Page 1: Installation Guide
ExtremeWireless ™ AP3805-FCC/ROW Installation Guide 9034961 Published April 2016... - Page 2 Copyright © 2016 Extreme Networks All rights reserved. Legal Notice Extreme Networks, Inc. reserves the right to make changes in specifications and other information contained in this document and its website without prior notice. The reader should in all cases consult representatives of Extreme Networks to determine whether any such changes have been made.
-
Page 3: Table Of Contents
Mounting to Solid Wall or Ceiling..........................15 LAN Connections.................................17 Power Connections................................17 Appendix A: Specifications....................23 Appendix B: Internal Antennas....................24 Appendix C: Regulatory Information..................28 AP3805....................................28 United States..................................28 Canada....................................30 European Community..............................32 Certifications of Other Countries..........................37 ExtremeWireless™ WS-AP3805-FCC/ROW Installation Guide... -
Page 4: Preface
Helpful tips and notices for using the product. Note Important features or instructions. Caution Risk of personal injury, system damage, or loss of data. Warning Risk of severe personal injury. This command or section is new for this release. ExtremeWireless™ WS-AP3805-FCC/ROW Installation Guide... -
Page 5: Providing Feedback To Us
Ideas for improvements to our documentation so you can find the information you need faster. • Broken links or usability issues. If you would like to provide feedback to the Extreme Networks Information Development team about this document, please contact us using our short online feedback form. -
Page 6: Related Publications
Preface • Your Extreme Networks service contract number and/or serial numbers for all involved Extreme Network products • A description of the failure • A description of any action(s) already taken to resolve the problem • A description of your network environment (such as layout, cable type, other relevant environmental information) •... -
Page 7: Chapter 1: Overview
AP. Note Throughout the remainder of this guide, the WS-AP3805i-FCC/ROW is referred to as AP3805. The following views illustrate the LED status indicators (front) and connection ports (back) on the AP3805. ExtremeWireless™ WS-AP3805-FCC/ROW Installation Guide... - Page 8 Overview Figure 1: AP3805 Front View ExtremeWireless™ WS-AP3805-FCC/ROW Installation Guide...
-
Page 9: About This Ap And Extremecloud
About This AP and ExtremeCloud This AP supports the use of ExtremeCloud as an alternative to using a controller. ExtremeCloud is a resilient and scalable cloud-based network management solution offered by Extreme Networks as a subscription service. ExtremeCloud is designed and optimized to take advantage of the elasticity, resilience and scalability provided via state-of-the-art datacenters distributed strategically for worldwide availability. -
Page 10: Led Indicators
The LAN port also supports power over Ethernet (PoE) based on the IEEE 802.3af standard. See Power Connections for information on supplying power to the AP3805 network port from a network device, such as a switch, that provides Power over Ethernet (PoE). ExtremeWireless™ WS-AP3805-FCC/ROW Installation Guide... -
Page 11: Antennas
AP to drop all connections and reset. If you hold the button down for 5 seconds or more, any configuration changes are removed, and the factory default configuration restores to the AP. Figure 4: AP3805 Reset Button ExtremeWireless™ WS-AP3805-FCC/ROW Installation Guide... -
Page 12: Chapter 2: Installation
The following accessories are available for the AP3805. For ordering information, contact your Extreme Networks sales representative. • WS-PSI12V-MR1 12V DC Power Supply with six country adapters For information about using an external power adapter, see Power Connections. ExtremeWireless™ WS-AP3805-FCC/ROW Installation Guide... -
Page 13: Installation Options And Procedures
If you plan to use ExtremeCloud to manage this AP, scan the QR code before you install the AP. The QR code is located on the back of the AP and on the box label. Figure 5: Attaching the T-rail Connector to the AP ExtremeWireless™ WS-AP3805-FCC/ROW Installation Guide... - Page 14 4 Attach the T-rail connectors (previous figure, item 2 or item 4) to the bottom cover of the AP using the provided short screws (previous figure, item 1) or long screws (previous figure, item ExtremeWireless™ WS-AP3805-FCC/ROW Installation Guide...
-
Page 15: Mounting To Solid Wall Or Ceiling
Note If you plan to use ExtremeCloud to manage this AP, scan the QR code before you install the AP. The QR code is located on the back of the AP and on the box label. ExtremeWireless™ WS-AP3805-FCC/ROW Installation Guide... - Page 16 3). For a tight fit, the holes should be slightly smaller than the diameter of the provided plastic anchors. 3 Screw the anchors (item 2) into the holes until they are flush with the wall, and screw the provided mounting screws (item 5) into the anchors. ExtremeWireless™ WS-AP3805-FCC/ROW Installation Guide...
-
Page 17: Lan Connections
The power supply is compatible with electrical requirements for multiple countries. It is shipped with six power adapters as shown in the following figure. Select the desired country adapter based on the power requirements at the point of installation. ExtremeWireless™ WS-AP3805-FCC/ROW Installation Guide... - Page 18 To connect the power adapter: Identify the correct adapter for the power supply based on the region where the AP3805 will be installed. 2 Align the tabs of the adapter to the slots of the power supply, as follows: ExtremeWireless™ WS-AP3805-FCC/ROW Installation Guide...
- Page 19 Installation Figure 9: Aligning the Power Adapter with the Power Supply 3 Push and turn the adapter clockwise until it clicks into position, as follows: ExtremeWireless™ WS-AP3805-FCC/ROW Installation Guide...
- Page 20 Figure 10: Connecting the Power Adapter Removing the Power Adapter from the Power Supply To remove the power adapter: Locate the release button, as shown in the following figure, and push it to unlock the adapter from the power supply. ExtremeWireless™ WS-AP3805-FCC/ROW Installation Guide...
- Page 21 Installation Figure 11: Release Button 2 Rotate the power adapter counterclockwise to remove it from the power supply, as follows: ExtremeWireless™ WS-AP3805-FCC/ROW Installation Guide...
- Page 22 Installation Figure 12: Removing the Power Adapter from the Power Supply ExtremeWireless™ WS-AP3805-FCC/ROW Installation Guide...
-
Page 23: Appendix A: Specifications
Specifications This appendix lists the specifications for the AP3805 and the Extreme Networks 12V DC Power Supply. Table 11: Specifications for the AP3805 Item Specification Enclosure material Plastic housing Power source 802.3af compliant PoE PD 12V DC input Maximum power consumption 9.6W... -
Page 24: Appendix B: Internal Antennas
The following radiation patterns apply to the antennas in the AP3805i only. In these diagrams, 0 degree is the AP front and +/- 180 degree is the AP back. Figure 13: Horizontal Radiation Pattern 2.4 GHz ExtremeWireless™ WS-AP3805-FCC/ROW Installation Guide... - Page 25 Internal Antennas Figure 14: Vertical Radiation Pattern 2.4 GHz ExtremeWireless™ WS-AP3805-FCC/ROW Installation Guide...
- Page 26 Internal Antennas Figure 15: Horizontal Radiation Pattern 5 GHz ExtremeWireless™ WS-AP3805-FCC/ROW Installation Guide...
- Page 27 Internal Antennas Figure 16: Vertical Radiation Pattern 5 GHz ExtremeWireless™ WS-AP3805-FCC/ROW Installation Guide...
-
Page 28: Appendix C: Regulatory Information
Networks could void the user's authority to operate the equipment. Only authorized Extreme Networks service personnel are permitted to service the system. Procedures that should be performed only by Extreme Networks personnel are clearly identified in this guide. Note The AP3805 is in compliance with the European Directive 2002/95/EC on the restriction of the use of certain hazardous substances (RoHS) in electrical and electronic equipment. - Page 29 CSA C22.2 No. 60950-22 (Outdoor install) • FCC CFR 47 Part 15, Class B Radio Transceiver • CFR 47 Part 15.247, Subpart C • CFR 47 Part 15.407, Subpart E Other • IEEE 802.11a (5 GHz) • IEEE 802.11b/g (2.4 GHz) ExtremeWireless™ WS-AP3805-FCC/ROW Installation Guide...
-
Page 30: Canada
This Part 15 radio device operates on a non-interference basis with other devices operating at the same frequency when using the antennas provided or other Extreme Networks-certified antennas. Any changes or modifications to the product not expressly approved by Extreme Networks could void the user's authority to operate this device. - Page 31 / ou endommager les appareils LE- LAN. Canada Conformance Standards This equipment meets the following conformance standards: Safety • C22.2 No.60950-1-03 • UL 60950-22 (Outdoor install) • CSA 22.2 No.60950-1-03 • CSA C22.2 No. 60950-22 (Outdoor install) • ICES-003, Class B ExtremeWireless™ WS-AP3805-FCC/ROW Installation Guide...
-
Page 32: European Community
Declaration of Conformity in Languages of the European Community The full text of the EU declaration of conformity is available at http://www.extremenetworks.com/ English Hereby, Extreme Networks, declares that this Radio LAN device is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. Finnish Valmistaja Extreme Networks vakuuttaa täten että... -
Page 33: New Member States Requirements Of Declaration Of Conformity
Regulatory Information Bij deze verklaart Extreme Networks dat deze Radio LAN device voldoet aan de essentiële eisen en aan de overige relevante bepalingen van Richtlijn 1999/ 5/EC. French Par la présente Extreme Networks déclare que l'appareil Radio LAN device est conforme aux exigences essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE. -
Page 34: Conditions Of Use In The European Community
Conditions of Use in the European Community Some EU countries allow outdoor operation with limitations and restrictions, which are described in this section. It is the responsibility of the end user to ensure operation in accordance with these rules, ExtremeWireless™ WS-AP3805-FCC/ROW Installation Guide... - Page 35 132,136,140 Noted) Austria Indoor only Indoor only Indoor or outdoor Indoor or outdoor Belgium Indoor only Indoor only Indoor or outdoor * Indoor or outdoor Bulgaria Indoor only Indoor only Indoor or outdoor Indoor or outdoor ExtremeWireless™ WS-AP3805-FCC/ROW Installation Guide...
- Page 36 Indoor or outdoor Switzerland Indoor only Indoor only Indoor or outdoor Indoor or outdoor Turkey Indoor only Indoor only Indoor or outdoor Indoor or outdoor U.K. Indoor only Indoor only Indoor or outdoor Indoor or outdoor ExtremeWireless™ WS-AP3805-FCC/ROW Installation Guide...
-
Page 37: Certifications Of Other Countries
The antennas used for this transmitter must be installed to provide a separation distance of at least 22 cm from all persons and must not be co-located or operating in conjunction with another antenna or transmitter. ExtremeWireless™ WS-AP3805-FCC/ROW Installation Guide...
