WARNING: Carefully remove each mantel piece one at a time from shipping carton. Do not try to lift all of the
WARNING ICON G 001
parts out of the box at once. This may damage mantel pieces.
IMPORTANT: Read entire instruction sheet before assem-
bling or installing mantel kit.
This mantel is only approved for use with DESA Heating
Products 32" fireboxes or 32" fireplace systems. Do not use
mantel with any other product. Several optional accesso-
ries are available for this mantel kit. Contact dealer to pur-
chase optional accessories.
This mantel kit contains the following pieces:
Item Part No.
Hardware Package 101472-01
Brass Trim Kit 102753-01
Trim Kit Hardware 102865-01
The hardware package contains the following*:
Qty. Item
1
13 #8 x 1 / " Screws
4
6 1" Finishing Nails
*Extra hardware may be included.
Tools required
• #2 Phillips screw driver
• Flat head screw driver
• Measuring tape
GMC11FD, GMC12UD, GMC13FD,
GM102WC, GMC8CU and GMC10CF

Cabinet Mantel

ASSEMBLY AND INSTALLATION INSTRUCTIONS

Note: Your mantel may differ slightly from illustrations.
•Pencil
•Drill
Shown with Optional Hearth Base
If any of these pieces are missing or damaged, contact the dealer where
you purchased this kit or DESA Heating Products at 1-866-672-6040
for referral information. For touch-up of the GM102W series mantel
use Sherwin Williams SW1095 semi-gloss enamel paint.
WARNING: Use care when finishing an unfinished
WARNING ICON G 001
mantel. Do not finish mantel pieces near running
heater or open flame. Vapors from most finishing
products are highly flammable. Follow manufacturer's
guidelines when using finishing products.
IMPORTANT: If you are staining an unfinished mantel, sand entire
outside of mantel to remove any dirt or oils. This will prevent
blemishes from appearing under the stain. Stain mantel according to
manufacturer's instructions. Apply sanding sealer.
IMPORTANT: If you are painting an unfinished mantel, apply an
oil base undercoat to the mantel before painting. This will seal the
wood. After undercoat dries completely, lightly sand and apply an
oil base top coat. If you do not apply an oil base undercoat and
topcoat, the wood grain will bleed through the paint.
