Rear Panel Description

Figure 2 shows the NetVanta 7100 rear panel, which contains a power connection and a single DB-9
(female) interface (labeled
terminal emulation software. The NetVanta 7100 has a rear panel Ethernet port (labeled
and/or administration connectivity, dual analog stations and trunks, compact flash (
(
),
, and alarm contacts (
MOH
PAGE
NetVanta 7100 contains modular network interfaces that accept a variety of modules (refer to Option
Modules on page 24). Appendix A shows the pinouts for the connectors.
Devices connected to the Station (FXS) ports must be ACTA/FCC Part 68 compliant due to
the direct connection to the PSTN in Life Line mode.
Connection directly to an external modem requires a cross-over cable.
CF
61200796L1-34D
) used for connecting to a VT100 terminal or a PC running VT100
CONSOLE
DOOR RELAY
SLOT 1 NIM/VIM
SLOT 2 NIM/VIM

Figure 2. NetVanta 7100 Rear Panel
