GEAppliances GBS22HCP Dimension Manual

GE Appliances
GBS22HCP – GE E
NERGY
Dimensions (in inches)
Front View
B
A
Specification Created 6/03
S ® 22.3 Cu. Ft. Bottom-Freezer Refrigerator with Icemaker
TAR
Top View
C
D
G
E
F
Height to top of hinge (in.) A
Height to top of case (in.) B
Case depth without door (in.) C
Depth less door handle (in.) D
Depth with door handle (in.) E
Depth with door open 90° (in.) F
Width (in.) G
Side clearance for 90° door open (in.)
Each side (in.)
Top (in.)
Back (in.)
Total volume and shelf
area are calculated by the
Listed by
Association of Home
Underwriters
Appliance Manufacturers'
R Laboratories
standards.
For answers to your Monogram, ® GE Profile
GE ® appliance questions, visit our website at
R
GEAppliances.com or call
GE Answer Center ® service, 800.626.2000.
68-5/8
67-7/8
28-1/4
31-3/4
34-1/8
62
32-7/8
1-1/4
1/8
1
1
®
As an ENERGY STAR Partner,
GE has determined that this product
meets the ENERGY STAR ®
guidelines for energy efficiency.
™ or
