INSTALLATION INSTRUCTIONS
CONTENTS
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
OUTDOOR DISHWASHER
AUTOMATIC HIGH LOOP
The drain hose is fastened to the back of the machine
at the best height. To eliminate potential drain problems,
leave this hose in place.
2
2
3
3
4
4
5
6
7
8
9
9
10
Advertisement
Table of Contents
Related Manuals for Asko D5954OUTDOORPH
Summary of Contents for Asko D5954OUTDOORPH
-
Page 1: Table Of Contents
OUTDOOR DISHWASHER INSTALLATION INSTRUCTIONS AUTOMATIC HIGH LOOP The drain hose is fastened to the back of the machine at the best height. To eliminate potential drain problems, leave this hose in place. CONTENTS INTRODUCTION WHAT YOU NEED UNIT DIMENSIONS PREPARING THE LOCATION EASYINSTALL CONNECTIONS WATER SUPPLY DRAIN CONNECTIONS... -
Page 2: Introduction
NOTE: If a dishwasher is being installed in this area for the first Cosmetic damage must be reported to the ASKO dealer time, most of the cabinet work, plumbing, and electrical within five days from the date of purchase. As soon as has to be done before you move the machine into place. -
Page 3: Unit Dimensions
UNIT DIMENSIONS Technical Data U.S. Metric Electricity 120 V, 60 Hz, 15 amp Height (Adjustable) 35˝ to 35-3/4˝ 889 to 908mm Water pressure 4.2 - 140 psi, 0.03-1.0 MPa, Width 24-5/8˝ 625 mm 0.3-10 Bar Depth (Includes high loop) 25˝ 635 mm Heating element 1200 watt... -
Page 4: Easyinstall Connections
EASYINSTALL CONNECTIONS PEX tubing with 3/8˝ compression Electrical cord 120 volts, 15 amp cord is supplied with fitting the dishwasher. PEX tubing has a 95-year spec life. Fits American dishwasher water supply valves. Be sure to install the O-Ring which is attached to the PEX tubing in a plastic bag WARNING! Risk of electric shock. -
Page 5: Drain Connections
DRAIN CONNECTIONS THREE WAYS TO INSTALL ASKO provides a 7/8˝ (22 mm) diameter corrugated drain hose which is connected to the back of the unit to DRAIN CONNECTIONS form a high loop. A) Typical connection to sink plumbing before trap... -
Page 6: Electrical Connections
ELECTRICAL CONNECTIONS CORD-CONNECTED APPLIANCE WARNING! GROUNDING INSTRUCTIONS Before working on wiring for any electrical appliance, This appliance must be grounded. In the event of a be sure the electrical power has been turned off at malfunction or breakdown, grounding will reduce the risk the breaker/fuse box. -
Page 7: Preparing The Dishwasher For Installation
PREPARING THE DISHWASHER FOR INSTALLATION SLIDES FOR LEGS At this point the styrofoam, plastic wrap, and the wood pallet (base) should be removed from the dishwasher. (Only certain models.) Now is an excellent time to inspect for any shipping The unit comes with white plastic slides for the legs to damage. -
Page 8: Moving The Machine Into Place
MOVING THE MACHINE INTO PLACE 1. Position the machine in front of the cabinet opening. WARNING! 2. Push the plastic feet into place on all steel feet Make sure you put the protective slides on the legs (included in document bag). (Only certain models.) to prevent damaging the floor when you slide the unit 3. -
Page 9: Connecting The Electrical Cable
CONNECTING THE ELECTRIC CABLE If the cord is not long enough, or if a hard-wire installation Connect ground wire to ground connection screw is needed, follow the steps below to complete the on the bottom. electrical connection. WARNING! Before starting this procedure, be sure the power is turned off at the breaker/fuse box. -
Page 10: Installation Checklist
INSTALLATION CHECKLIST ASKO - DISHWASHER Appliance Installation Checklist • Remove packaging and check for cosmetic damages. • Remove the information packets from inside the dishwasher. • Attach the drain line using the largest section of the disposer boot allowable. Leave the high loop in place. - Page 11 NOTES Page 11 Customer Care Center 1-800-898-1879 www.askona.com...
- Page 12 Art. No 492161 Rev. 01 Page 12 Customer Care Center 1-800-898-1879 en (10-14) www.askona.com...
