAMP LIFE REMAINING], [LAMP HOURS USED], [FILTER HOURS USED], [TOTAL CARBON...
Page 149 5. Using On-Screen Menu Clearing the Filter Usage Hours [CLEAR FILTER HOURS] Resets the filter usage back to zero. Selecting this option displays submenu for a confirmation. Select [YES] and press the ENTER button. The [OFF] item is selected for [FILTER MESSAGE] at the time of shipment. When [OFF] is selected, you do not need to clear the filter usage hour. NOTE: Elapsed time of the filter use will not be affected even when [RESET] is done from the menu.
Page 150: ❽ Menu Descriptions & Functions [Info.]
❽ Menu Descriptions & Functions [INFO.] Displays the status of the current signal and lamp usage. This item has nine pages. The information included is as follows: TIP: Pressing the HELP button on the remote control will show the [INFO.] menu items. [USAGE TIME] [LAMP LIFE REMAINING] (%)* [LAMP HOURS USED] (H) [FILTER HOURS USED] (H) [TOTAL CARBON SAVINGS] (kg-CO2) * The progress indicator shows the percentage of remaining bulb life. The value informs you of the amount of lamp usage. When the remaining lamp time reaches 0, the LAMP LIFE REMAINING bar indicator changes from 0% to 100 Hours and starts counting down. • The message to the effect that the lamp or the filters should be replaced will be displayed for one minute when the projector is turned on and when the POWER button on the projector or the remote control is pressed. To dismiss this message, press any button on the projector or the remote control. NP42LP Lamp life (H) PA803U PA723U PA653U PA853W PA703W PA903W ECO mode OFF 3000 3500 4000 3000 4000 3000 ECO mode 5000 • [TOTAL CARBON SAVINGS] This displays the estimated carbon saving information in kg. The carbon footprint factor in the carbon saving cal-...
Page 151: [Source(1)]
5. Using On-Screen Menu [SOURCE(1)] INPUT TERMINAL RESOLUTION HORIZONTAL FREQUENCY VERTICAL FREQUENCY SYNC TYPE SYNC POLARITY SCAN TYPE SOURCE NAME ENTRY NO. [SOURCE(2)] SIGNAL TYPE BIT DEPTH VIDEO LEVEL SAMPLING FREQUENCY 3D FORMAT [SOURCE(3)] INPUT TERMINAL RESOLUTION HORIZONTAL FREQUENCY VERTICAL FREQUENCY SYNC TYPE SYNC POLARITY SCAN TYPE SOURCE NAME ENTRY NO.
Page 152: [Source(4)]
5. Using On-Screen Menu [SOURCE(4)] SIGNAL TYPE BIT DEPTH VIDEO LEVEL SAMPLING FREQUENCY 3D FORMAT [WIRED LAN] IP ADDRESS SUBNET MASK GATEWAY MAC ADDRESS [VERSION] FIRMWARE DATA FIRMWARE2...
Page 153: [Others]
5. Using On-Screen Menu [OTHERS] DATE TIME PROJECTOR NAME MODEL NO. SERIAL NUMBER LENS ID [CONDITIONS] INTAKE TEMPERATURE EXHAUST TEMPERATURE ATMOSPHERIC PRESSURE INSTALLATION POSITION X-AXIS Y-AXIS Z-AXIS About the X-AXIS, Y-AXIS and Z-AXIS CONDITIONS * Arrow direction of the Z-AXIS in the figure represents the top of the projector. X-AXIS �� Display the projector image at an angle of −100 – +100 X-AXIS value of degrees to the horizontal in the X-axis direction� the projector Horizontal plane X-axis...
Page 154: [Hdbaset]
5. Using On-Screen Menu Z-AXIS �� Display the projector image at an angle of −100 – +100 Z-AXIS value of degrees to the vertical in the Z-axis direction� the projector Horizontal plane Z-axis Gravity direction [HDBaseT] SIGNAL QUALITY OPERATION MODE LINK STATUS HDMI STATUS...
Page 155: Connecting To Other Equipment
6. Connecting to Other Equipment ❶ Mounting a lens (sold separately) Eight separate bayonet style lenses can be used with this projector. The descriptions here are for the NP13ZL (2x zoom) lens. Mount other lenses in the same manner. Important: • Be sure to carry out [LENS CALIBRATION] after replacing the lens. • The projector and lenses are made of precision parts. Do not subject them to shock or excessive forces. • Remove the separately sold lens when moving the projector. If not, the lens could be subject to shock while the projector is being moved, damaging the lens and the lens shift mechanism. • When dismounting the lens from the projector, return the lens position to the home position before turning off the power. Failure to do so may prevent the lens from being mounted or dismounted because of narrow space between the projector and the lens. • Turn off the power and wait for the cooling fan to stop before mounting or removing the lens.
Page 156: Installation And Connections
6. Installation and Connections 4. Turn the lens clockwise. Turn until a click is heard. The lens is now fastened onto the projector. TIP: Mounting the lens theft prevention screw Fasten the lens theft prevention screw included with the projector to the bottom of the projector so that the lens cannot be removed easily. Removing the lens Preparations: 1. Turn on the projector and display an image. 2.
Page 157: ❷ Making Connections
6. Installation and Connections ❷ Making Connections A computer cable, HDMI cable, or a DisplayPort cable can be used to connect to a computer. The connection cable is not enclosed with the projector. Please get ready a suitable cable for the connection. Analog RGB signal connection • Connect the computer cable to the monitor out terminal (mini D-sub 15 pin) on the computer and the computer video input terminal on the projector. Please use a computer cable attached with a ferrite core. AUDIO IN COMPUTER IN AUDIO OUT Stereo mini-plug audio cable (not supplied) Computer cable (sold commercially) NOTE: • Please check the operating manual of the computer as...
Page 158: Digital Rgb Signal Connection
6. Installation and Connections Digital RGB signal connection • Connect a commercially available HDMI cable between the computer’s HDMI output connector and the projector’s HDMI1 or HDMI2 input connector. • Connect a commercially available DisplayPort cable between the computer’s DisplayPort output connector and the projector’s DisplayPort input connector. HDMI 1 IN DisplayPort IN HDMI 2 IN DisplayPort cable (not supplied) HDMI cable (not supplied) • Select the source name for its appropriate input connector after turning on the projector. INPUT button on the projector Input connector Button on the remote control cabinet HDMI 1 IN 1:HDMI 1 1/HDMI 1 HDMI 2 IN 2:HDMI 2 2/HDMI 2 DisplayPort IN...
Page 159 6. Installation and Connections Cautions when using a DVI signal • When the computer has a DVI output connector, use a commercially available converter cable to connect the computer to the projector’s HDMI 1 or HDMI 2 input connector (only digital video signals can be input). Also, con- nect the computer’s audio output to the projector’s audio input connector. In this case, switch the HDMI1 or HDMI2 setting at on-screen menu’s audio selection on the projector to [COMPUTER]. (→ page 130) To connect the computer’s DVI output connector to the projector’s DisplayPort input connector, use a commercially available converter. HDMI 2 IN AUDIO IN HDMI 1 IN AUDIO OUT NOTE: When Viewing a DVI Digital Signal • Turn off the power of the computer and projector before connecting.
Page 160: Connecting Component Input
6. Installation and Connections Connecting Component Input COMPUTER IN 15-pin - to - RCA (female) × 3 cable adapter (ADP-CV1E) Component video RCA × 3 cable (not supplied) Audio Equipment Blu-ray player Stereo mini plug - to - RCA audio cable (not supplied) • Select the source name for its appropriate input connector after turning on the projector.
Page 161: Connecting Hdmi Input
6. Installation and Connections Connecting HDMI Input You can connect the HDMI output of your Blu-ray player, hard disk player, or notebook type PC to the HDMI 1 IN or HDMI 2 IN connector of your projector. HDMI 1 IN HDMI 2 IN AUDIO OUT HDMI cable (not supplied) Use High Speed HDMI ® Cable. Audio cable (not supplied) INPUT button on the projector Input connector Button on the remote control cabinet HDMI 1 IN 1:HDMI 1 1/HDMI 1 HDMI 2 IN 2:HDMI 2 2/HDMI 2 TIP: For users of audio video equipment with an HDMI connector: Select “Enhanced” rather than “Normal” if HDMI output is switchable between “Enhanced” and “Normal”.
Page 162: Connecting To A Hdbaset Transmission Device (Sold Commercially)
6. Installation and Connections Connecting to a HDBaseT transmission device (sold commercially) Use a LAN cable sold commercially to connect the HDBaseT IN/Ethernet port of the projector (RJ-45) to a HDBaseT transmission device sold commercially. The HDBaseT IN/Ethernet port of the projector supports HDMI signals (HDCP) from transmission devices, control signals from external devices (serial, LAN) and remote control signals (IR commands). • Refer to the owner’s manual accompanied with your HDBaseT transmission for connecting with your external de- vices. Connection example Computer (for output use) Computer (for control use) Our company’s remote control (RD-465E) Wired-Remote AUDIO IN HDMI IN COMPUTER IN RS-232C...
Page 163: Connecting Several Projectors
6. Installation and Connections Connecting several projectors It enables to project HDMI, DisplayPort, HDBaseT image on several projectors connecting the HDBaseT IN/Ethernet port and the HDBaseT OUT/Ethernet port by LAN cable. The projectors support same brightness and resolution can be connected up to four units, HDBaseT OUT/Ethernet Master projector HDBaseT IN/Ethernet Other projector • The signal from the COMPUTER IN terminal is not output from the HDBaseT OUT/Ethernet port of this projector. • Projectors of which brightness and resolution are different, these can not be connected even if these are in same series. At the same time, this projector is not guaranteed to work correctly in the connection with an other device as a monitor. • When outputting HDMI signals, turn on the power of the video device on the output side and keep it connected before inputting video signals into this device. The HDMI output terminals of the projector are equipped with repeater functions. When a device is connected to the HDMI output terminal, the resolution of the output signal is limited by the resolution supported by the connected device. • Connecting and disconnecting an HDMI cable or selecting another input source on the second and subsequent projectors will disable the HDMI repeater function.
Page 164: Portrait Projection (Vertical Orientation)
6. Installation and Connections Portrait projection (vertical orientation) Portrait screens from a computer can be projected by installing the projec- tor in a vertical orientation. Angle to display all the screens such as the on-screen menu can be changed by the menu [SETUP] → [MENU(2)] → [MENU ANGLE]. Precautions during installation • Please do not install the projector in a vertical orientation on top of the floor or table on its own. The intake vent may be obstructed, resulting in the projector getting warm and the possibility of fire and malfunction occurring. • For vertical installation, install the projector with the intake vent (filter) facing downwards. A stand for supporting the projector needs to be made for this purpose. In this case, the stand must be designed such that the center of gravity of the projector is located well within the legs of the stand. If not, the projector may fall over and result in injury, damage and malfunction. Design and manufacturing conditions for the stand Please engage an installation service provider for the design and manufacture of the customized stand to be used for portrait projection. Please ensure that the following are complied with when designing the stand. 1. Maintain an opening of at least 315 × 150 mm so as not to obstruct the intake vent / filter of the projector. 2. Maintain a distance of at least 130 mm between the projector intake vent and the floor (for the opening of the filter cover). 3. Use the four screw holes at the back of the projector to secure it to the stand. Screw hole center dimension: 200 × 250 mm Screw hole dimension on the projector: M4 with a maximum depth of 8 mm.
Page 165 6. Installation and Connections Reference drawings * The drawing showing the dimensional requirements is not an actual stand design drawing. [Side View] [Front View] [Bottom View] Screw holes for 4 - M4 use 315 or greater Filter cover Tilt foot (remove) Rear foot 130 or greater Filter cover (when opened) Horizontal adjuster...
Page 166: Connecting To A Wired Lan
6. Installation and Connections Connecting to a Wired LAN The projector comes standard with a LAN port (RJ-45) which provides a LAN connection using a LAN cable. To use a LAN connection, you are required to set the LAN on the projector menu. Select [SETUP] → [NETWORK SETTINGS] → [WIRED LAN]. (→ page 126). Example of LAN connection Example of wired LAN connection Server LAN cable (not supplied) NOTE: Use a Category 5 or higher LAN cable.
Page 167: Maintenance
7. Maintenance This section describes the simple maintenance procedures you should follow to clean the filters, the lens, the cabinet, and to replace the lamp and the filters. ❶ Cleaning the Filters The filter at the intake vent keeps dust and dirt from getting inside the projector. If the filter is dirty or clogged, your projector may overheat. WARNING • Please do not use a spray containing flammable gas to remove dust attached to the filters, etc. Doing so may result in fires. NOTE: The message for filter cleaning will be displayed for one minute after the projector is turned on or off. When the message is displayed, clean the filters. The time to clean the filters is set to [OFF] at time of shipment. (→ page 112) To cancel the message, press any button on the projector cabinet or the remote control. To clean the filter, detach the filter unit and the filter cover. CAUTION • Before cleaning the filters, turn off the projector, disconnect the power cord and then allow the cabinet to cool. Failure to do so can result in electric shock or burn injuries. 1.
Page 168 7. Maintenance 3. Vacuum dust on the front and back faces of the filter unit. • Get rid of dust in the filter. • Gently get rid of dust on the filter cover and in the accordion pleats of the filter. NOTE: • Whenever you vacuum the filter, use the soft brush attachment to vacuum. This is to avoid damage to the filter. • Do not wash the filter with water. Doing so can result in filter clog- ging. Filter cover Filter unit 4. Mount the filter unit back onto the projector cabinet. Insert the filter unit onto the projector aligning the two protru- Groove sions on each top and bottom of the filter unit to the grooves on the projector cabinet.
Page 169: ❷ Cleaning The Lens
7. Maintenance ❷ Cleaning the Lens • Turn off the projector before cleaning. • The projector has a plastic lens. Use a commercially available plastic lens cleaner. • Do not scratch or mar the lens surface as a plastic lens is easily scratched. • Never use alcohol or glass lens cleaner as doing so will cause damage to the plastic lens surface. WARNING • Please do not use a spray containing flammable gas to remove dust attached to the lens, etc. Doing so may result in fires. ❸ Cleaning the Cabinet Turn off the projector, and unplug the projector before cleaning. • Use a dry soft cloth to wipe dust off the cabinet. If heavily soiled, use a mild detergent. • Never use strong detergents or solvents such as alcohol or thinner. • When cleaning the ventilation slits or the speaker using a vacuum cleaner, do not force the brush of the vacuum cleaner into the slits of the cabinet. Vacuum the dust off the ventilation slits. • Clogged ventilation slits may cause a rise in the internal temperature of the projector, resulting in malfunction.
Page 170: ❹ Replacing The Lamp
• The bar indicator as the LAMP LIFE REMAINING shows the percentage of remaining bulb life. When the remaining lamp time reaches 0%, the LAMP LIFE REMAINING bar indicator changes from 0% to 100 Hours as the grace period for replacing lamp and starts counting down. In the grace period, the LAMP indicator will blink in orange. When it reaches 0 hours, the LAMP indicator will start blinking in red. If you continue to use the lamp after the lamp reaches the end of its life, the lamp bulb may shatter, and pieces of glass may be scattered in the lamp case. Do not touch them as the pieces of glass may cause injury. If this hap- pens, contact your NEC dealer for lamp replacement. *NOTE: This message will be displayed under the following conditions: • for one minute after the projector has been powered on • when the (POWER) button on the projector cabinet or the STANDBY button on the remote control is pressed To turn off the message, press any button on the projector cabinet or the remote control. Optional lamp and tools needed for replacement: • Phillips screwdriver (plus-head)
Page 171 7. Maintenance To replace the lamp: 1. Remove the lamp cover. (1) Loosen the lamp cover screw • The lamp cover screw is not removable. (2) Pull the bottom of the lamp cover towards you and remove it. 2. Remove the lamp housing. (1) Loosen the two screws securing the lamp housing until the phillips screwdriver goes into a freewheeling condi- tion.
Page 172 7. Maintenance 3. Install a new lamp housing. (1) Insert a new lamp housing gently. (2) Secure it in place with the two screws. • Be sure to tighten the screws. 4. Reattach the lamp cover. (1) Insert the top edge of the lamp cover into the groove in the projector and close the lamp cover. (2) Tighten the screw to secure the lamp cover.
Page 173 7. Maintenance To clear the lamp usage hours: 1. Place the projector where you use it. 2. Plug the power cord into the wall outlet, and then turn on the projector. 3. Clear the lamp usage hours. From the menu, select [RESET] → [CLEAR LAMP HOURS] and reset the lamp usage hours. (→ page 134)
Page 174: ❺ Replacing The Filters
7. Maintenance ❺ Replacing the filters Replace the filter every 10000 used hours. Usable time of the filter is varies depends on the projector installation circumstances. If your projector is installed in dusty circumstance, recommend to replace the filter earlier than 10000 hours. • The replacement filter, NP06FT, is available at our dealers. NOTE: • DO NOT TOUCH THE FILTER UNIT immediately after the projector has been used. Turn the projector off and then disconnect the power cord and leave the projector cooled down enough. • Time for replacing the filter is vary depends on the operation circumstances. To replace the filters: NOTE: • Before replacing the filters, wipe off dust and dirt from the projector cabinet. • The projector is precision equipment. Keep out dust and dirt during filter replacement. • Do not wash the filters with soap and water. Soap and water will damage the filter membrane. • Put filters into place. Incorrect attachment of a filter may cause dust and dirt to get into the inside of the projector. 1. Press down on the buttons on the left and right and then pull the filter cover towards you to open it. The cover will open about 90 degrees before it stops.
Page 175 7. Maintenance 5. Mount the filter unit back onto the projector cabinet. Insert the filter unit onto the projector aligning the two protru- Groove sions on each top and bottom of the filter unit to the groove on the projector cabinet. Protrusion 6. Close the filter cover. Keep to push the filter cover frame around the buttons until a “click”...
Page 176: Appendix
8. Appendix ❶ Throw distance and screen size Eight separate bayonet style lenses can be used on this projector. Refer to the information on this page and use a lens suited for the installation environment (screen size and throw distance). For instructions on mounting the lens, see page 141. Lens types and throw distance WUXGA Type Screen size Lens model name NP11FL NP30ZL NP12ZL NP13ZL NP14ZL NP40ZL NP41ZL NP42ZL 30" 0.7 - 0.9 40" 1.0 - 1.3 1.2 - 2.5 60" 1.0 - 1.3 1.5 - 1.9 1.9 - 3.8 3.7 - 6.0 1.0 - 1.4 1.7 - 3.9 3.9 - 7.7 80"...
Page 177 8. Appendix WXGA Type Screen size Lens model name NP11FL NP30ZL NP12ZL NP13ZL NP14ZL NP40ZL NP41ZL NP42ZL 30" 0.7 - 1.0 40" 1.0 - 1.3 1.2 - 2.5 60" 1.0 - 1.3 1.5 - 2.0 1.9 - 3.8 3.7 - 6.0 1.0 - 1.4 1.7 - 3.9 3.9 - 7.7 80" 1.4 - 1.8 2.0 - 2.6 2.5 - 5.1 5.0 - 8.1 1.4 - 1.9 2.2 - 5.2 5.2 - 10.3 100" 1.7 - 2.2 2.5 - 3.3 3.2 - 6.4 6.3 - 10.1 1.7 - 2.4 2.8 - 6.5 6.5 - 12.8 120"...
Page 178 8. Appendix XGA Type Screen size Lens model name NP11FL NP30ZL NP12ZL NP13ZL NP14ZL NP40ZL NP41ZL NP42ZL 30" 0.7 - 0.9 40" 0.9 - 1.2 1.2 - 2.4 60" 1.0 - 1.3 1.4 - 1.9 1.8 - 3.7 3.6 - 5.8 1.0 - 1.4 1.6 - 3.7 3.8 - 7.4 80" 1.3 - 1.7 1.9 - 2.5 2.4 - 4.9 4.8 - 7.8 134 - 1.8 2.2 - 5.0 5.0 - 9.9 100" 1.6 - 2.1 2.4 - 3.2 3.0 - 6.1 6.0 - 9.7 1.6 - 2.3 2.7 - 6.3 6.2 - 12.3 120"...
Page 179 8. Appendix Projection range for the different lenses NP11FL WUXGA Type: 0.7–2.6 m Motorized zoom / Motorized focus WXGA Type: 0.7–2.6 m Manual zoom / Manual focus XGA Type: 0.6–2.5 m Manual focus NP30ZL WUXGA Type: 1.0–11.3 m WXGA Type: 1.0–11.3 m XGA Type: 1.0–10.9 m NP12ZL WUXGA Type: 0.7–16.5 m WXGA Type: 0.7–16.7 m XGA Type: 0.7–16.0 m 30-500" 40-150" 60-500" 40-500" 50-500" 60-500" 50-500" 50-500" NP40ZL WUXGA Type: 0.8 - 12.2 m WXGA Type: 0.8 - 12.2 m XGA Type: 0.8 - 11.7 m NP13ZL WUXGA Type: 1.2–31.9 m WXGA Type: 1.2–32.1 m XGA Type: 1.2–30.8 m NP41ZL WUXGA Type: 1.4 - 32.6 m WXGA Type: 1.4 - 32.8 m...
Page 180: Tables Of Screen Sizes And Dimensions
8. Appendix Tables of screen sizes and dimensions WUXGA Type/WXGA Type Size (inches) Screen width Screen height (inches) (cm) (inches) (cm) 25.4 64.6 15.9 40.4 Screen 16:10 screen size (di- 33.9 86.2 21.2 53.8 height agonal) 50.9 129.2 31.8 80.8 67.8 172.3 42.4 107.7 84.8 215.4 53.0 134.6...
Page 181: Lens Shifting Range
8. Appendix Lens shifting range This projector is equipped with a lens shift function for adjusting the position of the projected image by buttons. The lens can be shifted within the range shown below. NOTE: • Use NP11FL at the home position. * Refer to the lens shift table on the next page for the drawing number of the lens shift range. Desk/front projection Width of projected image Height of projected image 100%V 10%H 10%H 100%H Description of symbols: V indicates vertical (height of the projected image), H indicates horizontal (width of the pro- jected image). Ceiling/front projector 100%H 10%H 10%H Height of projected image 100%V Width of projected image...
Page 182 8. Appendix Lens shift table Applicable Drawing Lens unit type number NP30ZL NP12ZL NP13ZL NP14ZL NP40ZL NP41ZL NP42ZL WUXGA Type 50% V 50% V 50% V 50% V 50% V 50% V 50% V ① 10% V 10% V 10% V 10% V 10% V 10% V 10% V ② 20% H 30% H 30% H* 30% H 20% H 20% H 20% H ③...
Page 183: ❷ Compatible Input Signal List
8. Appendix ❷ Compatible Input Signal List HDMI Signal Resolution ( dots ) Aspect Ratio Refresh Rate ( Hz ) 640 × 480 4 : 3 60/72/75/85/iMac SVGA 800 × 600 4 : 3 56/60/72/75/85/iMac 1024 × 768 4 : 3 60/70/75/85/iMac 1280 × 720 16 : 9 1280 ×...
Page 184: Analog Rgb
8. Appendix HDBaseT Signal Resolution ( dots ) Aspect Ratio Refresh Rate ( Hz ) 640 × 480 4 : 3 SVGA 800 × 600 4 : 3 1024 × 768 4 : 3 1280 × 720 16 : 9 WXGA 1280 × 768 15 : 9 1280 × 800 16 : 10 Quad-VGA 1280 ×...
Page 185 8. Appendix HDMI 3D Signal Resolution ( dots ) Aspect Ratio Refresh Rate ( Hz ) 3D Format Frame Packing 23.98/24 Side By Side (Half) Top And Bottom Side By Side (Half) Top And Bottom Frame Packing 1920 × 1080p 29.97/30 Side By Side (Half) Top And Bottom Side By Side (Half) Top And Bottom Side By Side (Half) 59.94/60 Top And Bottom Side By Side (Half) Top And Bottom 1920 × 1080i Side By Side (Half) 16 : 9 59.94/60 Top And Bottom Frame Packing 23.98/24 Side By Side (Half) Top And Bottom Side By Side (Half) Top And Bottom...
Page 186: ❸ Specifications
8. Appendix ❸ Specifications Model name PA803U/PA723U/PA653U PA853W/PA703W PA903X Method Three primary color liquid crystal shutter projection method Specifications of main parts Liquid crystal Size 0.76" (with MLA) × 3 (aspect ratio: 16:10) 0.76" (with MLA) × 3 panel (aspect ratio: 4:3) Pixels 2,304,000 (1920 dots × 1200 lines) 1,024,000 (1280 786,432 (1024 dots (*1) dots × 800 lines) × 768 lines) Projection lenses Refer to the specifications of option lens (→ 174 page) Light source PA803U: 420 W (280 W when ECO mode PA853W: 420 W 420 W (280 W when is on) (280 W when ECO ECO mode is on) PA723U: 400 W (280 W when ECO mode mode is on)
Page 187 8. Appendix Model name PA803U/PA723U/PA653U PA853W/PA703W PA903X HDBaseT/Eth- Video input Deep Color (color depth): Support 8/10/12 bits ernet Colorimetry: Support RGB, YCbCr444, YCbCr422 , YCbCr420 , REC2020, REC709, REC601 Support LipSync , HDCP , 4K , 3D, HDR (*4) Video output RJ-45x1, 100BASE-TX Deep Color (color depth): Support 8/10/12 bits Colorimetry: Support RGB, YCbCr444, YCbCr422, REC709, REC601 Support LipSync, HDCP , 4K , 3D (*4) Audio input Sampling frequency: 32/44.1/48 kHz Sampling bit: 16/20/24 bit Audio output Sampling frequency: 32/44.1/48 kHz Sampling bit: 16/20/24 bits DisplayPort Video input DisplayPort × 1 Data rate: 5.4 Gbps/2.7Gbps/1.62Gbps No. lanes: 1 lane/2 lanes/4 lanes Color depth: 8 bits, 10bits, 12bits Colorimetry: RGB, YCbCr444, YCbCr422 , REC709, REC601 HDCP compatible...
Page 188 8. Appendix *1 Effective pixels are more than 99.99%. *2 This is the light output value (lumens) when the [PRESET] mode is set to [HIGH-BRIGHT]. The light output values will drop to 80% when [ON] is selected for [ECO MODE]. If any other mode is selected as the [PRESET] mode, the light output value may drop slightly. *3 Compliance with ISO21118-2012 *4 If you are unable to view material via the HDMI input, this does not necessarily mean the projector is not functioning properly. With the implementation of HDCP, there may be cases in which certain content is protected with HDCP and might not be displayed due to the decision/intention of the HDCP community (Digital Content Protection, LLC). Video: HDR, Deep Color, 8/10/12-bit, Lip Sync. Audio: LPCM; up to 2 ch, sample rate 32/44.1/48 KHz, sample bit; 16/20/24-bit HDMI: Supports HDCP2.2/1.4 DisplayPort: Supports HDCP 1.4 HDBaseT: Supports HDCP 2.2/1.4 *5 95 to 104°F (35 to 40°C) – “Forced eco mode” • These specifications and the product’s design are subject to change without notice. Option lens (sold separately) NP11FL Throw ratio 0.81:1, F2.3, f=13.2mm NP12ZL Throw ratio 1.16 - 1.52:1, F2.20 - 2.69, f=19.4 - 25.3mm NP13ZL Throw ratio 1.46 - 2.95:1, F1.70 - 2.37, f=24.4 - 48.6mm NP14ZL Throw ratio 2.90 - 4.68:1, F2.20 - 2.64, f=48.5 - 77.6mm NP30ZL Throw ratio 0.79 - 1.04:1, F1.90 - 2.10, f=13.2 - 17.2mm NP40ZL Throw ratio 0.79 - 1.10:1, F2.00 - 2.43, f=13.3 - 18.6mm NP41ZL Throw ratio 1.30 - 3.02:1, F1.70 - 2.00, f=21.8 - 49.8mm NP42ZL Throw ratio 2.99 - 5.98:1, F2.20 - 2.30, f=49.6 - 100.0mm NOTE: • The above throw ratio is for projecting on 100" screen by WUXGA.
Page 189: ❹ Cabinet Dimensions
8. Appendix ❹ Cabinet Dimensions Unit: mm (inch) 499 (19.6) Lens center Lens center 250 (9.8)
Page 190: ❺ Mounting The Cable Cover (Sold Separately)
8. Appendix ❺ Mounting the cable cover (sold separately) Mounting the separately sold cable cover (NP10CV) on the projector allows you hide the cables for a cleaner appearance. CAUTION • After mounting the cable cover, be sure to fasten using the screws provided. If not, the cable cover could fall and damage the cable cover and possibly resulting in injury. • Do not bundle the power cord and place it under the cable cover. Doing so could lead to fire. • Do not hold the cable cover while moving the projector and do not apply excessive force to the cable cover. Doing so could damage the cable cover, resulting in the projector falling or causing injury. Mounting Preparations: 1. Connect the power cord and cables to the projector (the connection cords are omitted from the diagrams). 2.
Page 191: ❻ Pin Assignments And Signal Names Of Main Connectors
8. Appendix ❻ Pin assignments and signal names of main connectors COMPUTER IN/ Component Input Connector (Mini D-Sub 15 Pin) Connection and signal level of each pin Pin No. RGB Signal (Analog) YCbCr Signal 11 12 13 14 15 Green or Sync on Green Blue Ground Signal Level Ground Red Ground...
Page 192 8. Appendix HDBaseT IN/Ethernet Port (RJ-45) Pin No. Signal TxD+/HDBT0+ TxD−/HDBT0− RxD+/HDBT1+ Disconnection/HDBT2+ Disconnection/HDBT2− RxD−/HDBT1− Disconnection/HDBT3+ Disconnection/HDBT3− USB-A Port (Type A) Pin No. Signal D− Grounding PC CONTROL Port (D-Sub 9 Pin) Pin No. Signal Unused RxD reception data TxD transmission data Communications protocol Unused Grounding...
Page 193: ❼ Changing The Background Logo (Virtual Remote Tool)
8. Appendix ❼ Changing the Background Logo (Virtual Remote Tool) This will help you perform operations such as projector’s power on or off and signal selection via a LAN connection. It is also used to send an image to the projector and register it as the logo data of the projector. After registering it, you can lock the logo to prevent it from changing. Control Functions Power On/Off, signal selection, picture freeze, picture mute, audio mute, Logo transfer to the projector, and remote control operation on your PC. Virtual Remote screen Remote Control Window Toolbar For getting the Virtual Remote Tool, please visit our web site and download it: http://www.nec-display.com/dl/en/index.html NOTE: • Logo data (graphics) that can be sent to the projector with Virtual Remote Tool has the following restrictions: (Only via serial or LAN connection) * File size: Within 256 kilobytes * Image size: Within the resolution of the projector * File format: PNG (Full color) • Logo data (image) sent using the Virtual Remote Tool will be displayed in the center with the surrounding area in black. • To put the default “NEC logo” back in the background logo, you need to register it as the background logo by using the image file (NP-PA803U/NP-PA723U/NP-PA653U: ¥Logo¥necpj_bbwux.png, NP-PA853W/NP-PA703W: ¥Logo¥necpj_bbwx.png, NP-PA903X: ¥Logo¥necpj_bb_x.png) included on the supplied NEC Projector CD-ROM.
Page 194: ❽ Troubleshooting
8. Appendix ❽ Troubleshooting This section helps you resolve problems you may encounter while setting up or using the projector. Feature of each indicator ① POWER indicator This indicator informs the power status of the projector. ② STATUS indicator This indicator lights/blinks when a button is pressed while the CONTROL PANEL LOCK function is utilized, or while performing the lens calibration and specific operations. ③ LAMP indicator This indicator informs the state of lamp, usage time of the lamp, and the status of ECO MODE. ④ TEMP. indicator This is the temperature indicator informing temperature trouble when the ambient temperature is too high/low. Indicator Message (Status message) POWER STATUS LAMP TEMP. Projector status Power is off In the state of Standby (Standby mode is NORMAL and the network is ready. Orange (Blink* In the state of Standby (Standby mode is NORMAL and the network is unavail- able.
Page 195 8. Appendix POWER STATUS LAMP TEMP. Projector status Powered state (ECO mode is ON) Blue Green (Light) (Blink* Performing the lens calibration Blue Green Status (Light) (Blink* varies OFF Timer is activated, OFF time as the proogram timer is activated (Powered state) Blue Status (Blink* varies Preparing for powering ON Blue (Blink* *1 Repetition to light on for 1.5 seconds / off for 1.5 seconds *2 Repetition to light on for 1.5 seconds / off for 7.5 seconds *3 Repetition to light on for 2.5 seconds / off for 0.5 seconds *4 Repetition to light on for 0.5 seconds / off for 0.5 seconds / on for 0.5 seconds / off for 2.5 seconds *5 Repetition to light on for 0.5 seconds / off for 0.5 seconds...
Page 196: Indicator Message (Error Message)
8. Appendix Indicator Message (Error message) POWER STATUS LAMP TEMP. Projector status Procedure A button has been pressed while the The projector's keys are locked. The KEY LOCK is activated. setting must be canceled to operate the projector. (→ page 122) Blink Orange Status (Light) varies ID numbers for the projector and the Check the control IDs (→ page 123) remote control do not match. Lamp replacement grace period. The lamp has reached the end of its ser- vice life and is now in the replacement Status Orange grace period (100 hours). Replace the...
Page 197: Explanation On The Power Indicator And Standby State
8. Appendix Explanation on the POWER indicator and standby state In the state the selected PROFILE for WIRED LAN is available. Available ports in each state (○: Available, ×: Unavailable) HDBaseT IN/ Ethernet PC CONTROL HDBaseT OUT/Ethernet Power consumption Power On High Indicator : Lights in blue Power On...
Page 198 8. Appendix In the state the selected PROFILE for WIRED LAN is Available ports in each state (○: Available, ×: Unavailable) unavailable. HDBaseT IN/Ethernet HDBaseT OUT/ PC CONTROL Ethernet Power consumption Power On High Indicator : Lights in blue ○ × ○...
Page 199: Common Problems & Solutions
8. Appendix Common Problems & Solutions (→ “Power/Status/Lamp Indicator” on page 180.) Problem Check These Items Does not turn on • Check that the power cord is plugged in and that the power button on the projector cabinet or the remote control or shut down is on� (→ pages 15, 17) • Ensure that the lamp cover is installed correctly. (→ page 158) • Check to see if the projector has temperature error, If projector inside temperature is too hot or cool, it disabled to turn on the projector as the protection� Wait for a moment and try turn on the projector again� • The lamp may fail to light. Wait a full minute and then turn on the power again.
Page 200 8. Appendix Problem Check These Items Cross color in RGB • Press the AUTO ADJ. button on the projector cabinet or the remote control. (→ page 30) mode • Adjust the computer image manually with [CLOCK]/[PHASE] in [IMAGE OPTIONS] in the menu. (→ page 92) For more information contact your dealer.
Page 201: If There Is No Picture, Or The Picture Is Not Displayed Correctly
In most cases the output signal from the notebook PC is not turned on unless connected to the projector before being powered up. NOTE: You can check the horizontal frequency of the current signal in the projector’s menu under Information. If it reads “0kHz”, this means there is no signal being output from the computer. (→ page or go to next step) • Enabling the computer’s external display. Displaying an image on the notebook PC’s screen does not necessarily mean it outputs a signal to the projector. When using a PC compatible laptop, a combination of function keys will enable/disable the external display. Usu- ally, the combination of the “Fn” key along with one of the 12 function keys gets the external display to come on or off. For example, NEC laptops use Fn + F3, while Dell laptops use Fn + F8 key combinations to toggle through external display selections. • Non-standard signal output from the computer If the output signal from a notebook PC is not an industry standard, the projected image may not be displayed correctly. Should this happen, deactivate the notebook PC’s LCD screen when the projector display is in use. Each notebook PC has a different way of deactivate/reactivate the local LCD screens as described in the previous step. Refer to your computer’s documentation for detailed information. • Image displayed is incorrect when using a Mac When using a Mac with the projector, set the DIPswitch of the Mac adapter (not supplied with the projector) ac- cording to your resolution. After setting, restart your Mac for the changes to take affect. For setting display modes other than those supported by your Mac and the projector, changing the DIP switch on a Mac adapter may bounce an image slightly or may display nothing. Should this happen, set the DIP switch to...
Page 202: ❾ Pc Control Codes And Cable Connection
8. Appendix ❾ PC Control Codes and Cable Connection PC Control Codes Function Code Data POWER ON POWER OFF INPUT SELECT HDMI1 INPUT SELECT HDMI2 INPUT SELECT DisplayPort INPUT SELECT COMPUTER INPUT SELECT HDBaseT PICTURE MUTE ON PICTURE MUTE OFF SOUND MUTE ON SOUND MUTE OFF NOTE: Contact your local dealer for a full list of the PC Control Codes if needed.
Page 203 8. Appendix ABOUT THE ASCII CONTROL COMMAND This device supports the common ASCII Control Command for controlling our projector and monitor. Please visit our web site for detailed information about the command. http://www.nec-display.com/dl/en/pj_manual/lineup.html HOW TO CONNECT WITH AN EXTERNAL DEVICE There are two methods to connect the projector with an external device such as a computer. ① Connection thru the serial port. Connects the projector to a computer by a serial cable (a cross cable). ② Connection via network (LAN/HDBaseT) Connects the projector to a computer by a LAN cable. Concerning to the type of LAN cable, please ask to your network administrator. CONNECTION INTERFACE ① Connection thru the serial port. Communication Protocol Item Information Baud rate 115200/38400/19200/9600/4800 bps Data length 8 bits...
Page 204 8. Appendix Status command Response Error Status error:cover Lamp cover trouble error:temp Temperature error error:fan Fan trouble error:light Light source trouble error:system System trouble warning:light Under the grace period of lamp replacement warning:filter Filter replacement...
Page 205: ❿ Troubleshooting Check List
8. Appendix ❿ Troubleshooting Check List Before contacting your dealer or service personnel, check the following list to be sure repairs are needed also by referring to the “Troubleshooting” section in your user’s manual. This checklist below will help us solve your problem more efficiently. * Print this page and the next page for your check. Frequency of occurrence □ always □ sometimes (How often?_____________________) □ other (__________________) Power □ No power (POWER indicator does not light blue)� See also “Status □ Shut down during operation� Indicator (STATUS)”� □ Power cord’s plug is fully inserted into the wall outlet� □ Power cord’s plug is fully inserted into the wall outlet�...
Page 206 8. Appendix In the space below please describe your problem in detail. Information on application and environment where your projector is used Projector Signal cable NEC standard or other manufacturer’s cable? Model number: Model number: Length: inch/m Serial No�: Distribution amplifier Date of purchase: Model number:...
Page 207: ⓫ Register Your Projector! (For Residents In The United States, Canada, And Mexico)
8. Appendix ⓫ REGISTER YOUR PROJECTOR! (for residents in the United States, Canada, and Mexico) Please take time to register your new projector. This will activate your limited parts and labor warranty and InstaCare service program. Visit our web site at www.necdisplay.com, click on support center/register product and submit your completed form online. Upon receipt, we will send a confirmation letter with all the details you will need to take advantage of fast, reliable warranty and service programs from the industry leader, NEC Display Solutions of America, Inc.
