- Page 1 Quick start guide TR1909 Trimline® telephone with caller ID/call waiting For customer service or product information, visit our website at www.telephones.att.com 1 (800) 222-3111 or call 1 (866) 288-4268 Canada, dial . In...
-
Page 2: Handset Layout
IN USE light Flashes quickly when there is an incoming call. Flashes slowly when the telephone line cord is not plugged into a wall jack or another telephone on the same line is in use. OPTION Press to display the setting options. - Page 3 M1, M2, M3 Press to dial a one- touch number from the memory. Listening volume Slide to adjust the handset listening volume to LO, MED, or HI. MEMORY Press to access telephone numbers stored in the memory. MUTE Press and hold MUTE to silence the microphone to prevent the other party from hearing you,...
-
Page 4: Screen Display Messages
Screen icons CALL# Call number in the call log. New (unreviewed) call. Repeat call from the same number. • The telephone line cord is not plugged into the wall jack. • The telephone or another telephone on the same line is in use. The battery power is low. -
Page 5: Battery Installation
Before using the telephone, you should install four good AA alkaline batteries (not included) to provide memory backup and enable the use of some features. The four AA batteries are required for caller ID features and the IN USE light to work. If good batteries are not installed, the display only works when you lift the handset. - Page 6 . Install four new AA batteries (not included) in the battery compartment according to the labels + and - engraved in the compartment. NOTES: • Do not mix old and new batteries and do not mix alkaline and standard (carbon-zinc) batteries. •...
-
Page 7: Telephone Installation
If you subscribe to high-speed Internet service (digital subscriber line - DSL) through your telephone lines, you must install a DSL filter between the telephone line cord and the telephone wall jack. The filter prevents noise and caller ID problems caused by DSL interference. -
Page 8: Installation Options
Your telephone base is ready for tabletop use. If you want to mount your telephone on a wall, use the provided wall-mount bracket to connect with a standard dual-stud telephone wall- mounting plate. If you do not have this mounting plate, you can purchase one from many hardware or consumer electronic retailers. - Page 9 2. Remove the bracket from the base. Hold the telephone base with both hands and then slide the bracket upwards as the arrows indicate. 4. Route the telephone line cord through the slot as shown below and plug the other end of the telephone line cord into a telephone wall jack.
- Page 10 5. Place the handset back on the telephone base. Tabletop installation To return the bracket from the wall installation to tabletop use, follow the instructions below. 1. Remove the telephone base from the wall mounting plate. Unplug the telephone line cord from the telephone wall jack and remove the cord from the slots under the telephone base.
- Page 11 3. Remove the bracket from the base. Hold the telephone base firmly and then slide the bracket downwards as the arrows indicate. 5. Route the telephone line cord through the slot as shown below. Plug the other end of the telephone line cord into the telephone wall jack.
- Page 12 www.telephones.att.com Trimline® is a registered trademark of Advanced American Telephones. © 2009 Advanced American Telephones. All rights reserved. AT&T and the AT&T logo are trademarks of AT&T Intellectual Property licensed to Advanced American Telephones, San Antonio, TX 78219. Printed in China. Issue 8 AT&T 08/09...
