MTD YM120 Parts List

3
40
4
5
3
8
9
1
2
Item Part No. Description
1 791-182059 Air Cleaner/Muffler Cover Assembly
(includes 2 & 40)
2 791-180350 Air Cleaner Filter
3 791-180351 Carburetor Mounting Screw Assembly
4 791-180226 Wavey Washer
5 791-182160 Choke Lever Assembly (includes 6)
6 791-182161 Choke Knob and Screw
7 791-182162 Choke Lever and Plate (includes 5)
8 753-04333 Carburetor Assembly (includes 9 & 20)
9 791-610675 Carburetor Gasket
10 791-181860 Carb Mount Screw
11 791-147351 Primer and Hose Assembly
12 753-1196 Carb Mount Assembly (includes 10 & 14
13 791-684451 Reed Assembly
14 753-1208 Carburetor Mount Gasket
15 753-04369 Crank Case Service Assembly
(includes 10 & 23)
16 791-612134 Rear Mounting Pad
17 753-04306 Fuel Tank Assembly (includes 18-20)
18 791-182529 Fuel Cap Assembly
19 791-181168 Fuel Return Line
20 791-682039 Fuel Line Assembly
21 791-145308 Front Mounting Pad
22 791-683065 Shroud Assembly (includes 23)
23 791-181861 Shroud Screw
24 791-182064 Shroud Extension and Stand
25 791-182736 Flywheel Assembly
26 791-181065 Spacer
27 753-04232 Recoil Pulley Assembly
28 791-613102 Recoil Spring
29 791-180930 Pulley Retainer Assembly
30 791-611061 Rope Guide
31 791-180317 Fuel Tank Guard Assembly
32 791-181079 Pull Handle
33 791-613103 Rope
34 791-181912 Housing Screw
ENGINE PARTS - MODEL YM120 CULTIVATOR
6
7
11
13
10
12
14
15
47
46
52
45
18
17
16
20
51
21
19
49
50
48
23
42
44
43
Item Part No.
35 791-182776
36 791-182368
37 791-182369
38 791-153592
39 791-180098
40 791-181345
41 791-153597
42 753-04337
43 791-181580
44 791-610311
45 753-04159
46 791-182174
47 791-182464
48 753-04323
49 753-1207
50 753-1197
51 791-182723
52 791-182747
* 753-04134
* 791-180090
* 791-180091
* 753-1209
* 753-04359
* 791-181599
* not shown
2-CYCLE GAS CULTIVATOR
PPN 21C-120R000
36
37
38
22
40
25
31
26
27
29
30
28
24
29
40
Description
Starter Housing Assembly
(includes 27-30, 32-34 & 40)
Clutch Washer
Clutch Rotor Assembly
Clutch Drum Assembly
Clutch Cover Assembly (includes 40)
Clutch Cover Screw
Upper Clamp Assembly
Module Assembly
Wire Lead
Spark Plug
Exhaust Gasket
Muffler Assembly (includes 45, 47 & 52)
Muffler Mounting Bolt Assembly
Cylinder Assembly (includes 50 & 51)
Piston and Rod Assembly
Cylinder Gasket
Cylinder Bolt
Spark Arrestor
Engine Gasket Kit
O.E.M. Carburetor Repair Kit
Gasket-Diaphragm Repair Kit
Piston Ring
Short Block Assembly
(includes 15, 44, 48-51)
Clutch Springs (Qty. 2)
39
41
32
33
35 34
Issued 12/02
