1. Operation and installation
instruction

1.1 Description of the unit.

The X-SLIM is a slim and pressure-
less instantaneous water heater that
gives you the ultimate shower
experience.
The heating of the water is electronically
controlled and the flow is switched
on and off by using the water valve.
Once the flow volume is sufficient,
the "Power" light will indicate that
the unit is switched on.
For safety the unit is fitted with an
overheating protection device.
Shower head level must not be higher than the unit.
d
for the user and the qualified installer
1.2 The essentials - in brief
a. Water valve
b. Rotary control for
temperature adjustment
c. "Power" light
d. Shower accessories
c
b
a
Fig 5
5
