Dell Vostro 260/260S
Setup And Features Information
About Warnings
WARNING: A WARNING indicates a potential for property damage, personal injury,
or death.
Mini Tower — Front And Back View
Figure 1. Front And Back View Of Mini Tower
1. optical drive
2. media-card reader status light
3. 19-in-1 media-card reader (optional)
4. optical drive eject button
5. optical drive bay
6. microphone and headphone
connectors
7. USB 2.0 connectors (2)
8. power button
9. hard-drive activity light
10. power-supply diagnostic light
Regulatory Type: D11M001, D06D001
Regulatory Model: D11M, D06D
2011–05
