Instruction Manual
Body Composition Monitor
HBF-701
Model
■ Illustrations in this manual are for reference only.
■ Thank you for purchasing OMRON Body Composition
Monitor.
■ Before using this unit for the first time, please be sure to
read this Instruction Manual carefully and use the unit
safely and properly.
■ Please keep this Instruction Manual at hand all the time
for future reference.
Contents
Foreword
Notes on Safety .......................................... 3
Know Your Unit ........................................... 7
Arranging the Display Unit .......................... 8
Installing the Battery ................................... 9
Setting Date and Time .............................. 10
Gender, Height) ........................................ 12
Changing / Deleting Personal Data .......................14
Measuring Methods and
Measuring Results
(with Personal Profile Number button /
Guest button) .........................................................
..................................................
Care and Maintenance
....................................................
Error Displays ....................................................... 25
Troubleshooting .................................................... 26
....................................................
Appendix
--Useful Information--
.............................. 29
........ 1
16
21
22
..................................
23
..........................
25
28
