Multitech CommPlete MR9600 User Manual page 67

01 00/00
03 00/00
05 00/00
07 00/00
09 00/00
11 00/00
13 00/00
15 00/00
17 00/00
19 00/00
21 00/00
23 00/00
E&M Immediate Start Protocol Tx(AB)
[33] A:\ # t1debug 1 b
1. Enable Signal Bit monitoring
2. Turn Off signal bit monitoring
3. Signal Poll interval (4)
=> 2
t1setup
Parameter: Device
Description: Sets the T1 configuration information associated with a T1 device. This information is stored
in a nonvolatile area of memory so that the device can be properly reconfigured on power-up or reset. The
specified device must be a T1 device. T1 devices can exist only at 1b, 1c, 5b, 5c, 9b, 9c, 13b, and 13c.
Security: Supervisor
Example:
[0] A:\MMM # t1setup 5b
Use settings from:
1. Use Active Settings (pre-configured card)
2. Use System Defaults (new card)
3. Use Stored Settings (swapping cards)
Enter Selection (q(uit), <1>): 1
Getting T1 Card Info ....
1. Wink High Time (ms) :220
2. After Wink Time (ms) :500
3. PreWink Time (ms) :220
4. Channel Polling Interval (Sec):0
5. Error Threshold :6
6. Disconnect Timeout (sec) :11
7. Framing Format :DS1 AT&T Extended Super Frame (ESF)
8. Line Coding :Binary 8 Zero Substitution (B8ZS)
9. FXS Signaling Options :E&M Immediate Start
10. Transmit Level :- 0.0dB
Enter Selection (-(previous), q(uit), d(one), <1>):
t1status
Parameter: Device
Description: Interrogates the status of the specified T1 device. The specified device must a T1 device. T1
devices can exist only at 1b, 1c, 5b, 5c, 9b, 9c, 13b, and 13c.
Security: Guest
Example:
[1] A:\MMM # t1status 5b
CommPlete Communications Server
02 00/00
04 00/00
06 00/00
08 00/00
10 00/00
12 00/00
14 00/00
16 00/00
18 00/00
20 00/00
22 00/00
24 00/00
OFF HOOK 11
ON HOOK 00
RINGING NA
Rx(AB)
11
00
NA
5 Commands
59
