GE Appliances
GSS25JFM - GE 24.9 Cu. Ft. Side-By-Side Refrigerator with Dispenser
Dimensions (in inches)
A B
Specification Revised 3/01
H
G
C
D
Top View
For answers to your Monogram,
GE appliance questions, visit our website at
WWW.GEAppliances.com or call
GE Answer Center
Height with hinge (in.) A
Height without hinge (in.) B
Depth without Doors (in.) C
Depth with Doors (in.) D
Depth plus Handle with Doors Closed (in.) E
Depth with Doors open 90° (in.) F
E Width with Doors Closed (in.) G
F
Width with Doors open 90° Less Door Handle(in.) H 35-3/4
Each side (in.)
Top (in.)
Back (in.)
Note: Add 9/16" for water hook-up. Hook-up fits in 5/8" back air clearance
when calculating installation depth.
If installed against a wall, allow clearance of 11-1/4" on freezer side to
remove bin.
To remove fresh food pans, remove door bins.
Clearance required to remove fresh food full-size pan without
disassembling: 13-5/8" (25 cu. ft.)
For Built-In Appearance allow height space of 69-3/4".
Plus, allow additional space for any necessary leveling adjustments.
® GE Profile ™ or
® service, 800.626.2000.
Total volume and shelf
VOLUME and
area are calculated by the
SHELF AREA
Association of Home
Manufacturer Certified to
Appliance Manufacturers'
R
ASSOCIATION OF HOME
APPLIANCE MANUFACTURERS
ANSI/AHAN HRF-1-1979
standards.
69-3/4
68-3/4
28
30-3/4
33
48-13/16
35-3/4
1/8
1
1
Listed by
Underwriters
Laboratories
