SERVICE MANUAL
SERVICE MANUAL
INTEGRATED AMPLIFIER
A-9355
MODEL
Black, Silver and golden models
B MPP
230V AC, 50Hz
S MPP
230V AC, 50Hz
G MGT
220-230V AC, 50/60Hz
G MDT
120V AC, 60Hz
G MGR
220-230V AC, 50/60Hz
SAFETY-RELATED COMPONENT
WARNING!!
COMPONENTS IDENTIFIED BY MARK
SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE
CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.
REPLACE THESE COMPONENTS WITH ONKYO
PARTS WHOSE PART NUMBERS APPEAR AS SHOWN
IN THIS MANUAL.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.
Ref. No. 3982
ON THE
A-9355
032007
RC-627S

Advertisement

loading

Related Manuals for Onkyo A-9355

Summary of Contents for Onkyo A-9355

  • Page 1 COMPONENTS IDENTIFIED BY MARK ON THE SCHEMATIC DIAGRAM AND IN THE PARTS LIST ARE CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK. REPLACE THESE COMPONENTS WITH ONKYO PARTS WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL. MAKE LEAKAGE-CURRENT OR RESISTANCE...

  • Page 2: Exploded View

    A-9355 EXPLODED VIEW A142 W901 P101A A145 x 2 pcs. x 6 pcs. A037 A200 A206 A517 A9000 x 2 pcs. A516 A203 x 17 pcs. A9000 A004 x 8 pcs. P5107 P9901 P5106 A519 x 2 pcs. x 2 pcs.
  • Page 3 A-9355 A-9355 SCHEMATIC DIAGRAMS-1 PRE-AMPLIFIER SECTION NAAF-9280 PRE-AMPLIFIER PC BOARD Q951 NAAF-9259 TONE CONTROL PC BOARD R151 +14.5V 2SA1358 R961 22(1/4W) 22(1/2W) EQ. AMP. R331 22(1/2W) Q107 Q105 2SA992 R153 Q953 C331 C333 2SA992 22(1/2W) -14.5V 2SC2712 470/10 223J R101...
  • Page 4 A-9355 A-9355 SCHEMATIC DIAGRAMS-2 POWER AMPLIFIER SECTION P5001 Q5007A HN3A51F Q5007B NRL-2P5A-DC09-163 NACLD-9283 RL5001 9.13 Q5009A Q5009B R5071 SP_A 11.3 HN3A51F POWER AMPLIFIER 33(1/4W) C5059 R5077 C5005 R5023 2SC2712 Q5013 D5810 Q5005 C5009 78L05 +8.5V 5.6K(1/2W) 4.7(1/4W) M1FL20U PC BOARD 1.2K...
  • Page 5 A-9355 SCHEMATIC DIAGRAMS-3 MICROPROCESSOR SECTION R846 R845 R834 R847 R844 1.2K 2.7K LOUDNESS 1.8K C818 S806 NASW-9253 104Z R835 S805 Q836 PURE DIRECT SELECTOR PC BOARD RN1402 U801 Q831 Q832 Q833 Q834 Q835 Q837 Q838 GP1UM281XKVF RN1402 RN1402 RN1402 RN1402...
  • Page 6 A-9355 SCHEMATIC DIAGRAMS-4 NASW-9290 POWER SUPPLY SECTION POWER NAPS-9287 POWER SUPPLY PC BOARD MAIN POWER TRANS P901A P901B S901 T911 F901 MPP, MGT, MGR : T1.25AL/250V TO P9002 MDT : 2.5A/125V C911 P904A P904B 103M/250V P902A F901 L902 POWER SWITCH...

  • Page 7: Packing Procedure

    A-9355 PACKING PROCEDURE A951 A961 A752 A952 A964 A810 A953 A965 A506 A512 Right side A751 marking A506 Front side A500 marking Front side A503 (L & R) Left side marking A701 A509 A801 Front side marking Front side A509...

  • Page 8: Printed Circuit Board Views

    A-9355 PRINTED CIRCUIT BOARD VIEWS-1 MICROPROCESSOR PC BOARD (NACPU-9251) Component side JL212A JL211C P802 NCCPU-9251 J863 P801 25139251 J866 J862 C804 J874 J868 C806 J871 JL211A J860 J865 J861 J872 J864 C803 Q803 J873 J850 J856 J851 C814 J852 C807...
  • Page 9 A-9355 PRINTED CIRCUIT BOARD VIEWS-2 LED PC BOARD (NADIS-9252) Component side 25139252 JL813B D805 DIS-9252 SELECTOR PC BOARD (NASW-9253) Component side D835 NCSW-9253 D834 D836 25139253 S802 D833 D837 J803 J802 D838 D831 D832 J801 U801 C815 S806 S805 Soldering side...
  • Page 10 A-9355 PRINTED CIRCUIT BOARD VIEWS-3 VOLUME PC BOARD (NASW-9258) Component side NCSW-9258 25139258 Soldering side HEADPHONE JACK PC BOARD (NATRM-9260) Component side NCTRM-9260 25139260 Soldering side...
  • Page 11 A-9355 PRINTED CIRCUIT BOARD VIEWS-4 PRE-AMPLIFIER PC BOARD (NAAF-9280) Component side...
  • Page 12 A-9355 PRINTED CIRCUIT BOARD VIEWS-5 PRE-AMPLIFIER PC BOARD (NAAF-9280) Soldering side R237 L7901 C240 R421 Q353 R214 R422 R213 R274 D341 R212 R211 R245 R246 R210 R209 C133 R208 R374 R207 R360 R206 R205 R366 R368 C132 R204 R367 R365...
  • Page 13 A-9355 PRINTED CIRCUIT BOARD VIEWS-6 POWER SUPPLY PC BOARD (NAPS-9287) Component side P906 T901 AC-H AC-G D904 D906 P907 J901 JL901B J902 RL901 RISK OF FIRE -REPLACE FUSE AS MARKED. C919 P904A RL_GND C911 ACPOWER POFF P902A P903A T1.25AL250V F901A...
  • Page 14 A-9355 PRINTED CIRCUIT BOARD VIEWS-7 OUTLET PC BOARD (NATRM-9288) <Note> MPP, MGT, MDT type only Component side P911 J931 F903A F903B T2.5AL250V NCTRM-9288 25139288 OUTLET PC BOARD (NATRM-9289) <Note> MGR type only Component side P913 P912 T2.5AL250V F904A F904B NCTRM-9289...
  • Page 15 A-9355 PRINTED CIRCUIT BOARD VIEWS-8 TONE CONTROL PC BOARD (NAAF-9259) Component side NCAF-9259 25139259 R308 C303 J310 J313 J315 J314 R320 J316 J307 J305 Soldering side R334 C335...
  • Page 16 A-9355 PRINTED CIRCUIT BOARD VIEWS-9 POWER AMPLIFIER PC BOARD (NACLD-9283) Side-A P9902 JL211B Digital Technology Vector Linear DC OFFSET NCCLD-9283 Q5024 Q5023 C5066 C5065 C5008 25139283A C5005 C5007 C5004 C5003 C5006 Q5026 DC OFFSET Q5025 C5009 C5012 C5014 C5011 C5013...
  • Page 17 A-9355 PRINTED CIRCUIT BOARD VIEWS-10 POWER AMPLIFIER PC BOARD (NACLD-9283) Side-B D5815 D5814 C9807 D5801 D5802 C9808 R5106 P5101 P5103 C5047 C5050 C5048 C5049 R5120 C5069 R5119 R5103 C5070 R5101 R5812 R5104 R5089 R5102 R5085 R5811 R5083 R5088 R5090 D5009...

  • Page 18: Ic Block Diagrams And Terminal Descriptions

    A-9355 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-1 Q201 : R2S15211FP (8 ch Electronic Volume and 11 Input Selector and Tone Control)-1/3 SYSTEM BLOCK DIAGRAM Multi Multi Rch Tone Lch Tone CLOCK DATA MCU I/F Tone Bass & Volume Volume Treble...
  • Page 19 A-9355 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-2 Q201 : R2S15211FP (8 ch Electronic Volume and 11 Input Selector and Tone Control)-2/3 BLOCK DIAGRAM AND PIN CONFIGURATION 35 34 31 30 37 36 AVCC DGND AVCC DATA TREL CLOCK BASSL2 AVEE...
  • Page 20 A-9355 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-3 Q201 : R2S15211FP (8 ch Electronic Volume and 11 Input Selector and Tone Control)-3/3 TERMINAL DESCRIPTION PIN No. Name Function 19,17, FROUT,FLOUT, 14,12, 6-OUT,5-OUT, Output pin of FL/FR/C/SW/SL/SR/SBL/SBR channel 4-OUT, 3-OUT, 9,7, 2-OUT,1-OUT...

  • Page 21: Block Diagram

    A-9355 IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS-4 Q5017, Q5018 : IRS20954S (Digital Audio Driver) BLOCK DIAGRAM FLOATING INPUT DETECT DETECT HIGH SIDE INPUT LOGIC 10.4V LEVEL SHIFT FLOATING HIGH SIDE LEVEL LEVEL SHIFT SHIFT 5V REG CHARGE/ DETECT DISCHARGE DEAD TIME...
  • Page 22 A-9355 MICROPROCESSOR TERMINAL DESCRIPTIONS-1 Q801 : MPD78F0532GK PIN No. PIN NAME ACT. DESCRIPTION TAPE LED TAPE LED control voltage output. DIRECT LED DIRECT LED control voltage output. LOUDNESS LED LOUDNESS LED control voltage output. Not used. ACPOWER Main power control voltage output.
  • Page 23 A-9355 MICROPROCESSOR TERMINAL DESCRIPTIONS-2 Q801 : MPD78F0532GK PIN No. PIN NAME ACT. DESCRIPTION MODE For model setting. VOLUP Volume up control voltage output. VOLDN Volume down control voltage output. FLSI For flash writer (SI). FLSO For flash writer (SO). FLSCK For flash writer (SCK).

  • Page 24: Service Procedure

    A-9355 SERVICE PROCEDURE 1. Replacing the fuses This symbol located near the fuse indicates that the fuse used is show operating type, For continued protection against fire hazard, replace with same type fuse , For fuse rating, refer to the marking adjest to the symbol.
  • Page 25 A-9355 OPERATION CHECK-1 SPEAKER PROTECT-1 (CURRENT DETECTION) [When] Exchange parts on Power amplifier PC board (NACLD-9283) and PC board ass’y. <Note> 1. Do not check two or more channels at the same time. 2. Do not connect dummy load to speaker terminal longer than 2 seconds.
  • Page 26 A-9355 OPERATION CHECK-2 SPEAKER PROTECT-2 (DC VOLTAGE DETECTION) [When] Exchange parts on Power amplifier PC board (NACLD-9283) and PC board ass’y. <Note> 1. Try again if protect did not work at the first time. 2. Do not connect load or short speaker terminals.

  • Page 27: Operation Check

    A-9355 OPERATION CHECK-3 PONPING DETECTION/ THERMAL SENSOR/ CARRIER WAVEFORM [When] Exchange parts on Power amplifier PC board (NACLD-9283) and PC board ass’y. [Procedure] 1. Connect the AC power cord to a wall outlet and turn on the unit. 2. Set the unit as follows.
  • Page 28 A-9355 ADJUSTMENT PROCEDURE DC OFFSET ADJUSTMENT [When] 1. Exchange the parts on the POWER AMPLIFIER PC board (NACLD-9283). 2. Exchange the POWER AMPLIFIER PC board ass'y (NACLD-9283). 3. Exchange the power trans (T911). <Note> No signal and No load. [Procedure] 1.
  • Page 29 1/37 PAGE A-9355 <Note> Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. NOTE : THE COMPONENTS IDENTIFIED BY THE MARK ! ARE CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK. REPLACE ONLY WITH PART NUMBER SPECIFIED.
  • Page 30 2/37 PAGE A031 SCREW 3TTB+8B(3BC) 838430088GR A034 HOLDER KGLS-18RT 27190657 A037 E-TERMINAL 3 x 14 25060044 A100 KNOB (POWER-AS) 28326523 A100 KNOB (POWER-AS) 28326522 A100 KNOB (POWER-AS) 28326524A A103 FACET (PURE) 28200024 A106 FACET (POW) 28200025 A109 KNOB (VOL)AS 28326564A A109 KNOB (VOL)AS...
  • Page 31 3/37 PAGE A139 SCREW 3TTB+8B(3BC) 838430088GR A142 COVER A-9355(B) 28184995A A142 COVER A-9355(S) 28184994A A142 COVER A-9355(G) 28184996A A145 SCREW 3TTB+8B(3BC) 838430088GR A145 SCREW 3TTB+8B(3CM)SR 801637 A145 SCREW 3TTB+8B(3CM)SR 801637 A200 REAR PANEL A-9355<MPP> 27123692 <MPP> A200 REAR PANEL A-9355MGT 27123693 <MGT>...
  • Page 32 4/37 PAGE P9901 CLAMP HL-28-0 27301396 P9902 CLAMP WS-2NS 27300833 P991 CLAMP HL-28-0 27301396 R5824 THERMISTOR PTH9M04BD222TS2F333 4000151 T911 P TRANS NPT-1559P 2301915 !, <MPP> T911 P TRANS NPT-1559G 2301914 !, <MGT> T911 P TRANS NPT-1559D 2301917 !, <MDT> T911 P TRANS NPT-1559G 2301914...
  • Page 33 5/37 PAGE SELECTOR PC board ass'y NASW-9253-1C INCLUDED IN REF.NO. U01 <MGR> VOLUME PC board ass'y NASW-9258-1A 1B190558-1A <MPP> VOLUME PC board ass'y NASW-9258-1D 1B190558-1D <MGT> VOLUME PC board ass'y NASW-9258-1E 1B190558-1E <MDT> VOLUME PC board ass'y NASW-9258-1C 1B190558-1C <MGR> HEADPHONE JACK PC board ass'y NATRM-9260-1A 1B190560-1A...
  • Page 34 6/37 PAGE POWER AMPLIFIER PC board ass'y NACLD-9283-1C 1B190583-1C <MGR> A-9355 PC BOARD PARTS LIST MICROPROCESSOR PC BOARD (NACPU-9251-1A / 1C / 1D / 1E) PCB1 LED PC BOARD (NADIS-9252-1A / 1C / 1D / 1E) PCB1 SELECTOR PC BOARD (NASW-9253-1A / 1C / 1D / 1E)
  • Page 35 7/37 PAGE Q822 or KRC102S 2216190R2 PCB1 Q823 RN1402 2214470R2 PCB1 Q823 or KRC102S 2216190R2 PCB1 Q831 RN1402 2214470R2 PCB1 Q831 or KRC102S 2216190R2 PCB1 Q832 RN1402 2214470R2 PCB1 Q832 or KRC102S 2216190R2 PCB1 Q833 RN1402 2214470R2 PCB1 Q833 or KRC102S 2216190R2 PCB1...
  • Page 36 8/37 PAGE D821 C-DIODE 1SR154-400 22380284R2 PCB1 D831 SEL2910A-TP6 225390T PCB1 D832 SEL2910A-TP6 225390T PCB1 D833 SEL2910A-TP6 225390T PCB1 D834 SEL2910A-TP6 225390T PCB1 D835 SEL2910A-TP6 225390T PCB1 D836 SEL2910A-TP6 225390T PCB1 D837 SEL2910A-TP6 225390T PCB1 D838 SEL2910A-TP6 225390T PCB1 L801 CHOKE COIL NCH-1479 231237K470R2...
  • Page 37 9/37 PAGE C818 C-CERA C CK725F1H-104Z1 332151040R1 PCB1 C819 C-CERA C CK725F1H-104Z1 332151040R1 PCB1 C820 C-CERA C CK725F1H-104Z1 332151040R1 PCB1 C881 TF C ECQ-B50V-102J 374721024T PCB1 C882 TF C ECQ-B50V-102J 374721024T PCB1 C883 TF C ECQ-V50V-104J 374721044T PCB1 C884 TF C ECQ-V50V-104J 374721044T PCB1...
  • Page 38 10/37 PAGE R838 C-CARBON R RN72K1J-103JE 435031034R1 PCB1 R839 C-CARBON R RN72K1J-473JE 435034734R1 PCB1 R841 C-CARBON R RN72K1J-183JE 435031834R1 PCB1 R842 C-CARBON R RN72K1J-682JE 435036824R1 PCB1 R843 C-CARBON R RN72K1J-332JE 435033324R1 PCB1 R844 C-CARBON R RN72K1J-182JE 435031824R1 PCB1 R845 C-CARBON R RN72K1J-122JE 435031224R1 PCB1...
  • Page 39 11/37 PAGE R875 C-CARBON R RN72K1J-151JE 435031514R1 PCB1 R876 C-CARBON R RN72K1J-151JE 435031514R1 PCB1 R877 C-CARBON R RN72K1J-151JE 435031514R1 PCB1 R878 C-CARBON R RN72K1J-151JE 435031514R1 PCB1 R881 METAL O R RS1/2WBJ-22 443522204T PCB1 R884 C-CARBON R RN72K1J-103JE 435031034R1 PCB1 R892 C-CARBON R RN72K1J-103JE 435031034R1...
  • Page 40 12/37 PAGE JL812 JUMPER LEAD JL10 150B(6-6) PCB1 JL812A WIRE HOL NSCT-10P881 25051094 PCB1 JL812B WIRE HOL NSCT-10P881 25051094 PCB1 JL813 JUMPER LEAD JL3 100 B(6-6) PCB1 JL813A WIRE HOL NSCT-3P874 25051087 PCB1 JL813B WIRE HOL NSCT-3P874 25051087 PCB1 JL901 JMP LEAD JL4 450 B(6-6) PCB1...
  • Page 41 13/37 PAGE Q114 2SA965-Y(TPE6_F) 2211644T PCB2 Q115 2SC2240-BL(TPE2_F) 2211406T PCB2 Q116 2SC2240-BL(TPE2_F) 2211406T PCB2 Q201 R2S15211FP 22242297R3 PCB2 Q301 NJM4580M-D 22241448R2 PCB2 Q302 NJM4580M-D 22241448R2 PCB2 Q348 NJM4580M-D 22241448R2 PCB2 Q349 2SD655-F 2211706T PCB2 Q350 2SD655-F 2211706T PCB2 Q351 2SD655-F 2211706T PCB2 Q352...
  • Page 42 14/37 PAGE D101 ZENER D MTZJ5.6B 224470562T PCB2 D102 ZENER D MTZJ5.6B 224470562T PCB2 D103 DIODE 1SS133 223163T PCB2 D103 or DIODE WG713A 223222T PCB2 D104 DIODE 1SS133 223163T PCB2 D104 or DIODE WG713A 223222T PCB2 D105 DIODE 1SS133 223163T PCB2 D105 or DIODE...
  • Page 43 15/37 PAGE D909 ZENER D UDZS5.1B 224550510R2 PCB2 D910 C-DIODE 1SS352 223234R2 PCB2 D910 or C-DIODE 1SS355 223269R2 PCB2 D911 C-DIODE 1SS352 223234R2 PCB2 D911 or C-DIODE 1SS355 223269R2 PCB2 D951 DIODE RL1N4003 22380260T PCB2 D951 or DIODE GP104003E 22380035T PCB2 D952 DIODE...
  • Page 44 16/37 PAGE C111 TF C ECQ-B50V-562J 374725624T PCB2 C112 TF C ECQ-B50V-562J 374725624T PCB2 C113 TF C ECQ-B50V-222J 374722224T PCB2 C114 TF C ECQ-B50V-222J 374722224T PCB2 C115 UTSP C CE04W50V-22M(UTSP) 397582207T PCB2 C116 UTSP C CE04W50V-22M(UTSP) 397582207T PCB2 C117 UTSP C CE04W50V-22M(UTSP) 397582207T PCB2...
  • Page 45 17/37 PAGE C301 UTSP C CE04W50V 47M(UTSP) 397584707T PCB2 C302 UTSP C CE04W50V 47M(UTSP) 397584707T PCB2 C303 UTSP C CE04W50V 47M(UTSP) 397584707T PCB2 C304 UTSP C CE04W50V 47M(UTSP) 397584707T PCB2 C305 TF C ECQ-V50V-333J 374723334T PCB2 C306 TF C ECQ-V50V-333J 374723334T PCB2 C307...
  • Page 46 18/37 PAGE C413 TF C ECQ-V50V-474J 374724744T PCB2 C414 TF C ECQ-V50V-473J 374724734T PCB2 C415 TF C ECQ-V50V-473J 374724734T PCB2 C416 TF C ECQ-B50V-223J 374722234T PCB2 C417 TF C ECQ-B50V-223J 374722234T PCB2 C418 UTSP C CE04W50V 47M(UTSP) 397584707T PCB2 C419 UTSP C CE04W50V 47M(UTSP) 397584707T...
  • Page 47 19/37 PAGE C959 VX C CE04W35V-2200M(VX_BLK) 397362227S PCB2 C961 VX C CE04W35V-470M(VX_BLK) 397364717S PCB2 C962 VX C CE04W35V-470M(VX_BLK) 397364717S PCB2 C963 UTSP C CE04W50V-22M(UTSP) 397582207T PCB2 C964 UTSP C CE04W50V-22M(UTSP) 397582207T PCB2 C965 UTSP C CE04W50V-2.2M(UTSP) 397580227T PCB2 C966 UTSP C CE04W50V-2.2M(UTSP) 397580227T PCB2...
  • Page 48 20/37 PAGE R114 CARBON R R16J-220 417342214T PCB2 R115 CARBON R R16J-220 417342214T PCB2 R116 CARBON R R16J-220 417342214T PCB2 R117 CARBON R R16J-22K 417342234T PCB2 R118 CARBON R R16J-22K 417342234T PCB2 R119 CARBON R R16J-6.8K 417346824T PCB2 R120 CARBON R R16J-6.8K 417346824T PCB2...
  • Page 49 21/37 PAGE R157 CARBON R R16J-470K 417344744T PCB2 R158 CARBON R R16J-470K 417344744T PCB2 R201 C-CARBON R RN72K1J-331JE 435033314R1 PCB2 R202 C-CARBON R RN72K1J-331JE 435033314R1 PCB2 R203 C-CARBON R RN72K1J-331JE 435033314R1 PCB2 R204 C-CARBON R RN72K1J-331JE 435033314R1 PCB2 R205 C-CARBON R RN72K1J-222JE 435032224R1 PCB2...
  • Page 50 22/37 PAGE R314 CARBON R R16J-10K 417341034T PCB2 R315 CARBON R R16J-10K 417341034T PCB2 R316 CARBON R R16J-10K 417341034T PCB2 R317 CARBON R R16J-3.9K 417343924T PCB2 R318 CARBON R R16J-3.9K 417343924T PCB2 R319 VARI R N14RGLC50KB25Z 5132535 PCB2 R320 VARI R N14RGLC50KB25Z 5132535 PCB2...
  • Page 51 23/37 PAGE R374 C-CARBON R RN72K1J-103JE 435031034R1 PCB2 R375 C-CARBON R RN72K1J-103JE 435031034R1 PCB2 R376 C-CARBON R RN72K1J-103JE 435031034R1 PCB2 R377 METAL O R RS1/2WBJ-22 443522204T PCB2 R378 METAL O R RS1/2WBJ-22 443522204T PCB2 R381 C-CARBON R RN72K1J-224JE 435032244R1 PCB2 R421 C-CARBON R RN72K1J-222JE...
  • Page 52 24/37 PAGE R967 NF CARBON R R25J-22 415472204T PCB2 R968 NF CARBON R R25J-22 415472204T PCB2 R969 CARBON R R16J-12K 417341234T PCB2 R970 CARBON R R16J-12K 417341234T PCB2 R971 C-CARBON R RN72K1J-122JE 435031224R1 PCB2 R972 C-CARBON R RN72K1J-122JE 435031224R1 PCB2 R973 METAL O R RS1/2WBJ-22...
  • Page 53 25/37 PAGE JL901B WIRE TRAP NPLG-4P587 25055625 PCB2 P201 PIN JACK NPJ-4PDWWRR624 25045845 PCB2 P201 or PIN JACK NPJ-4PDBL162 25045303 PCB2 P202 PIN JACK NPJ-4PDWWRR624 25045845 PCB2 P202 or PIN JACK NPJ-4PDBL162 25045303 PCB2 P203 PIN JACK NPJ-4PDWWRR624 25045845 PCB2 P203 or PIN JACK NPJ-4PDBL162...
  • Page 54 26/37 PAGE Q5002 HN3C51F-BL(TE85L_F) 2217185R2 PCB3 Q5003 2SC2712-GR 2213145R2 PCB3 Q5004 2SC2712-GR 2213145R2 PCB3 Q5005 2SC2712-GR 2213145R2 PCB3 Q5006 2SC2712-GR 2213145R2 PCB3 Q5007 HN3A51F(TE85L_F) 2217190R2 PCB3 Q5008 HN3A51F(TE85L_F) 2217190R2 PCB3 Q5009 HN3A51F(TE85L_F) 2217190R2 PCB3 Q5010 HN3A51F(TE85L_F) 2217190R2 PCB3 Q5011 TC7W14FU(TE12L_F) 22241161R2 PCB3 Q5012...
  • Page 55 27/37 PAGE Q5806 DTC123JKA 2216690R2 PCB3 Q5807 2SA1162-GR 2214375R2 PCB3 Q5808 2SA1162-GR 2214375R2 PCB3 Q5809 2SA1162-GR 2214375R2 PCB3 Q5810 DTC123JKA 2216690R2 PCB3 Q9801 2SA1837(F) 2202790 PCB3 Q9802 2SC3421-Y(Q) 2212654 PCB3 Q9803 2SC2712-GR 2213145R2 PCB3 Q9804 2SA1162-GR 2214375R2 PCB3 Q9805 78M12HF(NJM78M12FA) 222780125JRC PCB3 Q9806...
  • Page 56 28/37 PAGE D5807 or C-DIODE 1SS355 223269R2 PCB3 D5808 C-DIODE 1SS352 223234R2 PCB3 D5808 or C-DIODE 1SS355 223269R2 PCB3 D5810 C-DIODE 1SS352 223234R2 PCB3 D5810 or C-DIODE 1SS355 223269R2 PCB3 D5811 C-DIODE 1SS352 223234R2 PCB3 D5811 or C-DIODE 1SS355 223269R2 PCB3 D5812 C-DIODE...
  • Page 57 29/37 PAGE C5014 UTSP C CE04W25V-220M(UTSP) 397552217T PCB3 C5015 FLIM C ECQP50V-102F 3800038S PCB3 C5016 FLIM C ECQP50V-102F 3800038S PCB3 C5017 FLIM C ECQP50V-102F 3800038S PCB3 C5018 FLIM C ECQP50V-102F 3800038S PCB3 C5019 C-CERA C CK725F1H-104Z1 332151040R1 PCB3 C5020 C-CERA C CK725F1H-104Z1 332151040R1 PCB3...
  • Page 58 30/37 PAGE C5047 C-CERA C CK725X7R2E-334K5 332213345R1 PCB3 C5048 C-CERA C CK725X7R2E-334K5 332213345R1 PCB3 C5049 C-CERA C CK725X7R2E-334K5 332213345R1 PCB3 C5050 C-CERA C CK725X7R2E-334K5 332213345R1 PCB3 C5051 PLA C ECQE250V-334J 3700083S PCB3 C5052 PLA C ECQE250V-334J 3700083S PCB3 C5053 TF C ECQ-V100-153J 374731534T PCB3...
  • Page 59 31/37 PAGE C9804 TF C ECQ-V50V-104J 374721044T PCB3 C9805 ELECT C CE69W50V-10000M 3504449 PCB3 C9806 ELECT C CE69W50V-10000M 3504449 PCB3 C9807 C-CERA C CK725F1H-104Z1 332151040R1 PCB3 C9808 C-CERA C CK725F1H-104Z1 332151040R1 PCB3 C9809 VX C CE04W35V-1000M(VX_BLK) 397361027S PCB3 C9810 VX C CE04W25V-47M(VX_BLK) 397354707T PCB3...
  • Page 60 32/37 PAGE R5015 C-CARBON R RN72K1J-222JE 435032224R1 PCB3 R5016 C-CARBON R RN72K1J-222JE 435032224R1 PCB3 R5017 C-CARBON R RN72K1J-470JE 435034704R1 PCB3 R5018 C-CARBON R RN72K1J-470JE 435034704R1 PCB3 R5019 C-CARBON R RN72K1J-470JE 435034704R1 PCB3 R5020 C-CARBON R RN72K1J-470JE 435034704R1 PCB3 R5021 TRIM R N06HR100BC 5210359T PCB3...
  • Page 61 33/37 PAGE R5048 C-CARBON R RN72K1J-331JE 435033314R1 PCB3 R5049 C-CARBON R RN72K1J-222JE 435032224R1 PCB3 R5050 C-CARBON R RN72K1J-222JE 435032224R1 PCB3 R5051 C-CARBON R RN72K1J-123JE 435031234R1 PCB3 R5052 C-CARBON R RN72K1J-123JE 435031234R1 PCB3 R5053 C-CARBON R RN72K2E-221JE 435222214R1 PCB3 R5054 C-CARBON R RN72K2E-221JE 435222214R1 PCB3...
  • Page 62 34/37 PAGE R5083 C-CARBON R RN72K2E-047JE 435220474R1 PCB3 R5084 C-CARBON R RN72K2E-047JE 435220474R1 PCB3 R5085 C-CARBON R RN72K1J-103JE 435031034R1 PCB3 R5086 C-CARBON R RN72K1J-103JE 435031034R1 PCB3 R5087 C-CARBON R RN72K1J-272FE 435032722R1 PCB3 R5088 C-CARBON R RN72K1J-272FE 435032722R1 PCB3 R5089 C-CARBON R RN72K1J-682FE 435036822R1 PCB3...
  • Page 63 35/37 PAGE R5116 C-CARBON R RN72K2E-068JE 435220684R1 PCB3 R5117 C-CARBON R RN72K1J-563FE 435035632R1 PCB3 R5118 C-CARBON R RN72K1J-563FE 435035632R1 PCB3 R5119 C-CARBON R RN72K2E-010JE 435220104R1 PCB3 R5120 C-CARBON R RN72K2E-010JE 435220104R1 PCB3 R5801 C-CARBON R RN72K1J-273JE 435032734R1 PCB3 R5802 C-CARBON R RN72K1J-223JE 435032234R1 PCB3...
  • Page 64 WIRE TRAP NPLG-6P589 25055627 PCB3 JL211B WIRE TRAP NPLG-10P593 25055631 PCB3 A9002 TAPE TAPE(CLOTH-8U) 29110082 PCB3 A-9355 PACKING PROCEDURE PARTS LIST REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS A500 SHEET 29095847 A503 L & R 29092360A A506 TAPE NITTO NO.29...
  • Page 65 CARTON A9355(G) 29054681A (G) <MDT> A801 CARTON A9355(G)MGR 29054685A (G) <MGR> A810 WRNTY CARD (ONKYO-CH) 29365098B <MGR> A951 INS MANUAL En(A-9355) 29344443 A952 INS MANUAL U3FrEsIt(A-9355) 29344444 <MPP> A952 INS MANUAL Ct(A-9355) 29344446 <MGT> A952 INS MANUAL Ct(A-9355) 29344446 <MDT>...
  • Page 66 Sales & Product Planning Div. : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN Tel: 072-831-8023 Fax: 072-831-8124 ONKYO U.S.A. CORPORATION 18 Park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: 201-785-2600 Fax: 201-785-2650 http://www.us.onkyo.com/ ONKYO EUROPE ELECTRONICS GmbH Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY Tel: +49-8142-4401-0 Fax: +49-8142-4401-555 http://www.eu.onkyo.com/...
