- Page 1 Inspiron 24 3000 Setup and Specifications Computer Model: Inspiron 24-3464 Regulatory Model: W12C Regulatory Type: W12C006...
- Page 2 WARNING: A WARNING indicates a potential for property damage, personal injury, or death. © 2016-2019 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective owners.
-
Page 3: Table Of Contents
Contents Set up your computer........... 5 Create a USB recovery drive for Windows....10 Views................11 ......................11 Front ......................12 Left ....................... 13 Right ......................14 Back ......................15 Tilt ..................15 Easel stand .................. 16 Pedestal stand Specifications.............. 18 ................18 Dimensions and weight ................. - Page 4 Getting help and contacting Dell......... 24 .................24 Self-help resources ..................25 Contacting Dell...
-
Page 5: Set Up Your Computer
Set up your computer CAUTION: Place the computer on a soft and clean surface to avoid scratching the display. - Page 6 Set up the stand. Pedestal stand a) Lift the stand riser and attach the base. b) Tighten the captive screw to secure the base to the stand riser. Easel stand Lift the stand. Set up the keyboard and mouse. See the documentation that shipped with the keyboard and mouse.
- Page 7 Route the power cable through the routing guide on the stand and connect the power adapter. Easel stand Pedestal stand...
- Page 8 SLN151664 SLN151748 at www.dell.com/support. For Windows: Follow the on-screen instructions to complete the setup. When setting up, Dell recommends that you: – Connect to a network for Windows updates. NOTE: If connecting to a secured wireless network, enter the password for the wireless network access when prompted.
- Page 9 Locate and use Dell apps from the Windows Start menu—Recommended Table 1. Locate Dell apps Resources Description My Dell Centralized location for key Dell applications, help articles, and other important information about your computer. It also notifies you about the warranty status, recommended accessories, and software updates if available.
-
Page 10: Create A Usb Recovery Drive For Windows
A message appears, indicating that all data in the USB flash drive will be deleted. Click Create. Click Finish. For more information about reinstalling Windows using the USB recovery drive, see the Troubleshooting section of your product's Service Manual at www.dell.com/support/manuals. -
Page 11: Views
Views Front Figure 1. Front view Camera Enables you to video chat, capture photos, and record videos. Camera-status light Turns on when the camera is in use. Microphone (for non-touchscreen model) Provides digital sound input for audio recording, voice calls, and so on. Microphone (for touchscreen model) Provides digital sound input for audio recording, voice calls, and so on. -
Page 12: Left
Left Figure 2. Left view Media-card reader Reads from and writes to media cards. USB 3.0 ports (2) Connect peripherals such as external storage devices and printers. Provides data transfer speeds up to 5 Gbps. Headset port Connect headphones or a headset (headphone and microphone combo). -
Page 13: Right
Press to put the computer in sleep state if it is turned on. Press and hold for 4 seconds to force shut‑down the computer. NOTE: You can customize the power‑button behavior in Power Me and My Dell at Options. For more information, see www.dell.com/... -
Page 14: Back
Back Figure 4. Back view Service Tag label The Service Tag is a unique alphanumeric identifier that enables Dell service technicians to identify the hardware components in your computer and access warranty information. Power-adapter port Connect a power adapter to provide power to your computer. -
Page 15: Tilt
Connect a gaming console, Blu-ray player, or other HDMI-out enabled devices. Audio-out port Connect audio-output devices such as speakers, amplifiers, and so on. Tilt Easel stand... -
Page 16: Pedestal Stand
Pedestal stand... -
Page 18: Specifications
6.38 kg (14.07 lb) NOTE: The weight of your laptop varies depending on the configuration ordered and the manufacturing variability. System information Table 3. System information Computer model Inspiron 24-3464 Processor • Generation Intel Core i3-7100U • Generation Intel Core i5-7200U •... -
Page 19: Memory
Memory Table 4. Memory Slots Two SODIMM slots Type DDR4 Speed Up to 2133 MHz Configurations supported 2 GB, 4 GB, 6 GB, 8 GB, and 16 GB Ports and connectors Table 5. Ports and connectors External: Network One RJ45 port •... -
Page 20: Video
• Wi-Fi 802.11b/g/n • Bluetooth 4.0 Video Table 8. Video specifications Integrated Discrete Controller Integrated in processor NVIDIA GeForce 920MX NOTE: You can connect a monitor to each available port on your graphics card. You can connect up to one monitor on this computer. -
Page 21: Storage
Storage Table 10. Storage Interface • SATA 3 Gbps for optical drive • SATA 6 Gbps for hard drive Hard drive One 2.5-inch drive Optical drive One 9.5-mm DVD+/-RW drive (optional) Media-card reader Table 11. Media-card reader Type One 4-in-1 slot Cards supported •... -
Page 22: Camera
Controls Brightness can be controlled through the display- brightness increase/decrease buttons Camera Table 13. Camera Resolution • Still image: 0.92 megapixels • Video: 1280 x 720 at 30 fps (maximum) Diagonal viewing angle 74 degrees Stand Table 14. Stand Easel Pedestal Height 174.80 mm (6.88 in) -
Page 23: Computer Environment
Type 65 W 90 W Temperature range: 0°C to 40°C (32°F to 104°F) Operating Temperature range: –40°C to 70°C (–40°F to 158°F) Storage Computer environment Airborne contaminant level: G1 as defined by ISA-S71.04-1985 Table 16. Computer environment Operating Storage Temperature range 0°C to 35°C (32°F to 95°F) –40°C to 65°C (–40°F to 149°F) Relative humidity... - Page 24 Getting help and contacting Dell Self-help resources You can get information and help on Dell products and services using these self-help resources: Table 17. Self-help resources Self-help resources Resource location Information about Dell products and www.dell.com services My Dell Tips...
- Page 25 BIOS information Product ID in the search bar. Contacting Dell To contact Dell for sales, technical support, or customer service issues, see www.dell.com/contactdell. NOTE: Availability varies by country/region and product, and some services may not be available in your country/region.
