Page 1 KT715-KT745 Service Manual IMPORTANT: Read all safety precautions and instructions carefully before operating equipment. Refer to operating instruction of equipment that this engine powers. Ensure engine is stopped and level before performing any maintenance or service. Safety Maintenance Specifications Tools and Aids...
Page 2 Safety SAFETY PRECAUTIONS WARNING: A hazard that could result in death, serious injury, or substantial property damage. CAUTION: A hazard that could result in minor personal injury or property damage. NOTE: is used to notify people of important installation, operation, or maintenance information. CAUTION WARNING WARNING...
Page 3 ² Have a Kohler authorized dealer perform this service. REPAIRS/SERVICE PARTS Kohler genuine service parts can be purchased from Kohler authorized dealers. To find a local Kohler authorized dealer visit KohlerEngines.com or call 1-800-544-2444 (U.S. and Canada). 32 690 03 Rev. E...
Page 4 OIL RECOMMENDATIONS STORAGE If engine will be out of service for 2 months or more We recommend use of Kohler oils for best performance. follow procedure below. Other high-quality detergent oils (including synthetic) of API (American Petroleum Institute) service class SJ 1.
Page 5: Specifications
Specifications Engine Dimensions Dimensions in millimeters. Inch equivalents shown in [ ]. 37.00 4X Ø 9.005 ± 0.035 [1.46] [.355 ± .0014] 254.00 B.C. [10.000] 32 690 03 Rev. E KohlerEngines.com...
Page 6 Kohler engine identification numbers (model, specification and serial) should be referenced for efficient repair, ordering correct parts, and engine replacement. Model ..... KT715 7000 Series Engine Numerical Designation Specification .
Page 7 Specifications TORQUE SPECIFICATIONS KT715 KT725 KT730 KT735 KT740 KT745 Carburetor Mounting Nut 6.2-7.3 N·m (55-65 in. lb.) Connecting Rod Cap Fastener (torque in increments) 11.3 N·m (100 in. lb.) Black Coating Gray Metallic Coating 13.6 N·m (120 in. lb.) Crankcase...
Page 8 Specifications TORQUE SPECIFICATIONS KT715 KT725 KT730 KT735 KT740 KT745 Solenoid (Starter) Mounting Hardware 4.0-6.0 N·m (35-53 in. lb.) Nut, Positive (+) Brush Lead 8.0-11.0 N·m (71-97 in. lb.) Speed Control Bracket Fastener 10.7 N·m (95 in. lb.) into new holes 7.3 N·m (65 in.
Page 9 Specifications CLEARANCE SPECIFICATIONS KT715 KT725 KT730 KT735 KT740 KT745 Crankshaft End Play (free) 0.075/0.595 mm (0.0030/0.0023 in.) Bore (in crankcase) 40.974/40.987 mm (1.6131/1.6137 in.) Max. Wear Limit 41.000 mm (1.6142 in.) Bore (in oil pan) 40.974/41.000 mm (1.6457/1.6142 in.) Crankshaft Bore (in oil pan)-to-Crankshaft Running Clearance 0.039/0.087 mm (0.0015/0.0034 in.)
Page 10 Specifications CLEARANCE SPECIFICATIONS KT715 KT725 KT730 KT735 KT740 KT745 Piston, Piston Rings, and Piston Pin Piston-to-Piston Pin Running Clearance 0.006/0.017 mm (0.0002/0.0007 in.) Pin Bore I.D. 17.006/17.012 mm (0.6695/0.6698 in.) Max. Wear Limit 17.025 mm (0.6703 in.) Pin O.D. 16.995/17.000 mm (0.6691/0.6693 in.) Max.
Page 11 Specifications GENERAL TORQUE VALUES English Fastener Torque Recommendations for Standard Applications Bolts, Screws, Nuts and Fasteners Assembled Into Cast Iron or Steel Grade 2 or 5 Fasteners Into Aluminum Size Grade 2 Grade 5 Grade 8 Tightening Torque: N·m (in. lb.) ± 20% 8-32 2.3 (20) 2.8 (25)
Page 12 Here is a list of tools and their source. SEPARATE TOOL SUPPLIERS Kohler Tools SE Tools Design Technology Inc. Contact your local Kohler source of 415 Howard St. 768 Burr Oak Drive supply. Lapeer, MI 48446 Westmont, IL 60559...
Page 13 For reaming worn valve guides to accept replacement oversize valves. Can be used in low-speed drill press or with handle below for hand reaming. Reamer Handle Design Technology Inc. For hand reaming using Kohler 25 455 12-S reamer. DTI-K830 AIDS Description Source/Part No.
Page 14 Tools and Aids FLYWHEEL HOLDING TOOL ROCKER ARM/CRANKSHAFT TOOL A flywheel holding tool can be made out of an old junk A spanner wrench to lift rocker arms or turn crankshaft flywheel ring gear and used in place of a strap wrench. may be made out of an old junk connecting rod.
Page 15: Troubleshooting
Troubleshooting TROUBLESHOOTING GUIDE When troubles occur, be sure to check simple causes which, at first, may seem too obvious to be considered. For example, a starting problem could be caused by an empty fuel tank. Some general common causes of engine troubles are listed below and vary by engine specification. Use these to locate causing factors.
Page 16 Troubleshooting EXTERNAL ENGINE INSPECTION Engine Loses Power NOTE: It is good practice to drain oil at a location away ● Dirty air cleaner element. from workbench. Be sure to allow ample time for ● Engine overheated. complete drainage. ● Excessive engine load. ●...
Page 17 Troubleshooting CRANKCASE VACUUM TEST WARNING WARNING Carbon Monoxide can cause severe nausea, Rotating Parts can cause severe injury. fainting or death. Stay away while engine is in operation. Avoid inhaling exhaust fumes. Engine exhaust gases contain poisonous carbon Keep hands, feet, hair, and clothing away from all monoxide.
Page 18 Troubleshooting COMPRESSION TEST For Command Twins: A compression test is best performed on a warm engine. Clean any dirt or debris away from base of spark plug(s) before removing them. Be sure choke is off, and throttle is wide open during test. Compression should be at least 160 psi and should not vary more than 15% between cylinders.
Page 19 Air Cleaner/Intake AIR CLEANER Air Cleaner Base These systems are CARB/EPA certified and components should not be altered or modified in any way. Air Cleaner Components Precleaner Paper Element Air Cleaner Cover Blower Housing Air Cleaner Air Cleaner Base Cover Lever NOTE: Operating engine with loose or damaged air cleaner components could cause premature wear and failure.
Page 20 Air Cleaner/Intake Disassembly/Reassembly BREATHER TUBE NOTE: On engines equipped with eChoke , stepper Ensure both ends of breather tube are properly ™ motor has a special retract routine that can be connected. activated to ensure motor is in correct position AIR COOLING prior to removal or upon replacement of stepper motor when a problem is shown to exist with...
Page 21: Fuel System
3. Connect pulse line to new fuel pump and make sure Low permeation fuel line must be installed on carbureted opposite end is properly connected into valve cover. Kohler Co. engines to maintain EPA and CARB regulatory compliance. 4. Attach new fuel pump using screws. Torque screws to 2.8 N·m (25 in.
Page 22 Fuel System CARBURETOR Walbro One-Barrel Carburetor Components WARNING Explosive Fuel can cause fires and severe burns. Do not fill fuel tank while engine is hot or running. Gasoline is extremely flammable and its vapors can explode if ignited. Store gasoline only in approved containers, in well ventilated, unoccupied buildings, away from sparks or flames.
Page 23 Fuel System Troubleshooting-Carburetor Related Causes Condition Possible Cause Conclusion Engine runs rich (indicated by black, Clogged air cleaner. Clean or replace air cleaner. sooty exhaust smoke, misfiring, loss Choke partially closed during Check choke lever/linkage to ensure of speed and power, governor operation.
Page 24 Fuel System Carburetor Adjustments Float Setting (Keihin Only) NOTE: Carburetor adjustments should be made only after engine has warmed up. Carburetor is designed to deliver correct fuel-to-air mixture to engine under all operating conditions. Main fuel jet is calibrated at factory and is not adjustable. Idle fuel adjusting needles are also set at factory and are not adjustable.
Page 25 Check spring loaded choke plate to make sure it 1219 meters (4000 ft.). To obtain high altitude kit moves freely on shaft. information or to find a Kohler authorized dealer visit KohlerEngines.com or call 1-800-544-2444 (U.S. and 22. Clean carburetor float bowl as required.
Page 26 Fuel System Smart-Choke ™ An air vane deflector assembly that operates by air from cooling fan opens choke partially when engine is running. When engine is cold, a spring on air vane deflector assembly, in conjunction with a bimetallic spring, holds choke closed for starting.
Page 27 Fuel System Troubleshooting Smart-Choke Related Causes ™ Condition Possible Cause Conclusion Engine starts hard, runs rough, or stalls at Choke not closing. Check choke lever/linkage to ensure idle speed. choke is operating properly. Check that bimetallic spring actuates freely. Engine runs rich (indicated by black, Choke partially closed during operation.
Page 28 If starter does not turn engine over, shut starter off immediately. Do not make further attempts to start engine until condition is corrected. Do not jump start using another battery. See your Kohler authorized dealer for trouble analysis. 4. For operation, after engine starts, move throttle and set desired engine operating speed.
Page 29 Calculations and unique software routines developed specifically for this Kohler engine operate a carburetor choke lever through an assembly (bracket, linkage) to control a stepper motor. Power and ground are supplied to master control and ignition module (Cylinder 2) which provides a signal for stepper motor by way of a control harness that is routed through cylinder #2 baffle.
Page 30 Fuel System eChoke System Standard Checks Blink Codes ™ NOTE: Procedures and troubleshooting may be easier eChoke system is equipped with an MIL connector that ™ to perform with engine cover removed. Refer to will allow connection of an LED lamp to show normal Disassembly/Inspection and Service and eChoke operation or specific error codes.
Page 31 Fuel System Operational Tests Test Step Description of What is happening at Operation MIL Lamp Status Number Operation eChoke ™ Choke system will cycle Remove and reconnect Power Cycle to complete open and engine connector. then complete close. System activated, temperature read, waiting for engine to crank &...
Page 32 Fuel System Failure Modes Pause at RUN and attempt to CRANK engine. Limit cranking time to about 5 seconds. For first 4 failed crank attempts, choke Failure to Start will reposition at each attempt. After four (4) attempts, key OFF and make one final attempt to start.
Page 33 Fuel System Troubleshooting eChoke Related Causes ™ Condition Possible Cause Conclusion Engine starts hard, runs rough, or Choke not closing/moving Stepper motor/bracket/link assembly stalls at idle speed. a. Incorrect set up of stepper must allow for full travel, make sure motor/link/bracket to link is located properly and carburetor.
Page 34 Fuel System 8. With engine/ambient temperature above 40°F (4°C), Starting an Engine Equipped with eChoke turn key switch from OFF to RUN. There should be a ™ NOTE: Do not crank engine continuously for more than noticeable movement of choke plate. 10 seconds at a time.
Page 35 Fuel System Governor/Throttle Control Connections Left Side Pull Cable Clamp Speed Control Lever Speed Setting Lever Choke Lever Right Side Pull Contact Point Choke Control Cable Dual Control High Speed High Speed Adjusting Throttle Control Cable Lever Stop Screw (Do Choke Linkage Screw Not Remove)
Page 36 If starter does not turn engine over, shut starter off immediately. Do not make further attempts to start engine until condition is corrected. Do not jump start using another battery. See your Kohler authorized dealer for trouble analysis. 4. For Operation – After engine starts, move throttle/...
Page 37: Governor System
Governor System GOVERNOR Governed speed setting is determined by position of throttle control. It can be variable or constant, depending on engine application. Governor is designed to hold engine speed constant under changing load conditions. Most engines are equipped with a centrifugal flyweight mechanical governor.
Page 38: Lubrication System
Lubrication System This engine uses a combination pressure/splash lubrication system, delivering oil under pressure to crankshaft, connecting rod and main bearing surfaces. Other component areas are splash lubricated. A high-efficiency gerotor oil pump maintains high oil flow and oil pressure, even at low speeds and high operating temperatures.
Page 39 Lubrication System OIL SENTRY (if equipped) Installation ™ NOTE: Make sure oil level is checked before each use, 1. Apply pipe sealant with Teflon (Loctite 592™ ® ® ® and is maintained up to FULL or F mark on Thread Sealant or equivalent) to threads of switch. dipstick.
Page 40: Electrical System
Electrical System SPARK PLUGS Inspection Inspect each spark plug as it is removed from cylinder CAUTION head. Deposits on tip are an indication of general Electrical Shock can cause injury. condition of piston rings, valves, and carburetor. Do not touch wires while engine is running. Normal and fouled plugs are shown in following photos: Normal Spark Plug Component and Details...
Page 41 Electrical System Carbon Fouled Battery Maintenance Regular maintenance is necessary to prolong battery life. Battery Test To test battery, follow manufacturer's instructions. ELECTRONIC IGNITION SYSTEMS All ignition systems are designed to be trouble free for life of engine. Other than periodically checking/replacing spark plugs, no maintenance or timing adjustments are necessary or possible.
Page 42 Electrical System Ignition Systems These systems use a capacitive discharge (CD) coil. With CDI fixed timing, ignition timing and spark remains constant regardless of engine speed. Timing of spark is controlled by location of flywheel magnet group as referenced to engine TDC.
Page 43 Electrical System Wiring Diagram-Electronic Ignition System with Smart-Choke System* ™ Solenoid Shift Inertia Driver Starter Solenoid Tang Green Starter Assembly Starter Assembly White Violet (Charging) Oil Sentry (Optional) Spark Plug(s) (AC Charging Leads) Rectifier-Regulator Flywheel Stator Rectifier-Regulator Ignition Module(s) Connector Assembly Intake Manifold Screw Ground...
Page 44 Electrical System Electronic Ignition Systems Tests NOTE: Ignition tester must be used to test ignition on these engines. Use of any other tester can result in inaccurate findings. Battery on unit must be fully charged and properly connected before performing tests (a battery that is hooked up or charged backward will crank engine but it won’t have spark).
Page 45 Electrical System BATTERY CHARGING SYSTEM NOTE: Observe following guidelines to avoid damage to electrical system and components: ● Make sure battery polarity is correct. A negative (–) ground system is used. ● Disconnect rectifier-regulator plug and/or wiring harness plug before doing any electric welding on equipment powered by engine.
Page 46 Electrical System 12/15/25 Amp Battery Charging Systems NOTE: Always zero ohmmeter on each scale before testing to ensure accurate readings. Voltage tests should be made with engine running at 3600 RPM with no load. Battery must be good and fully charged. When problems occur in keeping battery charged or battery charges at high rate, charging system or battery might be causing problems.
Page 47: Starter System
Starter System NOTE: Do not crank engine continuously for more than 10 seconds. Allow a 60 second cool-down period between starting attempts. Failure to follow these guidelines can burn out starter motor. NOTE: If engine develops sufficient speed to disengage starter but does not keep running (a false start), engine rotation must be allowed to come to a complete stop before attempting to restart engine.
Page 48 If splines are dirty, clean them with solvent. 7. Splines should have a light film of lubricant. Lubricate as necessary with Kohler starter drive lubricant. Reinstall or replace drive components, assembling them in reverse order they were removed.
Page 49 5. Install thru bolts and torque to 4.5-5.7 N·m Plate Plug (40-50 in. lb.). Solenoid Frame and Field 6. Lubricate drive shaft with Kohler starter drive Brush Holder lubricant. Install drive components following Commutator End instructions for servicing starter drive. Screw...
Page 50 Brush Replacement 4 brushes and springs are serviced as a set. Use a new Kohler brush and spring kit if replacement is necessary. 1. Perform steps 1-5 in Starter Disassembly. 2. Remove screws securing brush holder assembly to end cap (plate).
Page 51 Starter System 10. Starter reassembly when replacing brushes/brush Starter Reassembly holder assembly: NOTE: Always use a new retainer. Do not reuse old a. Hold starter assembly vertically on end housing, retainers that have been removed. and carefully position assembled brush holder NOTE: Correctly installed, center pivot section of drive assembly, with supplied protective tube, against lever will be flush or below machined surface of...
Page 52 Starter System Solenoid Tests NOTE: DO NOT leave 12 volt test leads connected to solenoid for any time over what is necessary for performing each of individual tests. Internal damage to solenoid may occur. Disconnect all leads from solenoid including positive brush lead attached to lower stud terminal. Remove mounting hardware and separate solenoid from starter for testing.
Page 53 To Carburetor Filter For engine to be Tier III compliant, it may be fitted with a Kohler supplied canister vapor recovery system, or a system developed and installed by Original Equipment Manufacturer (OEM). Details on Kohler system are included below.
Page 54 Emission Compliant Systems SECONDARY EMISSION COMPLIANT SYSTEM Twin Secondary Air Induction System Hose To Exhaust Secondary Air Inlet Screen Hose To Carburetor Manifold Valve Assembly Hose To Exhaust Manifold Single Secondary Air Induction System Secondary Air Hose To Exhaust Hose To Carburetor Inlet Screen Valve Assembly Manifold...
Page 55 Emission Compliant Systems Remove Inlet Screen Inlet Components Secondary Air Valve Assembly Barb Inlet Screen 1. Remove inlet screen from secondary air valve assembly by grasping inlet screen at base and gently pulling away from valve assembly. 2. Use a soft brush to remove debris from screen. 3.
Page 56 Disassembly/Inspection and Service WARNING Before working on engine or equipment, disable engine as Accidental Starts can cause severe injury or follows: 1) Disconnect spark plug lead(s). 2) Disconnect death. negative (–) battery cable from battery. Disconnect and ground spark plug lead(s) before servicing.
Page 57 Disassembly/Inspection and Service Clean all parts thoroughly as engine is disassembled. Remove Throttle Controls Only clean parts can be accurately inspected and gauged for wear or damage. There are many Control Bracket Components commercially available cleaners that will quickly remove grease, oil and grime from engine parts.
Page 58 Disassembly/Inspection and Service Remove Air Cleaner and Carburetor Smart-Choke ™ Thermostat Bracket Assembly WARNING eChoke Bracket ™ Stepper Motor Explosive Fuel can cause fires and severe Assembly burns. NOTE: On engines equipped with eChoke stepper Do not fill fuel tank while engine is hot or ™, motor has a special retract routine that can be running.
Page 59 Disassembly/Inspection and Service 4. Remove screws securing rectifier-regulator to Remove Intake Manifold and Rectifier-Regulator backing plate and disconnect plug. 1. Remove screws securing intake manifold to cylinder 5. Use tip of a small screwdriver or similar small flat heads. Note which screws hold wiring clamp(s). tool to bend locking tang, then remove B+ (center 2.
Page 60 Disassembly/Inspection and Service Remove Spark Plugs Remove Cylinder Heads Remove spark plug from each cylinder head. NOTE: Exhaust side is located on output shaft side of engine, while intake side is located on fan side Remove Valve Covers and Cylinder Heads of engine.
Page 61 Disassembly/Inspection and Service Inspection and Service Valve Details Exhaust Insert Exhaust Valve Intake Valve Intake Insert Dimension Intake Exhaust Seat Angle 89° 89° Insert O.D. 36.987/37.013 mm (1.4562/1.4572 in.) 32.987/33.013 mm (1.2987/1.2997 in.) Guide Depth 4 mm (0.1575 in.) 6.5 mm (0.2559 in.) Guide I.D.
Page 62 Disassembly/Inspection and Service Valve Seat Inserts Flywheel/Ignition/Breather Components Hardened steel alloy intake and exhaust valve seat inserts are press-fitted into cylinder head. Inserts are not replaceable but can be reconditioned if not too badly pitted or distorted. If cracked or badly warped, cylinder head should be replaced.
Page 63 Replace flywheel if it is cracked. Replace flywheel, crankshaft, and key if flywheel key is sheared or keyway is damaged. Inspect ring gear for cracks or damage. Kohler does not provide ring gears as a serviceable part. Replace flywheel if ring gear is damaged.
Page 64 Disassembly/Inspection and Service 3. Carefully inspect governor gear shaft and replace it Remove Oil Pan Assembly only if it is damaged. After removing damaged shaft, 1. Remove screws securing oil pan to crankcase. press or lightly tap replacement shaft into oil pan to depth shown.
Page 65 Corresponding camshaft lobe(s) should also be checked for wear or damage. Whenever tappets are Piston Piston Pin replaced, apply a liberal coating of Kohler lubricant to base of each new tappet before it is installed. Connecting Rod Connecting Rod...
Page 66 Disassembly/Inspection and Service Inspection and Service Ring failure is usually indicated by excessive oil Check bearing area (big end) for excessive wear, score consumption and blue exhaust smoke. When rings fail, marks, running and side clearances (See Specifications). oil is allowed to enter combustion chamber where it is Replace rod and cap if scored or excessively worn.
Page 67 Subtract journal diameters from their respective 23°-33° Crosshatch bore diameters to get running clearances. Check results NOTE: Kohler pistons are custom-machined to exacting against values in Specifications. If running clearances tolerances. When over-sizing a cylinder, it are within specification, and there is no evidence of should be machined exactly 0.25 mm (0.010 in.)
Page 68 Disassembly/Inspection and Service 3. When bore is within 0.064 mm (0.0025 in.) of desired size, remove coarse stones and replace them with burnishing stones. Continue with burnishing stones until bore is within 0.013 mm (0.0005 in.) of desired size and then use finish stones (220-280 grit) and polish bore to its final size.
Page 69 Reassembly NOTE: Make sure engine is assembled using all Install Flywheel End Oil Seal specified torque values, tightening sequences, 1. Make sure seal bore of crankcase is clean and free and clearances. Failure to observe specifications of any nicks or burrs. could cause severe engine wear or damage.
Page 70 Reassembly Crankshaft/Governor Gear/Oil Pump Components Install Governor Cross Shaft 1. Lubricate governor cross shaft bearing surfaces in crankcase with engine oil. 2. Slide lower washer onto governor cross shaft and install cross shaft from inside of crankcase. 3. Install nylon washer onto governor cross shaft, then start push-on retaining ring.
Page 71 Reassembly NOTE: Cylinders are numbered on crankcase. Make 4. Turn governor cross shaft clockwise until lower end sure to install piston, connecting rod, and end (blade) is laying against bottom of cylinder. Make cap into its appropriate cylinder bore as sure cross shaft remains in this position while previously marked during disassembly.
Page 72 Reassembly Install Oil Pan Assembly Flywheel/Ignition/Breather Components Sealant Pattern Fastener Torque Sequence RTV sealant is used as a gasket between oil pan and crankcase. Refer to Tools and Aids for a listing of approved sealants. Always use fresh sealant. Using outdated sealant can result in leakage.
Page 73 Reassembly Install Breather Reed and Breather Reed Cover Install Flywheel and Fan Breather Reed Cover Sealant CAUTION Damaging Crankshaft and Flywheel can cause personal injury. Using improper procedures can lead to broken fragments. Broken fragments could be thrown from engine. Always observe and use precautions and procedures when installing flywheel.
Page 74 Reassembly Cylinder Head Components Gasket Valve Cylinder Head Valve Spring Cap Valve Stem Seal Valve Spring Valve Spring Keeper Stud Spark Plug Guide Plate Push Rod Rocker Arm Rocker Arm Pivots Adjusters Washer Valve Cover 1. Check to make sure there are no nicks or burrs on Assemble and Install Cylinder Heads sealing surfaces of cylinder head or crankcase.
Page 75 Reassembly Adjust Valve Clearance Install Valve Covers Adjusters Retaining Push Rods Valve Cover RTV Sealant Adjuster Rocker Arm 1. Rotate crankshaft to establish TDC on compression stroke for cylinder 1. Check for: a. Compression will be felt through spark plug hole. RTV Sealant b.
Page 76 Reassembly Install Spark Plugs 1. Check gap using wire feeler gauge. Adjust gap to 0.76 mm (0.03 in.). 2. Install plug into cylinder head. 3. Torque plug to 27 N·m (20 ft. lb.). External Engine Components Fixed Guard Air Cleaner Cover Debris Screen Blower Housing Hose Clamp...
Page 77 Reassembly Install Ignition Modules Install Intake Manifold Torque Sequence Smart-Choke Deflector Support Tab ™ 1. On engines equipped with Smart-Choke , install air ™ vane deflector into intake manifold. Torque screw to 1 N·m (9 in. lb.). 2. Install intake manifold using new O-rings, with wiring harness attached, onto cylinder heads.
Page 78 Reassembly Install Carburetor Choke Unloader Linkage WARNING Explosive Fuel can cause fires and severe burns. Do not fill fuel tank while engine is hot or running. Gasoline is extremely flammable and its vapors can explode if ignited. Store gasoline only in approved containers, in well ventilated, unoccupied buildings, away from sparks or flames.
Page 79 Reassembly Install Carburetor with eChoke Install External Governor Controls ™ Control Bracket Components eChoke Carburetor Components ™ Air Cleaner Base Solenoid Lead eChoke Bracket Stepper Motor ™ Assembly Choke Linkage Throttle Linkage Carburetor Governor Lever Governor Spring NOTE: On engines equipped with eChoke stepper ™, motor has a special retract routine that can be...
Page 80 Reassembly 1. Install governor lever onto governor cross shaft if Install Blower Housing disconnected previously. NOTE: Do not completely tighten screws until all are 2. Make sure throttle linkage is connected to governor installed to allow shifting for hole alignment. lever and throttle lever on carburetor.
Page 81 Reassembly Install Fuel Pump Install Oil Filter and Fill Crankcase with Oil NOTE: Make sure oil drain plug is installed and torqued WARNING to specification to prevent oil leakage. Explosive Fuel can cause fires and severe 1. Install oil drain plug. Torque plug to 13.6 N·m burns.
Page 82 KohlerEngines.com 32 690 03 Rev. E...
Page 83 32 690 03 Rev. E KohlerEngines.com...
