EXMARK NEXT GENERATION MOWERS
OPERATOR'S MANUAL
ASSEMBLY
MANUAL PART#: Q0384
MODEL 35621217 & 35621228
OPERATION
PRO 12
GRASS COLLECTION
SYSTEM
MAINTENANCE
$10.00
REV: 0

Advertisement

Table of Contents
loading

Summary of Contents for Peco Pro 12

  • Page 1 P P P PRO 12 PECO PECO PECO PECO PECO GRASS COLLECTION SYSTEM MODEL 35621217 & 35621228 EXMARK NEXT GENERATION MOWERS OPERATOR’S MANUAL ASSEMBLY OPERATION MAINTENANCE MANUAL PART#: Q0384 $10.00 REV: 0...
  • Page 2: Table Of Contents

    PECO GRASS COLLECTION SYSTEM TABLE OF CONTENTS SECTION PAGE SECTION PAGE Safety - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2...
  • Page 3: Safety Alert Symbols

    SAFETY WARNING! NEVER operate the unit unless the discharge guard and either the deflector assembly or the vacuum collector adapter are fastened securely in place. WARNING! Do not work around the mower deck boot or the blower area until you are certain that the mower blades and the blower impeller have stopped rotating.
  • Page 4: Warranty

    PECO elects, without charge if the defect appears within 90 days from the date of installation of such part or before the expiration of the original warranty period, whichever is later.
  • Page 5: Introduction And Description

    INTRODUCTION AND DESCRIPTION 1-1 Introduction Rotating The Donaldson Air Cleaner We are pleased to have you as a PECO customer. Your Note: If equipped with a Donaldson air cleaner, unit collection system has been designed to give you a low...
  • Page 6: Lower Main Frame Leg Installation

    Figure 2-3c 2-3 Lower Main Frame Leg Installation Left Lower Frame Leg B0529 Attach to R.O.P.S. Looking from the rear of mower, locate the ROPS mounting bolts and remove the lower hex bolt and washer from each side of the ROPS. On the mowers rear bumper, locate the slotted hole on each side.
  • Page 7: Lift Handle Installation

    Figure 2-6a 2-5 Lift Handle Installation Insert Pins Insert Pins The various parts of the handle assembly P#(A0273) From Outside From Outside must be attached to the container frame. PAGE 12 shows the orientation and location of the components. Slide the lift handle into the slot in the handle mount bracket P#(B1730) on the grass container.
  • Page 8: Engine Mount Arm Assembly Installation

    2-8 Engine Mount Arm Assembly 2-10 Boot To Mower Deck Installation Installation To mount the boot plates P#(B0538) to the boot P#(E1039) use (2) 3/8”-16 x 1” carriage bolts P#(K1182) Slide the engine mount arm assembly P#(A0318) and (2) 3/8”-16 nyloc nuts P#(K1216). Make certain that when bolting the boot and boot plate together, that the (Figure 2-8) into the outer engine mount tube P#(A0600) until the hole in the engine mount arm assembly aligns...
  • Page 9: Blower Cone Installation

    2-11 Blower Cone Installation 2-12 Impeller Blade Removal/Replacement Thread (1) 5/16”-18 jam nut P#(K0120) onto each end of (2) 5/16”-18 x 2-1/2” HHCS P#(K0125). Now partially To Remove: First remove the center bolt (#1), washer thread the bolts into each of the two tabs located on the (#2) and spacer (#3) from the taper-lock bushing (#5).
  • Page 10: Throttle Cable Installation

    2-13 Throttle Cable Installation Figure 2-13d To install the throttle cable kit P#(A0060 for 5.5HP) or P#(A0294 for 6.0 HP) to the box assembly, align the large end of the slot in the throttle base plate (Figure 2- 13a) with the rivets located on the front of the box assembly frame (Figure 2-13b).
  • Page 11: Length Of Hose Adjustment

    2-14 Length Of Hose Adjustment The hoses in steps 2-15 and 2-16 must be cut to fit your mower. Follow steps 2-15 and 2-16, however, do not cut the hoses until you have tried to fit them on your mower. Figure 2-16 Remember that the hoses have to be long enough to allow for enough clamping surface between the inlet,...
  • Page 12: Exploded Parts Views And Assemblies

    Lift Handle Assembly Aluminum Grass Container Assembly Inlet Aluminum Grass Container With Handle Attached Latch Hook Mechanism Assembly MAIN FRAME...
  • Page 14 MODEL#: 35621217 MOWER NAME: EXMARK MOWER MODEL: LAZER Z NEXT GENERATION MOWER DECK SIZE: 48” 52” 60” & 72” VAC NAME: 12 CUBIC FOOT BOX FOR YEAR: 2009 - 2010 ENG: 900 SER. BR (9.00 GROSS TORQUE / 205 cc) 5/8/2012 REVISED: MANUAL: Q0384...
  • Page 15 P P P P P P P MODEL#: 35621228 PECO PECO PECO PECO PECO PECO MOWER NAME: EXMARK MOWER MODEL: LAZER Z NEXT GENERATION MOWER DECK SIZE: 48” 52” 60” & 72” VAC NAME: 12 CUBIC FOOT BOX FOR YEAR: 2009 - 2010 6.5HP BRIGGS AND STRATTON VANGUARD...
  • Page 16: Operating Instructions

    * Mow twice, at different height settings, (high, then low), been torn or worn through, replace with genuine if grass is extra tall. PECO parts. * Remember that horsepower requirements will vary with the mowing conditions such as type and height of turf...
  • Page 17: Parts And Service

    SECTION V PARTS AND SERVICE 5-1 Parts And Service Information PeCo collection system owners should record the name and telephone number of their Service Center. Your Service Center will be happy to supply replacement parts, accessories, and do any service or repairs to your collection system.
  • Page 18: Safety Decals

    SAFETY DECALS To promote safe operation, PECO supplies safety decals on all products manufactured. Damage can occur to safety decals either through shipment, use or reconditioning. Contact your local Service Center for replacement decals. Part #: R4027 OPERATION Part #: R1069...
  • Page 20 P P P PECO PECO PECO PECO PECO 100 AIRPORT ROAD ARDEN, NORTH CAROLINA 28704 (800) 438-5823 OR (828) 684-1234 FAX: (828) 684-0858 EMAIL: peco@lawnvac.com WEBSITE: www.lawnvac.com...
