Physical Description
LEDs
STAT
SLOT 1/ SLOT 2
Port Status (1 through
24, and G1/G2)
Power over Ethernet
(PoE)
(RJ-45)
61200796L1-34D

Table 1. Front Panel LED Descriptions

Color Indication
Off The unit is not receiving power.
Green (flashing) On power-up STAT LED blinks rapidly for five seconds, during
which time the user may escape to boot mode from the console
port.
Green (solid) The power is on and self-test passed.
Red (solid) The power is on, but the self-test failed or the boot code could not
be booted.
Off No NIM/VIM installed or interface is administratively down
Green (solid) The NIM/VIM module is up and everything is okay.
Green (flashing) There is activity (TX/RX) on the port.
Amber (solid) The NIM/VIM module is in test.
Red (solid) An alarm condition is occurring on the interface, or there is a
self-test failure.
Off Port is administratively disabled or does not have a connection.
Green (solid) The link is up and the port is enabled. The port is connected to a
host (link is up), and there was activity (receive or transmit) in the
past 30ms interval.
Amber (flashing) Port has activity (transmit or receive).
Green (solid) Power is being applied (48V) to interface.
Red (solid) Fault detected on interface.
