Grazie per aver scelto il sistema di sicurezza Spyball di Cobra. Vi invitiamo a leggere e conservare con cura il presente manuale di utilizzo. Sommario Contenuto del kit Caratteristiche del telecomando radio 2.1. Riallineamento di un trasmettitore 2.2. Inizializzazione di nuovi trasmettitori Funzione Biker Recognition 3.1.
E‟ alimentato da una batteria al Litio CR 2032 da 3V. Quando la batteria è prossima ad esaurirsi, il sistema lo segnala con un lampeggio aggiuntivo degli indicatori di direzione alla disattivazione. In tal caso, sostituite la pila esausta e smaltitela servendoVi degli appositi contenitori. E‟ importante che la sostituzione ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Prima che il LED si spenga, spegnere e poi riaccendere il quadro. Un segnale sonoro breve e acuto conferma che il sistema si è predisposto per l‟inizializzazione, il LED si spegne. Avete a disposizione 6 secondi per completare la procedura descritta di seguito. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Per i dettagli relativi all‟inserimento e disinserimento in modalità Biker Recognition, consultate anche i relativi paragrafi sottostanti. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Per attivare il sistema premete una volta il pulsante n. 1 del trasmettitore. L‟inserimento è confermato da: Tre lampi brevi degli indicatori di direzione Tre segnali sonori acuti (se questa funzione è abilitata – v. paragrafo 14) (*) L‟accensione della spia LED. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
L‟immobilizzatore è già operativo durante il tempo di inibizione. Se la funzione Biker Recognition è attivata, il disinserimento avviene anch‟esso automaticamente quando il motociclista fa ritorno al mezzo protetto e il trasmettitore rientra nel raggio di azione del ricevitore. E‟ confermato da: ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Protezione anti-sabotaggio (v. anche paragrafo 11). In caso di interruzione dell'alimentazione normale (ad esempio, taglio dei cavi della batteria della moto) la batteria interna permette al sistema di intervenire segnalando il sabotaggio. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Premere il pulsante n. 1 per incrementare la sensibilità. Si ottiene un breve segnale sonoro acuto di conferma. Premere il pulsante n. 2 per decrementarla. Si ottiene un breve segnale sonoro grave di conferma. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
30 secondi L'allarme è dato da una sirena piezoelettrica 114dB incorporata nel dispositivo (allarme sonoro) e dal lampeggio degli indicatori di direzione (allarme ottico). All'arresto il sistema di allarme si riposiziona in stato 'inserito'. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Se la simulazione è rilevata correttamente, viene segnalata da segnali sonori acuti. Se occorre, regolate la sensibilità. Accendete il quadro. Se la protezione del blocchetto chiave funziona correttamente, si ottiene una serie di segnali sonori acuti. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Biker Recognition attivata e la moto sottratta è accesa. Dopo 2 minuti di assenza del segnale codificato trasmesso dal telecomando, la sirena suona – dapprima con potenza acustica ridotta, poi con potenza piena - e gli indicatori lampeggiano in una serie ininterrotta di cicli di allarme. Allo spegnimento del ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
La configurazione Service permette di sospenderli temporaneamente con una procedura semplificata: Accendere il quadro e premere il pulsante n. 2 del trasmettitore. L‟ingresso in service mode è confermato da un breve segnale sonoro acuto. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
1 del trasmettitore, fino all‟accensione del LED. Il LED rimane acceso per circa 3 secondi. Durante questo lasso di tempo, premere nuovamente il tasto n. 1. Un breve segnale sonoro acuto ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 15
Seguono 3 segnali sonori acuti Segue 1 segnale sonoro acuto Polarità positiva Polarità negativa Al termine delle selezioni, un segnale sonoro grave prolungato ne conferma il buon esito. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
16. DISINSERIMENTO D’EMERGENZA TRAMITE CODICE PIN In caso di smarrimento o guasto del radiocomando, potete disattivare il sistema attraverso la procedura sotto descritta, utilizzando il codice PIN individuale che trovate incollato sulla busta del CD-ROM o quello che ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
- propone 4 serie di lampeggi. Contate e annotate il numero dei lampeggi corrispondenti alle 4 serie. Otterrete i 4 numeri che compongono il codice PIN. La conclusione della lettura è confermata da un breve segnale sonoro acuto. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Nota 1): Possono essere impostati valori compresi tra 1 e 18. Superato il 18° lampeggio, la procedura si interrompe e deve essere ripetuta; Nota 2) Per uscire dalla procedura senza apportare modifiche, spegnere il quadro prima che il nuovo codice sia completato. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
E‟ trascorso il tempo di inibizione? Il sistema non va in allarme per Il sensore di spostamento è attivato (non escluso)? spostamento Regolate il sensore di spostamento (v. paragrafo 7) Se nessuna delle operazioni ha esito positivo, contattate un centro assistenza Spyball ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Illustrazioni, descrizioni e caratteristiche sono fornite solo a titolo indicativo. Il fabbricante si riserva il diritto di modificarle senza preavviso. Si declina qualsiasi responsabilità per malfunzionamenti/danni imputabili ad installazione o utilizzo non conformi alle specifiche fornite. Il sistema ha esclusivamente funzione dissuasiva contro eventuali furti. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 21
Thank you for choosing Spyball by Cobra. We recommend you to read this guide carefully and keep it for future reference. Table of contents Kit composition Features of the radio transmitter 2.1. Realignment of a transmitter 2.2. Pairing of new transmitters Biker Recognition function 3.1.
It is powered by a Lithium CR 2032 3V-battery. When the battery is close to flat, the user is warned by an additional flash of the turn indicators upon disarming. Replace it as soon as possible and dispose of it at the appropriate collection ___________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Before the dashboard LED extinguishes, turn ignition off and then on again. A short and sharp sound signal confirms that the system is ready for pairing. The LED switches off. You have 6 seconds at your disposal to complete the operation as described below. ___________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
3 meters. Similarly it deactivates when the biker returns to his/her vehicle and the transmitter signal reaches the receiver. For more details regarding arming and disarming in Biker Recognition mode, please see also the information provided in the paragraphs below. ___________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
ARMING / DISARMING OF THE SECURITY SYSTEM 4.1. Arming / disarming without Biker Recognition function (use as a conventional transmitter) To activate the system, press push-button n. 1 of the transmitter once. Arming is confirmed by: Three short flashes of the turn indicators. ___________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
(about 3 meters). Arming is confirmed by: Three short flashes of the turn indicators. Three sharp sound signals (if this function is enabled – see paragraph 14) (*) The dashboard LED lights up. ___________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Movement detection. Triggers the alarm in the event of e.g. lifting, towing, forcing the steering lock. It is ___________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
The movement detector can be adjusted to 8 different levels of sensitivity to displacement + 8 different levels of sensitivity to shock. Normally it is fine-tuned for optimal performance by the installer during the final testing, but the procedure is simple and sensitivity can be modified by the user if required. ___________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 29
(instead of a full alarm cycle). Remarks: To ensure accurate adjustment, avoid generating shocks while selecting the level of sensitivity to displacement. It is recommended to evaluate the optimal sensitivity levels once both adjustments have been set, before quitting the procedure. ___________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
When arming, keep push-button n. 1 of the transmitter pressed for about 7 seconds. Upon arming, keep push-button n. 1 pressed for about 7 seconds. The reduction of the sound power is confirmed by two deep short audible signals. This setting is valid for one arming period only. ___________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
/ case (instantaneous trigger input), cut of power supply 2 audible signals = lifting or dragging the motorcycle 3 audible signals = a + b The warning signal remains stored until the end of the inhibition time (60 secs) that follows the subsequent arming. ___________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
This function is also selectable, that is it can be enabled or disabled as chosen by the user. Please refer to the table included in paragraph 14, which provides general information about the possible configurations of the system (5 selectable functions). ___________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
This ancillary function does not relate to anti-theft protection, but it can make riding easier and safer. If you enable it, the system will remind you with audible warning signals after a turn indicator has been flashing for more than 24 seconds. The procedure of selection is described in paragraph 14. ___________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
One (1) sharp audible signal signals follow follows 2 flashes Arming and disarming audible Press push-button n. 1 of the Press push-button n. 2 of the signals + panic function transmitter after the second transmitter after the second ___________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 35
Remark 4): the audible on/off signals and the “panic” function are not allowed by the Road Rules in some Countries. Please check your local regulations and set up the system accordingly. ___________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
(see paragraph 16.2.). The last page of this manual includes also a quick description of the disarming procedure; we recommend that you print it, record or apply the PIN code there, then keep it in your wallet for future reference. Turn ignition on. The alarm starts to sound. ___________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
4 strings of flashes. Count and note the number of flashes in each string. Those are the numbers of the PIN code. The end of the reading is confirmed by a short sharp audible signal. ___________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Remark 2): To quit the procedure without making any changes, turn ignition off before the new code is completed. 17. TROUBLESHOOTING GUIDE Malfunction Recommended inspections / operations The alarm does not respond to the Make sure the system has not entered the sleep condition (see ___________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 39
The system is not triggered by Has the inhibition time elapsed? moving/lifting the bike Is the movement detector activated (not deselected)? If necessary, please adjust the movement detector (see paragraph 7.) If none of these operations is successful, contact a Spyball dealer ___________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Diagrams, descriptions and features are only indicative. The manufacturer reserves the right to modify them without notice. The manufacturer will not be responsible for malfunctions/damages resulting from the negligence of the the supplied installation and operation instructions. The system must only be consider ed as a deterrent against theft attempts. ___________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 41
Merci d’avoir choisi le système de sécurité Spyball de Cobra. Nous Vous recommandons de lire et garder soigneusement ce mode d’emploi. Répertoire Eléments du kit Caractéristiques de la télécommande radio Realignement d‟un émetteur 2.1. 2.2. Programmation de nouveaux émetteurs Fonction Biker Recognition 3.1.
Page 42
„scanners' et de dispositifs à même d‟enregistrer et reproduire le code émis (grabbers'). Il est alimenté par une batterie au Lithium CR 2032 de 3V. Lorsque la batterie est presque épuisée, le système le signale par un clignotement ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 43
En cas de panne ou perte, on peut programmer un ou deux nouveaux émetteurs comme décrit ci-dessous : Si le système de sécurité est armé, désarmez-le par l‟émetteur restant (si disponible) ou bien à travers le code PIN (voir procédure au paragraphe 16). ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 44
Recognition (= identification du motocycliste). Cette fonction est sélectionnable. Si la fonction Biker Recognition est en service, toutes les 1,5 secondes la petite LED clignote et l‟émetteur envoie automatiquement (sans pression du bouton) un signal codé, avec une portée d‟env. 3 mètres. Dans ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 45
(*) : pour éviter d‟armer le système ou déclencher l‟alarme panique accidentellement (cela arrive si on n‟appuye pas exactement en même temps sur les deux boutons), il est recommandé d‟effectuer cette opération à l‟écart de la moto, hors de la portée du récepteur. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 46
(par ex. le compartiment sous-selle ouvert, la béquille latérale soulevée), qui sera mise hors service pendant ce cycle d‟armement. (**) Un court clignotement supplémentaire indique que la batterie va s‟épuiser et qu‟il faut la remplacer au plus tôt. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 47
(par ex. le compartiment sous-selle ouvert, la béquille latérale soulevée), qui sera mise hors service pendant ce cycle d‟armement. (**) Un court clignotement supplémentaire indique que la batterie va s‟épuiser et qu‟il faut la remplacer au plus tôt. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 48
Le système peut être armé sans détection des déplacements. Cela peut s‟avérer utile à plusieurs occasions; par exemple, en cas de transport par ferry-boat ou de stationnement au bord d‟une route où le passage fréquent de poids lourds pourrait provoquer des déclenchements intempestifs, etc.). ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 49
Le niveau minimal et le niveau maximal de sensibilité sont confirmés par trois signaux acoustiques successifs. Une fois le niveau approprié sélectionné, coupez le contact, puis rallumez-le immédiatement. Un signal sonore grave confirme l’accès à la procédure de réglage de la sensibilité au choc. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 50
(exemple: une tentative de sabotage du contact principal) provoque le déclenchement d'un cycle d'alarme de 30 sec.. L'alerte est donnée par la siréne piézoélectrique 114dB incorporée dans le dispositif (alarme sonore) ainsi que par le clignotement des indicateurs de direction (alarme optique). ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 51
Testez le détecteur de déplacement, en simulant par exemple une tentative de forcer l‟antivol de direction, le remorquage, le soulèvement de la béquille latérale. Si la simulation est détectée correctement, Vous percevrez des signaux sonores aigus. S‟il le faut, réglez la sensibilité. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 52
Cette fonction a été étudiée pour faire face au phénomène malheureusement de plus en plus fréquent de la rapine du véhicule en marche, qui a lieu typiquement lorsque le conducteur s‟arrête en présence d‟un signal de stop ou d‟un feu rouge. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 53
(s‟il est armé) de se déclencher pour signaler le sabotage. Lorsque l‟alimentation est rétablie, le système se représente dans le même état (armé / désarmé) où il se trouvait avant la coupure. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 54
Si elle est activée, le système Vous rappelle par des signaux sonores que Vous avez actionné les indicateurs de direction pour tourner à droite ou à gauche. Le signal acoustiq ue s‟actionne env. 25 secondes après que l‟indicateur a commencé de clignoter. La procédure de sélection est décrite au paragraphe 14. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 55
INDICATION FONCTION SELECTIONNABLE POUR ACTIVER POUR DESACTIVER LUMINEUSE SIGNAL DE SIGNAL DE CONFIRMATION CONFIRMATION 1 clignotement Biker Recognition Appuyez sur le bouton n. 1 de Appuyez sur le bouton n. 2 de ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 56
5ème l‟émetteur après 5ème l’installateur!!) clignotement clignotement Confirmation par 3 signaux Confirmation signal sonores aigus sonore aigu Polarité positive Polarité négative Une fois les sélections complétées, un signal sonore grave prolongé confirme le succès de l‟opération. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 57
PIN comme décrit au paragraphe 16. Si l‟allumage du contact n‟est pas suivi par la pression de l‟émetteur ou bien que le code n‟est pas rentré correctement, au bout de quelques secondes la sirène sonne. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 58
30 secondes, à l’arrêt duquel on pourra répéter la procédure. UNE FOIS TOUS LES CHIFFRES RENTRES CORRECTEMENT, LE SYSTEME SE DESARME AVEC UN SIGNAL SONORE PROLONGE SUIVI PAR QUATRE SIGNAUX SONORES COURTS ET PASSE EN MODE GARAGE (voir paragraphe 12). ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 59
Remettez le contact et procédez de la même façon pour sélectionner les 3 numéros restants. Un court signal acoustique aigu indique que la procédure a été complétée avec succès. Re-lisez le code que Vous avez rentré (voir paragraphe 16.1) pour Vous assurer qu‟il corresponde bien à ce que Vous aviez choisi. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 60
Est-ce que l‟interrupteur RUN/OFF se trouve en position mais la moto ne démarre pas (6828-9) RUN? Assurez-Vous que le fusible principal de la moto soit intact Assurez-Vous que la batterie de la moto soit chargée Quelques modèles de moto ne permettent le démarrage ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 61
Consommation de courant < 1 mA OFF; 1mA ON (y compris la LED) Autoalimentation Batterie rechargeable 7,2V 170mAh NiMH Capacité relais coupure moteur Max 6A (6828-9) Température de fonctionnement -20°C / +85°C Puissance acoustique sirène 114dB@1m Dimensions centrale 90x67x30mm ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 62
Le fabricant rejette toute responsabilité en cas de pannes/dommages imputables à l‟installation ou à l‟utilisation non conformes aux spécifications fournies. Le système a uniquement une fonction dissuasive contre les tentatives de vol. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 63
Herzlichen Dank, dass Sie sich für das Spyball Alarmsystem von Cobra entschieden haben. Bitte lesen Sie dieses Handbuch sorgfältig durch und bewahren Sie es gut zugänglich auf. Inhaltsverzeichnis Lieferumfang Eigenschaften des Handsenders 2.1. Handsender neu synchronisieren 2.2. Handsender anlernen Fahrererkennung (Biker Recognition) 3.1.
Sendevorgangs blinkt. Der Handsender verfügt über einen innovativen Wechselcode. Aufgefangene Codes können nicht wieder verwendet werden. Der Handsender wird mit einer 3V Lithium-Batterie CR 2032 betrieben. Ist die Batterie fast leer, werden beim Ausschalten der Alarmanlage die ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Ist die Alarmanlage geschärft, entschärfen Sie diese bitte mit dem Handsender (wenn verfügbar) oder durch Eingabe des PIN-Codes (siehe Punkt 16). Schalten Sie die Zündung ein und warten Sie 20 Sekunden. Die LED leuchtet für etwa 3 Sekunden auf. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Handsender sendet in diesem Intervall automatisch und ohne Drücken der Taste ein verschlüsseltes Signal mit einer Reichweite von etwa 3 Metern aus. Das Alarmsystem wird automatisch geschärft, wenn Sie mit dem Sender die Reichweite des Alarmsystems verlassen. Auf die gleiche Weise entschärft sich das System ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Sie diese Einstellung bitte in einigem Abstand zu Ihrem Motorrad und außerhalb der Reichweites Ihres Alarmsystems aus. 4. SCHÄRFEN UND ENTSCHÄRFEN DES ALARMSYSTEMS 4.1. Schärfen und Entschärfen, Fahrererkennung nicht aktiviert Zum Schärfen des Systems drücken Sie einmal die Taste 1 des Handsenders. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Nach Ausschalten der Zündung aktiviert sich das Sicherheitssystem innerhalb von 21 Sekunden automatisch nachdem Sie sich mit dem Handsender aus dem Aktionsradius des Alarmsystems (etwa 3 Meter) heraus bewegt haben. Das Schärfen des Alarmsystems wird bestätigt durch: ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Diese können zum Beispiel unter dem Sitz oder im Gepäckkoffer angebracht werden. Versucht jemand auf diesen Bereich zuzugreifen, wird ein Alarm ausgelöst. Die Eingangspolarität kann frei gewählt werden. So kann auch der Raum unter dem Sitz mit Hilfe eines positiven Signals, welches bei Einschalten der ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Der Lagesensor wird beim nächsten Schärfungsvorgang wieder automatisch aktiviert. 7. EMPFINDLICHKEIT DES LAGESENSORS EINSTELLEN Sie können den Lagesensor in je 8 Empfindlichkeitsstufen (Positionsänderung, Erschütterung) einstellen. Die Voreinstellung der Empfindlichkeit übernimmt Ihr Einbaubetrieb. Sie können die Einstellung jederzeit selbst ändern: ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 71
Haben Sie die Empfindlichkeit richtig eingestellt, gibt die Alarmanlage ein hohes Tonsignal, statt einem kompletten Alarmzyklus, aus. Bemerkungen: Simulieren Sie eine Auslösung nicht während der Einstellung, sondern erst wenn Sie beide Einstellungen (Empfindlichkeit bei Positionsveränderungen, Erschütterungsempfindlichkeit) vorgenommen haben. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Alarmanlage bitte die Taste 1 des Handsenders für etwa 7 Sekunden. Die Verringerung der Lautstärke wird Ihnen durch zwei kurze tiefe Töne bestätigt. Bei der nächsten Schärfung des Alarmsystems wird die Lautstärke wieder auf den Normalwert zurückgestellt. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Entschärfung Ihres Alarmsystems der Alarmgrund mit Hilfe verschiedener akustischer Signale ausgegeben: 1 akustisches Signal = Alarmauslösung durch unberechtigten Startversuch des Motorrades, durch Öffnen von abgesicherten Klappen, durch Unterbrechung der Stromzufuhr 2 akustische Signale = Alarmauslösung durch Abschleppversuch, durch Erschütterung des Motorrades ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Wichtig: Damit Sie diese Funktion nutzen können, muss die Fahrererkennung aktiviert werden. Bei aktivierter Funktion müssen Sie den Handsender unbedingt mit sich führen, wenn Sie das Motorrad bewegen. Bitte bewahren Sie den Zündschlüssel und den Handsender immer getrennt voneinander auf. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Werkstattmodus bestätigt. Wenn Sie die Fahrererkennung bei aktiviertem Werkstattmodus wieder aktivieren möchten, drücken Sie die Taste 1 Ihres Handsenders. Zur Erinnerung an den aktivierten Werkstattmodus ertönen jedes Mal wenn die Zündung eingeschaltet wird, 4 hohe kurze Tonsignale. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
LED zur Bestätigung aufleuchtet. Lassen Sie nun die Taste des Handsenders wieder los. Die LED bleibt etwa 3 Sekunden lang an. Drücken Sie bitte während dieser Zeitspanne erneut die Taste 1. Die LED erlischt und gibt mit verschiedenen Blinkfrequenzen die programmierbaren Zusatzfunktionen an. Bitte beachten Sie die nachstehende Tabelle: ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 77
Drücken Sie nach dem vierten Drücken Sie nach dem vierten Blinken die Taste 1 des Blinken die Taste 2 des Handsenders. Handsenders. Bestätigung durch 3 hohe Bestätigung durch 1 hohes Tonsignale. Tonsignal. Ihre Einstellungen werden mit einem langen tiefen Tonsignale bestätigt. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Sirene. 16. NOTDEAKTIVIERUNG MIT DEM PIN-CODE Bei Verlust oder Ausfall Ihres Handsenders können Sie das Alarmsystem notdeaktivieren. Verwenden Sie dazu bitte Ihren persönlichen PIN-Code (auf der Hülle der CD-ROM geklebt). Auf der letzten Seite dieses ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Sie dazu wie folgt vor: Entschärften Sie das Alarmsystem. Schalten Sie die Zündung ein und halten Sie die Taste 1 des Handsenders für 7 Sekunden lang gedrückt. Die LED leuchtet für 3 Sekunden auf, erlischt, und sendet 4 Blinkfrequenzen. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Hinweis 1): Sie können Ziffern zwischen 1 und 18 wählen. Nach dem 18. Blinken, wird das Verfahren abgebrochen und muss wiederholt werden; Hinweis 2): Um die Programmierung zu beenden, schalten Sie die Zündung aus bevor der neue Code vollständig ist. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Stellen Sie sicher, dass die Motorradbatterie geladen ist Einige Motorradmodelle lassen sich nur dann starten, wenn der Seitenständer hochgeklappt ist oder der Kupplungshebel angezogen wird Wenn keine dieser Maßnahmen hilft, wenden Sie sich bitte an eine Spyball Servicestelle ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 83
Abbildungen, Beschreibungen und Eigenschaften werden nur unverbindlich angegeben. Der Hersteller behält sich vor, ohne vorherige Mitteilung, Änderungen vorzunehmen. Der Hersteller haftet nicht für Betriebsstörungen/Schäden, die auf einen unsachgemäßen Einbau oder Verwendung zurückzuführen sind. Die Alarmanlage ist lediglich als ein Warnsystem zu betrachten. ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 84
Moreover it will not apply if the unit is opened by personnel not authorised by COBRA AT.
Page 85
Schützen Sie Umwelt und Gesundheit! Die CR 2032 Akkus der Funkfernsteuerungen dürfen auf keinen Fall mit dem normalen Haushaltsmüll entsorgt werden. Sie müssen getrennt gesammelt und an den von den Lokalverwaltungen oder bei den Vertragshändlern eingerichteten Sammelstellen entsorgt werden . ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 87
THE SYSTEM DISARMS WITH A LONG BLEEP FOLLOWED BY LUNGO SEGUITO DA QUATTRO SEGNALI BREVI E SI PONE IN FOUR SHORTER AUDIBLE SIGNALS, THEN IT SWITCHES TO SERVICE MODE (v. paragrafo 12). SERVICE MODE (see paragraph 12). ____________________________________________________________________________________________________ SPYBALL 6808-9/6828-9...
Page 88
TONSIGNAL + VIER KURZE TONSIGNALE. DAS SYSTEM ET PASSE EN MODE GARAGE (voir paragraphe 12). WECHSELT DANN IN DEN WERKSTATTMODUS (S. Abschnitt 12). Cobra Automotive Technologies SpA Via Astico 41 – 21100 VARESE – ITALY 06DE2949C – 04/12 www.cobra-at.com ____________________________________________________________________________________________________...
