Page 2
HD7686/90 DISASSEMBLY- AND RE-ASSEMBLY ADVISE REPAIR INSTRUCTION - Remove bottom base plate (3 screws). - Descaling: Regular de-scaling will prolong the life of your appliance - Now the Power module and switch PCB can be reached and will guarantee optimal brewing results.
Page 3
EXPLODED VIEW & PARTS LIST HD7686/90 Service code Description Service code Description 4222 459 45032 Button 4222 459 45037 Lid assy fi lterholder Black 4222 459 45030 Switch panel Black 4222 459 45022 Filter insert assy Black 4222 459 45033...
