Summary of Contents for Motorola BASIC XTS 3000

  • Page 1 D I G I T A L S O L U T I O N S Digital XTS 3000 Basic Model User’s Guide...
  • Page 2: Preface

    Preface This manual describes how to operate an ASTRO Digital XTS 3000 Basic Model Portable Radio. The basic model has no display and no keypad. This manual first introduces you to your new radio. Then it covers general radio operation and commonly used radio features. Next, special radio features available on an ASTRO Digital XTS 3000 radio are described.
  • Page 3: Table Of Contents

    Smart PTT ..........24 , Motorola, ASTRO, XTS 3000, Private-Line, Digital Private-Line, Call Alert, MDC-1200, DVP, DVP-XL, Private Conversation, Call Alert, SmartZone, and Quik-Call are trademarks of Motorola, Inc.
  • Page 4: Computer Software Copyrights

    The Motorola equipment described in this manual may include copyrighted Motorola computer programs stored in semiconductor memories or other media. Laws in the United States and in other countries preserve for Motorola certain exclusive rights for copyrighted computer programs, including the exclusive right to copy or reproduce in any form the copyrighted computer program.
  • Page 5: Introduction

    Motorola is committed to leadership in two-way radio communications for all types of private and public use. In addition to providing you with a wide range of analog solutions, Motorola is the leader in developing new digital solutions to serve you today and in the years ahead. ASTRO narrowband technology is the world’s first digital two-way radio system.
  • Page 6: Radio Controls

    Introduction Radio Controls Programmable Switches and Buttons Refer to Table 1 for the features that are programmable, through radio service software (RSS), to the ASTRO Digital XTS 3000 radio controls. Then write, in the space provided below the appropriate switch or button on this page, the features that apply to your radio’s programming (consult your service technician).
  • Page 7 Table 1. Programmable Features Call Response (pg. 19) Channel (pg. 12, 13) Dynamic Priority (pg. 23) Emergency (pg. 15-17) Light (pg. 38) Monitor (pg. 13) Nuisance-Delete (pg. 23) PL Defeat (pg. 20) Repeater/Direct (pg. 21) (pg.XX) = Page Number of Feature Description Introduction Repeater/Direct (pg.
  • Page 8: Switches/Buttons/Knobs/Indicators

    Introduction Switches, Buttons, Knobs, and Indicators Indicates the radio’s operating status: Red =Transmitting Blinking Red = Channel Busy or Low Battery (while transmitting) Blinking Green = Receipt of Individual Call 16-Position Select Knob Selects the operating system (zone) and/or specific channel. On/Off/Volume Control Knob Turns the radio on and off and...
  • Page 9: Antenna Installation And Removal

    Antenna Installation and Removal Before installing the antenna, ensure that the match between your radio and antenna is correct. Your radio’s model number is on a label attached to the back of your radio. A typical model number might be H09UCC9PW5AN. The fourth position of the model number (in this example “U”) identifies the operating-frequency band of the radio.
  • Page 10 Introduction Approx. Length Antenna Type VHF Wide Band Helical VHF Helical UHF Helical UHF Wide Band Whip 800MHz Whip 800MHz Dipole 800MHz Stubby, Quarterwave To install the antenna, screw the threaded end of the antenna into the antenna receptacle on the top of the radio. Rotate the antenna clockwise until it seats firmly against the bushing.
  • Page 11: Battery Installation And Removal

    Battery Installation and Removal To avoid a possible explosion: DO NOT replace the battery in an area labeled “hazardous atmosphere.” DO NOT discard batteries in a fire. If your radio is programmed with volatile-key retention (consult your service technician), encryption keys will be retained for approximately 30 seconds after battery removal.
  • Page 12: Belt-Clip Installation And Removal

    Introduction Belt-Clip Installation and Removal The battery must be removed from the radio before the belt clip Note can be installed or removed. Installing the Belt Clip Hold the battery in one hand so that the top of the battery faces upward and the back of the battery faces you.
  • Page 13: Universal Connector Cover Installation And Removal

    Universal Connector Cover Installation and Removal When the universal connector is not in use, keep it covered with the Installing the Universal Connector Cover 1. Looking at the antenna side of the radio, insert the top (flat) hooked end of the cover into the slot on the top of the radio, above the universal connector.
  • Page 14 Introduction Notes...
  • Page 15: General Radio Operations

    General Radio Operations After a fully-charged battery and an antenna have been connected to the radio, you can begin operation. If necessary, refer to page 2 to ensure a complete understanding of the radio’s controls and indicators. Also, for your convenience, the “Additional Information” section (starting on page 33) contains a glossary, alert tone table, helpful tips, and an index.
  • Page 16: Selecting A Zone And Channel

    General Radio Operations Selecting a Zone and Channel A zone is a grouping of channels. A channel is a group of radio characteristics such as transmit/receive frequency pairs. After you turn your radio on, select the desired zone and channel. Zone Selection Place the Zone Switch (if programmed, see page 2) to the desired position.
  • Page 17: Receiving/Transmitting

    Receiving/Transmitting After you have turned your radio on and selected the desired zone and channel, you can receive (listen) or transmit (send) communications as follows: 1b. Press the Volume Set 1a. Listen until Button (if programmed, you hear a transmission. see page 2) to hear the volume set tone.
  • Page 18: General Radio Features

    General Radio Operations General Radio Features Time-Out Timer The new ASTRO portable radio is equipped with a programmable time-out timer which, upon expiration, will turn off the transmitter. This timer is programmable through radio service software and can be set from 0 seconds (off) to 7.75 minutes (465 seconds), at 15 second increments.
  • Page 19: Common Radio Features

    Common Radio Features Emergency For radios programmed with the emergency feature, pressing the Emergency Button (if programmed, see page 2) will send out an emergency signal that takes precedence over any other signalling activity in progress on the selected channel. There are two types of emergency signals: •...
  • Page 20 Common Radio Features 2a. Emergency Alarm During a non-silent emergency alarm state: • the LED will light, • a short, medium- pitched tone will be heard, • when the emergency alarm is acknowledged by the dispatcher, the radio sounds four beeps and the alarm ends.
  • Page 21 Exiting the Emergency State It is important that you exit the emergency state when you have finished. There are four ways to exit the emergency state: Press the Emergency Button for approximately 1 second (this time is programmable through radio service software); a medium-pitched, emergency-exit tone sounds until the button is released and the radio returns to normal operation.
  • Page 22: Individual Calls - Receive Only

    Common Radio Features Individual Calls – Receive Only Individual calls are defined as follows: • Telephone Calls — similar to standard telephone calls, except you use your radio. These calls can be landline caller to radio, radio to landline caller, or landline caller to radio talkgroup. •...
  • Page 23 Answering an Individual Call When an individual call is being received, you will hear and/or see: • a telephone-type ringing if it is a telephone call in a trunked radio; • two alert tones if it is a Private-Conversation call or selective call; •...
  • Page 24: Pl Defeat

    Common Radio Features PL Defeat The PL defeat feature allows you to override any coded squelch (DPL, PL, or network ID) that may be programmed to a channel. To activate this feature, place the PL Defeat Switch (if programmed, see page 2) in the PL defeat position.
  • Page 25: Repeater/Direct

    Common Radio Features Repeater/Direct The repeater/direct feature allows you to bypass the repeater and talk directly to another radio. This is known as DIRECT operation or talkaround operation. The transmit frequency is the same as the receive frequency. In REPEATER operation, you talk through the repeater, which increases the radio’s operating range.
  • Page 26: Scan

    Common Radio Features Scan The scan feature allows you to monitor activity on different channels by scanning a “scan list.” Each radio can have up to 20 different scan lists. The channels to be scanned can be programmed with the radio service software. Three types of scan lists are available (consult your service technician for additional information): •...
  • Page 27 Turning Scan On and Off Place the Scan On/Off Switch (if programmed, see page 2) in the “scan on” position or the “scan off” position. Deleting Nuisance Channels When the radio scans to a channel that you do not wish to hear (nuisance channel), you can temporarily delete the channel from the scan list.
  • Page 28: Selecting Squelch Operation

    Common Radio Features Selecting Squelch Operation Tone Private-Line® (PL), Digital Private-Line™ (DPL), network ID, and carrier squelch operations are all available in the same radio on a per channel basis. Network ID is only available on ASTRO “digital” channels Note (consult your service technician).
  • Page 29: Special Radio Features

    Special Radio Features Dynamic Regrouping The dynamic regrouping feature allows the dispatcher to temporarily reassign selected radios to a single special channel so that they can communicate with each other. This feature, enabled in each radio by means of the radio service software, is typically used during special operations. You will not notice whether your radio has this feature enabled until a dynamic regrouping command is sent by the dispatcher.
  • Page 30 Special Radio Features Talk and listen as usual. When the dynamic regrouping is cancelled by the dispatcher, the radio will automatically return to the present knob/switch zone and/or channel position. Reprogram Request This feature allows you to notify the dispatcher that you want a new dynamic-regrouping assignment.
  • Page 31: Ptt-Id Transmit

    Special Radio Features PTT-ID Transmit The PTT-ID transmit feature is a per channel feature where your radio’s ID number is automatically sent every time the PTT Switch is pressed. Depending upon how your radio was programmed, your radio’s ID can be transmitted at the beginning of a transmission, at the end of a transmission, or at the beginning and ending of a transmission.
  • Page 32: Secure Operation

    Secure operation provides the highest level of commercially Note available voice security on trunked or conventional channels. Unlike other forms of security, Motorola digital encryption provides signalling that makes it virtually impossible for others to decode any part of an encrypted message.
  • Page 33: Managing Encryption

    Managing Encryption KEY Loading Refer to the key-variable loader (KVL) manual for equipment connections and setup. When the KVL is attached to your radio, all other radio functions will be locked out. Pressing the KVL’s PTT switch will load the encryption keys into your radio.
  • Page 34: Selectable Power-Level

    Special Radio Features Selectable Power-Level This feature allows you to select the power level at which your radio will transmit messages. The radio will always turn on to the default setting as determined Note through radio service software. Place the TX Power-Level Switch (if programmed, see page 2) in the “high-power”...
  • Page 35: Trunking System Controls

    Trunking System Controls Busy Override When a talkgroup call is placed in a SmartZone™ system and the system is not able to obtain voice channels at all necessary sites, a busy tone will be generated. If so programmed in the zone manager and through the radio service software, you may override this busy by performing the following steps: Press the PTT Switch;...
  • Page 36: Site Lock

    Special Radio Features Out-of-Range If you go out of range of the system and can no longer lock onto a control channel, the radio will sound a low-pitched tone. Your radio will remain in this out-of-range condition until it (1) locks onto a control channel, (2) locks onto a failsoft channel, or (3) is turned off.
  • Page 37: Additional Information

    Additional Information Glossary Channel Control Channel Conventional Dispatcher Hang Up Landline Caller Page Radio-To-Landline Repeater Squelch Standby Talkgroup Trunking Zone Acknowledgment of communication A group of characteristics such as transmit/receive frequency pairs, radio parameters, and encryption encoding In a trunking system, one of the channels that is used to provide a continuous, two-way/data communications path between the central controller and all radios on the system...
  • Page 38: Alert Tones

    Additional Information Alert Tones Sound Tone Name Radio Self-Test Fail Short, No ACK Received Low-Pitched Tone Time-Out Timer Warning Time-Out Timer Timed Out Talk Prohibit/ PTT Inhibit Continuous, Out-of-Range Low-Pitched Tone Invalid Mode Individual Call Warning Tone A Group of Low-Pitched Tones (Busy Tone) Radio Self-Test Pass...
  • Page 39 Alert Tones (cont.) Sound Tone Name Low-Battery Chirp Short, High-Pitched Tone Phone Dekey Chirp (Chirp) Continuous, Quik-Call™ Group High-Pitched Tone A Group of Quik-Call High-Pitched Tones Individual Call Phone Ringing Ringing Enhanced Call Received Dynamic Regrouping/Over- Gurgle The-Air Programming when battery is below preset threshold value from radio to phone line upon releasing the PTT when a Quik-Call group call is received Call...
  • Page 40: Battery Charging And Disposal

    (NiMH) rechargeable battery. Charge the battery before use to ensure optimum capacity and performance. The battery was designed specifically to be used with a Motorola charger. Charging in non-Motorola equipment may lead to battery damage and void the battery warranty.
  • Page 41 In addition, U.S. Environmental Protection Agency (EPA) regulations classify used Ni-Cd batteries as hazardous waste, unless certain exemptions apply. Motorola fully endorses and encourages the recycling of Ni-Cd batteries. If you are located in the United States or Canada, you can ship, post paid, your used Ni-Cd batteries to INMETCO, an EPA approved recycling facility, at the address listed below.
  • Page 42: Helpful Tips

    Problem Not Solved If, after following steps 1 and 2, your radio still has a problem, review your service agreement and call the applicable Motorola service representative. If you do not have a service agreement on your radio, contact your nearest authorized Motorola service shop for guidance toward a prompt and expedient evaluation and/or repair.
  • Page 43: Radio Care

    Radio Care • Cleaning Clean external surfaces of your radio with the following solution: one teaspoon of mild dishwashing detergent to one gallon of water (0.5% solution). Do not use solvents to clean your radio; spirits may be harmful and permanently damage the radio housing. Apply the detergent solution sparingly with a stiff, non-metallic, short-bristled brush, being careful not to allow excess detergent to remain entrapped near connectors and controls or in cracks and crevices.
  • Page 44: Air Bag Safety Information

    Service Proper repair and maintenance procedures will assure efficient operation and long life for this product. A Motorola maintenance agreement will provide expert service to keep this and all other communication equipment in perfect operating condition. A nationwide service organization is provided by Motorola to support maintenance services.
  • Page 45: Index

    Index Air Bag Safety ..........40 Alert Tones .
  • Page 46 Index Monitor ............13 Multikey .
  • Page 47 Digital XTS 3000 Basic Model Portable Radio Quick-Reference Card Concentric 16-Position Switch Select Knob _ _ _ _ _ _ On/Off/ Top Button Volume Knob _ _ _ _ _ _ _ Top Side Button 3-Position _ _ _ _ _ _ _ Switch _ _ _ _ _ _ _ Side Button 1...
  • Page 48: Radio Features

    COMMON and SPECIAL RADIO FEATURES Most of your radio features can be accessed by performing the following step. For more detail, refer to the feature description in your manual. Press (or rotate) the Feature Button/Switch (if programmed). LED DESCRIPTION Indicates the radio’s operating status: •...
  • Page 49 QUESTIONNAIRE We believe that reports from users provide valuable information for producing quality operating instructions. Your comments and answers to the following questions will aid us in preparing manuals that contain accurate and complete information of maximum benefit to you. In reference to Manual No.
  • Page 51: Fcc Safety Standards

    Standard. In March, 1993, the Federal Communi- cations Commission (FCC) proposed the adoption of this updated Standard. Motorola subscribes to the same safety standard for the use of its products. Proper operation of this radio will result in user exposure substantially below FCC recommended limits: •...
  • Page 52 Motorola 8000 West Sunrise Boulevard Fort Lauderdale, Florida 33322...
