SERVICE MANUAL
COMPACT DISC STEREO SYSTEM
• This Service Manual is the "Revision Publishing" and replaces "Simple Manual".
NSX-AJ24 <U> / BL24 <LH>
NSX-BL23 <LH> / BL34 <LH>
NSX-BL24 <HS>
• If requiring information about the CD mechanism, see Service Manual of AZG-1.
AZG-1 ZD8RDC
AZG-1 YZD8RDM
AZG-1 ZD4RDC
NSX-AJ24
NSX-BL23
NSX-BL24
NSX-BL34
NSX-BL24E
NSX-BL34E
BASIC TAPE MECHANISM : ZZM-3
BASIC CD MECHANISM : AZG-1
(S/M Code No. 09-003-426-1T1)
(S/M Code No. 09-004-426-1T4)
(S/M Code No. 09-004-426-1T5)
(S/M Code No. 09-001-335-3NA)
(S/M Code No. 09-001-335-3N6)
(S/M Code No. 09-001-335-3N8)
S/M Code No. 09-005-426-1R1
U
LH
LH, HS
LH
HA
HA
